AMATI MC6 User manual

3

11
1
10
7-9
4-6
12-14
15-16
25
26
27
28-29
29
30
31
32
33
34
35
35-36
36-37
38
39-43
16-17
17
18-21
21-24

67
44-45
45-46
46
46

.
89
The Wi-Fi indicator display will not be flashing when
connected to the Wi-Fi Network.

10 11
A programmable thermostat helps make it easy for you to save by offering
four pre-programmed settings to regulate your home's temperature
in both summer and winter - when you are home, asleep, or away.
The pre-programmed settings that come with programmable thermostats
are intended to deliver savings without sacrificing comfort. Depending on
your schedule, you can see significant savings by sticking
with those settings or adjust them as appropriate for your family.
The key is to establish a program that automatically reduces heating and
cooling in your home as your required.
There are two modes in MC6 for user to select: Thermostat mode and Timer
mode.
Benefits of Programmable Thermostats

“ ”
APP Operation 01-07
Please Enable the “Location”to MyHouse App in your mobile settings
before any operation, or else the GEO distance will not correct.
Open the MyHouse and register your account.
Press the Icon on App home screen.
Log into your account.
Press "Location Name" to add the Location, for example
Home/Office etc.
Press icon to confirm the property.
Press icon to go back to the main screen.
Press the icon on App home screen to enter the
"Add Device" screen.
Select "Smart Config" optioin on Add device screen.
Press the bottom button "Add device location to enter WiFi
configuration.
12 13

Find ”Pair to App(Smart Config)“ and press it.
Enter the Wi-Fi password (please ensure this router password must
be correct ).
Press the button"Next" on the bottom to enter "Pairing device"
screen.
Waiting for thermostat feedback on the "Pairing device" screen,
the count down time is 120 seconds, if pairing failed please check
the Wi-Fi password and pair again.
Thermostat Operation
On the MC6 Home scren , press the icon and enter
"Feature Settings".
Wait for the devices to pair,(This may take serveral minutes to
activate).
The App will display "Connected to the Wi-Fi" and will display
"App Matching Success" on the controller .
enter the setting interface.
14 15
The function has a relatively high priority, say, whatever setting you have
made, when you switch the thermostat to Hold mode, all the pre-settings
done before will be temporarily ignored, except hold temperature，which
will maintain until the end of the "hold period" you set.

count down
16 17
When user switches the thermostat to away mode, the thermostat
will still protect itself from frost after the defrost temperature is set.
When temperature is lower than the set defrost temperature,
heating will be turned on, meanwhile, the flame icon will be
displayed on the thermostat.

18 19

20 21
(can be adjusted)

Output Delay:
22 23
With a set temperature of 20 degrees, as we know,
the room temperature is lower than 20 degrees, heating function
will be triggered, however, how much lower will trigger the heating
is a question, thus we need a parameter to define it, that is switch
the differential. When we set it as 0.5, the heating will be triggered at
19.5 degrees, when we set it as 1, the heating will be triggered at 19
degrees, in the above two cases, the heating will both stop when
room temperature reaches 20 degrees.
There are three sensor modes selectable:
1. Air temperature sensor
2. Floor temperature sensor
3. Air temperature sensor and floor temperature sensor
When you select the third sensor mode, that is, “Air temperature and
floor temperature”, floor sensor will take charge of sensing and
monitoring the temperature beyond the set limit which would do harm
to the floor itself or even dangerous to people in the room.
To trigger this function user have firstly to enable
the floor senor, the default value of the floor temperature limit is 28,
the user can adjust it to the value from 20 to 45 degrees
as per personal needs.

and
24 25
MC6 makes use of the rate of change previously
figured out to further calculate how far ahead of time the heating
function should be triggered in order to maximize the energy
conservation as well as be able to make the house warm and
comfortable at designated time. For example, if the rate of change is 20,
that is to say, it will take 20 minutes to realize the rise of 1 degree. Then
MC6 can further figure out how far ahead of time the heating
function has to be triggered to make the room comfortable on the
premise of energy saving.
It represents how long it will take to realize the
rise of 1 degree.

26 27

28 29

30 31

,
enter the
setting interface
32 33

34 35

36 37
your
recessed
(DO NOT OVER-TIGHTEN)

Dimension:
MC6-E Wiring Diagram-230V Electric 16A Heating
38 39
