Amatis AMBR User manual

!
!
!
!
!
!
AMBR!
AMATIS Border Router!
!
!
!
User Guide!
!
!
!
!
!
!

!
pg.2% v4.0%
!
Version 4.0!
October 2015!
TABLE OF CONTENTS!
!
!
1.0 INTRODUCTION!
1.1 BEFORE YOU START!
1.2 NETWORK FIREWALL REQUIREMENTS!
!
2.0 INSTALLING AMBR!
2.1 TROUBLESHOOTING AMBR CONNECTIVITY!
2.2 AMBR INDICATOR LIGHTS!
!
3.0 ENERGY DASHBOARD!
3.1 REGISTRATION AND SET UP!
3.2 AMATIS DASH USER GUIDE!
!
4.0 END USER LICENSE AGREEMENT!
!
!
!
!
!
!

!
pg.3% v4.0%
!
!
!
!
!
!
!
CUSTOMER SUPPORT!
970-300-1344!
[e-mail]!
1.0 INTRODUCTION!
Thank you for choosing Amatis Controls. This AMBR Installation
Manual will guide you through the process of installing AMBR.
Within an hour or so your system will be reporting valuable energy
data to the Amatis Energy Dashboard, which you can access
online. All components must be installed correctly to ensure the
overall accuracy of this kit.!
!
1.1 BEFORE YOU START!
Before beginning your installation, make sure the installation site
has:!
● High speed Internet connection (configured for DHCP)
● AMBR can also be configured to use a static IP address
● Ethernet and electric outlets, within 200 ft, of AMBR
!

!
pg.4% v4.0%
1.2 NETWORK FIREWALL REQUIREMENTS!
TCP 1195 outbound to vpn.amatiscontrols.com!
UDP 1195 outbound to vpn.amatiscontrols.com!
TCP 3306 outbound to vpn.amatiscontrols.com!
TCP 80 outbound to checkip.dyndns.org!
TCP 80 outbound to vpn.amatiscontrols.com!
!
!
! !

!
pg.5% v4.0%
!
2.0 INSTALLING AMBR!
!
AMBR connects your Amatis system to the Internet. Follow the
steps below:!
!
1. Connect one end of the blue Cat5/Ethernet wire to the
back of AMBR.
2. Connect the other end of the blue Cat5/Ethernet wire to
an available Ethernet port.
NOTE: Some cable & DSL modems have only one Ethernet port. In order to
connect AMBR you may need to add another Ethernet port. Ethernet
Switches are available to add more Ethernet ports to the same Internet
connection. One option is illustrated below:!
!

!
pg.6% v4.0%
3. Plug the barrel end of the white 5V power supply into the
back of AMBR, then the plug into the wall socket.
4. Wait for 1-2 minutes while AMBR completes its startup
sequence and connects to the Internet. The startup LED
sequence is as follows:
a. red led, power GOOD
b. white led, AMBR started
c. blue led, hardware GOOD
d. yellow led, networking possible
e. green led blinking, loading software
5. On the front of AMBR a solid green light confirm AMBR
has booted up correctly and is connected to the Internet.
Startup sequence is complete, refer to section 2.2 for
descriptions of regular LED functions.
6. If AMBR does not show a blue light after 5 minutes, you
may be experiencing an Internet connectivity problem.
Follow the troubleshooting steps in the next section.
!
2.1 TROUBLESHOOTING AMBR CONNECTIVITY!
!
1. Restart your modem and AMBR.
a. Power both devices off
b. Power modem on
c. After modem reboots and shows Internet activity
d. Plug AMBR back in
e. Verify AMBR shows blue blinking light
2. Confirm your modem is configured in DHCP mode
a. Follow modem owner’s manual directions
b. Contact your Internet service provider
3. Identify which AMBR indicator lights are active.

!
pg.7% v4.0%
NOTE: When AMBR is connected to power, all lights turn on, then turn off,
then turn back on one-by-one. Indicators can be diagnosed in the table
below:!
!
!
! !

!
pg.8% v4.0%
!
2.2 AMBR INDICATOR LEDS!
!
!
!
LED!
Flashing!
Solid!
Off!
Green!
Processor boot-up
SUCCESS!
Processor boot-up
SUCCESS!
Processor!
ERROR!
Orange!
!
Off Line data logging
SUCCESS!
Off line logging!
ERROR!
Blue!
Data logging and
configuration enabled!
SUCCESS!
Data logging enabled!
SUCCESS!
Internet connection
ERROR!
White!
!
!
Normal operation!
Red!
!
Power connection
SUCCESS!
Power connection
ERROR!
!
NOTE: this table is only valid after AMBR’s startup sequence AND
the green led is solid.!
!
!
! !

!
pg.9% v4.0%
!
5.0 AGENCY CERTIFICATIONS!
!
!
!
!
Operating Requirements and Conditions!
The design of AMBR complies with FCC and IC safety levels of
radio frequency (RF) exposure for Mobile devices.!
!
Mobile Device RF Exposure Statement!
RF Exposure - This device is only authorized for use in a mobile
application. At least 20 cm of separation distance between the
AMBR device and the user's body must be maintained at all times.!
!
Caution Statement for Modifications!
CAUTION: Any changes or modifications not expressly approved
by Amatis Controls, LLC could void the user’s authority to operate
the equipment.!
!
FCC Notices!
AMBR has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These

!
pg.10%v4.0%
limits are designed to provide reasonable protection against
harmful interference in an installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation.!
!
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning AMBR off
and on the user is encouraged to try to correct the interference by
one or more of the following measures:!
● Increase the separation between the equipment and
receiver.
● Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
● Consult the dealer for help.
!
!
!
!
!
OEM Labeling Requirements!
!

!
pg.11%v4.0%
WARNING! The Original Equipment Manufacturer (OEM) must
ensure that FCC/IC labeling requirements are met. This includes a
clearly visible label on the outside of the final product enclosure
that displays the contents shown below.!
!
FCC:!
Contains FCC ID: 2ADDY-BR1!
The enclosed device complies with Part 15 of the FCC
Rules. Operation is subject to the following two
conditions:!
1. this device may not cause harmful
interference, and
2. this device must accept any interference
received, including interference that may
cause undesired operation
!
IC:!
Contains Model AMBR, IC:20256-BR1!
This device complies with Industry Canada licence-
exempt RSS standard(s). Operation is subject to the
following two conditions:!
1. this device may not cause interference, and
2. this device must accept any interference,
including interference that may cause
undesired operation of the device
!

!
pg.12%v4.0%
!
!
!
Exigences et conditions de fonctionnement:!
La conception de AMBR est conforme aux limites d'exposition aux
Frequences Radio définies par les normes IC et FCC pour les
appareils mobiles."!
!
Déclaration d'exposition aux fréquences radio d'appareil
mobile!
Exposition fréquences radio - Cet appareil est seulement conçu
pour usage mobile. Au moins 20 cm de séparation doit être
maintenue à tout instant entre l'appareil AMBR et l'utilisateur.!
!
Déclaration de mise en garde concernant les modifications!
ATTENTION: Tous changements ou modifications qui ne sont pas
expressément approuvés par Amatis Controls, LLC sont
susceptibles de révoquer les droits d'utilisation de cet
équipement.!
!
!
Avis IC!
AMBR a été testé et entre dans la catégorie des appareils
numériques de Classe B, selon la Section 15 de la réglementation
de la IC. Ces limites ont été conçues pour protéger les installations

!
pg.13%v4.0%
domestiques contre les interférences néfastes. Cet équipement
génère, utilise et émet de l'énergie sous forme de fréquences radio
et, en cas de non-respect des instructions d'installation et
d'utilisation, risque de provoquer des interférences radio. Il
n'existe cependant aucune garantie contre ces interférences.!
!
En cas d'interférences radio ou télévisuelles, pouvant être vérifiées
en allumant, puis en éteignant l'équipement, l'utilisateur est invité à
essayer de résoudre le problème de l'une des façons suivantes :!
● Eloigner l'équipement du poste de réception ;
● Brancher l'équipement sur une prise appartenant à un
circuit différent de celui du récepteur ;
● Demander de l'aide auprès du revendeur ou d'un
technicien radio/TV
!
Exigences en matière d'étiquetage OEM :!
!
ATTENTION! Le fabricant d'équipement d'origine (OEM) doit
veiller à ce que les exigences en matière d'étiquetage de la FCC /
IC soient respectées. Cela comprend une étiquette clairement
visible sur l'extérieur de l'enceinte du produit final qui affiche le
contenu ci-dessous.!
!
IC:!
!

!
pg.14%v4.0%
Contient le model AMBR, IC:20256-BR1!
Cet appareil respecte le(s) standard(s) RSS de l'Industry
Canada sans license. Pour cela le sujet doit respecter
les deux conditions suivantes:!
1. cet appareil ne doit pas causer des
interférences, et
2. cet appareil doit supporter toute interférence,
incluant des interférences pouvant déclencher
des fonctionnements indésirables de l’appareil
!
! !

!
pg.15%v4.0%
!
3.0 END USER SOFTWARE LICENSE AGREEMENT!
!
!
1. USER NOTICE!
Please read this End User Software License Agreement (“License
Agreement”) carefully before using your Amatis product. By installing and
registering an Amatis device you hereby agree with the terms of this License
Agreement. If you do not agree with the terms of this License Agreement, do
not use the Amatis Product and Amatis Software.!
!
2. TERMS!
The terms of this License Agreement are applicable to anyone who uses
Amatis Controls Software and Firmware included in a product purchased
from Amatis and/or Amatis partners. This license does not permit the use of
the Amatis Software in any other product. Amatis Controls reserves the right
to take legal action against anyone else using, selling or distributing the
software. By using the Amatis Product and Amatis Software, you agree to the
terms of this License Agreement.!
!
3. LICENSE!
Amatis Controls grants a single, non-sublicensable, non-exclusive, non-
transferable license to use the Amatis Software solely as part of products
obtained from Amatis and/or any Amatis partner for which applicable fees
have been paid. Except for the limited license rights expressly granted in this
License Agreement, Amatis Controls reserves all rights in and to the Amatis
Software and any modifications or copies thereto.!
!
4. GENERAL RESTRICTIONS!
In exchange for the license, you agree not to: decompile, disassemble, or
reverse engineer the Amatis Software; alter, modify or create any derivative
works based on the Amatis Software; use, copy, sell, sublicense, lease, rent,

!
pg.16%v4.0%
loan, assign, convey or otherwise transfer the Amatis Software except as
expressly authorized in writing by Amatis Controls; distribute, disclose, or
allow use of the Amatis Software, in any format, through any timesharing
service, service bureau, network or by any other means; allow any service
provider or other third party, with the exception of Amatis Controls authorized
resellers, distributors, and their designated employees who are acting solely
on behalf of and for the benefit of the end user, to use or execute any
software commands that cause the Amatis Software to perform functions that
facilitate the maintenance or repair of any product.!
!
5. DISCLAIMER OF WARRANTIES!
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, AMATIS
CONTROLS PROVIDES THE AMATIS SOFTWARE “AS IS” AND “AS
AVAILABLE” WITH ALL FAULTS AND WITHOUT WARRANTY OF ANY KIND.
AMATIS CONTROLS HEREBY DISCLAIMS WITH RESPECT TO THE AMATIS
SOFTWARE ALL WARRANTIES AND CONDITIONS, WHETHER EXPRESS,
IMPLIED OR STATUTORY, INCLUDING BUT NOT LIMITED TO ANY (IF ANY)
WARRANTIES OR CONDITIONS OF OR RELATED TO: NON-
INFRINGEMENT, MERCHANTABILITY, FITNESS FOR A PARTICULAR
PURPOSE, LACK OF VIRUS, ACCURACY, OR COMPLETENESS OF
RESPONSE.!
!
6. TERMINATION!
If you breach the license limitations or restrictions in this License Agreement,
Amatis Controls may, with immediate effect, terminate the software licenses
granted in this License Agreement without prejudice to any available rights
and remedies. Upon termination or expiration of the license for any reason,
you shall immediately return the Amatis Software and any copies to Amatis
Controls, or, at Amatis Controls’ discretion, you shall permanently destroy all
copies of the Amatis Software and any related materials in your possession or
control. Inadvertent copies of the Amatis Software and any related materials
remaining in the possession of the End User subsequent to termination or
expiration shall not be implied or construed as Amatis Controls consenting to
transfer ownership of the software and any related materials to the End User.!
!

!
pg.17%v4.0%
7. LIMITATION OF LIABILITY!
TO THE EXTENT NOT PROHIBITED BY APPLICABLE LAW, IN NO EVENT
SHALL AMATIS CONTROLS BE LIABLE FOR ANY CONSEQUENTIAL,
INDIRECT, SPECIAL, EXEMPLARY, OR PUNITIVE DAMAGES WHATSOEVER
(INCLUDING BUT NOT LIMITED TO DAMAGES FOR: LOSS OF PROFITS,
LOSS OF CONFIDENTIAL OR OTHER INFORMATION, BUSINESS
INTERRUPTION) ARISING OUT OF OR IN ANY WAY RELATED TO THE USE
OF OR INABILITY TO USE THE AMATIS SOFTWARE, EVEN IF AMATIS
CONTROLS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES.!
!
8. COMPLIANCE!
Amatis Controls will have the right to inspect your compliance with these
License Agreement terms.!
!
!
!
9. GOVERNMENT END USERS!
The Amatis Software is classified as “commercial computer software” and the
Documentation is classified as “commercial software documentation” or
“commercial items.” Any use, modification, reproduction, release,
performance, display or disclosure of the Amatis Software or Documentation
shall be governed solely by the terms of this License Agreement and shall be
prohibited except to the extent expressly permitted.!
!
10. APPLICABLE LAWS!
This License Agreement will be governed by and construed in accordance
with the laws of the United States. Severability in the event that any part or
parts of this agreement shall be held illegal or null and void by any court or
administrative body of competent jurisdiction, such determination shall not
affect the remaining parts of this agreement, and they shall remain in full force
and effect as if such part or parts determined illegal or void had not been
included.!
