AmazonBasics Patio Heater
Patio Heater_14-0979_V4_ENG.book Page 1 Tuesday, September 2, 2014 10:00 AM
FINAL V4

2
English . . . . . . . . . . . . . . . . . . . . . .5
Patio Heater_14-0979_V4_ENG.book Page 2 Tuesday, September 2, 2014 10:00 AM

3
Safety and compliance
Patio Heater_14-0979_V4_ENG.book Page 3 Tuesday, September 2, 2014 10:00 AM

4
Patio Heater_14-0979_V4_ENG.book Page 4 Tuesday, September 2, 2014 10:00 AM

5
English
Instruction Manual · English
Patio Heater
Contents
Make sure that the package contains the following parts and hardware before you begin
assembly:
H- Regulator (1)
J - Base* (1)
I - Post supports (3)
A - Reector panel (4)
B - Reector center cap (1)
C- Head assembly (1)
E- Gas hose (1)
D - Tank housing (1)
F- Upper post (1) G- Lower post (1)
K - Wheel assembly (1)
L - Chain (1)
Patio Heater_14-0979_V4_ENG.book Page 5 Tuesday, September 2, 2014 10:00 AM

6
Tools Required for Assembly (Not Included):
•Phillips screwdriver
•Leak-test solution (see step 12for more information)
Wing nut (3) Cap nut (12)
Large bolt (6) Small bolt (5)
Small screw (12) Larg Small nut (6)
Wrench (1)
Patio Heater_14-0979_V4_ENG.book Page 6 Tuesday, September 2, 2014 10:00 AM
Small bolt with lock washer (4)

7
Assembly Instructions
Step 1: Remove the four large screws and large nuts that secure the base to the sandbox, then
pry open the plastic cap on the top. Fill the sandbox with water or sand, then place the plastic
cap. Slide the base back on the sandbox, then reinsert the screws and secure by tightening
the nuts on the bolts.
Step 2: Align holes in the wheel assembly with the holes in the base, then insert two small
bolts through the holes and hand tighten. Make sure that the wheel assembly is parallel to the
base, then tighten the bolts with the wrench.
Large screws
(pre-installed with
four nuts)
Base
Plastic cap
Sandbox
Patio Heater_14-0979_V4_ENG.book Page 7 Tuesday, September 2, 2014 10:00 AM
Small bolts (2)

8
Step 3: Align the holes in the bottom of the post support (I) and base, then secure with a small
bolt (hand tighten). Repeat with the other two post supports, then tighten all bolts with the
wrench.
Step 4: Align the holes in the lower post (G) with the holes in the tops of the post supports.
Insert a large bolt through each hole, then secure with a small flange nut. Tighten with the
wrench after all bolts have been inserted.
Step 5:Screw the upper post (F) onto the lower post.
Small
bolt (3)
Large bolt (6)
Flange nut (6)
Patio Heater_14-0979_V4_ENG.book Page 8 Tuesday, September 2, 2014 10:00 AM

9
Step 6: Insert the tank housing (D) onto the upper post and lower it until it rests on the base.
Step 7:Insert the reflector studs into the large flat washers, then push them into the holes on
the top of the head assembly (C).
Reflector
stud (3)
Large flat
washer (3)
Patio Heater_14-0979_V4_ENG.book Page 9 Tuesday, September 2, 2014 10:00 AM

10
Step 8: Attach head assembly (C) to upper post (F).
Route the gas hose (E) down through the post assembly, then place the head
assembly on the upper post, making sure that the screw holes on the head assembly
align with the holes in the upper post (the control knob should be above decal on post).
Insert the four small bolts and lock washers and tighten securely.
Step 9:
Note: Make sure that you remove the protective plastic covering on the re pieces before
assembly!
Slide two of the re panels together, then insert one small screw and loosely screw on a
cap nut. Add the third and fourth re y.
Small bolt
with lock
washer (4)
Small screw (4)
Cap nut (4)
Patio Heater_14-0979_V4_ENG.book Page 10 Tuesday, September 2, 2014 10:00 AM

11
Slide the reflector center cap (B) onto the assembled reflector panels. Insert one small screw
and loosely screw on a cap nut. Repeat with two more small screws and cap nuts to complete
reflector assembly. Fully tighten all screws and cap nuts.
Assembly Tip: If the reflector sections aren't aligning, loosen each screw before further
assembly and retighten after the sections are aligned.
Step 10: While supporting the heater, tilt the head assembly and slide three large flat washers
over the reflector studs. Place the reflector assembly onto the reflector studs, then slide three
more large flat washers over the reflector studs and onto the reflector assembly. Secure with
three wing nuts.
Step 11: Lift the tank housing up and rest a standard 20 lb. propane tank (sold separately) on
the top of the assembled post supports.
Screw the regulator onto the gas hose (be careful not to cross-thread) and hand-tighten
securely, then tighten with a wrench.
Attach the regulator to the valve on the propane tank and hand-tighten securely.
Small screw (8)
Cap nut (8)
Wing nut (3)
Large flat
washer (3)
Large flat
washer (3)
Patio Heater_14-0979_V4_ENG.book Page 11 Tuesday, September 2, 2014 10:00 AM

12
Move the propane tank onto base of the heater. Secure the propane tank by attaching the
chain to the post supports. Lower the tank housing.
Note:Only use a standard 20 lb. propane tank with this heater. Use this heater only with a
propane vapor withdrawal supply system. See chapter 5 of the standard for storage and
handling of liquefied petroleum gas, ANSI/NFPA 58. Your local library or fire department should
have this book.
Step 12:Perform a leak test.
Make 2-3 oz. of leak test solution by mixing one part liquid dishwashing detergent and three
parts water.
Apply several drops of solution where the hose attaches to the regulator and where the regula-
tor connects to the propane tank.
Make sure all patio heater valves are OFF, then turn the propane tank valve ON.
IF BUBBLES APPEAR AT ANY CONNECTION, THERE IS A LEAK. Do the following:
Turn the propane tank valve OFF.
If a leak is detected at the hose/regulator connection, tighten the connection and perform
another leak test. If bubbles continue to appear, call Well Traveled Living’s specialized cus-
tomer service hotline at 1-904-557-7011, 9 a.m. - 6 p.m., EST, Monday - Friday.
If a leak is detected at the regulator/cylinder valve connection, disconnect, then reconnect and
perform another leak test. If you continue to see bubbles after several attempts, the propane
tank valve is defective. Call Well Traveled Living’s specialized customer service hotline at
1-904-557-7011, 9 a.m. - 6 p.m., EST, Monday - Friday
IF NO BUBBLES APPEAR AT ANY CONNECTION, THE CONNECTIONS ARE SECURE.
Patio Heater_14-0979_V4_ENG.book Page 12 Tuesday, September 2, 2014 10:00 AM

13
Note: Whenever gas connections are loosened or removed, you must perform a complete leak
test.
Using Your Patio Heater
Caution:Do not attempt to operate this appliance until you have read and understand all of
the safety information in the manual, the assembly is complete, and leak tests have been
performed.
Before Turning the Gas Supply ON
• Your heater was designed and approved for OUTDOOR use only. Do NOT use it inside a
building, garage, or any other enclosed area.
• Make sure that surrounding areas are free of combustible materials, gasoline, and other
flammable vapors or liquids.
• Make sure that there are no obstructions to air ventilation. Be sure all gas connections are
tight and there are no leaks.
• Make sure that the cylinder cover is clear of debris. Be sure any component removed
during assembly or servicing is replaced and fastened prior to starting.
Before Lighting Your Heater
Your heater should be thoroughly inspected before each use, and by a qualified service person
at least annually. Always wait at least five minutes if you are re-lighting a hot heater.
Inspect the hose assembly for evidence of excessive abrasion, cuts, or wear. Suspected areas
should be leak-tested. If the hose leaks, it must be replaced prior to operation. Use only a
replacement hose assembly specified by the manufacturer.
Lighting Your Heater
Note: When starting your heater for the first time, or after you change the propane tank, push
and hold the control knob in for two minutes to remove air from the gas lines.
1. Push in the control knob and turn it OFF.
Patio Heater_14-0979_V4_ENG.book Page 13 Tuesday, September 2, 2014 10:00 AM

14
2. Fully open the propane tank valve.
3. Push the control knob in and rotate to HI.
4. While pushing in the control knob, press the red IGNITOR button repeatedly until the main
burner lights. Continue to hold the control knob in for 30 more seconds, then release the it.
5. Turn the control knob
6. When you are turn the control knob and propane tank OFF. Wa
minutes before re-lighting the heater.
If you experience any ignition problems, please see “Troubleshooting” on page 17. Unit will operate
at reduced efficiency below 40°F (4.4°C).
Caution: Avoid inhaling the fumes emitted from the heater's first use. Smoke and odor from
the burning of oils used in the manufacturing may be present. The smoke and odor dissipates
after approximately 30 minutes. The heater should NOT produce thick black smoke.
When the Heater is ON
The emitter screen becomes bright red due to intense heat. The color is more visible at night.
The burner displays tongues of blue and yellow These es should not be yellow or produce thick
black smoke, indicating an obstruction of air ow through the burners. The should be blue with
straight yellow tops. If excessive yellow ame is detected, turn off the heater and refer to
“Troubleshooting“on page 17.
Re-lighting Your Heater
1. Push in the control knob and turn it OFF.
Patio Heater_14-0979_V4_ENG.book Page 14 Tuesday, September 2, 2014 10:00 AM

15
2. Wait at least five minutes to allow gas to dissipate before re-lighting.
See “Lighting your heater” for instructions.
Shutting Down Your Heater
1. Push in the control knob and turn it OFF. The burner may make a slight popping noise as it
turns off.
2. Turn the propane tank valve off and disconnect the regulator when the heater is not in use.
Note:After use, some discoloration of the emitter screen is normal.
After Operating Your Heater
• The gas control knob should be in the OFF position.
• The gas tank valve should be OFF.
• Disconnect the gas line.
• The heater should be stored upright in a secure location.
Operation Checklist
Perform these checks before each use:
1. Read the instruction manual to understand correct operation and precautions.
2. All components are properly assembled, intact and operable.
3. No alterations have been made.
4. All gas connections are secure and do not leak.
5. Wind velocity is below 10 mph.
6. Heater is for use outdoors (outside any enclosure).
7. There is adequate fresh air ventilation.
8. Heater is away from gasoline or other flammable liquids or vapors.
9. Heater is away from windows, air intake openings, sprinklers and other water sources.
Patio Heater_14-0979_V4_ENG.book Page 15 Tuesday, September 2, 2014 10:00 AM

16
11. Heater is situated at least 36 inches on top and 24 inches on sides from combustible materials.
12. Heater is on a hard and level surface.
13. There are no signs of spider or insect nests in the heater.
14. All burner passages are clear.
15. All air circulation passages are clear.
16. Children and adults should stay a safe distance away from the heater to
avoid burns or clothing ignition. If children are near the heater for any
reason, they should be carefully supervised by an adult.
17. Clothing or other protective material should not be hung from the heater
or placed on or near the heater.
18. Any guard or other protective device removed for servicing
the heater must be replaced prior to operating the heater.
Maintaining Your Heater
To enjoy years of outstanding performance from your heater, make sure you perform the fol-
lowing maintenance activities on a regular basis:
• Keep exterior surfaces clean.
• Use soapy water for cleaning. Never use flammable or corrosive cleaning agents.
• While cleaning your unit, be sure to keep the area around the burner and controlcompartment
dry at all times. Do not submerge the control valve assembly. If the gascontrol is submerged
in water, do NOT use it. It must be replaced.
• Installation and repair should be done by a qualified service person. The heater should be
inspected before each use and at least annually by a qualified service person.
• More frequent cleaning may be required as necessary. It is imperative that control
compartment burner and circulating air passageways of the heater be kept clean and free of
debris and/or spider or insect nests.
• Air flow must be unobstructed. Keep controls, burner, and circulating air passageways clean.
Signs of possible blockage include:
• Gas odor with extreme yellow tipping of flame.
• Heater does NOT reach the desired temperature.
• Heater glow is excessively uneven.
• Heater makes popping noise.
• Spiders and insects can nest in burner or orifices. This dangerous condition can damage heater
and render it unsafe for use. Clean burner holes by using a heavy-duty pipe cleaner. Compressed
air may help clear away smaller particles.
• Carbon deposits may create a fire hazard. Clean the dome and burner screen with warm soapy
water if any carbon deposits develop.
Note: In a salt-air environment (such as near an ocean), corrosion occurs more quickly than
normal. Frequently check for corroded areas and repair them promptly.
Tip (for stainless steel models): Use high-quality automobile wax to help maintain the appear-
ance of your heater. Apply to exterior surfaces from the post down. DO NOT apply to the emit-
ter screen or domes.
Storing Your Heater
• Disconnect the propane tank.
• Store the heater upright in an area sheltered from direct contact with inclement weather
(such as rain, sleet, hail, snow, dust, and debris).
Patio Heater_14-0979_V4_ENG.book Page 16 Tuesday, September 2, 2014 10:00 AM

17
• You can cover your heater to protect the exterior surfaces and to help prevent dirt
build-up in air passages. Never leave the propane tank exposed to direct sunlight or
excessive heat.
Note:Wait until heater is cool before covering.
Troubleshooting
Servicing Your Heater
Only a qualified service person should repair gas passages and associated components.
Caution: Always allow heater to cool before attempting service.
Specifications
You may return this item sold by Amazon.com within 30 days of delivery for a full refund. Ama-
zon.com will pay the return shipping cost if the return is a result of our error. Please note that
we are unable to exchange items. Visit www.amazon.com/help for more information.
Thank you for choosing this product by Amazon.com.
Problem Possible Cause Solution
The main burner won’t
light
The gas valve may be OFF. Make sure that the gas valve is ON.
The LP tank may be empty. Refill the propane tank.
The burner orifice may be
blocked.
Clean or replace the burner orifice.
You may have air in the system. Purge any air from the lines by opening the gas lines
and depressing the control knob for two to three
minutes.
A loose connection. Make sure that all connections and fittings are tight.
Igniter failure. Use a stick lighter or match to light the burner.
The gas pressure is too low with
the valve fully open.
Replace the propane tank or the regulator.
You are lighting a new tank for
the first time.
Purge any air from the lines by opening the gas lines
and depressing the control knob for two to three
minutes.
The propane tank valve is on
but no gas is flowing.
Replace the hose/regulator assembly.
Low burner flame
Low pressure. Replace the low propane tank with a full one.
The propane tank is low on fuel. Replace the low propane tank with a full one.
The gas hose is kinked. Check the hose and either straighten or replace it.
Obstructions in the system. Check for obstructions at passageways and orifices.
Burner unit smoking Carbon on the reflector and
emitter screen.
Clean the components as needed.
Thick black smoke Blockage in the burner
assembly.
Thoroughly clean the burner.
Dimensions (H x W x D) 35.6-39.2 x 25.8 x 27 inches
(90.4 - 99.6 x 65.5 x 68.6 cm)
Maximum load weight 225 lbs. (102.1 kg)
Patio Heater_14-0979_V4_ENG.book Page 17 Tuesday, September 2, 2014 10:00 AM

18
Patio Heater_14-0979_V4_ENG.book Page 18 Tuesday, September 2, 2014 10:00 AM

19
Patio Heater_14-0979_V4_ENG.book Page 19 Tuesday, September 2, 2014 10:00 AM

V4 14-0979 Made in China
Patio Heater_14-0979_V4_ENG.book Page 33 Tuesday, September 2, 2014 10:00 AM
