patioSchwank 2300 series Operating instructions

GP-M230-BX-010A
2300 / IO 210 Manual
RD: June 2006
R.L. 10A
KH
INSTALLATION /OWNER’S MANUAL
2300 & IO-210
SERIES
HIGHEFFICIENCY
INFRA-RED PATIO HEATER
FOROUTDOORANDNONRESIDENTIAL
INDOOR SPACES
FOR YOUR SAFETY:
Do not store or use gasoline or other flammable
vapours and liquids in the vicinity of this or any
other appliance.
If you smell Gas:
>Shut off gas to the appliance
>Extinguish any open flames
>Don’t touch electrical switches
>Call your Gas supplier immediately
FIELD CONVERTIBILITY:
“The conversion shall be carried out in accordance
with the requirements of the authorities having
jurisdiction and in accordance with the
requirements of the B149.1 ( latest edition)
INSTALLATION CODE” in Canada, and the
ANSI Z223.1 (latest edition) in the U.S.A.
MEMBER OF

GP-M230-BX-010A
2300 / IO 210 Manual
RD: June 2006
R.L. 10A
KH
NOTICE:
The manufacturer reserves the right to make changes to equipment and specifications without
obligation or notification.
This publication, or parts thereof, may not be reproduced in any form, without prior written consent
from the manufacturer
Unauthorized use or distribution of this publication is strictly prohibited.
Infrasave
5285 Bradco Boulevard
Mississauga, Ontario
L4W 2A6
Phone: 1- 866-INFRASV (463-7278)
Fax: [phone]
e-mail: [e-mail]
Waynesboro, Georgia,
USA 30830
Customer Service:
Phone: [phone]
Fax: [phone]
Technical support:
1-877-446-3727
e-mail: [e-mail]
Schwank
5285 Bradco Boulevard
Mississauga, Ontario
L4W 2A6
Phone: [phone]
Fax: [phone]
e-mail: [email protected]
1-866-361-0417
PO Box 988, 2 Schwank Way
Waynesboro, Georgia,
USA 30830
Phone: [phone]
Fax: [phone]
e-mail: [email protected]
1-877-446-3727
http://www.schwankheaters.com

GP-M230-BX-010A
2300 / IO 210 Manual
RD: June 2006
R.L. 10A
KH
TABLE OF CONTENTS
TOPIC PAGE NUMBER
1. GENERAL.............................................. 1
2. INSTALLATION REQUIREMENTS... 1
2.1 MOUNTING CLEARANCES......... 1
2.2 HEATER MOUNTING.................... 1
2.3 GAS SUPPLY INSTALLATION.... 1
2.4 GAS PRESSURE ............................. 2
3. INSTALLATION PROCEDURES........ 2
4. LIGHTING INSTRUCTIONS.............. 3
5. SHUT DOWN INSTRUCTIONS .......... 3
6. FINISH COAT OF HEATER................. 3
7. SERVICING GUIDE ............................. 3
8. CONFIGURATION ............................... 5
8.1 DIMENSIONS.................................. 5
8.2 DELUXE HANGING KIT............... 5
8.3 MOUNTING OPTIONS................... 6
8.4 MINIMUM CLEARANCES TO
COMBUSTABLES........................ 11
8.5 SUGGESTED MOUNTING
DISTANCES.................................. 12
2300 /IO-210
SERIES
INFRA-RED PORTABLE PATIO HEATER
FOR OUTDOOR AND NON RESIDENTIAL
INDOOR SPACES
TOPIC PAGE NUMBER
9. ELECTRICAL REQUIREMENTS...... 13
9.1 REMOTE CONTROL.................... 13
10. SEQUENCE OF OPERATION-
HONEYWELL S87C DSI.................... 13
11. WIRING DIAGRAM– HONEYWELL
S87C DSI.............................................. 14
12. FLAME SENSING CIRCUIT -
HONEYWELL S87C DSI.................... 15
13. TROUBLESHOOTING GUIDE.......... 16
14. WIRING DIAGRAM- FENWAL 35-60
DSI........................................................ 18
15. SEQUENCE OF OPERATION-
FENWAL 35-60 DSI............................ 19
16. SPARK IGNITION CIRCUIT ............. 20
17. COMMISSIONING REPORT............. 21
18. REPLACEMENT PARTS LIST...........23
19. LIMITED WARRANTY...................... 24

GP-M230-BX-010A
2300 / IO 210 Manual
RD: June 2006
R.L. 10A
KH
Important notice To Installer:
Installation and repairs should be done by a qualified service person.
This Operation & Instruction manual is not to be removed from the site. It
MUST be given in its entirety to the consumer and retained for future refer-
ence.
IMPORTANT NOTICES AND WARNINGS:
Warning
•Improper Installation, adjustment, alteration, service or maintenance can
cause injury or property damage. READ the installation, operating and
maintenance instructions thoroughly before installing or servicing this
equipment. It is imperative that control compartment, burners and
circulating air passageways be kept clean and unobstructed.
Warning
•Due to the effects of radiant heat upon certain materials it is not recom-
mended to store or place items that could be damaged or distorted, directly
under this heater....i.e. Non combustible patio furniture etc.
•Children and Adults should be alerted to the hazards of high surface tem-
peratures and should be careful to avoid burns or clothing ignition.
•Young children should be carefully supervised when in the area of a heater.
•Clothing or other flammable materials should not be hung from, or placed
near to the heater.
Warning
Keep this appliance area free from combustible materials, gasoline and other
flammable vapours and liquids.

GP-M230-BX-010A
2300 / IO 210 Manual
RD: June 2006
R.L. 10A
KH
1. GENERAL
2. INSTALLATION REQUIREMENTS
2.1 MOUNTING CLEARANCES
Series 2300 / IO 210 Heaters must be mounted with minimum clearances as shown in Section
8.4. It should also be located with respect to building construction and equipment so as to pro-
vide sufficient clearance and accessibility for servicing and cleaning of burners and ignition
control. Minimum mounting height is to be no less than 96”. Do not store or place anything di-
rectly underneath heater
2.2 HEATER MOUNTING
IMPORTANT:For either horizontal or angle mounting, the long axis of the heater must be
level. Use only non-combustible mounting hardware. Diagram 2 on Page 5 illustrates typical
suspension hardware that may be used., and provided by Schwank as an optional component.
2.3 GAS SUPPLY LINE INSTALLATION
•All piping must be installed according to local codes.
•An approved flexible connector between the heater and gas piping must be installed. The
same is available as an option from Schwank.
•A drip-pocket at the inlet connection must be provided.
•On propane-fired units, a main line filter is recommended.
•Piping joint compounds must be resistant to the action of liquefied petroleum gases.
•All piping joints should be tested for leaks with a soap and water solution.
Page 1
Series 2300 / IO 210 Heaters are approved for both horizontal and angle mounting. When angle
mounting, the short axis may be rotated to a maximum of 45°; however this may direct a large
portion of infrared heat above the heads of seated occupants in many applications.
Schwank recommends a 30° mounting angle in most applications. Refer to Diagram 8. Im-
proper angle mounting can result in damage to the heater or unsafe operation, and will void
warranty.
The gas fired infra-red combined intensity heaters are suitable to be installed for heating of out-
door and non residential indoor spaces. These installation instructions are intended for the Se-
ries 2300 / IO 210 Heaters.
All installations must conform to the following:, all local and national code requirements in-
cluding the current CAN/CGA-B149.1 installation code for gas burning appliances and equip-
ment as well as the Canadian Electrical Code PART 1 CSAC22.1 (latest edition) must be ob-
served. All installations in the U.S.A. must conform to local and national code requirements
including, National Fuel Gas code ANSI Z223.1, and the National Electrical Code ANSI/NFPA
No 70 (latest edition). Due to ever changing standards and requirements, revision to equipment
and installation procedures may be necessary. In case of discrepancies, the latest installation
manual will take priority.

GP-M230-BX-010A
2300 / IO 210 Manual
RD: June 2006
R.L. 10A
KH
CAUTION:DO NOT INSTALL ANY GAS PIPING IN HEAT ZONES.
The maximum supply pressure must be limited to 14" w.c. (0.5 psi). If the line pressure is
above 14" w.c., then a separate pressure reducing regulator must be installed. The minimum
pressure at the inlet to the heater regulator must be equal to or greater than 6.0" w.c. for natural
gas and 11.0" w.c. for propane gas.
2.4 GAS PRESSURE
a) Properly install gas line as outlined in Section 2.3.
b) Mount heaters by using non-combustible mounting hardware as illustrated in Diagram 2.
Observe the minimum clearances as outlined in Sections 8.4 and suggested mounting dis-
tances in section 8.5
WARNING: When using Wall Mounting Bracket JP-2300-MB, or Arm Mounting Bracket JP-
2300-MA, ensure the anchoring to the structure is of sufficient strength, quality
and workmanship, to support the weight of the heater and any other loads such as
snow.
c) Connect heater to the main gas line. An approved 1/2" flexible connector (available as an
option from the manufacturer) must be used to absorb gas line expansion and any vibration -
check local code requirements.
(d) Check gas line for leakage by using soap test or gas meter test. Ensure gas pressure meets
the requirements out lined in Section 2.4 (above).
WARNING: When testing the main gas line pressure up to 0.5 psig, ensure that the isolation
valve and combination gas valve are "OFF", otherwise damage to the combina-
tion gas valve will result. When testing gas line in excess of 0.5 psig the appli-
ance and shut off valve must be disconnected from the gas supply piping system
during any such pressure testing.
Proper manifold pressure will be maintained when the main burner is operating under the fol-
lowing supply pressure:
LINE PRESSURE w.c.” MANIFOLD PRESSURE w.c.”
MINIMUM MAXIMUM AT GAS VALVE TEST POINT
NATURAL GAS 6.0 14.0 5.0
PROPANE GAS 11.0 14.0 10.0
Natural Gas: models are orificed for 1000 BTU/CU.FT.
Propane Gas: models are orificed for 2500 BTU/CU.FT.
3. INSTALLATION PROCEDURES
Page 2

GP-M230-BX-010A
2300 / IO 210 Manual
RD: June 2006
R.L. 10A
KH
5. SHUT DOWN INSTRUCTIONS
a) For temporary shutdown, turn off the electrical circuit.
b) For complete shutdown, turn off the electrical circuit and turn gas control knob to the
"OFF" position.
4. LIGHTING INSTRUCTIONS
6. FINISH COAT OF HEATER
Exterior heater surfaces, including stainless steel components, are coated with a black high
emissive coating that serves to preserve the aesthetic appearance of the heater and improve the
radiant heat output. With extended use, the finish coat may discolor and deteriorate to some ex-
tent due to the impact of heat and the deposit of ambient air born particles. This is a normal oc-
currence and in no way affects the operation of the heater or the manufacturer’s warranty. The
heater finish coat can be touched up using high temperature emissive coating (Schwank/
InfraSave Part # JA-0587-XX) that is compatible with the original finish. No other coating or
paint finish may be applied to the heater – use of an incompatible finish coating could cre-
ate a hazardous condition such as fire or noxious fumes, cause damage to the heater, and
will void the warranty.
Servicing of heater is essential for continued efficient operation. Servicing should be carried
out annually by qualified and licensed service personnel as follows:
•Clean the ceramic tile with compressed air. Avoid directing air stream at gasket material
between tile and heater body. The air pressure must be lower than 20 psig.
•Clean the venturi tube with compressed air. The air pressure must be lower than 20 psig.
7. SERVICING GUIDE (See Heater servicing on next page)
Page 3
1. Ensure the correct voltage is supplied and gas valve is in the ON position.
2. Turn on power to heater, set thermostat (if applicable) to desired setting, the heater will light.
3. If heater does not light: Turn off power to heater, turn gas valve to OFF position.
4. Wait for five minutes and repeat steps above. If heater does not light after three attempts, call
a qualified service technician.
e) Ensure proper electrical rating in the system by checking voltage at ignition module
terminals. To avoid system malfunction, the voltage range must be within 21.6 Volts to 26.4
Volts, and correct polarity must be maintained throughout the system.
f) Test-fire the heating system by following the lighting instructions as shown below and on
heater.

GP-M230-BX-010A
2300 / IO 210 Manual
RD: June 2006
R.L. 10A
KH
Indication of back firing:
•Loud ignition noise, followed by distinct hissing sound.
•Little or no visible burning on the ceramic tile surface.
•Combustion is taking place inside the burner body.
Cause & remedy of back firing:
•Improper gas pressure entering the venturi tube: check pressure.
•Breakage of a ceramic tile and or gasketing: - replace damaged part.
•Faulty sealing of the ceramic tile to the burner body, caused by breakdown of gasket mate-
rial: contact your local distributor or contractor.
WARNING: If heater backfires during operation, it must be turned off immediately.
HEATER SERVICING INSTRUCTIONS:
WHEN USING WALL MOUNT BRACKET JP-2300-MB:
1. Slacken the upper bolt to allow the rotation of the mounting bracket and the heater.
2. Remove the lower bolt securing the bracket and rotate the bracket up to the service position.
3. Insert the bolt in the upper hole to hold the heater for servicing, and apply locking nut to bolt
for extra safety. Heater panel can now be accessed and serviced safely.
4. NOTE: Do not start up the heater when in this Service position as the gas valve is in a
compromising position. Before starting the heater, ALWAYS restore the heater
bracket back to its original plane and correct support position.
5. To restore bracket, lift and support the weight of the heater and remove nut and bolt from up-
per hole.
6. Slowly rotate the heater back down to the correct lower position.
7. Insert and fasten the bolt in the bottom hole, and secure with the nut.
8. At completion of service, ensure that both support bolts are tightened securely.
Page 4

GP-M230-BX-010A
2300 / IO 210 Manual
RD: June 2006
R.L. 10A
KH
Page 5
MODEL Voltage
VAC Current amps Btu/hr input Total Weight (lbs). Length < A >
2312 / IO 212 -NG
2312 / IO 212 -LP
2313 / IO 213 -NG
2313 / IO 213 -LP
2315 / IO 215 -LP
2315 / IO 215 -NG
24 40 VA*
23,000
23,000
35,000
35,000
50,000
50,000
32
32
44
44
48
48
30 1/2”
30 1/2”
43 1/2”
43 1/2”
43 1/2”
43 1/2”
8.1 DIMENSIONS & CONFIGURATIONS FOR THE SERIES
2300 HIGH INTENSITY HEATERS
Diagram 1: DIMENSIONS
Front View End View
8. CONFIGURATION
CAPACITIES & CONFIGURATIONS
* For a multiple installation, the first heater is sized at 40 VA and each consecutive heater will be sized at 20
VA. The sum total will be the required Transformer size. If total VA exceeds one size (in between sizes) se-
lect the next highest VA rating.
8.2. MOUNTING KITS (NOTE: For unusual mounting application contact manufacturer.)
ITEM
NO PART NUMBER DESCRIPTION QTY
1 JP-2300-MB WALL MOUNTING BRACKET 1
2 JP-2300-MA ARM MOUNTING BRACKET 1
3 JP-2300-PC POST BRACKET 1
The heater is supplied with chain mounting bracket; JP-2300-HS
Other optional mounting kits are available:
WARNING: When using Wall Mounting Bracket JP-2300-MB, or Arm Mounting Bracket JP-
2300-MA, ensure the anchoring to the structure is of sufficient strength, quality
and workmanship, to support the weight of the heater and any other loads such as
snow.

GP-M230-BX-010A
2300 / IO 210 Manual
RD: June 2006
R.L. 10A
KH
Page 6
WALL MOUNTING BRACKET
ARM MOUNTING BRACKET
(WITH GAS HOSE AND WIRING) CHAIN HANGING SUPPORT
(SUPPLIED WITH HEATER)
POST MOUNTING BRACKET
8.3 MOUNTING OPTIONS FOR THE 2300 SERIES HIGH INTENSITY HEATERS
CHAIN HANGING
(BRACKET SUPPLIED
WITH HEATER)
POST MOUNTING
ARM MOUNTING
WALL MOUNTING
Diagram 3: MOUNTING OPTIONS
Diagram 2: MOUNTING KIT OPTIONS

GP-M230-BX-010A
2300 / IO 210 Manual
RD: June 2006
R.L. 10A
KH
Diagram 4: 2300 MOUNTING ARM TEMPLATE
Page 7

GP-M230-BX-010A
2300 / IO 210 Manual
RD: June 2006
R.L. 10A
KH
Diagram 5: 2300 WALL BRACKET TEMPLATE
Page 8

GP-M230-BX-010A
2300 / IO 210 Manual
RD: June 2006
R.L. 10A
KH
1. Install the Wall Mount Bracket on the wall, using four bolts...(not supplied). See warning
note (page 5)
2. Install the heater bracket on the heater using four nuts.
4. Install the heater bracket to the wall mount bracket, and remove the chains from the top of
the heater.
NOTE: The heater should be installed with enough slack on the wiring and a flexible gas con-
nector to allow the rotation of the heater up to the service position.
(See service installation on the next page).
Page 9
Diagram 6: HEATER INSTALLATION
Wall Mount Bracket
Heater Bracket

GP-M230-BX-010A
2300 / IO 210 Manual
RD: June 2006
R.L. 10A
KH
Page 10
Diagram 7: SERVICING HEATER

GP-M230-BX-010A
2300 / IO 210 Manual
RD: June 2006
R.L. 10A
KH
Note: Do not store or place anything directly under heater
Page 11
MODEL NO Ends Horizontal 30° Angle 45° Angle
C D E F G H J K L
2312 / IO 212 -N\L OUTDOOR 3” 5.5” 7” 9.5” 1” 9.5” 12.5” 1” 11.5”
2312 / IO 212 -N\L INDOOR 4” 8” 10” 12.5” 2.5” 14” 16” 2” 15.5”
2313 / IO 213 -N\L OUTDOOR 5” 7.5” 9” 9.5” 1.5” 21” 10.5” 1.5” 23”
2313 / IO 213 -N\L INDOOR 6” 10.5” 14.5” 14.5” 2.5” 26” 17” 2.5” 28”
2315 / IO 215 -N\L OUTDOOR 16” 8” 13.5” 10” 2” 21” 12.5” 2” 24.5”
2315 / IO 215 -N\L INDOOR 17” 11” 19” 16.5” 3” 28.5” 18.5” 3” 30”
Diagram 8: MOUNTING CLEARANCES
8.4 MINIMUM CLEARANCES TO COMBUSTIBLES: Table 2
The clearances to combustibles are established at points reaching a surface temperature of 1600 F. Some materials
such as awnings or plastic may require higher distances. Respect clearances as shown above.
Note: Ensure mounting height in any location
is sufficient to prevent patio patrons from
coming in contact with heater

GP-M230-BX-010A
2300 / IO 210 Manual
RD: June 2006
R.L. 10A
KH
8.5 SUGGESTED MOUNTING DISTANCES FOR COMFORT
Mounting
Parameters *** MODELS
2312 / IO 212 MODELS 2313 / IO 213 MODELS 2315 / IO 215
V—Mounting angle Horizontal 300 Horizontal 300 Horizontal 300
H—Minimum mounting
height to patio floor 6’ 6” 6’ 6” 7’ 0” 7’ 0” 8’0” 8’ 0”
C—Side distance to
patio edge 3’ 6” 3’ 6” 4’ 0” 4’ 0” 5’ 0” 5’ 0”
Y—Side distance be-
tween heaters 6’ 0” 6’ 0” 8’ 0” 8’ 0” 10’ 0” 10’ 0”
W—Distance to wall in
front 6’ 0” 7’ 0” 7’ 0” 8’ 0” 8’ 0” 9’ 0”
Z—Distance to heater in
front 12’ 0” 14’ 0” 14’ 0” 16’ 0” 16’ 0” 18’ 0”
*** Note: These mounting angles and distances are suggested, and are subject to on site conditions.
If in doubt, please contact your Schwank distributor.
Diagram 9: Distances/ Mounting Parameters
Page 12

GP-M230-BX-010A
2300 / IO 210 Manual
RD: June 2006
R.L. 10A
KH
10. SEQUENCE OF OPERATION: HONEYWELL S87C DSI CONTROL
(See page 19 for FENWAL Control)
1. On A call for heat the S87C DSI Control will check for a false flame condition or short to
ground. The module will lock out if a false flame condition is present. (Reset is usually done
manually from the Thermostat).
2. Spark (30,000volts) is generated at the Spark Ignition Stud, for direct ignition of the main
Burner by the single Spark Igniter.
3. Main Gas Control Valve is powered and OPENS lighting off the Main Burner.
4. Seperate Flame Sensor, relays the presence of Main Burner flame back to the DSI Control by
a rectified dc voltage signal. (TFI period)
5. If this dc signal is a minimum of 1.5ua (microamps) the flame remains established and the
DSI Control discontinues the ignition spark.
6. This is the 21 second T.F.I (Trial For Ignition) period where flame has to be established
first, and confirmed with a minimum signal strength of 1.5 uAmps(microamps) back to the
DSI Control. Failing this the DSI will go into a Safety Lockout Mode and shut down the
Burner. (Reset is manually done from the Thermostat).
7. On a loss of power the S87 allows the system to shut down safely. Start up is initiated when
power is restored
8. On a loss of Main Burner flame, the timed T.F.I. is repeated. Safety Lock-out occurs if the
flame is not re-established within the T.F.I period. After a 5 minute complete shut off period
has expired, the heater may be reset manually from the Thermostat.
Page 13
9. ELECTRICAL REQUIREMENTS AND THERMOSTAT CONTROL
All electrical installations must meet local and the latest edition Electrical Code PART 1 CSA
C22.1 in Canada and ANSI/NFPA N0 70 in the U.S.A.. Single heater requires 24 Volt, 60 Hz
electrical transformer sized at 40 VA. If multiple heaters are connected to a single transformer,
the proper transformer is 24 Volt, 60 Hz, sized at 40 VA for the first heater, and 30 VA each for
all subsequent additional heaters. For example, four heaters wired together (parallel), require a
transformer of 150 VA. It is recommended to install at most 2 heaters per zone for best comfort
control and economy of operation. PROPER WIRING POLARITY MUST BE MAINTAINED,
particularly when grouping the heaters in a zone.
Total wiring distances of up to 200' must use minimum 16 gauge electrical wire, and wiring dis-
tances of over 200' must use minimum 14 gauge electrical wire. The heater must be electrically
grounded in accordance with the local
electrical code. Malfunction of the heating system will result if the voltage varies by more than
+10% or -10%.
The heater can be controlled by a line moisture proof thermostat “off-on” switch, or Remote
Control. Total load of all heaters must be considered in determining the required contact rating
of the controlling thermostat or switch.
9.1. REMOTE CONTROL
Patio Heaters can be operated with Remote Control Option; JP-1234-RK and handset JP-1234-
HS. Refer to the manual accompanying the remote control for installation.

GP-M230-BX-010A
2300 / IO 210 Manual
RD: June 2006
R.L. 10A
KH
11. WIRING DIAGRAM FOR 2300 / IO 210 SERIES with Honeywell
S87C DSI Control (See page 18 for FENWAL control wiring)
If installing remote control; JP-1234-RK, refer to wiring diagram in the remote control
manual
Page 14

GP-M230-BX-010A
2300 / IO 210 Manual
RD: June 2006
R.L. 10A
KH
LOW/ UNSTEADY FLAME CURRENT
If the current to the S87C flame circuit is
less than 1.5 uA or is unsteady, check the
burner flame, flame sensor location and
electrical connections as follows.
Electrical Connections and Shorts
Connections at the flame sensor must be clean
and tight. If wiring needs replacement, use
moisture resistant #18 wire rated for
continuous duty up to 1050C [2210F].
Flame Sensor
The flame signal is best when about 1 in. [25
mm] of flame rod is immersed in the burner
flame. Abent flame rod, or mounting bracket
or a cracked ceramic insulator can affect
flame signal. Replace flame sensor if necessary.
Burner Flame
Theflame sensor must be constantly immersed
in flame. Check burner flame conditions as
shown opposite. Observe Burner rating
plate for the correct gas pressure, and check
it with a manometer. If gas pressure is OK
check gas line and orifice for obstructions.
12. FLAME SENSING CIRCUIT - HONEYWELL S87C DSI CONTROL
Flame current is the current which passes through the flame from the sensor to ground. The
minimum flame current necessary to keep the Honeywell S87C system from lockout is 1.5
uAmps (microamps). The output of the flame sensing circuit cannot be checked directly on
the S87C Control body. The flame sensing circuit current can be checked by bridging the
flame sensing current from the sensor to the S87C as follows.
1. Connect a meter (dc microammeter scale) in series with the flame sensor wire as
shown below. Using the Honeywell W136A Test Meter or equivalent. Disconnect
the sensor wire from the S87C, Connect the red (positive) meter lead to the free end of
the sensor wire. Connect the black (negative) meter lead to the quick-connect sensor
terminal on the S87C.
2. Restart the system and read the meter. The flame sensor current must be at least 1.5 uA and
steady. If the reading is less than 1.5uA or unsteady, see LOW OR UNSTEADY FLAME
CURRENT section, below.
If a flame is present at sensor and a reading of zero uA is obtained, check for a
secondary ground connection to the 25V (GND) terminal. If secondary connection
exists, temporarily remove connection and measure flame current again.
A good rectifying flame is
achieved with approx 1”
of sensor in a strong blue
flame, positioned 1/4” to
1/2” away from flame
source surface.
A lazy or weak flame is
not a good rectifying flame.
Check gas pressure and gas
line/orifice etc for insects.
and spider cocoons.
1”
1/4” to 1/2”
Sensor spade
on S87C
connect to
wire from
sensor
Page 15

GP-M230-BX-010A
2300 / IO 210 Manual
RD: June 2006
R.L. 10A
KH
13. TROUBLESHOOTING GUIDE
TURN HEATER ON :
(AT PATIO CONTROL PANEL IF INSTALLED)
24 VOLTS INTO DSI CONTROL
24 VOLTS OUT FROM CONTROL
24 VOLTS AT GAS CONTROL
SPARK ACROSS IGNITER.
IS HIGH VOLTAGE SPARK
OK ?
MAKE SURE THE MANUAL
LEVER ON THE VALVES
ARE OPEN AND THAT
THERE IS GAS GOING TO
THE VALVES.
*CHECK 120 V AT PRIMARY TRANSFORMER
*CHECK VOLTAGE OUT AT SECONDARY.
*IF THERE IS NOT 24V TO SECONDARY....
.......REPLACE THE TRANSFORMER
*ENSURE GAS IS TURNED ON AT VALVE.
*CHECK ELECTRICAL CONNECTIONS AT
CONTROL & GAS VALVE.
*CHECK 24V WIRING CONTINUITY FROM DSI
IGNITION CONTROL TO GAS VALVE, RE
PLACE WIRES IF NECESSARY.
*PERFORM IGNITION LEAD TEST DESCRIBED
IN “SPARK IGNITION CIRCUIT”.
*CHECK DSI MODULE IGNITION POST FOR
DEFECTS.
*SPARK IGNITER MAY BE OUT OF POSITION.
*CHECK BOOT OF THE IGNITION CABLE FOR
SIGNS OF MELTING OR BUCKLING. TAKE
PROTECTIVE ACTION TO SHIELD CABLE &
BOOT FROM EXCESSIVE TEMPERATURES.
*CHECK CERAMIC INSULATOR FOR CRACKS *
*CHECK SPARK GAP, 1/8”-3/16” .
*CHECK IGNITION CABLE, AND GROUND
WIRE,
*CHECK 24V WIRING FROM TRANSFORMER
TO IGNITION CONTROL / AND CHECK IF
CORRECT GAUGE OF WIRE FOR DISTANCE.
*REPLACE WIRES IF NECESSARY.
*CHECK FOR 24 VAC ACROSS GAS VALVE
TERMINALS ON CONTROL. IF NO VOLTAGE,
.........REPLACE CONTROL.
YES NO
NO
YES
YES
YES
YES
YES
NO
NO
NO
IF 24V IS PRESENT AND VALVE DOES NOT
OPEN.......REPLACE VALVE
GAS VALVE OPENS.
NO
Page 16
