Welcome Guide •English
Contents:
Before getting started, ensure the package contains the following components:
Surge Protection / Prises de protection contre les surtensions
Press to Reset
Touche/disjoncteur Réinitialiser
A
B
C
D
E
F
G
H
I
J
L
K
APower button GUSB type B socket
BMUTE button HWIRING FAULT indicator
CONLINE indicator IBattery backup & surge protection outlets
DAVR indicator JPower cord with plug
EON BATTERY indicator KSurge protection outlets
FOVERLOAD indicator LRESET button/circuit breaker
4
SAVE THESE INSTRUCTIONS
Read these instructions carefully and retain them for future use. If this
product is passed to a third party, then these instructions must be
included.
When using electrical appliances, basic safety precautions should always be followed
to reduce the risk of fire, electric shock, and/or injury to persons including the
following:
CAUTION Risk of Energy Hazard! 12 V, 9 Ampere-hour battery. Before
replacing batteries, remove conductive jewelry such as chains, wrist
watches, and rings. High energy through conductive materials could
cause severe burns.
CAUTION Risk of explosion! Do not dispose of batteries in fire. The batteries
may explode.
CAUTION Risk of injury! Do not open or mutilate batteries. Released material
is harmful to the skin and eyes. It may be toxic.
CAUTION Risk of electric shock! A battery can present a risk of electrical
shock and high short-circuit current. The following precautions
should be observed when working on batteries:
a) Remove watches, rings, or other metal objects.
b) Use tools with insulated handles.
c) Wear rubber gloves and boots.
d) Do not lay tools or metal parts on top of batteries.
e) Disconnect charging source prior to connecting or disconnecting
battery terminals.
• Disconnect Device Requirement - for PLUGGABLE EQUIPMENT, the socket-
outlet shall be installed near the equipment and shall be easily accessible.
• The maximum ambient operating temperature of the product is 104 °F (40 °C).
• Do not use surge protectors or extension cords with the product.
• Do not use for medical or life support equipment.
• Do not use with or near aquariums.
• Do not use the product on transportation means.
• Intended for installation in a temperature controlled, indoor area free of conductive
contaminants.
WARNING Risk of fire, explosion, or burns! Do not disassemble, heat above
140 °F (60 °C), or incinerate the battery.
CAUTION Risk of electric shock! Do not remove the cover except to replace
the battery. Turn off and unplug the product before replacing the
batteries. There are no user serviceable parts inside except for the
battery.
CAUTION
Risk of fire! To reduce the risk of fire, connect only to a circuit provided
with 20 amperes maximum branch circuit over current protection in
accordance with the National Electric Code, ANSI/NFPA 70.
5
CAUTION Not for use in a computer room as defined in the Standard for the
protection of information Technology Equipment, ANSI/NFPA 75.
Additional Battery Warnings
• Keep batteries out of the reach of children.
• If the battery leaks avoid contact with skin and eyes. Rinse affected areas
immediately with plenty of clean water, then consult a doctor.
• If the product appears to be bulging or shows other undesirable phenomena (e.g.
excess noise), stop using it immediately.
• Do not cover while in operation.
• Charge this product once every 3 months to avoid shortening its battery life.
Symbols
Provided battery contains Lead. Dispose of the battery according
to local regulations.
Direct current.
Alternative current.
Before First Use
• Check for transport damages.
• Before connecting the product to the power supply, check that the power supply
voltage and current rating corresponds with the power supply details shown on
the product rating label.
• Choose a wall outlet that’s in a branch circuit protected by a fuse or a circuit
breaker and does not connect in parallel to appliances or equipment with a large
power consumption.
DANGER Risk of suffocation! Keep any packaging materials away from
children – these materials are a potential source of danger, e.g.
suffocation.
NOTICE To ensure the maximum battery’s capacity, it is recommended to
charge the battery for at least 24 hours before first use.
NOTICE The product is equipped with a delivery safety lock. The product
needs to be connected to the power supply before the initial
start-up.
6
Operation
Connecting an external equipment
CAUTION Risk of damage! Do not connect equipment with a combined
power consumption of more than 1000 VA/550 W.
NOTICE It is suggested not to exceed 80% of the product’s total capacity
when connecting to the battery backup & surge protection
outlets (I). Do not connect larger appliances, such as laser printers,
paper shredders, heaters etc. to battery backup & surge protection
outlets (I). The power requirement of such equipment might
overload and potentially damage the product.
• Connect the external equipment to the product’s outlets (I) or/and (K).
• Connect the power plug (J) to the appropriate wall outlet.
Switching on/off
Battery backup & surge protection outlets (I)
The outlets (I) provide battery backup and surge protection. In case of a power
outage, battery power is automatically provided to these 5 outlets.
Surge protection
outlets (K)
USB
Surge Protection / Prises de protection contre les surtensions
Press to Reset
WIRING FAULT
Défaillance de câblage
Touche/disjoncteur Réinitialiser
Battery backup & surge
protection outlets (I)
• Press the power button (A). The product beeps and the ONLINE indicator (C)
lights up. The product supplies the power to the connected equipment.
• The product now supplies the power to the connected equipment.
• In case of a power outage, the ON BATTERY indicator (E) lights up and the
product beeps twice in 7 seconds to indicate the battery backup mode operation.
7
NOTICE If an overload is detected the product stops operation and the
OVERLOAD indicator (F) lights up and the product beeps. Switch
off the product and unplug at least one connected equipment so
that the maximum capacity is not exceeded. Wait 10 seconds and
press the RESET button (L). Then switch on the product again.
Surge protection outlets (K)
The outlets (K) provide only surge protection. Those outlets do not provide power
during a power outage.
NOTICE The surge protection outlets (K) are constantly on, whenever the
product is connected to the power supply.
Status
1. Power outage The product operates in the battery backup mode.
2. Low battery The battery capacity is low. The battery will be drained
quickly during power outage.
3. Overload
Product rated capacity is exceeded. Switch off the product
and unplug at least one connected equipment so that the
maximum capacity is not exceeded. Wait 10 seconds and
press the RESET button (L). Then switch on the product
again.
4. Short fault
Switch off the product and unplug at least one connected
equipment from the battery backup outlets. Then switch
on the product again.
5. Charge fault The battery charging voltage is too high or too low.
Contact professional repair centre.
8
Indicators patterns
Status Online (C) On
Battery (E) AVR (D) Overload (F) Alarm
1. OFF
Flashes
while
beeping
OFF OFF
Beeps twice
every 30
seconds
2. OFF
Flashes
while
beeping
OFF OFF Beeps rapidly
3. ON OFF OFF ON Constant alarm
OFF ON
4. ON OFF OFF OFF Constant alarm
OFF ON
5. ON OFF OFF OFF Beeps every 2
seconds
OFF ON
Automatic voltage regulation
The product features AVR (Automatic Voltage Regulation) that allows to stabilize
the inconsistent power input to the nominal level (110-120 V~) that is safe to the
connected external equipment. Once the AVR protection is activated the AVR
indicator (D) lights up.
Sensitivity adjustment
In line mode, the AC input voltage can not be stable all the time. To prevent the
connected equipment from damage caused by the unexpected voltage fluctuations,
adjust the sensitivity of the product.
• Switch the product on in the line mode.
• Press the MUTE button (B) for 6 seconds. All indicators flash rapidly.
• The product indicates the current sensitivity setting:
9
Indicators Sensitivity Description
Red Low
If the connected equipment can tolerate more
power events (e.g. unstable power in a stormy
weather), select Low Sensitivity and the product
will go to Battery Mode less often.
Yellow, red Medium
(Default)
The product will go to Battery Mode if the power
is unstable.
Green, yellow,
red High
If the connected equipment is more sensitive to
power events, select High Sensitivity and the
product will go to Battery Mode more often.
• To change the setting, press the MUTE button (B) repeatedly.
• To save the setting, press and hold the MUTE button (B) until the
ONLINE indicator (C) lights up.
NOTICE The product exits the sensitivity setup automatically if no button is
pressed for 7 seconds.
Connecting to a computer
NOTICE The PowerPanel®Personal software enables to view the connection
and energy consumption status as well as configure the product.
Use the type B to type A USB cable to connect the product to a
computer.
Download and installation
• Visit www.amazon.com website.
• Search the B07RRYB3RJ product number.
• Scroll down to “Technical Specification” section and download the
PowerPanel®Personal software.
• Launch the software and follow the on-screen setup instructions.
10
Replacing the battery
CAUTION Risk of Energy Hazard! 12 V, 9 Ampere-hour battery. Before
replacing batteries, remove conductive jewelry such as chains, wrist
watches, and rings. High energy through conductive materials could
cause severe burns.
CAUTION Risk of explosion! Do not dispose of batteries in a fire. The
batteries may explode.
CAUTION Risk of injury! Do not open or mutilate batteries. Released material
is harmful to the skin and eyes. It may be toxic.
CAUTION Risk of electric shock! A battery can present a risk of electrical
shock and high short circuit current. The following precautions
should be observed when working on batteries:
1) Remove watches rings, or other metal objects.
2) Use tools with insulated handles.
NOTICE When replacing batteries, replace with the same number of the
following battery: amazonbasics/ABRB 1290.
• Switch off and unplug all the connected equipment.
• Switch off the product and disconnect it from the power supply.
• Place the product on its side, on a solid and stable surface.
• Loosen the battery compartment cover screws.
• Slide the battery compartment cover and put it aside.
1
2
3
• Disconnect the battery wires from the battery terminals.
11
( - )
( + )
• Slide the battery out of the battery compartment.
• Slide the replacement battery into the battery compartment.
• Connect the red wire to the positive (+) terminal and black wire to the negative (-)
terminal of the new battery.
• Close the battery compartment cover and secure it with the screws.
WARNING Risk of explosion! Always connect the (+) red connector and (-)
black connector to the correct terminals (+) and (-).
12
Cleaning and Maintenance
NOTICE Switch the product off and unplug it from the power supply before
cleaning.
NOTICE During cleaning do not immerse the product in water or other
liquids. Never hold the product under running water.
Cleaning
• To clean, wipe with a soft, slightly moist cloth.
• Never use corrosive detergents, wire brushes, abrasive scourers, metal or sharp
utensils to clean the product.
Maintenance
• Replace the battery after 3-6 years of use.
Storage
• Store the product covered in a cool, dry location, with the battery fully charged.
Fully charge the battery every 3 months.
Transport
• Switch off and disconnect all the connected equipment. Disconnect the product
from power supply and then disconnect all the internal batteries.
• Pack and secure the product properly to protect it from shocks and vibrations.
System Functional Block Diagram
Input EMI
Filter AVR
Charger AC/DC
Output
Battery
Inverter
Normal mode
Battery mode
Surge
supressor
13
Troubleshooting
Problem Possible cause Solution
The circuit breaker has
tripped.
Power supply
overload.
Switch off the product and unplug
at least one connected equipment
so that the maximum capacity is
not exceeded. Wait 10 seconds and
press the RESET button (L). Switch
on the product again.
The product does
not perform expected
runtime.
Battery is not fully
charged. Recharge the battery.
Battery is worn out. Replace the battery.
The product does not
switch on.
The product is not
connected to the
socket-outlet.
The product must be connected to
a 120 V, 60 Hz socket-outlet.
The power
button (A) is
designed to prevent
damage from
rapidly turning it off
and on.
Switch off the product. Wait
10 seconds and switch on the
product again.
Battery is worn out. Replace the battery.
PowerPanel®Personal
software is inactive (all
icons are gray).
The USB / serial
cable is not
connected.
Connect the USB / serial cable to
the product and an USB port of
your computer.
The USB / serial
cable is connected
to the wrong port.
Connect the USB / serial cable to
another USB port of your computer.
The product is not
providing battery
power.
Switch off the product. Wait
10 seconds and press the RESET
button (L). Switch on the product
again.
14
FCC – Supplier’s Declaration of Conformity
Unique Identifier B07RRYB3RJ - AMBT1000
Responsible Party Amazon.com Services, Inc
U.S. Contact Information 410 Terry Ave N.
Seattle, WA
98109, United States
Telephone Number (206) 266-1000
FCC Compliance Statement
1. This device complies with Part 15 of the FCC rules. Operation is subject to the
following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
2. Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
FCC Interference Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Canada IC Notice
• This Class B digital apparatus complies with Canadian CAN ICES-3(B) / NMB-3(B)
standard.
15
Specifications
Model number: ABMT1000
Input voltage/frequency: 120 V~, 57 Hz (± 0.5 Hz) - 63 Hz (± 0.5 Hz)
Battery backup mode output
voltage/frequency: 120 V~ (± 5%), 60 Hz (± 1 %)
Power capacity: 1000 VA, 550 W
Maximum load for the surge
protection outlets (K): 12 A
Battery type/voltage/capacity:
Maintenance-free sealed lead-acid battery
12 V , 9 AH
Standby use: 13.5-13.8 V
Cycle use: 14.4-15 V
Initial current: less than 2.7 A
Battery backup mode wave form: Simulated sine wave
Estimated backup battery time: Half Load (275 W) - 1 minute
Full Load (550 W) - 7 minutes
Battery charging time: 24 hours to 90% from full discharge
Operating temperature: 32 °F to 104 °F (0 °C to 40 °C)
Operating humidity: 10 – 95 % RH
Net weight: 15 lbs (6.8 kg)
Dimensions (W x H x D): 3.9 x 9 x 10.2" (10 x 22.8 x 26cm)
Feedback and Help
Love it? Hate it? Let us know with a customer review. AmazonBasics is committed
to delivering customer-driven products that live up to your high standards. We
encourage you to write a review sharing your experiences with the product.
amazon.com/review/review-your-purchases#
amazon.com/gp/help/customer/contact-us
HECHO EN CHINA
FABRIQUÉ EN CHINE
MADE IN CHINA
amazon.com/AmazonBasics
V8-01/20
Table of contents
Other AmazonBasics UPS manuals
