amber connect AIT450-m Operator's manual

Know your device
AIT 450-M Device view
Pinout
AIT 450-M socket pinout
Pin
number
Pin name
Description
2
PWM_BUS+/VPW
4
GND (-)
Ground
5
GND (-)
Ground
6
CAN_H
CAN high
7
K-Line
10
PWM_BUS-
14
CAN_L
CAN low
15
L-Line
16
VCC (12 - 30)V DC(+)
Power supply (+10-30 V DC)
AIT 450-M socket pinout

Set up your device
How to insert Micro-SIM card and connect the battery
1. Gently remove AIT 450-M cover using plastic pry tool from both sides.
2. Insert Micro-SIM card as shown with PIN request disabled or read our Wiki how to enter it later in Amber
Configurator. Make sure that Micro-SIM card cut-off corner is pointing forward to slot.
3. Connect battery as shown to device. Position the battery in place where it does not obstruct other
components.’
4. Attach device cover back.
Device is ready to be connected.
Cover removal
Micro-SIM card insert
Battery connection
Attaching cover back

Mounting recommendations
Connecting the device to the vehicle:
Find OBDII connector in your vehicle (Figure 10. Most common OBDII connector locations.).
Before connecting the device to the OBDII socket, make sure that ≥3A fuse is present on OBD
connector power supply.
Most common AIT 450-M connector locations.
LED indications
Navigation LED indications
Behaviour
Meaning
Permanently switched on
GNSS signal is not received
Blinking every second
Normal mode, GNSS is working
Off
GNSS is turned off because: Device is not working or
Device is in sleep mode
Blinking fast constantly
Device firmware is being flashed
Status LED indications
Behaviour
Meaning
Blinking every second
Normal mode
Blinking every two seconds
Sleep mode
Blinking fast for a short time
Modem activity
Off
Device is not working or Device is in boot mode

Characteristics
Basic characteristics
Module
Name
AIT 450-M
Technology
LTE CAT M1/CAT NB1/EGPRS/GNSS/BLUETOOTH
GNSS
GNSS
GPS, GLONASS, GALILEO, BEIDOU, SBAS, QZSS,
DGPS, AGPS
Receiver
33 channel
Tracking sensitivity
-165 dBM
Accuracy
< 3 m
Hot start
< 1 s
Warm start
< 25 s
Cold start
< 35 s
Cellular
Technology
LTE CAT M1, CAT NB1
2G bands
EGPRS: 850/900/1800/1900MHz
4G bands
LTE FDD: B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B28
LTE TDD: B39 (For CAT M1 Only)
Data transfer
CAT M1: Max. 375Kbps (DL), Max. 375Kbps (UL)
CAT NB1: Max. 32Kbps (DL), Max. 70Kbps (UL)
GPRS: Max. 107Kbps (DL), Max. 85.6Kbps (UL)
Data support
SMS (text/data)
Power
Input voltage range
10 - 30 V DC with overvoltage protection
Back-up battery
170 mAh Li-Po battery 3.7 V (0.63 Wh)
Internal fuse
3 A, 125 V
Power consumption
GPRS: max 50 mA rms
Nominal with no load: average 35 mA rms
GPS sleep: average 12 mA
Deep Sleep: average 4.5 mA
Bluetooth
Specification
4.0 + LE
Supported peripherals
Temperature and Humidity sensor, Headset, OBDII
dongle, Inateck Barcode Scanner, Universal BLE sensors
support
OBD INTERFACE
Data
K-Line, CAN Bus data
Data reading
Up to 32 vehicle onboard parameters, 9
Interface
Connection
OBDII socket
GNSS antenna
Internal High Gain
GSM antenna
Internal High Gain
USB
2.0 Micro-USB
LED indication
2 status LED lights
SIM
Micro-SIM

Memory
128MB internal flash memory
Physical specification
Dimensions
67,2 x 49,6 x 25 mm (L x W x H)
Weight
63 g
Operating environment
Operating temperature (without
battery)
-40 °C to +85 °C
Storage temperature (without battery)
-40 °C to +85 °C
Operating humidity
5% to 95% non-condensing
Ingress Protection Rating
IP41
Battery charge temperature
0 °C to +45 °C
Battery discharge temperature
-20 °C to +60 °C
Battery storage temperature
-20 °C to +45 °C for 1 month
-20 °C to +35 °C for 6 months
Features
Sensors
Accelerometer
Scenarios
Green Driving, Over Speeding detection, Jamming
detection, GNSS Fuel Counter, Excessive Idling detection,
Unplug detection, Towing detection, Crash detection, Auto
Geofence, Manual Geofence, Trip
Sleep modes
GPS Sleep, Online Deep Sleep, Deep Sleep, Ultra Deep
Sleep
Configuration and firmware update
FOTA Web, FOTA, Amber Configurator (USB, Bluetooth),
FMBT mobile application (Configuration)
SMS
Configuration, Events,Debug
GPRS commands
Configuration,Debug
Time Synchronization
GPS, NITZ, NTP
Fuel monitoring
OBDII
Ignition detection
Accelerometer, External Power Voltage, Engine RPM
Safety information
This message contains information on how to operate AIT 450-M safely. By following these
requirements and recommendations, you will avoid dangerous situations. You must read
these instructions carefully and follow them strictly before operating the device!
•The device uses SELV limited power source. The nominal voltage is +12 V DC. The
allowed voltage range is +10...+30 V DC.
•To avoid mechanical damage, it is advised to transport the device in an impact-proof
package. Before usage, the device should be placed so that its LED indicators are
visible. They show the status of device operation.
•Before mounting device make sure that a ≥3A fuse is present on OBD connector power supply.
•Before unmounting the device from vehicle, ignition MUST be OFF.
Do not disassemble the device. If the device is damaged, the power supply cables
are not isolated or the isolation is damaged, DO NOT touch the device before
unplugging the power supply.
All wireless data transferring devices produce interference that may affect other
devices which are placed nearby.

Please consultrepresentatives of your vehicle model regarding OBDII location on
your vehicle. In case you are not sure about proper connection, please consult
qualified personnel.
The programming must be performed using a PC with autonomic power supply.
Installation and/or handling during a lightning storm is prohibited.
The device is susceptible to water and humidity.
Amber is not responsible for any harm caused by wrong cables used for
connection between PC and AIT 450-M
WARNING! Do not use AIT 450-M device if it distracts driver or causes
inconvenience due to OBDII placement. Device must not interfere with driver.
Battery should not be disposed of with general household waste. Bring damaged
or worn-out batteries to your local recycling center or dispose them to battery
recycle bin found in stores.
Certification and Approvals

•AIT 450-M RoHS
This sign on the package means that it is necessary to read the User‘s Manual
before your start using the device. Full User‘s Manual version can be found in our
Wiki.
This sign on the package means that all used electronic and electric equipment
should not be mixed with general household waste.
17 Warranty
Amber connect guarantees its products to be free of any manufacturing defects for a period of 24
months. With additional agreement we can agree on a different warranty period, for more detailed
information please contact our sales manager.
All batteries carry a reduced 6 month warranty period.
If a product should fail within this specific warranty time, the product can be:

•Repaired
•Replaced with a new product
•Replaced with an equivalent repaired product fulfilling the same functionality
•Amber can also repair products that are out of warranty at an agreed cost.
Warranty Disclaimer
Amber products are intended to be used by persons with training and experience. Any other use
renders the limited warranties expressed herein and all implied warranties null and void and same are
hereby excluded. also excluded from this limited warranty are any and all incidental or consequential
damages including but not limited to, loss of use or revenue, loss of time, inconvenience or any other
economic loss.
.
