amber connect Amber Swift C300 User manual

1. Overview
1.1. Accessories
Device
Bracket
User guide
Charger
Charge cable
1.2. Main Functions
Intelligent power saving
IPX5 water resistant grande
Tamper alert
Strong magnet installation
Fast charging
10000mAh battery
Listen-in capability
1.3. Specification
2. My Device
2.1. Appearance
Frequency: 900MHz
GSM 850/900/1800/1900MHz
Location accuracy
<10 meters
Monitoring range
S5 meters
Working voltage/current
3.7V/60mA
Battery
10000mAh/3.7V industrial grade lithium polymer battery
LED
Red: work status
Operating Temperature
-20°C to 70°C
Dimension
108*61*30 mm
Weight
285g

2.2. GSM Indicator
The GSM Indicator will turn off after the device has been powered on for 3 minutes.
Once the device is on, tap the power button to activate the LED, which will turn off automatically after
60 seconds.
3. SIM Card
The SIM card should have access to GPRS and SMS. Remove the device cover, switch to OFF and
insert the SIM card.
Status
Meaning
Blinking quickly
GSM initialization/No GSM
Blinking slowly
Connect to the Amber Connect platform
Always ON
Voice calling feature enabled

4. Installation
The device is built with a strong magnet which can be easily attached to any surface with a magnetic
pull. To attach the device to a non-magnetic surface, use the 3M foam tape and bracket included in
your package.
Problems
Causes
Solutions
Poor signal
The signal waves are unable to transmit
when using the GPS tracker in places
with poor signal reception, such as tall
buildings or basements.
Relocate to an area with adequate signal
reception.
Unable to boot
Power switch is OFF
Switch to ON
No battery
Charge battery
No SIM card
Insert SIM card
Unable to
connect to
thenetwork
SIM card inserted incorrectly
Check SIM card
SIM card has dust, debris
Clean SIM card
Invalid SIM card
Contact network supplier
Not in GSM service area
Move to GSM service area
Fail to locate
Poor signal
Move to an area with adequate signal
reception
SIM has no access to GPRS
Contact network supplier to get GPRS
service
Always reply "Address inquiry failed"
Contact supplier
5. Operation
5.1 Power ON/OFF
Power on: Press power button for 3 seconds (battery switch is in ON position).
Power off: Press power button for 3 seconds.
5.2 Emergency Number
Set emergency number via App.
5.3 Working Mode
(1) Tracking mode (default): GSM is always ON and location data uploaded in set time intervals.
(2) Ultra-long standby mode: device wakes up and uploads location data based on preset frequency
set up to a maximum of 72 hours of location update.

Notice: In this mode, commands will NOT be executed
until the device wakes up at preset time intervals. You can force the device to wake up and receive
communication by:
a. triggering the tamper alert button at the back
b. unplugging the battery and plugging it in again.
5.4 Tamper Alert
The anti-tamper button will pop out and an alert will be sent if the device has been disassembled. In
standby mode, an alert message will be uploaded and tracking mode will be activated for 20
minutes if device disassembly is detected. After 20 minutes, the device enters into ultra-long
standby mode.
5.5 Cover Remove Alert
The cover detection button pops out and an alert will be sent if the device cover is dismantled. In
standby mode, an alert message will be uploaded and tracking mode will be activated for 20 minutes
if cover dismantling is detected. After 20 minutes, the device enters into ultra-long standby mode.
5.6 Low Battery Alert
When the battery is low, the device will activate a low battery alarm.
5.7 Vibration Alarm
The vibration alarm only works in tracking mode. To activate this function, please go to the Amber
Connect.
App: safety > safety settings > vibration alert.
5.8 Geo-fence Alarm
The geo-fence alarm only works in tracking mode. When the vehicle enters/exits the pre-set geo-
fence area, the Amber Connect App will send a real-time notification.
5.9 Voice Monitoring
Use pre-set SOS number to make and receive calls from the device. The device will automatically
call back. Answer the call and monitor sounds inside the vehicle.

6. App And Web Platforms
6.1. Download App
Please download and install the Amber Connect App from your digital App store and follow the
onscreen instructions to register your device.
6.2. Web App
Visit www.amberconnect.com/portal/customer/login and go to login > customer > sign up and follow
the onscreen instructions to register your device.
7. Warning
Battery specified by the manufacturer is recommended. Maintenance or service arising from any third
party accessories is not guaranteed. The manufacturer assumes no responsibility for any damage
caused by non-original accessories. Do not bend or open the battery. Do not immerse or burn the
battery. Device disassembly is strongly forbidden.
Non-professionals' operation may lead to device damage.
8. Troubleshooting
If you are having trouble with your device, try the troubleshooting procedures before contacting a service
professional.
