AmbiCom WL1100B-USB Installation instructions

11 Mbps Wireless LAN USB Adapter
Model: WL1100B-USB
Product Specifications
Model Number WL1100B-USB
Descriptions Wave2Net IEEE 802.11b Wireless LAN USB Adapter
Interface USB V1.1 Compliant
Radio Specifications
Protocol Support TCP/IP, IPX, NetBEUI, BOOTP, SNMP, Telnet, DHCP, FTP
Radio Type Direct Sequence Spread Spectrum (DSSS)
Data Rate 1, 2, 5.5, 11 Mbps Per Channel
Antenna Internal with Diversity Function
Frequency Band (ISM Band)
and Operating Channels
(IEEE 802.11b Compliant)
N. America/FCC: 2.412 ~ 2.462 GHz (11 channels)
Europe CE/ETSI: 2.412 ~ 2.472 GHz (13 channels)
Japan: 2.457 ~ 2.484 GHz (14 channels)
France: 2.457 ~ 2.472 GHz (4 channels)
Spain: 2.457 ~ 2.462 GHz (2 channels)
Type of Modulation BPSK: 1 Mbps
QPSK: 2 Mbps
CCK: 5.5 and 11 Mbps
Receiver Sensitivity 11 Mbps <-83 dBm
5.5 Mbps <-86 dBm
2 Mbps <-89 dBm
1 Mbps <-91 dBm
(FER = 8*10E-2)
Operating Range
Confined Environment 164 ft. (50M) @ 11 Mbps
262 ft. (80M) @ 5.5 Mbps
394 ft. (120M) @ 2 Mbps
492 ft. (150M) @ 1 Mbps
Open Environment 820 ft. (250M) @ 11 Mbps
1,148 ft. (350M) @ 5.5 Mbps
1,312 ft. (400M) @ 2 Mbps
1,640 ft. (500M) @ 1 Mbps
Transmit Power 2.7v to 3.0v: 13 dBm ~ 20 dBm
Operation Humidity 0% to 95% Non-condensing
Operation Temperature 32°F to 131°F (0°C to 55°C)
Storage Temperature -2°F to 176°F (-20°C to 80°C)
Power Consumption TX: 380 mA (Max)
RX: 320 mA
Encryption 64-bit or 128-bit Key WEP, RC4 Wireless Data Encryption
Physical Specifications
Size Including Ant. 5 x 2.7 x 1.32 inches (126.5 x 69 x 33.5 mm)
Weight With included USB Cable 3.5 oz. (110 g)
LED Power in Red, TX/RX in Green
Operating System Support Windows ME/2000/98
Standard Conformance IEEE 802.11b USA: FCC, Class B
Europe: CE, Class B Japan: RCR STD-33
Warranty 1-Year Limited
