AmbiCom WL1100B-BR Installation instructions

11 Mbps Wireless LAN Inter-Building Bridge
Model: WL1100B-BR
Product Specifications
Rev : 1.1
Model Number WL1100B-BR
Descriptions Wave2Net IEEE 802.11b Wireless LAN Inter-Building
Bridge
Radio Specifications
Radio Type Direct Sequence Spread Spectrum (DSSS)
Data Rate 1, 2, 5.5, 11 Mbps Per Channel
Antenna External with Diversity Function
Reverse Polarity SMA Connector
Frequency Band
(ISM Band) and
Operating Channels
(IEEE 802.11b Compliant)
N. America/FCC: 2.412~2.462 GHz (11 channels)
Europe CE/ETSI: 2.412~2.472 GHz (13 channels)
Japan: 2.457~2.484 GHz (14 channels)
France: 2.457~2.472 GHz (4 channels)
Spain: 2.457~2.462 GHz (2 channels)
Type of Modulation BPSK: 1 Mbps
QPSK: 2 Mbps
CCK: 5.5 and 11 Mbps
Receiver Sensitivity -83dBm @ 11 Mbps, PER<8*10-2
Typical Operating Range
50 M @ 11 Mbps 80 M @ 5.5 Mbps 120 M @ 2 Mbps 150 M @ 1 Mbps
Output Power >13dBm
Security 64-bit or 128-bit Key WEP, RC4 Wireless Data
Encryption
Function Supported Roaming, Inter-Building with Repeating (PxP) Core
Function, Wireless NIC Station Adapter, MAC Address
Control
Ports WAN: One 10BaseT/100BaseTX RJ-45
Maximum Clients 256 (15 -20 Recommended)
Remote Configuration Web Browser Interface, SNMP, Telnet
Power Consumption 12 VDC
Ethernet Wired Interface IEEE 802.3 (10BaseT), IEEE 802.3u (100BaseTX)
Physical Specifications
Size 172 x 124 x 34 mm
Weight 320 g
LED Power, AP Ready, Wireless Activity, Ethernet Activity,
Wireless Link
Standard Conformance IEEE 802.11b, IEEE 802.3 10BaseT, IEEE 802.3u
100BaseTX Ethernet
USA: FCC, Part 15, Sections 15.247, 15.107 and 15.109
Europe: CE, Class B Japan: RCR STD-33
Warranty 1-Year Limited
