AmbiCom WL1100B-AR Installation instructions

11 Mbps Wireless LAN Access Router
Model: WL1100B-AR
Product Specifications
Model Number WL1100B-AR
Descriptions Wave2Net IEEE 802.11b Wireless LAN Access Router
Radio Specifications
Radio Type Direct Sequence Spread Spectrum (DSSS)
Data Rate 1, 2, 5.5, 11 Mbps Per Channel
Antenna Internal with Diversity Function
Frequency Band (ISM Band)
and Operating Channels
(IEEE 802.11b Compliant)
N. America/FCC: 2.412 ~ 2.462 GHz (11 channels)
Europe CE/ETSI: 2.412 ~ 2.472 GHz (13 channels)
Japan: 2.457 ~ 2.484 GHz (14 channels)
France: 2.457 ~ 2.472 GHz (4 channels)
Spain: 2.457 ~ 2.462 GHz (2 channels)
Type of Modulation BPSK: 1 Mbps
QPSK: 2 Mbps
CCK: 5.5 and 11 Mbps
Receiver Sensitivity -83 dBm @ 11 Mbps, PER<8*10-2
Operating Range
Confined Environment 164 ft. (50M) @ 11 Mbps
262 ft. (80M) @ 5.5 Mbps
394 ft. (120M) @ 2 Mbps
492 ft. (150M) @ 1 Mbps
Open Environment 820 ft. (250M) @ 11 Mbps
1,148 ft. (350M) @ 5.5 Mbps
1,312 ft. (400M) @ 2 Mbps
1,640 ft. (500M) @ 1 Mbps
Output Power >13 dBm
Encryption 64-bit or 128-bit Key WEP, RC4 Wireless Data
Encryption
Function Supported Roaming, IP Router, Brouter (to bridge non-TCP/IP
traffic), IP Sharing (NAT), DHCP Client, DHCP Server,
PPPoE Client, MAC Address Control
Ports WAN: One 10BaseT/100BaseTX RJ-45
Maximum Clients 256 (15 – 20 Recommended)
Remote Configuration Web Browser Interface, SNMP, Telnet
Power Consumption 12V DC
Ethernet Wired Interface IEEE 802.3 (10BaseT), IEEE 802.3u (100BaseTX)
Physical Specifications
Size 6.7 x 4.9 x 1.3 inches (172 x 124 x 34 mm)
Weight 11 oz. (320 g)
LED Power, AP Ready, Wireless Activity, Ethernet Activity,
Wireless Link
Standard Conformance IEEE 802.11b, IEEE 802.3 10BaseT, IEEE 802.3u
100BaseTX Ethernet
USA: FCC, Part 15, Sections 15.247, 15.107 and 15.109
Europe: CE, Class B Japan: RCR STD-33
Warranty 1-Year Limited
