AMC MP 03 User manual

Important
Do not install this equipment in a
confined space such as a book case or
similar unit.
The apparatus should not be dripped or
splashed and no objects filled with
liquids, such as vases, should not be
placed on the apparatus.
This unit should not be used near water
(e.g. near bathtub, washbowl, kitchen
sink, laundry tub, in a wet basement, or
near a swimming pool, etc.) are should
be taken so than objects do not fall and
liquids are not spilled into enclosure
through openings.

ONTENTS:
Before you start
What's in the box 4
Hints on installation 4
Disc, flash disc formats 4
ontrols and connections
Front panel 5
Rear panel 5
Settings and functions
Tuner functions 6
D functions 6
RS 232 commands list 8
Specifications
General 9
Tuner section 9
D section 9

What’s in the box
The accessories which are included in the box are:
•Remote control
•Instruction manual
•Power cable
Hints on installation
Do…
•Use in a well-ventilated room.
•Place on a solid, flat, level surface, such as a table, shelf or stereo rack
Don’t…
•Use in a place exposed to high temperatures or humidity, including near radiators and other
heat-generating appliances.
•Place on a window sill or a place where the player will be exposed to direct sunlight.
•Use in an excessively dusty or damp environment.
•Place directly on top of an amplifier, or other component that becomes hot in use.
•Use near television or monitor as you may experience interference-especially if the television
uses an indoor antenna.
•Use in a kitchen or other room where the player may be exposed to smoke or steam.
•Use on a thick rug or carpet, or cover with cloth-this may prevent proper cooling of the unit.
•Place on an unstable surface, or one that is not large enough to support all four of the unit’s
feet.
•Do not use or store batteries in direct sunlight or other hot place, such as inside car or near
heater. This can cause batteries to leak, overheat ,explode or catch fire. It can also reduce the
life or performance of batteries.
Disc, flash disc formats
You can play following disc formats: D, D-R, D-RW, it does support DDA ( D
Text) as well as ISO 9660 D-ROM’s. ompressed audio files are supported from
USB/SD drive as well as from D.

Front Panel
1. Power ON/OFF switch
2. D Display
3. Repeat
4. Folder skip button
5. Folder skip button
6. A-B repeat button
7. Mute
8. D/USB/SD selector
9. SD/MM slot
10. Tuner display
11. Station preset button 6
12. Station preset button 7
13. Station preset button 8
14. Station preset button 9
15. Station preset button 10
16. Jump through 10 radio station
17. Memory button
18. LED indicator for IR remote control
19. USB slot
20. D slot
21. Program button
22. Track skip button
23. Track skip button
24. Stop button
25. Play/pause button
26. D eject button
27. Station preset button 1
28. Station preset button 2
29. Station preset button 3
30. Station preset button 4
31. Station preset button 5
32. Station search button (down)
33. IR detector for IR remote control
34. Stations search button (up)
Rear Panel
1. 9-pin D-Sub connection for Serial
Interface (RS232)
2. FM antenna input
3. Output from Tuner R A connector
4. Output from Tuner balanced
Phoenix connector
5. Output from D/USB/SD player R A
connector
6. Output from D/USB/SD player balanced
Phoenix connector
7. Mains power input.
8. A fuse holder

Tuner Functions
MEMORY
This function is designed for adding radio stations in the presets. Memory mode is activated by
pressing the “Memory” button. After pressing “Memory” button display will displays “MEMO” logo. At
this moment the displayed frequency will be memorized in the selected preset (from 1to 60) when
"Memory" button will be pressed “one more time. After 5 seconds of inactivity memory mode shuts
off automatically.
UP/DOWN
Seek tuning starts after pressing “UP” or “DOWN” key for more than 0,5 sec
When “UP” or “DOWN” key is pressed for a short time manual search mode is activated,
1 Push = 1 step.
+10
This key jumps 10 steps through the presets stations list. For example. If preset 2 is selected, after
pressing +10 button preset No 12 will be selected. if +10 button will by pressed one more time
preset No 22 will be selected.
D Functions
PLAY/PAUSE
By pressing this key when D is stopped, play starts after track search.
When this key is pressed during playing the D mode is changed in to pause.
When this key is pressed during D is paused, it switches back to play mode.
STOP
When D is playing or is in pause mode, by pressing this key it stops.
FUNC
This button is designed for audio source selection. ( D/USB/ ARD)
A - B
This function is for repeat the selected place in the sound track. When sound track is playing press
this button one time to set start point and press second time to set end point. For the stopping "A -
B" repeat, press "A – B" button one more time.
CUE
In stop mode this key changes starting track (file) in ascending order, and automatically goes to first
track if it is in the last track.
Single pressed in play mode or program mode changes to next track, in random mode skips to
random track.
By pressing longer than 0,7 sec. switches to fast forward mode.
RE
In stop mode this key changes starting track (file) in descending order, and automatically goes to
the last track if it is in first track.
Single pressed in play mode or program mode changes to previous track (file).
By pressing longer than 0,7 sec switches to fast reverse mode.

FOLDER >>
In stop mode this key skips the starting play folder to next folder, and automatically switches to first folder if
current folder is last.
In the program entry mode this key switches to next folder’s first file, if the folder is last it switches to first
folder.
In normal play mode this key skips the playing file and switches to next folder’s first file.
FOLDER <<
In stop mode this key skips the starting play folder to next previous, and automatically switches to last folder
if current folder is first.
In the program entry mode this key switches to previous folder’s first file, if the folder is first it switches to last
folder.
In normal play mode this key skips the playing file and switches to previous folder’s first file.
REPEAT
In USB/SD mode, when pushing the key PLAY mode switches like shown below:
While pushing the key in D mode, PLAY mode is changed in this order:
EJECT
By pushing this key D is ejected.
PROG
This key is used for programming.
All program is cleared when STOP key is pushed in the programming mode.
MUTE
When this key is pushed during D/USB/SD is playing, the sound output is muted. Pressed again the
sound is turned on again.

SPE IFI ATIONS
GENERAL
1. FM tuner
2. D/USB/SD player with compressed audio files support.
3. 60 preset for FM station memory.
4. D with mechanical and electronic anti-shock, D, D-R, D-R/W, USB, SD/MM available.
5. Input: FM 75 ohm antenna terminal
USB port, SD/MM port
6. Output: Stereo balanced XLR output for FM tuner
Stereo balanced XLR output for
D/USB/SD player.
7. Power supply : 230V A 50Hz
8. Power consumption: 50 VA
9. Weight: 3,5kg
10. Dimension: 482mm*44mm*250mm
TUNER SECTION
1. Tuning Frequency range 87,5 – 108 MHz
2. IF frequency 10,7 MHz
3. 30dB quieting sensitivity 10 μV
4. S/N ratio 60 dB
6. IF rejection 75 dB
7. Image rejection 25 dB
8. THD 0.8 %
9. Frequency response 100 Hz ~ 10 KHZ
CD SECTION
1. Output level: 1.2V ± 2dB
2. Output level difference between channels 2dB
3. Frequency response 20 Hz 20 KHz
4. hannel separation @ 1 KHz More than 60 dB
5. THD Less than 0.1 %
6. S/N ration More than 70 dB
AMC is a registered trademark of AMC Baltic www.amcpro.lt
