AMC XO User guide

IA
POWER
H.O.M.E. AUTOMATION SERIES
XODigital Home system
1
5
2
6
3
7
4
8
AMC XO
8 ZONE 8 SOURCE DIGITAL H.O.M.E. SYSTEM
with Remote Local Sources
&
Instant Installing All Zone Connectors

APPLICATION AND FEATURE LIST
2
Features of the AMC model XO
TM
* System for total 8 Zones
* System with 8 Sources 4 Global Sources & 4 Remote Local Sources
* Only RJ45 & Speaker Wires used for installations between zones
* Two ways Digital Data Communication System between XO main unit and keypads
in all zones
* Designed with cascade feature for keypad XK1
* Two All Zone Connectors for making installing XO like 123 in seconds
* Volume Control & Tone Control for each Zone
* four 38KHz and four 56KHz IR outputs
* Doorbell and telephone mute system (PDM1)
* With RS232 to digital link with other systems including lighting controls like Lutron
system with RS232 interface
* IR remote control receiver on each zone for controlling XO main unit and Local
Sources in other zones
* RCA, 3.5mm mini jack and RJ45 Remote Local Source input jacks in each Zone
* Low profile 1U
* Power of each channel / zone : 15W x 2 Digital Amplifiers for each Zone
* The XO package contents:
1 XO Eight-Source (4 local & 4 Remote), Eight-Zone Digital Home System
main unit
1 ZT8 8 Zone Terminal
2 SCSI 50 wires cable
4 IRE1 IR emitters with feedback LED
1 Remote Control Handset
* Options : XK1, XS1, XU1, PDM1 (numbers of XK1, XS1, XU1, PDM1 required based
on each installation designs)

Digital Home System AC115V/
60Hz
120W
FUSE: T2AL 250V
L
R
L
R
1234
SOURCE
1133
2244
IR OUT IR OUT
-38KHz -56KHz
MUTE
LINK
STATUS +12VDC PRE-OUT VC/NVC
ZONE 5 ZONE 6 ZONE 7 ZONE 8
RS232
12
ALL ZONE CONNECTOR
VC VC VC VC
NVC NVC NVC NVC
Doorbells1&2
RearFront
Tel Lines1&2
POWER
H.O.M.E. AUTOMATION SERIES
XODigital Home system
1
5
2
6
3
7
4
8
1 2
1. Source Inputs 1~4
2. IR Out - 38KHz
3. IR Out - 56KHz
4. Mute
5. Link
6. Status
7. 12VDC
8. PRE-OUT VC/NVC (Zone 5~8)
9. All Zone Connector-1
10. All Zone Connector-2
11. AC input receptacle with Fuse
12. RS232
123456 7 8 91011
3
Zone 1
Zone 2
Zone 3
Zone 4
Zone 5
Zone 6
Zone 7
Zone 8
8 Zones
AMC PDM1
(Phone-Doorbell-Mute Module)
ZT8
REAR PANEL CONNECTIONS/FRONT PANEL CONTROLS
FRONT PANEL
1. Power Switch (Standby / Off) &
Blue LED
2. Zone LED & 8 square Recesses

REAR PANEL CONNECTIONS
4
1. Source Inputs 1~4
2. IR Out - 38KHz
3. IR Out - 56KHz
4. Mute
5. Link
6. Status
7. 12VDC
8. PRE-OUT VC/NVC (Zone 5~8)
9. All Zone Connector-1
10. All Zone Connector-2
11. AC input receptacle with Fuse
12. RS232
Each of these stereo RCA inputs
receives an audio signal from up to
four independent audio sources.
Remarks: There are other 4 local
sources from Zone 1~4 as Remote
Source Inputs R5 to R8 can be
selected by all zones.
for most Audio Sources
for cable and satellite boxes
This 3.5mm non-shorting Stereo
connector (Power, Mute, Gnd) is
designed to be used in conjunction
with the AMC PDM1 (Phone-
Doorbell-Mute Module)
This 3.5mm mono connection is
used to expand the AMC XO from
eight to sixteen zones.
This 3.5mm mono connection
provides a constant +12VDC output
when a zone is turned on. This can be
used to trigger external equipment.
for supplying 12VDC to external
modules. (total 1A max)
These 4 switched are for setting Zone
5~8 PRE-OUTS to be with VC (Volume
Control) or NVC (No Volume Control)
This is SCSI Connector for Speaker-
Zone 1~4 and PRE-OUTS-Zone 5~8
(Balanced)
This is SCSI Connector for IR in/out
Data, Status, R5 to R8 Remote
Sources Signals(From Z1~Z4), +12V
and Ground.
This is used for making interface with
other system and for factory purposes.

5
FRONT PANEL CONTROLS
1. Power Switch (Standby / Off) & Blue LED
2.ZoneLED&8squareRecesses
The Power Switch turns AMC XO "Standby" or "Off"
The Blue LED will be lit up during "Standby", will be turned off during "Off"
Each of these LEDs indicates, when lit, that its zone keypads are turned on.
The 8 square recesses are for putting labels of names of all zones

6
710
98
1
2
5
4
3
1. LED's of Volume Level of the zone
2. Volume up / down
3. IR Receiver
4. Power
5. Mute
6. Source Selection
7. JK1 (RJ45) (TO XS1) (Only for Zone
1~ Zone 4)
8. JK2 (RJ45) (TO ZT8)
9. JK3 (RJ45) (Another XK1)
10. JK4 (RJ45) (This is Pre-Out) (To
Main-in)
volume-only one LED will be light up.
Each keypad has an IR receiver for
controlling the audio source
equipment.
The power button turns that keypad's
zone on and off independently of the
other zones. Pressing and holding the
power button turns all the zones off
simultaneously.
The mute button temporarily silences
any audio playing in that keypad's
zone.
The 8 source buttons independently
select any of the four sources ( Source
1 to 4) connected to the rear panel of
AMC XO and another four Remote
Sources (Source R5 to R8) connected
to the remote sources on the four
keypads of four zones. (R5 located at
keypad of Zone 1, R6 located at
keypad of Zone 2, R7 located at
keypad of Zone 3 and R8 located at
keypad of Zone 4) The selected source
button will remain lit.
Use CAT5 cable to connect from the
JK1 of XK1 to the RJ45 connector of
XS1.
Use CAT5 cable to connect from the
JK2 of XK1 to ZT8 or JK3 of Another
XK1.
Use CAT5 cable to connect from the
JK3 of XK1 to JK2 of Another XK1.
Use CAT5 cable to connect from the
JK4 of XK1 to main-in of amplifiers or
power speakers.
6
KEYPAD

SCSI Connector 1
SCSI Connector 2
JK14 (RJ45)
Zone 4
Zone 4
SPK
Zone 3
SPK
Zone 2
SPK
Zone 1
SPK
JK1 (RJ45)
Zone 5
JK13 (RJ45)
Zone 3
JK2 (RJ45)
Zone 6
JK12 (RJ45)
Zone 2
JK3 (RJ45)
Zone 7
JK11 (RJ45)
Zone 1
JK4 (RJ45)
Zone 8
8 ZONE TERMINAL ZT8
7

RCA Jack Input
(L & R)
3.5mm Mini Jack
Input (L & R)
IR Output
(3.5mm Mini Jack)
RJ45
(L & R and IR Output)
RJ45 to JK1 of XK1
via CAT5 Cable
REMOTE SOURCE XS1
BALANCED TO UNBALANCED MODULE XU1
8

1. Power On & Off
2. Source Selection
3. Mute & Mute On & Mute Off
4. Volume
This button turns the zone on and off
and powers all the zones off when it is
pressed and held.
These 8 buttons correspond to the four
local source buttons ( source 1~4) and
four remote source buttons (source R5
~R6) on the zone keypad.
"Mute" button mutes the zone in the
same way as the keypad mute button.
"Mute On" and "Mute off" turn the mute
"On" or "Off"
Perform the same function as the
volume button on the zone keypads.
The volume level indicator on the
keypad will respond correspondingly to
the volume command from the remote
control.
5. The remote control is basically with the
same functions of keys as AMC S84
1
2
3
4
REMOTE CONTROL
9

1. Prewire
The XO uses Cat-5 cable for keypad control and either two- or four-conductor 16-
gauge speaker wire. All the wire is homerun from each zone to the location of
ZT8 that normally located behind XO and hooked to XO via short SCSI cable.
2. The XO digital home systems require Cat5, unshielded, twisted pair (UTP), for
communication between the keypads/display pads and the main XO unit. Each end
of the wire is terminated with an RJ45 connector.
The XO system can accommodate 2000 total feet of Cat5 cable. For the most
reliable operation,it is best that no single run of Cat5 exceeds 250 feet.
The correct wiring scheme for the Cat5 cable is standard EIA/TIA 568A. Properly
terminating the Cat5 cable is crucial for the operation of the system. It is very
important to use a good quality crimp tool, and testing each end to end run with
Cat5 wire tester will insure that your system operate flawlessly, Fig. 1.
10
INSTALLING THE XO DIGITAL HOME SYSTEM
Fig.1: EIA 568A wiring scheme for Cat 5 Cable
Pin #
1. Green Stripe
2. Green
3. Orange Stripe
4. Blue
5. Blue Stripe
6. Orange
7. Brown Stripe
8. Brown
Note: Colors listed as "stripe" are a white wire
with a colored stripe.

Step-by-Step Crimping instructions
Step1 Stripa2to3inch portion of the insulation, exposing the 4 twisted pairs.
Step2 Untwist the wires and fan them out individually. Arrange the wires into the
correct color scheme as shown in Fig.1
Step3 Flatten the wires in their correct order, and trim them evenly across the top.
Most crimp tools have a wire trimmer built-in. It is best to trim the wires to
about 1/2 in length.
Step4 While holding the wires flat between your thumb and forefinger, insert the wires
into the RJ45 connector, so each is its own slot. Push the wire into the RJ45,
so all 8 conductors touch the end of the connector. The insulation jacket
should extend beyond the crimp point of the RJ45.
Step5 Insert the RJ45 into the crimp tool receptacle and squeeze the tool firmly. Note
that a ratchet type tool should tighten down until it no longer clicks.
Step6 The RJ45 should be firmly crimped to the Cat5 insulation. It is necessary that
the color scheme be repeated identically on each end of the wire.
3. Speaker Wire Termination at ZT8 (8 Zone Terminal)
It is important to keep the proper orientation of positive and negative signal for each
speaker connection. Typically, two-conductor speaker wire uses red to denote
positive and black to denote negative. Some types of wire indicate positive with dark
line running through the insulation. Four-conductor wire can also be used. This has
four separated wires in one outer jacket, making it possible to run a single speaker
wire to a zone for its pair of speakers. This type of wire typically uses red and black
for one speaker and white as positive and green as negative for the second
speaker.
11

RS232
1ALL ZONE CONNECTOR
4. ZT8
Both the speaker wire and Cat5 cables for each zone terminate into the back side of
the ZT8. The order of Cat5 plug-ins is irrelevant to the operation of the system,but it
is recommended that you label the individual Cat5 cables for future references.
Follow the zone and polarity labeling for speaker wire termination, Fig. 2
The final connections from ZT8 is made with the SCSI cables supplied with XO Digital
Home System, fig. 3
Fig. 2
12
Fig. 3

L
R
L
R
1234
SOURCE
1
2
L
R
L
R
1234
SOURCE
1133
2244
IR OUT IR OUT
-38KHz -56KHz
MUTE
LINK
Source 1
Tuner 1
Audio
Out
Fig. 5
5. Installing the XO
The XO is designed to be placed on a shelf or in a component rack. If you are
mounting the XO with other components,you should remove the feet.
The audio sources are plugged into the four source inputs on the back panel of the
XO using stereo RCA cables, Fig.4
6. IR Outputs
The XO system ships with four IRE1 IR Emitters for transferring IR data from the
keypad receivers (located under the volume button) to the IR receiver on each piece
of source equipment. There are two separated IR output sections on the back panel.
The 38Khz outputs are used for most audio sources. The exception to this is cable
and satellite boxes, which operate at a higher IR carrier frequency closer to 56Khz.It
is important that the output being used for each source matches the source input
number. The outputs work individually with each source to allow independent source
control. Simply plug the IRE1 IR emitter into the appropriate IR output on the back
of the XO and attach the flasher end over the IR receiver of the source equipment,
fig. 5
13

Volume
Volume
Mute
Mute
Power
Power
Fig 8
14
7. Keypad XK and Zone Setup
EQ Control and Source Grouping
The Zone number each keypad XK belonging to is decided by which RJ45
connector each keypad connected through CAT5 cable from JK2 of XK to ZT8.
The keypads can be used to set specific zone functions. These are for bass and
treble EQ response and source grouping. To change bass response, press the Mute
button and Source 1 button simultaneously. Adjust the bass level up or down by
using the Volume Up and Volume Down buttons. The Volume indicator LEDs will
indicate the output level, fig. 7. Adjust treble response using the same process. This
is accessed by pressing the Mute and Source 2 buttons. Once the desired setting is
made, press the Source button again to return the keypad to normal operation.
Source grouping is a feature that allows multiple zones in an open living space to
always share the same source selection but still retain individual volume and on/off
control. This is achieved by pressing the Mute and Source 3. Volume Up enables
the group function, and Volume Down disable the group function and cause the
keypad to operate independently of all other groups, fig 8.
The XO system keypads automatically reset the listening volume to a low level
when all zones have been turned off and a zone is turned on again. If a zone is
turned off and turned back on before all the zones are turned off, it will return at
previous volume level.
All the zones in the system can be turned off simultaneously from any keypad by
pushing and holding the power button until the keypad goes completely dark. A
single push and release the power button will only turn that zone off. If another zone
is on, the power button will remain lit.
Volume Reset
All off
Flat +4dB-4dB-6dB-8dB +6dB +8dB
Group Disabled Group Enabled

1
2
3
AMC PDM1 (Phone-Doorbell-Mute Module)
Front Rear
8. Using the Link Jack to create Sixteen Zones
9. Mute Input and the AMC PDM1 (Phone-Doorbell-Mute Module)
Two XO can be made to react as one using the back-panel 3.5mm connection
labeled "Link". This requires the use of "Y" cables to link the source inputs and IR
outputs. A single mono mini-patch cable is then plugged into the "Link" jack on both
XO. This links the All Off command so when it is initiated at any of the zone
keypads, all sixteen zones will turn off.
The back panel of the XO has a 3.5mm non-shorting stereo connector input labeled
"Mute". This is designed to be used with the AMC PDM1 Phone-Doorbell-Mute
module. When the PDM1 is connected, the system will temporarily mute when the
phone or doorbell rings.
1,2 Doorbell
3. RJ-11 Connection
The back of PDM1 will accept up to two AC or DC voltages from two different
doorbell chimes.
This connection is done with two conductor wire from the terminals on the doorbell
chime to the Doorbell A or Doorbell B inputs on the back of the PDM1, Polarity is not
important for this connection.
Up to two phone lines can be brought into the RJ-11 connection on the back.
The voltage from the phone ringer will trigger the XO System to mute.
15

16
SPECIFICATIONS
Weltronics Corp. reserved the right to improve its products at any time. Specifications
are subject to change without notice.
Total Zones ............................................................... 8 Zones
Zone 1~4 with Speaker Outputs ..................................... 15Wrms x 2
Zone 5~8 with Stereo Audio Signal Outputs
Output Level ............................................... 1.1 Vrms
Volume Control ........... with Pre-out VC/NVC switch for each Zone
Controls for each Zone ........................ Volume and Tone Controls
Sources .......................... 4 Global Sources & 4 Remote Local Sources
Sensitivity ....................................................... 60mV
IR outputs frequencies .................... four 38KHz and four 56KHz
IR output level ....................................................... 5V p-p
Phone input sensitivity ................................. AC25V~AC100V 20Hz
Doorbell input sensitivity ....................................... AC/DC 3~12V
PHYSICAL
Dimensions (W x H x D).................W 430.0mm x H 53.3mm x D 338.5mm
Net weight................................................................6.0Kgs
Shipping weight (4 pieces).......................................... 38.0Kgs
Power consumption.................................................. 100W

All the safety and operating instructions should be read
before the appliance is operated.
The safety and operating instructions should be retained for
future reference.
All warnings on the appliance and in the operating instructions
should be adhered to.
All operating and use instructions should be followed.
The appliance should not be used near water - for example,
near a bathtub, washbowl, kitchen sink, laundry tub, in a wet
basement, or near a swimming pool, etc.
The appliance should be used only with a cart or stand that is
recommended by the manufacturer.
An appliance and cart combination should be
moved with care. Quick stops, excessive force,
and uneven surfaces may cause the appliance
and cart combination to overturn.
This equipment is not designed for use mounted on a wall or a
ceiling.
The appliance should be situated so that its location or position
does not interfere with its proper ventilation. For example, the
appliance should not be situated on a bed, sofa, rug, or similar
surface that may block the ventilation openings, or placed in a
built-in installation, such as bookcase or cabinet that may
impede the flow of air through the ventilation openings.
The appliance should be situated away from heat sources
such as radiators, heat registers, stoves, or other appliances
(including amplifiers) that produce heat.
The appliance should be connected to a power supply only of
the type described in the operating instructions or as marked
on the appliance.
Power-supply cords should be routed so that they are not likely
to be walked on or pinched by items placed upon or against
them, paying particular attention to cords at plugs,
convenience receptacles, and the point where they exit from
the appliance
The appliance should be cleaned only as recommended by
the manufacturer.
The power cord of the appliance should be unplugged from the
outlet when left unused for a long period of time.
Care should be taken so that objects do not fall and liquids are
not spilled into the enclosure through openings.
The user should not attempt to service the appliance beyond
that described in the operating instructions. All other servicing
should be referred to qualified service personnel.
The appliance should be serviced by qualified service
personnel when:
a) The power-supply cord or the plug has been damaged; or
b) Objects have fallen, or liquid has been spilled into the
appliance; or
c) The appliance has been exposed to rain; or
d) The appliance does not appear to operate normally or
exhibits a marked change in performance; or
e) The appliance has been dropped, or the enclosure is
damaged.
(APPLIES TO TUNERAND RECEIVERS ONLY)
An outdoor antenna should be located away from power lines.
(APPLIES TO TUNERAND RECEIVERS ONLY)
If an outside antenna is connected to the receiver, be sure the
antenna system is grounded so as to provide some protection
against voltage surges and built up static charges.
Section 810 of the National Electrical Code,ANSI/NFPA No.
70-1984, provides information with respect to proper
grounding of the mast and supporting structure, grounding of
the lead-in wire to an antenna discharge unit, size of grounding
conductors, location of antenna-discharge unit, connection to
grounding electrodes, and requirements for the grounding
electrode. See Figure.
a) Use No. 10 AWG (5.3 mm ) copper, No. 8 AWG (8.4 mm )
aluminum, No. 17 AWG (1.0 mm ) copper-clad steel or
bronze wire, or larger, as a ground wire.
b) Secure antenna lead-in and ground wires to house with
stand-off insulators spaced from 4-6 feet (1.22-1.83 m)
apart.
c) Mount antenna discharge unit as close as possible to where
lead-in enters house.
d) Use jumper wire not smaller than No.6 AWG (13.3 mm )
copper, or the equivalent, when a separate antenna-
grounding electrode is used. See NEC Section 810-21(j).
1. READ INSTRUCTIONS
2. RETAIN INSTRUCTIONS
3. HEED WARNINGS
4. FOLLOW INSTRUCTIONS
5. WATER AND MOISTURE
6. CARTS AND STANDS
6A.
7. WALL OR CEILING MOUNTING
8. VENTILATION
9. HEAT
10. POWER SOURCES
11. POWER-CORD PROTECTION
12. CLEANING
13. NON USE PERIODS
14. OBJECT AND LIQUID ENTRY
15. SERVICING
16. DAMAGE REQUIRING SERVICE
17. POWER LINES
18. OUTDOOR ANTENNA GROUNDING
22
2
2
SAFETY INSTRUCTION
S3125A
PORTABLE CART WARNING
Antenna Lead
In Wire
Ground
Clamp
Electric
Service
Equipment
Power Service Grounding
Electrode System
(NEC Art 250 Part H)
Ground Clamps
Antenna
Discharge
Unit (NEC
Section 810.20)
Grounding Conductors
(NEC Section 810.21)
Antenna Grounding According to
the National Electrical Code
National Electrical Code
Available from Library, book
stores, or National Fire Protection
Association (Batterymarch Park,
Quincy. MA 02269).
AMC 21-3004

WELTRONICS CORP.
LONDON/L.A.
AMC Web: http://www.amchome.com
PN: 21R-4209
