USER MANUAL
ATR-22

http://www.amcrest.com 2
http://www.amcrest.com
PREFACE
Thank you for purchasing the ATR-22 Amateur Portable Radio from Amcrest Radio US, the official Amcrest distributor in the
United States.
The ATR-22 is a two way radio that incorporates the latest in advanced technology and high quality production. This
intuitive radio will help you deliver instant and reliable communications with the utmost efficiency. Please read this manual
carefully before you use the device. The information presented herein will help you maximize the functionality and performance
of your radio.

http://www.amcrest.com 3
http://www.amcrest.com
Table of Contents
............................................................................................................................................................................................................ 1
Preface................................................................................................................................................................................................ 2
Safety Information .............................................................................................................................................................................. 5
Getting Started.................................................................................................................................................................................... 6
Initial Setup ..................................................................................................................................................................................... 6
What’s In the Box........................................................................................................................................................................ 6
Assembly..................................................................................................................................................................................... 7
Charging and Battery Maintenance .......................................................................................................................................... 10
Getting to Know the Radio............................................................................................................................................................ 13
Radio Overview......................................................................................................................................................................... 13
Accessory Jack........................................................................................................................................................................... 14
Basic Use ....................................................................................................................................................................................... 15
Power and Volume.................................................................................................................................................................... 15
Turning the Unit On/Off............................................................................................................................................................ 15
Adjusting the Volume ............................................................................................................................................................... 15
Selecting the Channel ............................................................................................................................................................... 15
Transmitting.............................................................................................................................................................................. 15
Advanced Functions and Features ................................................................................................................................................ 16
Squelch Level ............................................................................................................................................................................ 16
Time-Out Timer......................................................................................................................................................................... 16
Scanning.................................................................................................................................................................................... 16
Voice Prompt ............................................................................................................................................................................ 16

http://www.amcrest.com 4
http://www.amcrest.com
Voice Operated Transmission (VOX)......................................................................................................................................... 17
Emergency Alarms .................................................................................................................................................................... 17
Battery Saver............................................................................................................................................................................. 17
Battery Low Alert ...................................................................................................................................................................... 17
Monitor ..................................................................................................................................................................................... 18
Busy Channel Lockout (BCL)...................................................................................................................................................... 18
Technical Specifications .................................................................................................................................................................... 19
GENERAL ....................................................................................................................................................................................... 19
WARRANTY CERTIFICATE .................................................................................................................................................................. 20
Related Products............................................................................................................................................................................... 22
Foscam .......................................................................................................................................................................................... 22
Baofeng ......................................................................................................................................................................................... 22
Accumed ....................................................................................................................................................................................... 22

http://www.amcrest.com 5
http://www.amcrest.com
Safety Information
The following safety precautions should always be observed during operation, service, and repair of this device:
This device should be serviced by qualified technicians only.
Do not modify or alter the radio for any reason.
Use only AMCREST supplied or AMCREST approved batteries and chargers.
Do not use a radio that has a damaged antenna. Contact with a damaged antenna may result in a minor burn.
Turn off the radio prior to entering any area with explosive and/or flammable materials.
Do not charge the battery in a location containing explosive and/or flammable materials.
Avoid electromagnetic interference and/or compatibility conflicts by turning off the radio in any area where posted
notices instruct you to do so.
Turn off the radio prior to boarding an aircraft. Any use of a radio within an aircraft must be in accordance with airline
regulations or crew instructions.
Turn off the radio prior to entering a blast area.
For vehicles with air bags, do not place the radio on the air bag deployment area.
Do not expose the radio to direct sunlight for extended periods of time, nor place it close to any source of heat.
When transmitting, hold the radio vertically with the microphone 3 to 4 centimeters away from your lips. Keep the
antenna at least 2.5 centimeters away from your body when transmitting.

http://www.amcrest.com 6
http://www.amcrest.com
Getting Started
Initial Setup
What’s In the Box
This radio comes shipped with the following accessories in the box:
Optional Accessories
Car Charging Cable & Adapter Speaker Microphone Attachment
Antenna Lithium-Ion Battery Pack Charging Cable & Adapter
Wrist Strap Belt Clip

http://www.amcrest.com 7
http://www.amcrest.com
Assembly
Antenna
This device is fitted with a Male SMA connector. To mount the antenna (Female SMA Connector), align the
two connectors and turn the antenna clockwise until it stops.
When installing the antenna, install it by holding the base and turning.
If an external antenna is used, ensure that the ‘SWR’ is about 1.5:1 or less to avoid damage to the
device’s transistors.
Holding the antenna with your hand or wrapping the outside may cause subpar operation of the
device.
Never transmit from the device without an antenna.
Belt Clip
On the back of the device, above the battery, there are two parallel screws. Remove these and
align them so that they go through the holes on the belt clip as they are screwed back into the
device body to securely affix the belt clip.
Install the belt clip at the rear of the battery compartment cover as shown in the figure to the
right.
Do not use glue to affix the screws onto the battery clip. Application of glue may cause
damage to the casing of the battery.

http://www.amcrest.com 8
http://www.amcrest.com
Battery
Before attaching or removing the battery make sure the device is turned off by turning the power/volume knob all the way
counter-clockwise.
Installation
To attach the battery, ensure the battery is parallel and in good contact with the aluminum chassis. The battery bottom is about
1 to 2 centimeters below the bottom of the device’s body.
Align the battery with the guide rails on the radio chassis and slide it upwards until it clicks into place.
The battery latch at the bottom locks the battery in place.
Removal
Ensure the device is off before removing the battery.
To remove the battery, press the battery release above the battery pack and slide the battery downward.
After sliding the battery down a few centimeters, the battery can be removed from the device body.

http://www.amcrest.com 9
http://www.amcrest.com
External Headset
Plug the external micro-headset connector into the jack of ‘SP & MIC’ of the device as shown in the figure
on the right.

http://www.amcrest.com 10
http://www.amcrest.com
Charging and Battery Maintenance
Charging the Battery
Follow the steps below to set up and use the charger:
1. Plug the end of the power adapter into the charger base.
2. Plug the power adapter into an electrical wall socket.
3. Place the device or battery in the charging slot on the charger.
4. Make sure the contact plates of the battery are making contact with the charger. Ensure that the device fits snugly into
the dock. When the red LED stays on, the device is charging.
5. The device is fully charged once the LED on the charger stays green. Please remove the device after it is fully charged to
avoid over-charging the battery.
Charger LED Codes
Charging Status
LED Indication
Charging
Red LED glows solidly
Fully Charged
Green LED glows solidly
