American DJ Flash Matrix Hub User manual

American DJ®LOS ANGELES, CA. 90058 USA
Model: Flash Matrix Hub™
SPECIFICATIONS:
Power: 110V/60Hz
Weight: 8 lbs.
Size: 10.5” x 5”
Fuse: 15A
Thank you for purchasing this
American DJ® product. For your
convenience this products ready to be
used, there is no assembly required.
Please read the following instructions
before installing or using your new unit.
Operating Instructions:
The American DJ® Flash Matrix Hub™, flash tube
controller is ideal for Club or rink use. One Flash
Matrix Hub™ will control 8 expandable lines of Flash
Tubes. The Flash Tubes are controlled by setting the
dipswitches to activate patterns of flashing. Some of
the patterns include swirl, starburst, pinwheel, double
pinwheel, flip flop. Adjust the Speed of chase by turn-
ing the SPEED knob.
For service, contact your American DJ® dealer.
American DJ®User Instructions
FLASH MATRIX HUB™
SET UP:
Link the Flash Tubes to the Flash Matrix Hub™ by insert-
ing tube connectors into controller sockets on the top of
unit.
If you use extensions the maximum length to first Flash
Tube™ is 10 ft. if more you need to use a Flash Buffer™
to increase the signal.
If you connect more than 30 Flash Tubes in any single
line use a Flash Buffer™ to boost signal.
At the end of each line connect a Flash-Term™. If you
don’t use one not all of the patterns will work and there
will be no flashing during that program.
Plug Flash-Matrix™ and any Flash Buffer™ that are
used into power.
Refer to Operating instructions for use.
8 CHANNEL FLASH TUBE CONTROLLER
Caution! Always use appropriate cables and
connectors. Remember to always replace with
same fuses. Always keep controllers dry. Don’t
exceed load and length limitations
