American DJ WiFly Par QA5 WH User manual

User Instructions
Rev. 2/14
WiFly Par QA5 WH
©2013 ADJ Products, LLC all rights reserved. Information,
specications, diagrams, images, and instructions herein are
subject to change without notice. ADJ Products, LLC logo and
identifying product names and numbers herein are trademarks
of ADJ Products, LLC. Copyright protection claimed includes all
forms and matters of copyrightable materials and information
now allowed by statutory or judicial law or hereinafter granted.
Product names used in this document may be trademarks or
registered trademarks of their respective companies and are
hereby acknowledged. All non-ADJ Products, LLC brands and
product names are trademarks or registered trademarks of their
respective companies.
ADJ Products, LLC and all aliated companies hereby dis-
claim any and all liabilities for property, equipment, building, and
electrical damages, injuries to any persons, and direct or indi-
rect economic loss associated with the use or reliance of any
information contained within this document, and/or as a result
of the improper, unsafe, unsucient and negligent assembly,
installation, rigging, and operation of this product.
Europe Energy Saving Notice
Energy Saving Matters (EuP 2009/125/EC)
Saving electric energy is a key to help protecting the enviroment.
Please turn o all electrical products when they are not in use. To
avoid power consumption in idle mode, disconnect all electrical
equipment from power when not in use. Thank you!

ADJ Products, LLC - www.adj.com - WiFly Par QA5 WH User Manual Page 3
• Rechargeable Lithium Battery
• Mulit-Colors
• Five Operating Modes
• Electronic Dimming 0-100%
• Built in Microphone
• DMX-512 protocol
• 3-Pin DMX Connection
• 8 DMX Channel Modes: 1 Channel Mode, 2 Channel Mode, 3
Channel Mode, 4 Channel Mode, 5 Channel Mode, 6 Channel
Mode, 7 Channel Mode, & 8 Channel Mode
• Built-In ADJ’s WiFly TransCeiver Wireless DMX
• ADJ RFC compatiable (Not Included)
• Power Cord Daisy Chain (See page 14)
WiFly Par QA5 WH Warranty Registration
WiFly Par QA5 WH Features
The WiFly Par QA5 WH carries a 3 year limited warranty. Please fill
out the enclosed warranty card to validate your purchase. All returned
service items whether under warranty or not, must be freight pre-paid
and accompany a return authorization (R.A.) number. The R.A. number
must be clearly written on the outside of the return package. A brief
description of the problem as well as the R.A. number must also be
written down on a piece of paper included in the shipping carton. If
the unit is under warranty, you must provide a copy of your proof of
purchase invoice. You may obtain a R.A. number by contacting our
customer support team on our customer support number. All pack-
ages returned to the service department not displaying a R.A. number
on the outside of the package will be returned to the shipper.
The unit should be mounted using a mounting clamp (not provided),
axing it to the mounting bracket that is provided with the unit.
Always ensure that the unit is rmly xed to avoid vibration and slip-
ping while operating. Always ensure that the structure to which you
are attaching the unit is secure and is able to support a weight of 10
times the unit’s weight. Also, always use a safety cable that can hold
12 times the weight of the unit when installing the xture.
The equipment must be installed by a professional, and it must be
installed in a place where it is out of the reach of people’s grasp.
WiFly Par QA5 WH Installation
WiFly Par QA5 WH Introduction
ADJ Products, LLC - www.adj.com - WiFly Par QA5 WH User Manual Page 2
Unpacking: Thank you for purchasing the WiFly Par QA5 WH by ADJ
Products, LLC. Every WiFly Par QA5 WH has been thoroughly tested
and has been shipped in perfect operating condition. Carefully check
the shipping carton for damage that may have occurred during ship-
ping. If the carton appears to be damaged, carefully inspect your x-
ture for any damage and be sure all accessories necessary to operate
the unit has arrived intact. In the case damage has been found or parts
are missing, please contact our toll free customer support number for
further instructions. Do not return this unit to your dealer without rst
contacting customer support.
Introduction: The WiFly Par QA5 WH is a rechargeable lithium battery
powered, DMX intelligent, LED par fixture with ADJ’s WiFly TransCeiver
with wireless DMX built-in. This unit give you the freedom to set up
your fixture where ever you wish without the restrictions of power or
DMX cabling. The built-in battery will keep charge for up to 6 hours (full
on) from a full, single charge. This xture can be used in a stand alone
mode or connected in a Master/Slave conguration. This wash has five
operating modes: Sound Active mode, Auto mode, RGB mode, Static
Color mode, and DMX control mode.
Customer Support: ADJ Products, LLC provides a customer support
line, to provide set up help and to answer any question should you
encounter problems during your set up or initial operation. You may
also visit us on the web at www.adj.com for any comments or sugges-
tions. Service Hours are Monday through Friday 8:00 a.m. to 4:30 p.m.
Pacic Standard Time.
Voice: [phone]
Fax: [phone]
E-mail: [e-mail]
Warning! To prevent or reduce the risk of electrical shock or re, do
not expose this unit to rain or moisture.
Caution! There are no user serviceable parts inside this unit. Do not
attempt any repairs yourself, doing so will void your manufactures war-
ranty. In the unlikely event your unit may require service please contact
ADJ Products, LLC.
PLEASE recycle the shipping carton when ever possible.

ADJ Products, LLC - www.adj.com - WiFly Par QA5 WH User Manual Page 5
1. Handling of Batteries
1.1 Do Not Short Circuit the Battery
Try to never short circuit the battery. It generates a very high
current which could cause the battery to overheat which may
result in electrolyte gel leakage, harmful fumes, or explosion.
The LIR tabs may easily short-circuit by placing them on con-
ductive surface. A short circuit may lead to heat build up and
damage of the battery. An appropriate circuitry with PCM is
employed to protect accidental short circuit of the battery pack.
1.2 Mechanical shock
Droping the unit, impact hit, bending, etc. may cause failure or
shortend life of the LIR battery.
3. Other
3.1 Battery connection
1). Direct soldering of wire leads or devices to the battery is
strictly prohibited.
2). Lead tabs with pre-soldered wiring shall be spot welded to
the batteries. Direct soldering may cause damage of compo-
nents, such as separator and insulator, by heat build up.
3.2 Prevention of short circuit within a battery pack
There is enough insulation layers between wiring and the bat-
teries to provide extra safety protection. The battery pack is
constructed in a way that no short circuit will occur which may
cause smoke or re.
3.3 Do No Disassemble the Batteries
1). Never disassemble the batteries.
Doing this may cause a internal short circuit in the battery,
which may lead to harmful fumes, re, explosion, or other prob-
lems.
2). Electrolyte Gel is harmful
Electrolyte Gel should not leak from the LIR battery. Should the
electrolyte gel come into contact with the skin or eyes, ush the
WiFly Par QA5 WH Battery Precautions
WiFly Par QA5 WH Safety Precautions
ADJ Products, LLC - www.adj.com - WiFly Par QA5 WH User Manual Page 4
• To reduce the risk of electrical shock or re, do not expose this unit
rain or moisture
• Do not spill water or other liquids into or on to your unit.
• Do not attempt to operate this unit if the power cord has been
frayed or broken. Do not attempt to remove or break o the ground
prong from the electrical cord. This prong is used to reduce the risk
of electrical shock and re in case of an internal short.
• Disconnect from main power before making any type of connection.
• Do not remove the cover under any conditions. There are no user
serviceable parts inside.
• Never operate this unit when it’s cover is removed.
• Never plug this unit in to a dimmer pack
• Always be sure to mount this unit in an area that will allow proper
ventilation. Allow about 6” (15cm) between this device and a wall.
• Do not attempt to operate this unit, if it becomes damaged.
• This unit is intended for indoor use only, use of this product out`
doors voids all warranties.
• During long periods of non-use, disconnect the unit’s main power.
• Always mount this unit in safe and stable matter.
• Power-supply cords should be routed so that they are not likely to
be walked on or pinched by items placed upon or against them,
paying particular attention to the point they exit from the unit.
• Cleaning -The fixture should be cleaned only as recommended by
t he manufacturer. See page 25 for cleaning details.
• Heat -The appliance should be situated away from heat sources
such as radiators, heat registers, stoves, or other appliances (inclu-
d ing amplifiers) that produce heat.
• The fixture should be serviced by qualified service personnel when:
A. The power-supply cord or the plug has been damaged.
B. Objects have fallen, or liquid has been spilled into the appliance.
C. The appliance has been exposed to rain or water.
D. The appliance does not appear to operate normally or exhibits a
marked change in performance.
CAUTION: This unit like any wireless device is highly susceptible
to static electricity. Static electricity can severly damage the unit.
Before touching the antenna, please ground/discharge yourself.

ADJ Products, LLC - www.adj.com - WiFly Par QA5 WH User Manual Page 7
life expectancy of the battery maybe shortened or the device
in which the battery is used may be damaged by electrolyte
gel leakage. If the batteries cannot maintain a charge for long
periods of time, even when they are charged correctly, this may
indicate it is time to change the battery.
6. Battery Disposal
Please dispose of battery according to local regulations.
WiFly Par QA5 WH Battery Precautions
ADJ Products, LLC - www.adj.com - WiFly Par QA5 WH User Manual Page 6
area of contact immediately with fresh water and seek medical
attention immediately.
3.4 Do Not Expose the Battery to Heat or Fire
Never incinerate or dispose of the batteries in re. This may
cause an explosion, which would be very dangerous.
3.5 Do Not Expose the Battery to water or liquids
Never soak/drop the batteries in liquids such as water, seawa-
ter, drinks such as soft drinks, juices, coee or other.
3.6 Battery Replacement
For battery replacement please contact ADJ customer support
[phone].
3.7 Do Not use a damaged Battery
The battery could be damaged during shipping, caused by
shock. Should the battery be found damaged, including dam-
ages to the plastic casing of the battery, deformation of the
battery package, smelling of an electrolyte, or leakage of the
electrolyte gel, or other, DO NOT use the battery. A battery with
a odor of electrolyte or a gel leakage should be placed away
from re to avoid re or explosion.
4. Battery Storage
When storing the battery, it should be stored at room tempera-
ture, with a charge of at least 50%. We recommend that during
long periods of storage that the battery be charged every 6
months. Doing this will prolong the life of the battery and will
also make sure that the battery charge does not fall below the
30% mark.
5. Other Chemical Reaction
Because batteries utilize a chemical reaction, battery per-
formance will deteriorate over time even if stored for a long
period of time without being used. In addition, if the various
usage conditions such as charge, discharge, ambient tempera-
ture, etc. are not maintained within the specied ranges, the
WiFly Par QA5 WH Battery Precautions

ADJ Products, LLC - www.adj.com - WiFly Par QA5 WH User Manual Page 9
Notice: Be sure to follow gures two and three when making your own
cables. Do not use the ground lug on the XLR connector. Do not con-
nect the cable’s shield conductor to the ground lug or allow the shield
conductor to come in contact with the XLR’s outer casing. Grounding
the shield could cause a short circuit and erratic behavior.
WiFly Par QA5 WH Set Up
DMX512 IN
3-PIN XLR
SOUND
REMOTE
CONTROL
INPUT
POWER
INPUT OUTPUT
SOUND
REMOTE
CONTROL
INPUT
POWER
INPUT OUTPUT
SOUND
REMOTE
CONTROL
INPUT
POWER
INPUT OUTPUT
DMX512
DMX+,DMX-,COMMON
1
2
3
Termination reduces signal errors and
avoids signal transmission problems
and interference. It is always advisable
to connect a DMX terminal, (Resistance
120 Ohm 1/4 W) between PIN 2 (DMX-)
and PIN 3 (DMX +) of the last fixture.
1
2
3
1
2
3
DMX +
DMX -
COMMON
DMX512 OUT
3-PIN XLR
Figure 2
Figure 3
1 Ground 1 Ground
XLR Male Socket
XLR Pin Conguration
3 Hot
2 Cold 2 Cold
3 Hot
XLR Female Socket
Pin 3 = Data True (positive)
Pin 2 = Data Compliment (negative)
Pin 1 = Ground
Special Note: Line Termination. When longer runs of cable are
used, you may need to use a terminator on the last unit to avoid erratic
behavior. A terminator is a 110-120 ohm 1/4 watt resistor which is con-
nected between pins 2 and 3 of a male XLR connector (DATA + and
DATA -). This unit is inserted in the female XLR connector of the last
unit in your daisy chain to terminate the line. Using a cable terminator
(ADJ part number Z-DMX/T) will decrease the possibilities of erratic
behavior.
DMX512 IN
3-PIN XLR
SOUND
REMOTE
CONTROL
INPUT
POWER
INPUT OUTPUT
SOUND
REMOTE
CONTROL
INPUT
POWER
INPUT OUTPUT
SOUND
REMOTE
CONTROL
INPUT
POWER
INPUT OUTPUT
DMX512
DMX+,DMX-,COMMON
1
2
3
Termination reduces signal errors and
avoids signal transmission problems
and interference. It is always advisable
to connect a DMX terminal, (Resistance
120 Ohm 1/4 W) between PIN 2 (DMX-)
and PIN 3 (DMX +) of the last fixture.
1
2
3
1
2
3
DMX +
DMX -
COMMON
DMX512 OUT
3-PIN XLR
Figure 4
5-Pin XLR DMX Connectors. Some manufactures use 5-pin DMX-
512 data cables for DATA transmission in place of 3-pin. 5-pin DMX
xtures may be implemented in a 3-pin DMX line. When inserting stan-
dard 5-pin data cables in to a 3-pin line a cable adaptor must be used,
these adaptors are readily available at most electric stores. The chart
below details a proper cable conversion.
Conductor 5-Pin XLR Male (In)3-Pin XLR Female (Out)
Pin 1
Do Not Use
Do Not Use
Pin 3
Pin 2
Pin 1
Pin 3
Pin 2
Not Used
Not Used
Data True (+ signal)
Data Compliment (- signal)
Ground/Shield
3-Pin XLR to 5-Pin XLR Conversion
ADJ Products, LLC - www.adj.com - WiFly Par QA5 WH User Manual Page 8
Power Supply: The ADJ WiFly Par QA5 WH contains a automatic
voltage switch, which will auto sense the voltage when it is plugged
into the power source. With this switch there is no need to worry about
the correct power voltage, this unit can be plugged in anywhere.
DMX-512: DMX is short for Digital Multiplex. This is a universal pro-
tocol used as a form of communication between intelligent fixtures
and controllers. A DMX controller sends DMX data instructions from
the controller to the fixture. DMX data is sent as serial data that trav-
els from fixture to fixture via the DATA “IN” and DATA “OUT” XLR ter-
minals located on all DMX fixtures (most controllers only have a DATA
“OUT” terminal).
DMX Linking: DMX is a language allowing all makes and models of
dierent manufactures to be linked together and operate from a single
controller, as long as all xtures and the controller are DMX compli-
ant. To ensure proper DMX data transmission, when using several
DMX fixtures try to use the shortest cable path possible. The order
in which fixtures are connected in a DMX line does not influence the
DMX addressing. For example; a fixture assigned a DMX address of 1
may be placed anywhere in a DMX line, at the beginning, at the end,
or anywhere in the middle. When a fixture is assigned a DMX address
of 1, the DMX controller knows to send DATA assigned to address 1
to that unit, no matter where it is located in the DMX chain.
Data Cable (DMX Cable) Requirements (For DMX Operation):
The WiFly Par QA5 WH can be controlled via DMX-512 protocol. The
WiFly Par QA5 WH has 8 DMX channel modes, please see page 12-13
for the dierent modes. The DMX address is set on the back panel of the
WiFly Par QA5 WH. Your unit and your DMX controller require a stan-
dard 3-pin XLR connector for data input and data
output (Figure 1). We recommend Accu-Cable
DMX cables. If you are making your own cables,
be sure to use standard 110-120 Ohm shielded
cable (This cable may be purchased at almost all
pro lighting stores). Your cables should be made
with a male and female XLR connector on either
end of the cable. Also remember that DMX cable
must be daisy chained and cannot be split.
WiFly Par QA5 WH Set Up
Figure 1

ADJ Products, LLC - www.adj.com - WiFly Par QA5 WH User Manual Page 11
WiFly Par QA5 WH Operating Instructions
as the ADJ Show Designer™.
RGBA Dimmer Mode:
1. Plug the fixture in and press the MODE button until:
2. When “r.XXX” is displayed you are in Red dimming mode. Press
the UP and DOWN buttons to adjust intensity.
3. When “G.XXX” is displayed you are in Green dimming mode.
Press the UP and DOWN buttons to adjust intensity.
4. When “b.XXX” is displayed you are in Blue dimming mode. Press
the UP and DOWN buttons to adjust intensity.
5. When “U.XXX” is displayed you are in Amber dimming mode.
Press the UP and DOWN buttons to adjust intensity.
6. After you have adjusted the RGBA colors to make your desired
color you can then activate strobing by pressing the SET UP but-
ton to enter the Flash (strobe) mode.
7. “FS.XX” will be displayed, this is Flash mode. The Flash can be
adjusted between “FS.00” (flash off) to “FS.15” (fastest flash).
Sound Active Mode:
In this mode the WiFly Par QA5 WH will react to sound, and chase
through the different colors.
1. Plug the fixture in and press the MODE button until “SoXX” is
displayed. “XX” represents the sound active mode (01-16) cur-
rently displayed.
2. The fixture will now change via sound.
3. Press the SET UP button to adjust the sound sensitivity. “SJ-X”
should be displayed. Use the UP or DOWN buttons to adjust the
sensitivity. “SJ-1” is the least sensitive, “SJ-8” is the most.
Auto Run Mode:
In this mode the WiFly Par QA5 WH will run a auto program. There
are 3 types of Auto Run Modes to choose from; Color Fade, Color
Change, and both modes running together. The running speed is
adjustable in all 3 modes.
1. Plug the fixture in and press the MODE button until either “AFXX”,
“AJXX”, or “A-JF” is displayed.
• AFXX = Color Fade mode, there are 16 Color Fade modes to
choose from. Use the UP or DOWN buttons to scroll through the
different Auto Fade modes.
WiFly Par QA5 WH Operating Instructions
Operating Power:
There are two ways to supply power to this unit; battery power or AC
power.
• AC Power - To run the unit using AC power, plug the unit into a
power source, and put the Load Switch into the ON position. When
using AC power make sure the Battery Switch is in the OFF position.
• Battery Power - To run the unit using Battery power, put the Load
and Battery Switches in the ON position.
LED Display On/Off:
To set the LED display to turn off after 60 seconds, press the MODE but-
ton until “don” is displayed, press the UP button to display “doff”. Now
the display will disappear after 60s. Press any button to turn the display
on again. Be advised though that the display will turn off automatically
after 10 seconds.
To set the display press the MODE button until “dXX” is displayed. Use
the UP or DOWN buttons to select either:
“don” = LED display on at all times.
“doFF” = LED display shuts off after 60 seconds.
LED Display Inversion:
Follow these instructions to flip the display 180°so that the display can
be read upside down.
1. Plug the fixture in and press the MODE button until “dXX” is dis-
played. “XX” represents either “on” or “oFF”.
2. Press the SET UP button until “Stnd” or “rev” is displayed.
3. Press the UP or DOWN buttons to reverse the display 180°.
Operating Modes:
The WiFly Par QA5 WH has five operating modes:
• Static Color Mode - There are 15 colors to choose from.
• RGBA Mode - Choose one of the four colors to remain static or
adjust the intensity of each color to make your desired color.
• Auto Mode - There are 3 Auto Modes to choose from.
• Sound-Active mode - The unit will react to sound, chasing through
the built in programs.
• DMX control mode - This function will allow you to control each
individual fixtures traits with a standard DMX 512 controller such as
ADJ Products, LLC - www.adj.com - WiFly Par QA5 WH User Manual Page 10

ADJ Products, LLC - www.adj.com - WiFly Par QA5 WH User Manual Page 13
WiFly Par QA5 WH Operating Instructions
sent the current DMX Channel Mode.
4. Use the UP or DOWN buttons to scroll through the DMX Channel
modes. The Channel modes are listed below:
To run the 1 Channel Mode, press the MODE button until “Ch01”
is displayed. This is the 4 Channel DMX Mode.
To run the 2 Channel Mode, press the MODE button until “Ch02”
is displayed. This is the 2 Channel DMX Mode.
To run the 3 Channel Mode, press the MODE button until “Ch03”
is displayed. This is the 3 Channel DMX Mode.
To run the 4 Channel Mode, press the MODE button until “Ch04”
is displayed. This is the 4 Channel DMX Mode.
To run the 5 Channel Mode, press the MODE button until “Ch05”
is displayed. This is the 5 Channel DMX Mode.
To run the 6 Channel Mode, press the MODE button until “Ch06”
is displayed. This is the 6 Channel DMX Mode.
To run the 7 Channel Mode, press the MODE button until “Ch07”
is displayed. This is the 7 Channel DMX Mode.
To run the 8 Channel Mode, press the MODE button until “Ch08”
is displayed. This is the 8 Channel DMX Mode.
5. Please see pages 18-23 for DMX values and traits.
6. After you have chosen your desired DMX Channel mode plug in
the fixture via the XLR connections to any standard DMX control-
ler.
Battery Life:
This menu is used to check/display the battery life.
1. Plug the fixture in and press the MODE button until “bXXX” is dis-
played. “XXX” represents a number between 0-100. The number
that is displayed is the remaining battery life. If “b---” is displayed,
it means either the battery is dead or your running the unit on AC
power.
Default Running Mode:
This is a default running mode. When this mode is activated all modes
will return to their default settings.
1. Plug the fixture in and press the MODE button until “dXX” is dis-
played. “XX” represents either “on” or “oFF”.
2. Press the SET UP button until “dEFA” is displayed.
3. Press the UP and DOWN buttons simultaneously. Press the
ADJ Products, LLC - www.adj.com - WiFly Par QA5 WH User Manual Page 12
WiFly Par QA5 WH Operating Instructions
• AJXX = Color Change mode, there are 16 Color Change modes to
choose from. Use the UP or DOWN buttons to scroll through the
different Auto Change modes.
• A-JF = Both Color Fade and Color Change modes running.
2. After you have chosen your desired running mode press the SET
UP button until “SP.XX” is displayed. When this is displayed you
can adjust the running speed of your desired program. Use the
UP or DOWN button to adjust the speed between “SP.01” (slow-
est) and “SP.16” (fastest). Once you have set your desired running
speed, press the SET UP button to return to your desired Auto
Run Mode.
Static Color Mode:
1. Plug the fixture in and press the MODE button until “CLXX” is
displayed. “XX” represents the current color number displayed.
2. There are 15 colors to choose from. Select your desired color by
pressing the UP and DOWN buttons. After you have selected
your desired color you can activate strobing by pressing the SET
UP button to enter the Flash (strobe) mode.
3. “FS.XX” will be displayed, this is Flash mode. The Flash can be
adjusted between “FS.00” (flash off) to “FS.15” (fastest flash).
DMX Mode:
Operating through a DMX controller gives the user the freedom to
create their own programs tailored to their own individual needs. This
function also allows you to use your fixtures as spot lights. The WiFly
Par QA5 WH has 8 DMX modes: 1 Channel mode, 2 Channel mode, 3
Channel mode, 4 Channel mode, 5 Channel mode, 6 Channel mode,
7 Channel mode, and a 8 Channel mode. See pages 18-23 for each
modes’ DMX traits.
1. This function will allow you to control each individual fixture’s
traits with a standard DMX 512 controller.
2. To run your fixture in DMX mode press the MODE button until
“d.XXX” is displayed. “XXX” represents the current displayed ad-
dress. Use the UP or DOWN buttons to select your desired DMX
address. then press the SET UP button to select your DMX
Channel mode.
3. When you press SET UP “ChXX” should be displayed. “XX” repre-

ADJ Products, LLC - www.adj.com - WiFly Par QA5 WH User Manual Page 15
WiFly Par QA5 WH Master-Slave Configuration
Master-Slave Configuration:
This function will allows you to link units together to run in a Master-Slave
mode. In Master-Slave operation one unit will act as the controlling unit
and the others will react to the controlling units built-in programs. Any
unit can act as a Master or as a Slave however, only one unit can be pro-
grammed to act as the “Master.”
Master-Slave Connections and Settings:
1. Daisy chain your units via the XLR connector on the rear of the unit.
Use standard XLR data cables to link your units together. Remember
that the Male XLR connector is the input and the Female XLR con-
nector is the ouput. The first unit in the chain (master) will use the
female XLR connector only. The last unit in the chain will use the
male XLR connector only.
2. Set the “Master” unit to your desired mode of operation.
3. On the “Slave” units press the MODE button until “SLAu” is dis-
played. The unit is now set as the “Slave” unit. Each slave unit
must be set to the same setting.
4. Connect the rst “Slave” unit to the “Master”, and the “Slave” unit
should now start follow the “Master”.
ADJ Products, LLC - www.adj.com - WiFly Par QA5 WH User Manual Page 14
MODE button to exit.
ADJ RFC:
This function is used to activate and deactivate the ADJ RFC (Remote
Control). When this function is activated you can control the fixture
using the ADJ RFC. Please see the next page for ADJ RFC controls
and functions.
1. Plug the fixture in and press the MODE button until “dXX” is dis-
played.
2. Press the SET UP button until “rFXX” is displayed. “XX” repre-
sents either “on” or “oF”.
3. Press the UP or DOWN buttons to either activate the remote func-
tion (On) or deactivate it (Off).
WiFLY Address:
This function is used to set the WiFly address. This address must
match the address that is set to WiFly TransCeiver or WiFly controller.
1. Plug the fixture in and press the MODE button until “rCXX” is dis-
played. “XX” represents a number between 00-15.
2. Press the UP or DOWN buttons to either activate the remote func-
tion (On) or deactivate it (Off).
Dimmer Curve Setting:
1. Plug the fixture in and press the MODE button until “d.XXX” is dis-
played. Now press the SET UP button until “dr-X” is displayed,
“X” representing a number between 0-4.
2. There are 5 dimmer curve settings to choose from. Please see the
Dimmer Curve Diagram Chart on page 23 to see the settings and
their respective beginning and ending fade times.
WiFly Par QA5 WH Operating Instructions
With this feature you can connect the xtures to one another
using the IEC input and output sockets. The quantity that can be
connected is 10 xtures maximum. After 10 xtures you will need
to use a new power outlet. They must be the same xtures. DO
NOT mix xtures.
NOTE: Fixtures cannot be power cord daisy chained and run by
battery power.
WiFly Par QA5 WH Power Cord Daisy Chain

ADJ Products, LLC - www.adj.com - WiFly Par QA5 WH User Manual Page 17ADJ Products, LLC - www.adj.com - WiFly Par QA5 WH User Manual Page 16
WiFly Par QA5 WH ADJ RFC Operation
The ADJ RFC remote (sold seperately) has many different functions
and allows you to control your WiFly Par QA5 WH from long distance.
The ADJ RFC remote can control your system up to 150 ft. To use the
RFC you must first activate the fixtures receiver, to activate the receiver
please see the instructions on page 14.
BLACKOUT - Pressing this button will blackout the fixture.
AUTO RUN -This button will run an automatic program. There are 3
Auto Run programs to choose from. Each press of the button will switch
between the different modes. You can control the speed of the Auto Run
modes by pressing the SPEED button and then pressing the “+” and “-”
buttons.
• AFXX = Color Fade mode, there are 16 Color Fade modes to choose
from. Use the UP or DOWN buttons to scroll through the different
Auto Fade modes.
• AJXX = Color Change mode, there are 16 Color Change modes to
choose from. Use the UP or DOWN buttons to scroll through the
different Auto Change modes.
• A-JF = Both Color Fade and Color Change modes running.
PROGRAM SELECTION - This button will activate Static Color mode.
Use the “+” or “-” to scroll through the 15 colors. Once you have found
your color, you can press the FLASH button to activate strobing and use
the “+” or “-” to adjust the Flash rate.
FLASH - This button will activate the flash (strobe) effect. You can con-
trol the flash speed by pressing the “+” and “-” buttons.
SPEED - Press this button and use the “+” & “-” buttons to adjust the
speed of the Auto run mode.
SOUND ACTIVE - This button activates sound active mode. Use the
“+” or “-” to choose from 1 of 16 sound active modes. Press this button
again to enter sound sensitivity adjustment. Use the “+” or “-” buttons to
adjust the sound sensitivity.
R G B W/A - Press either one of these buttons and the press the “+” or
“-” to adjust the brightness. Press the FLASH button to activate strobing
and use the “+” or “-” to adjust the Flash rate.
“+” and “-” - Use these buttons to adjust the flash rate, speed of the
Auto Run mode, Auto Run program selection, sound sensitivity, and
color select.
WiFly Par QA5 WH WiFly Set Up
WiFly Par QA5 WH WiFly Master-Slave Set Up
With this feature you are able to control the unit with DMX without the need
of XLR cables. Your DMX controller must be connected to a ADJ WiFly
TransCeiver to use this function. You are able to communicate up to 400 feet
(open line of sight)
NOTE: The ADJ RFC control must be set to OFF to use this function.
See page 14 to turn OFF ADJ RFC.
1. Turn on the WiFly function using the WiFly On/Off switch and set the
antenna to either a up position or down position.
2. Follow the instructions on page 14 to set the Wireless address. The
address must match the address set on the WiFly Transceiver.
3. After you have set the WiFly address, follow the DMX instructions on
pages 12-13 to select your desired DMX Channel mode and set your
DMX address.
4. Apply power to the ADJ WiFly Transceiver. The fixture must be set up
first before you apply power to WiFly Transceiver.
5. If everything is set up properly and the fixture is receiving a Wireless
signal, Wireless status LED next to LED screen will glow green.
Note: If the sync does not work, switch the WiFly power off then on again.
This feature will let you link units to run in a master-slave mode without the
use of XLR cables.
NOTE: The ADJ RFC control must be set to OFF on all the units to use
this function. See page 14 to turn OFF ADJ RFC.
1. Follow the instructions on page 14 to set the Wireless address. The
addresses on each fixture must be the same.
2. After you have set the WiFly address, select your master unit and set
your desired operating mode.
3. Put the antenna in either a up position or down position then turn the
WiFly On, using the WiFly power switch.
Note: All antennas must be in the same position, they must either be all up
or all down, but never at an angle.
4. For the Slave units, put the unit in Slave mode. See page 15 Master-
Slave configuration when setting the unit as a Slave. Then switch ON the
WiFly power switch.
5. If everything is set up correctly, the Master units WiFly status LED will
glow orange, and the slave units Wireless status LED will glow green.
NOTE: If they do not sync up master-slave, switch the Master fixtures
WiFly power switch off then on again.

ADJ Products, LLC - www.adj.com - WiFly Par QA5 WH User Manual Page 19
Channel Value Function
1 RED
0 - 255 0% - 100%
2 GREEN
0 - 255 0% - 100%
3 BLUE
0 - 255 0% - 100%
4 AMBER
0 - 255 0% - 100%
5 MASTER DIMMER
0 - 255 0% - 100%
WiFly Par QA5 WH 5 Channel - DMX Values & Functions
WiFly Par QA5 WH 4 Channel - DMX Values & Functions
Channel Value Function
1 RED
0 - 255 0% - 100%
2 GREEN
0 - 255 0% - 100%
3 BLUE
0 - 255 0% - 100%
4 AMBER
0 - 255 0% - 100%
ADJ Products, LLC - www.adj.com - WiFly Par QA5 WH User Manual Page 18
WiFly Par QA5 WH 1 Channel - DMX Values & Functions
Channel Value Function
1 COLOR MACROS
0 - 15 OFF
16 - 31 RED
32 - 47 GREEN
48 - 63 BLUE
64 - 79 AMBER
80 - 95 RED & GREEN
96 - 111 RED & BLUE
112 - 127 RED & AMBER
128 - 143 GREEN & BLUE
144 - 159 GREEN & AMBER
160 - 175 BLUE & AMBER
176 - 191 RED & GREEN & BLUE
192 - 207 RED & GREEN & AMBER
208 - 223 RED & BLUE & AMBER
224 - 239 GREEN & BLUE & AMBER
240 - 255 RED & GREEN & BLUE & AMBER
WiFly Par QA5 WH 2 Channel - DMX Values & Functions
Channel Value Function
1 0 - 255 COLOR MACROS
(See 1 Channel DMX mode for colors)
2 MASTER DIMMER
0 - 255 0% - 100%
WiFly Par QA5 WH 3 Channel - DMX Values & Functions
Channel Value Function
1 0 - 255 COLOR MACROS
(See 1 Channel DMX mode for colors)
2 MASTER DIMMER
0 - 255 0% - 100%
3 STROBING
0 - 15 NOTHING
16 - 255 STROBING SLOW - FAST
