American Dynamics ADC780 Assembly instructions

ADC780 SERIES VANDAL-RESISTANT CAMERA 8000-2811-01, REV. C1
INSTALLATION AND SETUP GUIDE 1 of 11
ADC780 Series Indoor/Outdoor
Vandal-Resistant Cameras
Installation and Setup Guide
The ADC780 series camera is for use in areas
subject to vandalism such as subway stations,
parking garages, prisons, police stations, corridors,
supermarkets, and elevators. This camera, which
comes in NTSC and PAL versions:
•Is contained in a cast aluminum housing with a
polycarbonate window or dome. Three versions
are offered: corner, flush, or surface mount.
•Has 480 lines of resolution to produce a sharp
picture with true color and has a 2.6–6mm
variable focal auto iris lens.
•Is protected by tamper-resistant hardware.
•Meets weather resistance standards:
−Surface Mount: NEMA 4, IP43
−Corner Mount: NEMA 3R, IP43
−Flush Mount: NEMA 1, IP40.
Outdoor Applications
Except when used in the flush mount, the camera
can be mounted outdoors using an optional heater
and thermostat that maintains the operating
temperature between –40°C to +50°C.
© 2005 Sensormatic Electronics Corp.
Features
•Adjustable camera mount
•Indoor/Outdoor installation (except flush mount)
•¾- and ½-inch conduit holes
•24Vac hookup
•2.6–6mm variable focal color camera with dc
auto-iris adjustment
Parts Supplied
Caution: Installation should be performed by
qualified service personnel and in accordance with
all local and federal electrical and building codes.
•Housing and associated hardware
•Mounting screws (4)
•Anchors, plastic (4)
•Screws, M6x35 (4)
•Washers, metal (4)
•O-rings, rubber (4)
•Desiccant (for corner mount, surface mount)
•Mounting Plate (for flush mount, surface mount)
•Screws, M4 x 8 pan head (4) – flush and
surface mounts only (for connection to electrical
box mounting plate)
Parts not Supplied
•Teflon®plumbers tape
•UL-listed electrical tape
•Silicone caulk
(for corner and surface mounts only)
•Threaded conduit
IMPORTANT! Threaded rigid type conduit must
be used for the corner and surface mount
versions.
Tools Required
•Torx wrench
•Small Phillips screwdriver
•Small slotted screwdriver
Corner Mount Flush Mount
Surface Mount

ADC780 SERIES VANDAL-RESISTANT CAMERA 8000-2811-01, REV. C1
INSTALLATION AND SETUP GUIDE 2 of 11
Corner Mount Installation
1. Loosen (DO NOT REMOVE) four captive Torx
screws to remove the cover from enclosure.
2. Prepare the four mounting screws. In extreme
environments: Wrap the screw head in Teflon®
tape with the tape going ¼ inch down the body
of the screw (A) and insert the washer and O-
ring (B). Otherwise, just use the washer and
O-ring (B). The O-ring goes on last.
3. Using the four mounting screws, attach the
enclosure to the corner. Use Teflon®tape to
wrap the ends of the conduit before connecting
it to the enclosure.
M6x35 Screws
(
4x
)
Teflon
Tape
Rubber
Washers
(4x)
M4 Plastic
Anchors (4x)
A B

ADC780 SERIES VANDAL-RESISTANT CAMERA 8000-2811-01, REV. C1
INSTALLATION AND SETUP GUIDE 3 of 11
4. If using the camera outdoors, see “Heater
Installation”, page 7.
5. Run 24vac and video cables to the enclosure.
Connect cables where shown and apply power
to the camera.
6. Holding the yoke (not the camera lens barrel),
swivel the camera to adjust (using a small
screwdriver) the auto-iris level control on the
edge of the top board.
7. Swivel the camera to adjust the ac phase
control on the edge of the bottom board.
8. Select DIP switch settings (page 8).
9. Holding the yoke (not the camera lens barrel),
swivel the camera to the desired view.
Caution: DO NOT point the camera directly at
the sun’s path.
10. Adjust zoom and focus arms on the lens barrel
to the desired setting and tighten them in place.
11. Tighten the two yoke screws.
12. If the humidity is high at the time of installation,
place the bag of desiccant inside the enclosure.
13. Reattach the cover on the enclosure using the
four Torx screws.
14. Place a bead of Silicone caulk everywhere
where the corner mount meets the wall.
Swivel camera
holding yoke
Auto-Iris Level
Adjustment
AC Phase
Adjustment
Focus
Zoom
DIP Switch
Yoke
Screws (2x)
Video Connection
AC Terminal Block
AC Camera
Connection

ADC780 SERIES VANDAL-RESISTANT CAMERA 8000-2811-01, REV. C1
INSTALLATION AND SETUP GUIDE 4 of 11
Flush Mount Installation
(In a wall or ceiling)
1. Loosen (DO NOT REMOVE) four captive Torx
screws to remove the cover from enclosure.
2. Using the mounting plate as a template, cut a
round opening in the wall or ceiling. Then, using
the four anchors and screws supplied, center
the gasket over the opening and attach it to the
ceiling.
3. Run 24vac and video cables through the
opening in the ceiling. Then attach the
enclosure to the gasket using screws shown.
Apply power to the camera.
4. Holding the yoke (not the camera lens barrel),
swivel the camera to adjust (using a small
screwdriver) the auto-iris level control on the
edge of the top board.
5. Swivel the camera to adjust the ac phase
control on the edge of the bottom board.
6. Select DIP switch settings (page 8).
7. Holding the yoke (not the camera lens barrel),
swivel the camera to the desired view.
Caution: DO NOT point the camera directly at
the sun’s path.
8. Adjust zoom and focus arms on the lens barrel
to the desired setting and tighten them in place.
9. Tighten the two yoke screws and reattach the
cover on the enclosure using the four Torx
screws.
M4 x 8 Pan Head
Screws
(
2x
)
Rubber
Washers
(
2x
)
FC1 M4 x 20 Flat
Head Screws (4x)
M4 Plastic
Anchors (4x)

ADC780 SERIES VANDAL-RESISTANT CAMERA 8000-2811-01, REV. C1
INSTALLATION AND SETUP GUIDE 5 of 11
Surface Mount Installation
1. Loosen (DO NOT REMOVE) four captive Torx
screws to remove the cover from enclosure.
2. Prepare the four mounting screws. In extreme
environments: Wrap the screw head in Teflon®
tape with the tape going ¼ inch down the body
of the screw (A) and insert the washer and O-
ring (B). Otherwise, just use the washer and
O-ring (B). The O-ring goes on last.
3. Using the four mounting screws, attach the
enclosure to the ceiling. Use Teflon tape to
wrap the ends of the conduit before connecting
it to the enclosure.
4. If connecting to an electrical box, see “Electrical
Box Attachment”, page 5. If using the camera
outdoors, see “Heater Installation”, page 7. If
humidity is a factor, see “Heater/Fan”
installation, page 7.
5. Run 24vac and video cables to the enclosure.
Connect cables where shown and apply power
to the camera.
6. Holding the yoke (not the camera lens barrel),
swivel the camera to adjust (using a small
screwdriver) the auto-iris level control on the
edge of the top board.
Screw Assembly (4x)
Teflon
Tape
Plastic Anchors (4x)
Swivel camera
holding yoke
Auto-Iris Level
Adjustment
AC Phase
Adjustment
Focus
Zoom
DIP Switch
Yoke
Screws (2x)
AC Terminal Block
Video Connection
AC Camera
Connection
A B

ADC780 SERIES VANDAL-RESISTANT CAMERA 8000-2811-01, REV. C1
INSTALLATION AND SETUP GUIDE 6 of 11
7. Swivel the camera to adjust the ac phase
control on the edge of the bottom board.
8. Select DIP switch settings (page 8).
9. Holding the yoke (not the camera lens barrel),
swivel the camera to the desired view.
Caution: DO NOT point the camera directly at
the sun’s path.
10. Adjust zoom and focus arms on the lens barrel
to the desired setting and tighten them in place.
11. Tighten the two yoke screws.
12. If the humidity is high at the time of installation,
place the bag of desiccant inside the enclosure.
13. Reattach the cover on the enclosure using the
four Torx screws.
14. Place a bead of Silicone caulk everywhere
where the surface mount meets the wall.
Electrical Box Attachment
Flush Mount
1. Attach the mounting plate to the electrical box
using four 8-32 screws shown.
2. Attach the enclosure to the mounting plate
using four M4 x 8 screws.
Note: Due to mounting hole locations on the
cover plate, the enclosure will be oriented 45° to
the electrical box.
Surface Mount
Connect enclosure to an electrical box using
screws shown.
M4 x 8 Pan Head
Screws (4x)
8-32 x 0.75 Flat
Head Screws (4x)
Electrical Box
Cover Plate
8-32 x 0.75 Flat
Head Screws (4x)
M4 x 8 Pan Head
Screws (4x)
Electrical Box
Cover Plate

ADC780 SERIES VANDAL-RESISTANT CAMERA 8000-2811-01, REV. C1
INSTALLATION AND SETUP GUIDE 7 of 11
Heater Installation
Corner Mount
Remove the ac terminal block and wiring to the AC
camera connection and replace it with the thermo-
stat PC board and heater element. Each compon-
ent is held in place by two screws. For wiring
details, see ac/heater wiring diagram on page 8.
Surface Mount
Remove the ac terminal block and wiring to the AC
camera connection and replace it with the thermo-
stat PC board and heater element. Each compon-
ent is held in place by two screws. For wiring
details, see ac/heater wiring diagram on page 8.
Heater/Fan
Installation
(Surface Mount only)
Remove the ac terminal block and wiring to the AC
camera connection and replace it with the thermo-
stat PC board and the heater/fan assembly. Each
component is held in place by two screws. For
wiring details, see ac/heater/fan wiring diagram on
page 8.
AC Terminal Block
Heater
Element
Thermostat
PC Board
AC Camera Connection
Thermostat
PC Board
Heater
Element
AC Terminal Block
AC Camera
Connection

ADC780 SERIES VANDAL-RESISTANT CAMERA 8000-2811-01, REV. C1
INSTALLATION AND SETUP GUIDE 8 of 11
DIP Switch Default Settings
1. Automatic White Balance (On)
2. Gamma (On)
3. Automatic Gain Control (On)
4. Electronic Sensitivity Control (Off)
5. Back Light Compensation (Off)
6. Flicker Less (On)
7. AE (On)
8. Not Used (Don’t Care)
87654321
OFF
AC/Heater Wiring Diagram
(Corner Mount or
Surface Mount only)
J3 J1
J2
SW1
SW1 (Thermostat)
J2
J1J3
Heater AC to Camera
AC In
AC/Heater/Fan
Wiring Diagram
(Surface Mount only)
Note:
•Red wire from the fan goes to the J3 terminal
marked “+”.
•“AC In” and “AC to the Camera” both connect
to the J1 terminal.
SW1 (Thermostat) 24Vac
Reg.
12Vac
Reg.
Heater AC In
AC to Camera
J2 J1 J3
–+
Fan
J3
J1
J2
SW1

ADC780 SERIES VANDAL-RESISTANT CAMERA 8000-2811-01, REV. C1
INSTALLATION AND SETUP GUIDE 9 of 11
Dimensions
Corner Mount
PT 3/4"
PT 1/2"
124.2mm
4.9"
75mm
2.95"
120mm
4.73"
104.6mm
4.12"
86mm
3.39"
100mm
3.94"
Flush Mount
91.5mm
3.6"
86.0mm
3.39"
85.0mm
3.35"
52.5mm
2.07"
40.0mm
1.57"
120.0mm
4.72"
120.0mm
4.72"
Surface Mount
91.5mm
3.60"
86.0mm
3.39"
120.0mm
4.72"
120.0mm
4.72"

ADC780 SERIES VANDAL-RESISTANT CAMERA 8000-2811-01, REV. C1
INSTALLATION AND SETUP GUIDE 10 of 11
Specifications
Models
NTSC
ADC780CM-24 ...........................................Corner Mount
ADC780SD-24.......................................... Surface Mount
ADC780FD-24 ..............................................Flush Mount
PAL
ADC780CM-24X .........................................Corner Mount
ADC780SD-24X........................................ Surface Mount
ADC780FD-24X............................................Flush Mount
Electrical
Power input* ..................24Vac (+20%, –15%)
60Hz NTSC
50Hz PAL
Power consumption .......3W
Connectors
Input power....................Screw terminal block
Composite video ............BNC on cord
Controls
AES ...............................On/Off
AGC...............................On/Off
Synchronization .............Line lock w/phase adjust.
DC iris............................Level control
Environmental
Operating temp.
(no heater) .....................–10°C to +50°C
(–14°F to +122°F)
Operating temp.
(with heater)...................–40°C to +50°C
(–40°F to +122°F)
Humidity.........................90% non-condensing
Storage temp. ................–20°C to +60°C
(–4°F to +140°F)
* North America: Listed Class 2 power supply required.
European Union: Certified limited power source
required.
Mechanical
Dimensions ............ (see page 9)
Weight ................... Flush Mount: 450g (1 lbs)
Surface Mount: 590g (1.3 lbs)
Corner Mount: 590g (1.3 lbs)
Color ...................... Light beige
Operational
Imager .......................... ¼" interline transfer CCD
Video output ................. 1.0Vp-p / 75-ohm composite
Active pixel count
NTSC......................... 768- (H) x 494 (V)
PAL............................ 752 (H) x 582 (V)
Lens .............................. 2.6–6mm variable focal,
auto iris lens
Sync system.................. Line lock
Minimum scene
illumination .................... 3.0 Lux at F1.4
Horizontal resolution ..... 480 TV line
Light compensation
modes ........................... Auto. electronic shutter On/Off
(NTSC 1/60–1/100,000 sec)
(PAL 1/50–1/100,000 sec)
Auto Iris Drive................ DC
Back light
Compensation............... On/Off selectable
Synchronization
modes ........................... Line lock with phase adjustment
White balance ............... Automatic
Geometric distortion ...... None
S/N ratio ........................ –50dB

ADC780 SERIES VANDAL-RESISTANT CAMERA 8000-2811-01, REV. C1
INSTALLATION AND SETUP GUIDE 11 of 11
Regulatory Compliance
REG ID: SV ALM-C
SV ALM-W
SV ALM-F
Emissions ............................... FCC part 15 Class A
CE: EN55022
ICES-003
Immunity......................................... CE: EN55082-1
CE: EN50130-4
Safety .........................................................UL1950
CSA C22.2 No. 950
EN60950
Weather resistance:
Surface mount ................... NEMA 4, IP43
Corner mount .................... NEMA 3R, IP43
Flush mount....................... NEMA 1, IP40
Impact resistance .............. ASTM D5420-98A
FCC COMPLIANCE: This equipment complies with Part 15
of the FCC rules for intentional radiators and Class A digital
devices when installed and used in accordance with the
instruction manual. Following these rules provides reasonable
protection against harmful interference from equipment
operated in a commercial area. This equipment should not be
installed in a residential area as it can radiate radio frequency
energy that could interfere with radio communications, a
situation the user would have to fix at their own expense.
CISPR 22 WARNING: This is a Class A product. In a
domestic environment this product may cause radio
interference in which case the user may be required to take
adequate measures.
EQUIPMENT MODIFICATION CAUTION: Equipment
changes or modifications not expressly approved by
Sensormatic Electronics Corporation, the party responsible for
FCC compliance, could void the user's authority to operate the
equipment and could create a hazardous condition.
Other Declarations
WARRANTY DISCLAIMER: Sensormatic Electronics
Corporation makes no representation or warranty with respect
to the contents hereof and specifically disclaims any implied
warranties of merchantability or fitness for any particular
purpose. Further, Sensormatic Electronics Corporation
reserves the right to revise this publication and make changes
from time to time in the content hereof without obligation of
Sensormatic Electronics Corporation to notify any person of
such revision or changes.
LIMITED RIGHTS NOTICE: For units of the Department
of Defense, all documentation and manuals were developed at
private expense and no part of it was developed using
Government Funds. The restrictions governing the use and
disclosure of technical data marked with this legend are set
forth in the definition of “limited rights” in paragraph (a) (15)
of the clause of DFARS 252.227.7013. Unpublished - rights
reserved under the Copyright Laws of the United States.
TRADEMARK NOTICE: American Dynamics, and the
American Dynamics logo are registered trademarks of
Sensormatic Electronics Corporation. Other product names (if
any) mentioned herein may be trademarks or registered
trademarks of Sensormatic or other companies.
No part of this guide may be reproduced in any form without
written permission from Sensormatic Electronics Corporation.
RLJ 02/2005
