FEATURES
This low-profile fixed drone, with its pre-installed
camera, can be surface mounted to any indoor
ceiling or wall, and provides a low-cost alternative
for users who require fixed camera coverage. The
330 line color camera has a 1/4-inch vari-focal
3.0 - 6.0 mm lens with an auto iris.
The 355° pan and 75° tilt mechanism enables the
internal camera to be manually positioned in
virtually any orientation for flexible viewing
requirements. The set screw holds the camera in
that fixed position, pointing at the desired camera
view.
The compact, lightweight housing is available in
two colors: black or white. The drone is easy to
install; just connect power and video, and mount
the unit via its two mounting screws (provided).
RT3300MC
MINI-CAMERA PRE-PACK
•Attractive, unobtrusive
alternative to standard fixed
cameras
•Compact, lightweight
design
•Pre-installed camera/lens
combination
•1/4-inch vari-focal
3.0 - 6.0 mm lens
•Auto iris
•330 TV lines resolution
•Automatic electronic
shutter
•Automatic gain control
•Manually adjustable pan
and tilt viewing angles
•Choice of camera housing
color: black or white
•12 VDC input
•Low power consumption
www.americandynamics.net

SPECIFICATIONS
Model Numbers
RT3300MC-VARI . . . . . . . . . . .NTSC Camera, 1/4-inch 3.0 - 6.0 mm
vari-focal lens, black housing
RT3300MC-VARIW . . . . . . . . .NTSC Camera, 1/4-inch 3.0 - 6.0 mm
vari-focal lens, white housing
Operational
Pan Travel . . . . . . . . . . . . . . . . . .355° with end stop
Tilt Travel . . . . . . . . . . . . . . . . . .15° to 90°
Internal Synchronization . . . .Built-in sync generator
Video Output Connector . . . .Female BNC
Camera
Imager . . . . . . . . . . . . . . . . . . . . .Interline transfer 1/4-inch CCD array
Scanning System . . . . . . . . . . .2:1 interlace
Video Output . . . . . . . . . . . . . .1.0 Vp-p, 75 Ω, composite
S/N Ratio . . . . . . . . . . . . . . . . . .>46 dB (AGC off)
Horizontal Resolution . . . . . .330 lines at center
Minimum Illumination . . . . .0.8 lux at 40 IRE
White Balance . . . . . . . . . . . . . .Automatic, 2500°K to 7500°K
AES . . . . . . . . . . . . . . . . . . . . . . . .1/60 to 1/100,000 sec
Effective Pixels . . . . . . . . . . . . . .510 (H) x 492 (V)
Horizontal . . . . . . . . . . . . . . . . .15.734 kHz
Vertical . . . . . . . . . . . . . . . . . . . .59.9 Hz
Lens
Design . . . . . . . . . . . . . . . . . . . . .Vari-focal, auto iris
Focal Length . . . . . . . . . . . . . . .3.0 - 6.0 mm
Aperture . . . . . . . . . . . . . . . . . . .f1.4
Viewing Angle
Horizontal . . . . . . . . . . . . . .105.1° - 53.2°
Vertical . . . . . . . . . . . . . . . . . .77.4° - 39.8°
Electrical
Input Voltage . . . . . . . . . . . . . . .12 VDC (±20%)
Power Consumption . . . . . . . .2.2 watts, maximum
Mechanical
Dimensions (D x H) . . . . . . . . .114 x 77.5 mm (4.49 x 3.05 in)
Unit Weight
(camera/lens/housing) . . .0.06 kg (0.13 lbs)
Shipping Weight . . . . . . . . . . . .0.82 kg (1.80 lbs)
Housing Material . . . . . . . . . . .ABS plastic
Housing Color . . . . . . . . . . . . . .Black or White
Environmental
Operating Environment . . . . .Indoor
Operating Temperature . . . . .-10˚ to 50˚C (14˚ to 122˚F)
Humidity . . . . . . . . . . . . . . . . . .85% RH (non-condensing)
Storage Temperature . . . . . . . .-20˚ to 70˚C (-4˚ to 158˚F)
Regulatory
Emissions . . . . . . . . . . . . . . . . . .FCC: Part 15, Class A
Safety . . . . . . . . . . . . . . . . . . . . . .UL: UL2044
cUL: C22-2, No. 1-98
