FEATURES
The ADV096HD High-Density Time-Lapse VCR
produces the clear, crisp images that effective
surveillance requires. The unit provides up to 96
hours of time-lapse recording and up to 24
hours of virtual real-time recording.
Onscreen programming allows for simplified
setup of features such as advanced time and
date search, timer recording and alarm
recording.
In high-density mode, the VCR can record up to
400 lines of horizontal resolution. The result is
smoother recording with more detailed images.
The easy-to-use Time and Date Search enables
you to play back specific alarms and events.
Alarm Recording designates the speed at which
the VCR will record; faster speeds yield
increased information.
The unit’s versatile shuttle dial allows for a
variety of playback options including fast
forward/reverse play, forward/reverse
fieldplayback and still field.
The VCR offers automatic startup after power
failure when power is restored, and automatic
daylight savings auto-switcher.
ADV096HD
96-HOUR HIGH DENSITY TIME-LAPSE VCR
•Standard and high
density recording
•Virtual 24-hour real-time
recording capability
•96-hour time-lapse
recording in high-density
mode
•Onscreen programming
•Tape rewind speed 120
seconds (T-120)
•Automatic head cleaner
and clog detection
•Time and date search
•Alarm search
•Programmable timer
settings
•One-touch recording
verification
•Convenient
multiplayback mode
shuttle
•Daylight savings time
auto-switcher
www.americandynamics.net
Front side – Single sheet – Letter size – print 4/c
ADV096HD_VS351.qxd 3/12/04 4:07 PM Page 1

SPECIFICATIONS
Model Number
ADV096HD . . . . . . . . . . . . . . . . . . . . . . .VCR, 96-hour, time-lapse, NTSC
Operational
Tape Format . . . . . . . . . . . . . . . . . . . . . .Standard 1/2 in VHS
Video Standard . . . . . . . . . . . . . . . . . . . .NTSC
Video Recording System . . . . . . . . . . .Rotary 2-head azimuth
Video Head Configuration . . . . . . . . .4-head double azimuth
Tape Transport
Rewind/FF Speed . . . . . . . . . . . . . . . .Within 120 seconds (with T-120
VHS tape)
Head Cleaning . . . . . . . . . . . . . . . . . . .Automatic
Auto Diagnostics . . . . . . . . . . . . . . . .Alarm buzzer, indicator light, and
display number
Video System
Virtual 24-Hour Real-Time
Record/Playback Time Mode (EP) . . .6H, L18H, L30H, 48H, 72H, 96H, 0H
Horizontal Resolution
(SR Mode) . . . . . . . . . . . . . . . . . . . . . . .400 lines
(VHS Mode) . . . . . . . . . . . . . . . . . . . . .240 lines
Luminance Signal . . . . . . . . . . . . . . . . .Frequency modulation recording
Video Input/Output (BNC) . . . . . . . .1.0 Vp-p, 75 Ω
Audio System
Record/Playback
Time Modes (EP) . . . . . . . . . . . . . . . . .6H, L18H, L30H
Audio Track . . . . . . . . . . . . . . . . . . . . .One track, mono
Frequency Response
(6H Mode) . . . . . . . . . . . . . . . . . . . . . . . .70 Hz to 4 kHz
Audio Input
Line Input . . . . . . . . . . . . . . . . . . . . . . .308 Vrms, > 47 k &, pin jack
Microphone Input . . . . . . . . . . . . . . .0.245 Vrms, < 5 k &, 3.5 jack
Audio Output . . . . . . . . . . . . . . . . . . .388 Vrms, < 4.7 k &, pin jack
Timer
Recording . . . . . . . . . . . . . . . . . . . . . . . . .8 event programmability
Recording Speed . . . . . . . . . . . . . . . . . .Programmable
On-Screen Displays*
Date . . . . . . . . . . . . . . . . . . . . . . . . . . . .Current month, day, and year
Day . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Current day of week
Time . . . . . . . . . . . . . . . . . . . . . . . . . . . .Current time of day
Speed . . . . . . . . . . . . . . . . . . . . . . . . . . .Tape speed
VCR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Sets the VCR number (1-8)
Alarm Counter . . . . . . . . . . . . . . . . . . . .Displays number of alarms
Electrical
Input Voltage . . . . . . . . . . . . . . . . . . . . .120 VAC, 60 Hz
Power . . . . . . . . . . . . . . . . . . . . . . . . . . . .20 watts
Mechanical
Dimensions (H x W x D) . . . . . . . . . . .95 x 425x 313 mm
(3.7 x 16 x 12.3 in)
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . .4.4 kg (9.7 lbs)
Shipping Weight . . . . . . . . . . . . . . . . . .5.1 kg (11.3 lbs)
Environmental
Operating Temperature . . . . . . . . . . . .5° to 40° C (41° to 104° F)
Storage Temperature . . . . . . . . . . . . . . .-20° to 60° C (-4° to 140° F)
Humidity . . . . . . . . . . . . . . . . . . . . . . . . .80% RH (non-condensing)
Regulatory
Emissions . . . . . . . . . . . . . . . . . . . . . . . . .FCC: Part 15, Class A Canada:
ICES-003, Class A
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . .UL: UL2044 CSA: C22.2 No. 1
AMERICAN DYNAMICS ADV096HD HIGH-DENSITY TIME-LAPSE VIDEO RECORDER
Product specifications and availability subject to
change without notice.
Certain product names mentioned herein may be trade
names and/or registered trademarks of other companies.
VS351-01 03/04 L
©2004 Sensormatic Electronics Corporation
Back side – Single sheet – Letter size – print b/w
*(can be set on or off at user’s discretion)
Note: Due to the new method for recording tapes in super resolution mode,
tapes recorded in the ADV096HD VCR cannot be reviewed using other models
of American Dynamics VCRs. In addition, tapes recorded on other American
Dynamics VCRs cannot be reviewed using the ADV096HD VCR.
