Amica FK3023 Installation and operating instructions

www.amica-international.co.uk
FK3023
Fridge Freezer
Installation, use and maintenance

2
Contents:
3 Important information
4 Before first use
5 Important safety notes
6 Important notes on use of the fridge
7 Important notes on use of the freezer
8 Information on the LED lighting
8 Important notes on first use and general usage
9 Fridge layout and storage
10 Setting the temperature
11 Super switch
12 Defrosting the fridge
13 Defrosting the freezer
14 Care and cleaning
15 Changing the light bulb
16 Troubleshooting
17 - 18 Fridge noise
19 Installation and ventilation
19 Appliance dimensions
20 Electrical information
22 Practical tips
23 Climate range
24 Warranty and service

3
Important
Amica cannot be held responsible for injuries or losses caused by
incorrect use or installation of this product. Please note that Amica
reserve the right to invalidate the guarantee supplied with this product
following incorrect installation or misuse of the appliance.
Under no circumstances should any external covers be removed for
servicing or maintenance except by suitably qualified personnel.
Do not use the appliance if the plug, the mains cord or the
appliance itself is damaged. If the mains cord is damaged, you
must have it replaced by the manufacturer, or an authorised
service centre or similarly qualified person in order to avoid a
hazard.
Appliance information:
Please enter the details on the appliance rating plate below for
reference, to assist Amica Customer Care in the event of a fault with
your appliance and to register your appliance for guarantee purposes.
Appliance Model
Serial Number
EU Declarations of Conformity:
This appliance meets the requirements of all applicable EU directives
with the corresponding harmonised standards which provide for CE
marking.
WARNING: Risk of fire/flammable materials

4
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE
PRODUCT IN ACCORDANCE WITH WEEE DIRECTIVE 2012/19/EU.
At the end of its working life, the product must not be disposed
of as urban waste. It must be taken to a special local authority
dierentiated waste collection centre or to a dealer providing this
service.
Disposing of a household appliance separately avoids possible
negative consequences for the environment and health deriving from
inappropriate disposal and enables the constituent materials to be
recovered to obtain significant savings in energy and resources. As a
reminder of the need to dispose of household appliances separately,
the product is marked with a crossed-out wheeled dustbin .
Before first use of the fridge/freezer
You must allow the fridge to settle for at least five hours prior to
switching the power on.
It is recommended that you clean the interior of the appliance prior to
first use, using a solution of bicarbonate of soda and warm water then
thoroughly dry the interior.
The fridge may have an odour to it at first use. This will disappear
as the appliance cools.
This appliance has been designed with ease of use in mind but
please read the following instructions carefully to ensure you
familiarise yourself with the appliance and its operation. This will help
you to get the best results and also help to prevent you from being
charged for unnecessary service calls.

5
Important
This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person
responsible for their safety.
• This refrigeration appliance is not intended for use as a built
inappliance.
•Children must not play with the appliance.
•Cleaning and user maintenance must not be made by children
without supervision.
•If the appliance is switched o, you should allow five minutes
before switching it on again to prevent unnecessary damage to
the compressor.
•WARNING - Keep ventilation openings clear of obstruction.
•WARNING - Do not use mechanical devices or other means to
accelerate the defrosting process.
•WARNING - Do not use electrical appliances inside the food
storage compartments of the appliance.
•WARNING - Do not damage the refrigerant circuit.
•WARNING - Do not store explosive substances such as aerosol
cans, with a flammable propellant, within this appliance.
•Children should be supervised to ensure that they do not play with
the appliance.
•This appliance is not intended for use at altitudes exceeding 2000
metres.
•This appliance is a household refrigerator and is intended to be
used in domestic environments and similar applications such as
sta kitchen areas, farm houses and bed and breakfast type

6
environments. It should not be used in commercial environments.
•If your appliance uses R600a as a refrigerant (this information will
be provided on the rating plate) you must take care during trans-
portation and installation to prevent the cooling system elements
from being damaged. R600a is an environmentally friendly and
natural gas, but is explosive. In the event of a leak due to damage
to the cooling system, move your fridge away from open flames
or heat sources and ventilate the room in which the appliance is
located for 5 minutes.
Fridge use
•Never put liquids in the refrigerator uncovered.
•Never put hot foods in the refrigerator. Warm food should be
allowed to cool to room temperature before being put into the
refrigerator.
•Nothing should rest against the rear wall of the refrigerator, as this
will cause frost and possible condensation problems which will be
dicult to remove.
•Make sure food is clean and any extra water is wiped away before
putting into the fridge.
•Wrap or cover food before putting into the fridge. This will help
prevent the loss of moisture, keep food fresh and avoid unpleasant
odours.
• Sort foods prior to storing. Any foods to be used soon should be
stored at the front of the shelf to prevent deterioration caused by
the door being open for prolonged periods.
•Do not overfill the fridge. There should be sucient space between
the foods to allow the cool air to circulate.

7
•Thawing frozen foods in the fridge compartment will help to keep
the temperature low and save energy.
•Never store raw meats above cooked meats or other produce.
This will help to prevent juices from raw meat contaminating other
foodstus. We recommend storing raw meat packages or containers
on kitchen roll and changing the roll regularly. This will help to stop
raw meat juices running around the appliance.
Freezer use
•The freezer compartments are designed to store only frozen food.
•Never put hot or warm foods in the freezer, allow them to cool fully
before putting them into the freezer.
• Follow the instructions on the food packaging for storage of frozen
food. If no information is provided, foods should not be stored for
more than three months after the purchase date.
•Store food in small packages (ideally less than 2kg). This reduces
the freezing time and improves the quality of the food after
thawing.
•Wrap food before putting into the freezer. To stop the wrapping
sticking together, ensure it is dry.
• Label the food before freezing with information including type of
food and dates of storage and expiry.
•Once food is thawed, it must not be refrozen. Only defrost as
much food as is required to prevent wastage.
• Bottled or canned drinks should not be stored in the freezer
compartments as they could explode.

8
•The maximum amount of fresh food that can be frozen within a 24
hour period is 8 kg.
•Do not attempt to freeze more than the maximum amount.
•To freeze fresh food more quickly, switch the thermostat to setting
5 a few hours prior to placing the food in the freezer. After the
food is frozen, lower the setting.
• Where possible, do not overload your fridge and freezer
compartments. This allows for air circulation around the contents
and keeping airways etc. as unobstructed as possible will ensure
optimum performance.
Note: If the appliance does not have a freezer compartment ( )it
is not suitable for freezing foodstus.
Important notes on first use and usage
•When you first switch on the appliance, you should ideally run
it without any contents for the first 24 hours and not open the
appliance doors. If you need to use it straight away, try not to put a
large quantity of food inside.
•The appliance will work continuously until it comes down to the
correct temperature.
•This appliance features a five minute delay function which, after
power has been cut and restored or the appliance turned o and
on again, allows five minutes to pass before switching the cooling
system on again. This is to prevent unnecessary damage to the
compressor.
•The climate class for this appliance is N. This means ambient
temperatures should not fall below 16°C or exceed 32°C.

9
Fridge layout and storage
1 - Thermostat dial and light 8 - Freezer bottom basket
2 - Fridge shelves 9 - Fridge compartment
3 - Crisper cover 10 - Door shelves
4 - Crisper 11 - Bottle shelf
5 - Freezer flap 12 - Freezer compartment
6 - Freezer upper basket
7 - Freezer middle basket
Fig. 1
1
2
3
4
5
6
7
8
9
10
11
12

10
Food types and where to store them within the fridge section:
Vegetables and fruits - Crisper drawer
Red meat - Fridge shelves (lower)
White meat & fish - Fridge shelves (lower)
Cheese - Door shelves (upper)
Butter and margarine - Door shelves (upper)
Bottled milk products and yoghurt - Bottle shelf
Cooked food - Fridge shelves (upper)
Setting the temperature
You must allow the fridge to settle for at least twenty four hours
prior to switching the power on.
To adjust the temperature turn the thermostat control knob from left
to right to the required level. This ranges from 1 to 5. The temperature
becomes colder the higher the number on the control.
When the thermostat is set to •the
cooling system is switched o.
We recommend initially setting the
temperature control in mid range for
the first 24 hours then adjusting the
temperature up or down from this point
as your personal preference. If your
fridge is often relatively empty, set the
thermostat to a low number to help
prevent straining the system. Thermostat location
Fig. 2

11
Thermostat location
Super switch
Low ambient switch
You can use your appliance even if
the ambient temperature is falling
down as low as -15 °C. However at
low ambient temperatures (as -15 °C),
food in the fridge compartment may
freeze. Please check first and then
you can consume food in the fridge
compartment. You can change the
setting of thermostat knob to suit your
needs when the ambient temperature
returns to normal.
Super freezing
If ambient temperature is more than
16 °C, this switch must be used as
super freeze switch. For maximum
freezing capacity, please turn on
this switch 3 hours before placing
fresh food. After placing fresh food in
the freezer, 24 hours ON position is
generally sucient. In order to save
energy, please turn o this switch
after 24 hours from placing fresh
food.
Super switch /
Low ambient Switch
Fig. 3
The maximum amount of fresh food (in kilograms) that can be
frozen within 24 hours is shown on the appliance label.

12
Defrosting the fridge
The fridge should not require defrosting in normal operation. Any
water from the back wall of the fridge gathers in a channel at the
rear of the appliance, drains through a drain hole and collects in the
evaporating tray above the compressor. The evaporating tray (at the
rear of the appliance, above the compressor - Fig. 5) and the drain
hole (Fig. 4) should be cleaned periodically to prevent issues.
Please note: If you notice water pooling in the fridge, and the
evaporating tray is dry, it is likely that the drain hole passage is
blocked.
Fig. 4
Fig. 5
Evaporating tray
location

13
Defrosting the freezer
Do not use heaters or defrosting sprays in this appliance. Always
disconnect the appliance from the power source before defrosting.
• Never use any metallic or sharp objects to remove the ice as this
could damage the lining.
• The freezer compartment should be defrosted regularly to ensure
the most ecient running of the freezer. Once the ice is more than
5mm thick, the freezer should be defrosted.
• First remove the freezer drawers. To speed up the process, place a
bowl of warm water in the base of the freezer compartment.
• Once defrosting is complete, dry the inside of the freezer
compartment with a sponge or clean cloth thoroughly.
• The freezer interior should be cleaned using a solution of
bicarbonate of soda and lukewarm water. Do not use abrasive
products or detergents. After washing, rinse and dry thoroughly.
• Clean the drawers separately by hand using soap and water. Do not
put them in a dishwasher.
• Once cleaning is complete and everything is dry, reconnect the
power.

14
Care and cleaning
Always disconnect the appliance from the power before ANY
cleaning or maintenance.
• Leave spaces between food items wherever possible to allow air to
flow between them. Do not allow food items or containers to touch
the rear or side walls of the appliance.
• Avoid contact of oily or acidic foods with the rear and side walls.
Oils and acids can damage the liner material. If any such foods
come into contact with the walls, clean the spot with warm water
and bicarbonate of soda.
• The refrigerator and freezer sections should be cleaned using a
solution of bicarbonate of soda and lukewarm water. Make sure that
no water enters the lamp housing or other electrical components.
• Do not use abrasive products or detergents. After washing, rinse
and dry thoroughly.
• Clean the shelves and balconies separately by hand, using soap
and water. Do not put them in the dishwasher.
• Keep the door seals clean to avoid damage to them and to help to
ensure that they continue to function correctly.
• Once cleaning is complete, then reconnect the power.
• If the appliance is not used for prolonged periods of time, unplug
and clean it. The doors should be left slightly open to prevent the
formation of mildew or odours.
• Where possible (e.g. freestanding appliances), clean the condenser
(black grille on the back of the appliance) with a soft bristle brush at
least twice a year.

15
Changing the light bulb
If the light bulb in your appliance fails, contact Amica Customer Care
using the details on page 18. This is because LED lighting should only
be replaced by authorised personnel.
To avoid contamination of food, please respect the following
instructions:
•Opening the door for long periods can cause a significant in-
crease of the temperature in the compartments of the appliance.
•Regularly clean surfaces that come in to contact with food and
accessible drainage systems.
•Store raw meat and fish in suitable containers in the refrigerator,
so that it does not make contact with or drip on to other food.
•Two-star frozen food compartments are suitable for storing pre-
frozen foo, storing or making ice cream and ice cubes.
•One, two and three-star star compartments are not suitable for
freezing of fresh food.
•If the appliance is left empty for long periods, it is advised to
switch o, defrost, clean, dry and leave the door open to prevent
mould developing within the appliance.

16
Troubleshooting
If you have any problems with your appliance, you should check the
troubleshooting prior to calling Amica Customer Care, to prevent
unnecessary service calls and potential cost. Contact details for
Amica Customer Care are on the rear cover of this manual.
If the appliance is not working, check the following;
• There is power to the appliance.
• The thermostat dial is not set to the o position ‘•’.
• The house fuses are intact and the fuse in the plug has not blown.
• The plug socket is functioning correctly. To check this, plug another
electrical appliance in to see if the socket is working.
If the appliance is working, but not very well, check the following;
• The appliance is not overloaded.
• The thermostat is set to an appropriate level. For a fully loaded
appliance, a higher setting (e.g 4 or 5) is better.
• The doors are closing properly.
• The cooling system at the rear of the appliance is clean and free of
dust, and not touching the rear wall.
• There is enough ventilation at the side and rear (p19).
If there is water in the lower part of the refrigerator compartment,
check the following:
•There are no items touching the rear wall of the appliance. If there
are, adjust their position so that they no longer touch it.
•Check that there is some resistance when opening the door of the
appliance. If it opens at the slightest touch it may mean that the
door seal needs to be replaced.

17
• Check the door seal for any kinks, debris or damage. If you notice
any, and are unable to resolve the issue yourself, contact Amica
Customer Care so that the seal can be replaced.
• If you notice water pooling in the fridge, and the evaporating tray is
dry, it is likely that the drain hole passage is blocked. You can pour
warm (not hot) water down the drain channel to help this.
If ice/frost has formed on the back wall of the fridge;
• It is normal for some ice droplets and/or frost to form on the back
wall of the fridge. This does not constitute a fault with the appliance.
•Ensure that no items inside the fridge are in contact with the back
wall.
•Check that there is some resistance when opening the door of the
appliance. If it opens at the slightest touch it may mean that the
door seal needs to be replaced.
•Check the door seal for any kinks, debris or damage. If you notice
any, and are unable to resolve the issue yourself, contact Amica
Customer Care so that the seal can be replaced.
If the appliance is noisy, check the following;
• The appliance is level and stable.
• The side, underside and rear walls are clear, and there is nothing
resting on the appliance.
• It is normal to hear the compressor running. This will operate
periodically and more so when the appliance doors are opened.
• The appliance may make what seem to be peculiar noises, even
when the compressor is not running. Details of the sorts of noise
you may hear are on page 18.

18
Cracking noise, similar to ice cracking - Normal noise that can occur
when the appliance is cooling or warming. Due to the expansion and
contraction of appliance materials.
Loud click - Normal noise and is usually the thermostat switching the
compressor on or o.
Ticking sound - Normal noise that is usually caused by the functions
of a valve at the back of the refrigerator.
Motor sound - Normal noise caused by the compressor running,
sometimes accompanied by a brief metallic rattle. This sound may be
more intense for the first seconds after the compressor starts. If the
metallic noise (i.e. metal hitting metal) is constant then it may be that a
compressor mount is loose. Contact the Customer Care Department
in this instance.
Bubbling noise - Normal noise caused by the movement of the
refrigerant within the appliance’s pipework.
If none of the aforementioned checks resolves your issue, please
contact Amica Customer Care using the contact details below:
A: Amica CCD, The CDA Group Building, Harby Road, Langar,
Nottinghamshire, NG13 9HY
T: 01949 862 012 F: 01949 862 003
E: [email protected]
W: www.amica-international.co.uk

19
Installation and ventilation
When installing this product we recommend
you seek the help of another individual. This
product may have some sharp edges. Please
take care and wear adequate PPE when
handling.
This appliance must never be installed close
to heat sources such as heating elements,
radiators, ovens and cookers nor installed in
damp places or direct sunlight.
Failure to provide adequate ventilation
can lead to increased running costs and
premature failure; it may also invalidate the
warranty provided with the product.
• The plug should be fully accessible at all times.
• Ensure ventilation openings are kept clear.
• Do not use a multi-plug adaptor in the socket to connect this
appliance alongside other appliances.
• Do not tilt the fridge beyond 45º.
• Do not exert excessive pressure on the appliance.
• Ensure that there is a gap of no less than 10cm above and to
the sides of the appliance to allow for ventilation. The clearance
between the sides and adjacent furniture must also allow the
doors to open fully. Note that a greater side gap will be required
if the appliance is to be positioned next to a wall to allow the
doors to open fully.
• A gap of 7cm should be allowed for ventilation between the rear
wall and the back of the appliance. There are plastic guides/
stoppers supplied with the appliance that should be fitted when
Fig. 6 Appliance dimensions
590
1820
540

20
aligning the appliance with a wall.
Place the guide into the condenser
and turn it by 90° (Fig 7). The guide
will then lock into place. Take
extreme care not to damage the
con-denser whilst doing this. These
guides will protect the condenser
and ensure a minimum air gap.
Electrical information
Warning! This appliance must be earthed.
The mains lead of this appliance has been fitted with a specially
earthed plug.
Important: Do not use the appliance without the fuse cover in
position. Should the fuse need to be replaced, it must be replaced
with a 13A fuse, ASTA approved to BS1362.
The plug must be used with a specially earthed socket of 13
amperes. If there is no such socket in your house, please have one
installed by an authorised electrician.
Fig. 7
Blue to Neutral
Cord Clamp
13A Fuse
Brown to live
Green and yellow to earth
13 A
A
B
