Amica FK328.3F User manual

FK328.3F
FK328.3FX
FK338.6GWF
FK338.6GBF
EN INSTRUCTION MANUAL

2
1
2
3
45
6
7
8
9
10
11
12
13
14 15
16
17
2
3
1
18

3
5
8
6
7
9
10
A
B
4

4
1
2
3
4
5
11
12
13
14

5
15 16
17

6
CHANGING THE DIRECTION OF THE DOOR OPENING
1. Unplug the appliance.
2. Remove the bottom rail, gently pulling it towards you (item 1).
3. RemovethecapsCusingaatscrewdriver
4. Holding the refrigerator door, remove the hinge assembly (item 6), remove the door by lifting them
up parallel to the appliance body. Remove the pin from the upper hinge and screw it on the other
side of the hinge (item 6).
5. Remove the pin pads located in the refrigerator door lower strip (item 5). Remove the cap from the
middle hinge pin hole it the upper strip of the freezer door (item 9).
6. Remove the caps from the mounting holes for the middle hinge (item 8).
7. Holding the freezer door (item 3), remove the middle hinge (item 4), remove the door by lifting it up
parallel to the appliance body.
8. Unscrew the bottom hinge (item 7), remove the pin and insert it into the opposite hole (item 2).
Remove the bottom rail handle located on the other side of the refrigerator body.
9. Attach the lower hinge on the other side of the appliance body. Position the freezer door in such a
way so that the lower hinge pin is aligned with the appropriate hole in the door.
10. The remaining door installation steps should be performed analogically to the above.
12. Check the door position towards the body of the appliance. If the door is in the correct position, use
the caps to cover the holes in the body and doors and install the lower cover.
13. Remove the door handles and attach them on the other side of the refrigerator and freezer door. To
remove the handle, remove the screw caps (item A) and remove the screws. Move the handle to
the side (in the direction of the previous handle position) and gently pull it forward. Install the handle
analogically to its removal.
Remember about the pads located on the hinge pins. Reuse them when changing the direction of
opening the door.
The installation kit does not include a screwdriver or wrench.
Changing the direction of the door opening should by carried out by two persons.

7

8
Your appliance is exceptionally easy to use and extremely efcient. Before being packaged
and leaving the manufacturer, the appliance was thoroughly checked with regard to safety and
functionality.
Before using the appliance, please carefully read these Operating Instructions
DEAR CUSTOMER!
THANK YOU FOR PURCHASING AN AMICA APPLIANCE
The appliance is intended for household
use only.
The manufacturer reserves the right to
introduce changes which do not affect the
operation of the appliance.
i
Figures in this user manual are for illustra-
tivepurposesonly.Fullappliancettings
are listed in a relevant section.
EN
CHANGING THE DIRECTION OF THE DOOR OPENING
GUIDELINES CONCERNING THE SAFETY OF USE
INSTALLATION AND OPERATING CONDITIONS OF THE APPLIANCE
OPERATION AND FUNCTIONS
USING THE REFRIGERATOR EFFICIENTLY
DEFROSTING, WASHING AND MAINTENANCE
TROUBLE-SHOOTING
ENVIRONMENTAL PROTECTION
CLIMATE RANGE
WARRANTY AND AFTER-SALE SERVICES
ITEMS OF EQUIPMENT
6
9
12
13
15
16
17
18
18
19
19

9
GUIDELINES CONCERNING THE SAFETY OF USE
EN
Someprovisionsinthisusermanualareuniedforre-
frigerating products of different types (for a refrigerator,
refrigerator-freezer or freezer)
The Manufacturer shall not be held liable for damage
arising from the failure to observe the instructions con-
tained in this manual.
Keep this manual for future reference, or to pass it over
to the next user.
This appliance is not intended for use by persons (inc-
luding children) with limited physical or mental capabili-
ties and persons who lack experience or familiarity with
the appliance.
Do not allow una tte nde d children to use the applian-
ce. Do not allow them to play with the appliance. They
must not climb inside the drawers and swing on the do-
ors.
The appliance operates properly at the ambient tem-
perature(seeproductche).Donotuseitinthecellar,
unheated summer cottage during autumn and winter.
When placing, moving, lifting the appliance, do not hold
the door han- dles, do not pull the condenser at the rear
part of the refrigerator and do not touch the compressor
unit.
When transporting, moving or positioning the fridge-
-freezer do not tilt it by more than 40° from the vertical
position. Should such a situation occur, the appliance
should be switched on after minimum 2 hours from its
re-placementintherightposition(g.2).
Pull the plug out from the mains socket before each ma-
intenance activity. Do not pull on the cord, but hold the
body of the plug instead.
The “cracking” sound, which the appliance may emit is
caused by the expansion and contraction of parts as a
result of temperature variations.
For safety reasons do not repair the appliance yourself.
Repairs car- ried out by persons who do not have the
requiredqualicationsmayresultinseriousdangerfor
the user of the appliance.

10
GUIDELINES CONCERNING THE SAFETY OF USE
Air the room in which the appliance is placed for a few
minutes (the size of the room for a product containing
isobuthane/R600a must be at least 4m3) to avoid da-
mage to the cooling system.
Do not refreeze partly thawed products.
Do not store beverages in bottles and cans, especially
carbonated be- verages, in the freezer chamber. The
cans and the bottles may explode.
Do not put frozen products, taken out directly from the
freezer (lollies, ice cubes, etc.) into your mouth, their
low temperature may cause severe frost-bite.
Make sure you do not damage the cooling system, by
puncturing the refrigerant pipes in the evaporator or
breaking the pipes. The refrige- rant  is ammable. If
the refrigerant makes contact with the eyes, rinse them
with clean water and call for medical assistance imme-
diately.
If the power wire gets broken, it should be replaced with
a new one in a specialist repair shop.
This appliance is intended for food storage, do not use
it for other purposes.
When performing activities, such as cleaning, mainte-
nance or moving, the appliance must be completely di-
sconnected from power supply (by pulling the plug out
from the socket)
This appliance can be used by children aged 8 years
and older or by persons with physical, mental or sen-
sory handicaps, or by those who are inexperienced or
unfamiliar with the appliance, provided they are super-
vised or have been instructed how to safely use the ap-
pliance and are familiar with risks associated with the
use of the appliance. Ensure that children do not play
with the appliance. Cleaning and maintenance of the
appliance should not be performed by children unless
they are 8 years or older and are supervised by a com-
petent person.
EN

11
GUIDELINES CONCERNING THE SAFETY OF USE
Anti-bacteria System (varies depending on the model.
Its presence is indicated by the label inside the applian-
ce chamber) - The Antibacteria System protects foods
and products inside the refrigerator from bacteria and
mould which may cause unpleasant smells and shorten
storage time. The Antibacteria System prolongs the fre-
shness of food. The special material used to construct
the fridge liner prevents bacterial, microorganism and
mould growth.
In order to obtain more space in the freezer, you can
remove the drawers and place the food directly on the
shelves. This has no effect on the product mechanical
properties and cooling performance. Declared freezer
capacity was calculated with the drawers removed.
EN

12
INSTALLATION AND OPERATING CONDITIONS OF THE APPLIANCE
EN
* Only free- standing appliances
** According to the model
Installation before using the ap-
pliance for the rst time
● Take the product out of the package,
re- move the scotch tape protecting the
door and the equipment. Any remaining
adhesive stains may be removed with a
mild washing agent.
● Donotthrowawaythepolystyreneele-
ments of the packaging. If it is necessary
to transport the fridge-freezer, pack it in
thepolystyreneelementsandlmaswell
as protect ing it with scotch tape
● Cleantheinteriorsurfaceofthefridge-
freezer and the elements of the equip-
ment with a washing agent dissolved in
lukewarm water, then wipe it dry.
● Placethefridge-freezeronaneven,at
and stable surface, in dry, aired and
shaded room, far from the heat sources
such as: oven, hob, central heating ra-
diators, central heating pipes, hot water
installation, etc.
● On the exterior surface of the product
may be a protective foil, this foils should
be removed.
● Make sure the appliance is placed in a
horizontal position by screwing in the 2
adju-stablefrontlegs(g.3)
● To ensure that the door opens freely, the
distance between the side of the applian-
ce (on door hinges side) and the wall is
shownongure5.*
● Ensure adequate ventilation of the room
and free air circulation from all sides of
theappliance(g.6).*
● Two condenser spacers enabling an
appropriate air circulation should be in-
stalledasshownonthegure(Fig.7).
● Appliance door is secured with a spacer
insert located in the bottom cover (Fig.
17). It must be removed before use.
Minimum distances from the heat
sources
- from the electric gas and other ovens -
30 mm,
 -fromoilorcoalredovens-300mm,
- from built-in ovens - 50 mm
If there is no possibility of ensuring the
above- mentioned distances, provide an
appropriate insulation board.
● Therearwalloftherefrigerator,inparti-
cular, the condenser and other elements
of the cooling system must not contact
other elements, which may damage
them, (e.g. central heating pipes and the
water supply pipes).
● It is forbidden to readjust or modify
any parts of the unit. It is crucial not to
damage the capillary tube visible in the
compressor recess. The tube may not
be bent, straightened or wound.
● Ifthecapillarytubeisdamagedbythe
usertheguaranteewillbevoid(g.8).
● Insomemodelsthehandleisputinto
the appliance, You should screw it with
Your own screwdriver,
Mains connection
● Prior to connection, it is recommended
to set the temperature control knob to an
„OFF” or other position that disconnects
the appliance from the power supply
(See page with the control description).
● This appliance should be connected to
AC 220-240V 50Hz supply socket. The
socketmustbettedproperly,andmust
be supplied with an earthing conduit and
a 10A fuse.
● It is a legal requirement that the applian-
ce is properly earthed. The manufacturer
will not be held liable for any damage or
injury which may result from the failure
tofullthisrequirement.
● Do not use adapters, multiple sockets
and two-wire extension leads. If it is
necessary to use the extension lead, it
must be equipped with a protection ring
and a single socket and must have a
VDE/GSsafetycerticate.
● If an extension lead is used (with a
protectionringandsafetycerticate),its
socket must be located at a safe distan-
ce, away from the sinks, and must not
beinaplacewhereitcouldbeooded
by water or waste water.
● Seethetypeplateatthelowerpartofthe
internal wall of the appliance for detailed
specications**.
Disconnecting the mains
● Makesuretheappliancecanbeeasily
disconnected from the mains, either by
pulling the plug out of the mains socket,
or by switching the two-pole switch off
(g.9).

13
OPERATION AND FUNCTIONS
EN
Control panel (Fig. 10).
1. Bulb cover
2. Thermostat
Temperature adjustment
Turning the knob to a different setting changes the temperature in the fridge-freezer.
Available knob settings:
• appliance switched off - OFF/0 setting
• maximum temperature - 1 setting
• optimal temperature - 2-6 setting
• minimum temperature - 7 setting
Do not put food into the fridge freezer befo-
re it has reached its operating temperature,
which takes minimum 4 hours.
Temperature inside the fridge / freezer chamber
Do not change the temperature settings due to the change in the season of the year. The ambient tem-
perature increase will be detected by the sensor and the compressor will be switched on automatically
for a longer period of time in order to maintain the temperature set inside the chambers.
Minor changes in temperature
The slight changes in temperature are perfectly normal and may occur, for instance during the storage
of great quantities of fresh products in the fridge, or when the door is open for a longer period of time.
This will not affect the condition of the stored foodstuff, and the temperature will quickly return to its set
value.
Replace the light bulb*
● Set the knob to „OFF”, then unplug the appliance.
● Remove the bulb cover (Fig. 18).
● Replace the bulb with one having identical parameters as the bulb factory pre-installed in the ap-
pliance (E14 thread, 220-240V, max 10W, maximum dimensions: diameter 26 mm, length 55 mm).
● Replace the bulb cover.
Bulbs of a higher or lower power should not be used, only use bulbs of the specication given
above.
The light bulb must not be used for room illumination.
* Applicable to appliances factory designed for incandescent lighting, and selected appliances equip-
ped with LED lighting in the form of a E14 thread light bulb.

14
OPERATION AND FUNCTIONS
EN
Storage of food in the fridge-freezer
Observe the following recommen- dations to
ensure the food remains fresh.
● The products should be placed on plates, in
containers or packed in food wrap. Di- stribute
them evenly l over the shelves.
● Ifthefoodcontactstherearwall,itmaycause
frosting or wetting of the products.
● Donotputdisheswithhotfoodtintothefridge
● Productswhichabsorbavours easily such as
butter, milk, white cheese and products with in-
tenseavour,suchassh,smokedmeat,hard
cheese must be placed on shelves, packed in
food wrap or in tightly sealed containers.
● Thestorageofvegetablescontainingsignicant
quantities of water will cause the deposition of
condensation on the vegetable containers, it
does not impact on the proper functioning of the
fridge.
● Beforeputtingthevegetablesintothefridge,dry
them well.
● Excessivemoistureshortenstheshelflifeofve-
getables, especially the leafed vegeta- bles.
● Donotwashthevegetablesbeforestoringinthe
refrigerator. Washing removes the natural pro-
tection, therefore it is better to wash the vegeta-
bles directly before con- sumption.
● Itisrecommendedtoplacetheproductsinfre-
ezer drawers 1, 2, 3* up to natural loading capa-
city (Fig. 11a / 11b).**
1. Packed products
2. Shelf
3. Natural loading capacity
4. (*/***)
● Stacking of products on the freezer shelves is
acceptable.*
● It is acceptable to place products beyond the
natural loading capacity by 20-30 mm.**
● Inordertoincreasetheloadingcapacityofthe
freezer chamber and allow the stacking of pro-
ducts on the freezer evaporator wire shelves up
to maximum height it is possi- ble to remove dra-
wers 1 and 2.*
Freezing food**
● Practicallyallthefoodproducts, exceptforve-
getables consumed raw, such as lettuce can be
frozen.
● Onlyfoodproductsofthehighestquality,divided
into small portions for single use, should be fro-
zen.
● Productsshouldbepackedinmaterialsthatare
odourless, resistant to air and moisture pene-
tration, and not susceptible to fat. Plastic bags,
polyethylene and aluminium sheets are the best
wrapping materials.
● Thepackagingshouldbetightandshouldstickto
the frozen products. Do not use glass containers.
● Keep fresh and warm foodstuff at am- bient
temperature away from the products, which have
already been frozen.
● Weadviseyounottoplacemoreoffreshfood
at a time to the freezer per day (see table witch
technicalspecication).
● Inordertomaintainoptimumqualityofthefrozen
food, reorganise the food that is in the middle of
the freezer, so that it does not touch the products
that are not yet frozen.
● It is recommended that you move the already
frozen products to one side and place the fresh
products that are to be frozen on the opposite
side, as close to the rear and side walls as po-
ssible.
● Tofreezingproducts,usespacemarked(*/***).
● Bear in mind that the temperature in the fre-
ezer is affected by several factors, including
the ambient temperature and the quantity of
food products in the chamber, the frequency
of opening the door, the amount of frost in the
freezer, and the thermostat setting.
● If you cannot open the freezer door immedia-
tely after closing it, allow 1-2 minutes for the
negative pressure to com- pensate, and try
again to open the door.
The storage time for frozen products depends on
their quality before freezing when fresh, and on the
storage temperature. The following storage periods
are recommended when the temperature of -18°C
or lower is maintained::
Products Months
Beef 6-8
Veal 3-6
Giblets 1-2
Pork 3-6
Poultry 6-8
Eggs 3-6
Fish 3-6
Vegetables 10-12
Fruit 10-12
Do not store frozen food in rapid cooling cham-
ber. Ice cubes can be prepared and stored in this
chamber.***
* Applicable to appliances with a freezer com-
partment at the bottom of the appliance.
** Applicable to appliances with a freezer com-
partment (*/***)
*** Not applicable to appliances with a freezer
compartment marked (*/***)

15
USING THE REFRIGERATOR EFFICIENTLY
Practical everyday tips
● Donotplacefridgesorfreezersnexttoradiators,
heaters, stoves or in direct sunlight.
● Makesurethatairventsarenotcoveredupand
clean the dust off them once or twice a year.
● Select the righttemperature: 6to 8°Cinyour
refrigeratorand-18°Cinyourfreezerissufcient.
● Whenonholiday,turnupthetemperatureinyour
fridge.
● Onlyopenyourfridgeorfreezerwhennecessary.
It helps if you know what food each contains and
where it is located. Return food to the fridge or
freezer as soon as possible after you have used
it so that it does not warm up too much.
● Wipetheinsideofyourfridgeregularlywitha
cloth soaked in a mild detergent. Appliances
which are not self-defrosting will require regular
defrosting. Do not allow frost layers thicker than
10 mm to form.
● Keepthesealaroundthedoorclean,otherwise
it will not shut properly. Always replace broken
seals.
Understanding the stars
*  Temperatureisatleast-6°C;sufcienttostore
frozen food for about a week. Drawers or com-
partments marked with one star used to be a
feature of (mostly) cheaper fridges.
** Food can be stored at -12°C or below for 1-2
weeks without losing its taste. Not suitable for
freezing food.
*** This rating is mainly used to store foods at -18°C
or below. Can also be used to freeze up to 1
kilogram of fresh food.
**** This appliance is suitable for storing foods at
-18°C or below and freezing larger quantities of
fresh foods.
Storage zones in the refrigerator
● Due to the natural circulation of the air in the
appliance, there are different temperature zones
in the refrigerator chamber.
● Thecoldestareaisdirectlyabovethevegetables
drawers. Use this area for all delicate and highly
perishable food e.g.
- Fish, meat, poultry
- Sausage products, ready meals
- Dishes or baked goods containing eggs or
cream
- Fresh dough, cake mixtures
- Pre-packed vegetable and other fresh food with
a label stating it should be kept at a temperature
of approx 4oC.
● The warmest areais inthe top sectionof the
door. Use this for storing butter and cheese.
Food that should not be stored in a refrigerator
● Notallfoodissuitableforstoringintherefrige-
rator, particularly:
- Fruit and vegetables which are sensitive to
cold, such as bananas, avocado, papaya, pas-
sion fruit, aubergines, peppers, tomatoes and
cucumbers.
- Fruit which is not yet ripe
- Potatoes
Example of storing the food - see gure 12.
EN

16
DEFROSTING, WASHING AND MAINTENANCE
EN
Never clean the product’s casing or plastic parts
using solvents or strong, abrasive detergents (e.g.
washing powders or creams)! Use mild liquid de-
tergents and soft cloths only. Do not use sponges.
Defrosting the fridge***
● Frostsettlesontherearwallofthefridgechamber.
It is removed automatically. During the defrosting,
the condensate, which contains contaminants may
clog the opening in the through. Should it occur,
carefully unclog the opening with the cleaning plug
(fig. 13).
● The appliance operates in cycles: it refrigerates
(then the frost settles on the rear wall), and defrosts
(water flows down the rear wall)
Disconnect the appliance from the mains
before cleaning by removing the plug
from the mains socket or switching off
the fuse. Prevent water from penetrating
the control panel or the light.
● Donotusedefrostingaerosols.Theymaycause
the formation of an explosive mixture, or contain
solvents which may damage the plastic compo-
nents of the appliance and even be harmful to
health.
● Makesurethewaterusedforcleaningdoesnot
flow into the evaporation container through the
discharge opening.
● Thewholeappliance,exceptforthedoorgasket
must be cleaned with a mild cleaning detergent.
The door gasket should be cleaned with water
and wiped dry.
● Washalltheaccessories(vegetablecontainers,
door shelves, glass shelves, etc.).
Defrosting the freezer**
● It is recommended to combine defrosting the
appliance with washing it.
● Excessiveaccumulationoficeonthefreezing
areas impairs the appliance’s freezing capacity
and increases the energy consumption.
● Defrost the appliance at least once or twice a
year. In case of a higher ice build-up, defrosting
must be carried out more frequently.
● If there is food in the freezer, set the knob to the
max. position about 4 hours before the planned
defrosting. This will ensure the possibility of
storing the food at the ambient temperature for
a longer time.
● Aftertakingthefoodoutofthefreezer,putitin
a container, wrap it with several layers of paper,
a blanket and store it at a cool place.
● Thedefrostingoperationshouldlastasshortas
possible. Long storage of food at the ambient
temperature shortens their shelf life.
In order to defrost the freezer chamber, you
must take the following steps:**
● Switch of the appliance using the control panel
and pull the plug out from the socket..
● Open the door and remove the food from the
freezer.
** Applicable to appliances with a freezer com-
partment (*/***) Not applicable to appliances
with a Frost-free System.
*** Applicable to appliances with a refrigerator
compartment Not applicable to appliances with
a Frost-free System.
**** Applicable to appliances with a Frost-free
System.
● Depending on the model, pull out the drainage
tube located in the bottom of the freezer com-
partment and place a suitable vessel underne-
ath.
● Leave the door open, this will speed up the de-
frost process. Additionally, a pot with hot water
(not boiling) may be placed inside the freezer
compartment.
● Wash the interior of the freezer and wipe it dry.
● Switch on the appliance as per the relevant
point in the manual.
Automatic fridge defrosting****
The fridge chamber has been equipped with an
automatic defrosting function. However, frost may
settle on the rear wall of the fridge chamber. This
happens usually, when large quantities of fresh
food products are stored in the fridge.
Automatic fridge defrosting****
The freezer chamber has been equipped with
an automatic defrosting function (no-frost). The
food is frozen in the cooled circulation air, and the
moisture from the freezer chamber is discharged
outside. As a result, no ice and frost is produced
in the freezer and the products do not freeze on
each other.
Washing the fridge and freezer chambers
manually****
It is recommended to wash the fridge and freezer
chambers at least once a year. This prevents the
formation of bacteria and bad odours. Switch off
the appliance, using button (1), remove the food
from the chambers and wash them using water
with a mild detergent. Then, wipe the chambers
dry with a cloth.
Taking out and putting in the shelves
Slide the shelf out, then slide it in as much as po-
ssibleso that its clampcould tthe guide groove
(g.15).
Taking out and putting in the door shelf
Lift the door shelf, remove it and put it back from
thetopintoitsrequiredposition(g.16).
You must not put an electric heater,
a heating fan or a hair dryer into the
freezer by any means.

17
TROUBLE-SHOOTING
Problems Possible causes Remedies
The appliance does
not work The electric circuit is disrupted
- check whether the plug is properly inserted into
the socket
- check whether the power cable of the appliance is
not damaged
- check whether there is voltage in the socket, by
plugging another appliance, e.g. a night lamp
- check whether the appliance is switched on by
setting the thermostat to a position above 0.
The lighting inside
the chamber does
not work
The bulb is loose or fused (only appliances
with bulb lightning type)
-tthebulbcorrectlyorreplaceit(seesectionabove
“Replacing the interior light bulb)
Temperature inside
the appliance is not
low enough or too
high
Incorrect setting of the adjustment knob - reset the knob to a higher position
The ambient temperature is higher or lower
than the climate range from table with
technicalspecication
- the appliance is adapted to operation in the clima-
terangefromtablewithtechnicalspecication.
The appliance is located in a sunlit place or
near heat sources
- move the appliance to another place. Observe the
guidelines contained in the manual
Too much warm food loaded at a time
- wait 72 hours until the food becomes cool (fre-
ezes) and the required temperature is reached
inside the chamber
Internal air circulation obstructed - place the food and containers in such a way that
they do not touch the rear wall of the fridge
The air circulation at the back of the ap-
pliance is obstructed
- move the appliance min. 30 mm away from the
wall
The door of the frid- ge/freezer is opened
too often and/or remains open for too long
- reduce the frequency of opening the door and/or
shorten the time when door remains open
The door does not close completely - place the food and containers so that they would
not interfere with door closed
The compressor is switched on too rarely - check whether the ambient temperature is not
lower than climate class
Door gasket inserted incorrectly - press the gasket in
The appliance
works continuously
Incorrect setting of the adjustment knob - reset the knob to a lower position
See. ”Temperature inside the appliance
is not low enough for description of other
possible causes
See. ”Temperature inside the appliance is not low
enough for description of other possible remedies
Water collects in
the lower part of the
appliance
The water discharge opening is clogged
(depending on the model)
- clean the discharge opening (see the operating
manual – chapter entitled ”Defrosting the fridge”)
Internal air circulation obstructed - place the food and containers in such a way as
that they do not touch the rear wall of the fridge
The appliance
generates unusual
noise
Incorrect levelling of the appliance - level the appliance properly
The appliance is touching furniture and/or
other objects
- place the appliance at a location that ensures
proper clearances around it
Certain sounds can be heard during normal use of the refrigerator, which do not affect its correct operation.
Sounds, which can be easily prevented:
● noisecausedbytheappliancewhichisnotlevel-adjustthepositionwiththeadjustableturn-infrontfeet.Alterna-
tively, place pads made of soft material under the rear rollers, especially when the appliance is placed on tiles.
● touchingtheadjacentpieceoffurniture-movetherefrigeratoraway.
● creakingofthedrawersorshelves-takeoutandputbackthedrawerorshelf.
● soundsofclinkingbottles-movebottlesapart.
Sounds heard during normal use are mainly due to operation of the thermostat, compressor (switching on) and cooling
system(thermalexpansionandcontractionoftheradiatorcausedbyowofthecoolingagent).
EN

18
ENVIRONMENTAL PROTECTION
Ozone layer protection
The refrigerants and
foaming agents, which are
100% free of FCKW and
FKW have been used for
manufacturing our product.
Therefore we are helping
to protect the ozone layer
and prevent the increase of
greenhouse effects. Also,
the innovative technology and environmental-
ly friendly insulation help in reducing energy
consumption.
Recycling of the packaging
Our packaging are made of
environmentally friendly mate-
rials, which can be reused:
● The external packaging is made of cardbo-
ard/foil
● The FCKW free shape of foamed polystyre-
ne (PS)
● Polyethylene (PE) foils and bags
ELIMINATION / DISPOSAL OF THE EQU-
IPMENT
If the appliance is no
longer in use, cut the
connecting cable off the
used equipment before its
scrapping. Also, remove
the appliance lock or
render it useless so that
the appliance presents no
danger to children while being stored for
di- sposal. This appliance is marked with a
symbol of the crossed out waste container
in conformance with the European Directi-
ve 2002/96/EC. Such marking informs that
the equipment may not be kept together
with other waste coming from the house-
hold after the period of its use. The user
is obliged to dispose of the appliance at
the waste collection point. The local waste
collection points, shops and communal
units form an appropriate system enabling
the disposal of the equipment.
Handling the used electrical and electro-
nic equipment properly contributes to the
avoidance of consequences harmful to the
human health and natural environment,
resulting from the presence of hazardous
substances and improper storage and
processing of such equipment.
CLIMATE RANGE
Climate range Permissible ambient
temperature
SN from +10°C to +32°C
N from +16°C to +32°C
ST from +16°C to +38°C
T from +16°C to +43°C
The information about the climate range of the appliance is provided on the rated plate. It indicates at which ambient
temperature (that is, room temperature, in which the appliance is working) the operation of the appliance is optimal
(proper).
Manufacturer’s Declaration
The manufacturer hereby declares that this product meets the requirements of the following European
directives:
● Low Voltage Directive 2006/95/EC,
● Electromagnetic Compatibility (EMC) Directive 2004/108/EC,
● ErP Directive 2009/125/EC
and has thus been marked with the symbol and been issued with a declaration of compliance made
available to market regulators.
EN

19
WARRANTY AND AFTER-SALE SERVICES
Warranty
Warranty service as stated on the warranty card
The manufacturer shall not be held liable for any damage caused by improper use of the product.
EN
ITEMS OF EQUIPMENT
FK328.3F FK328.3FX FK338.6GWF FK338.6GBF
Glass shelf 3 3 3 3
Glass shelf over the containers 1 1 1 1
Vegetable container 2 2 2 2
Egg tray 1 1 1 1
Large door shelf 1 1 1 1
Medium door shelf 2 2 2 2
Small door shelf 2 2 2 2
Cleaning plug 1 1 1 1
Freezer shelf 3 3 3 3
Wire handle in lower door shelf - - 1 1
1 Light
2 Glass shelf
3 Bottle rack
4 Cleaning plug
5 Glass shelf over the containers
6 Vegetable container
7 Frozen fruit tray
8 Freezer shelf
9 Draining tube
10 Upper door shelf
11 Egg tray
12 Medium door shelf
13 Small door shelf
14 Large door shelf
15 Condenser
16 Condensate tray
17 Compressor
18 Control Panel

IO-REF-0016/2
(04.2015)
