Amica VKSR 354 150 R User manual

Refrigerator / Kühlschrank / Chladnička / Chladnička /
Réfrigérateur / Koelkast / Hladnjak / Hladilnik
VKSR 354 150 R
VKSR 354 150 B
VKSR 354 150 T
IO-REF-0518
(07/2018)
OPERATING INSTRUCTIONS EN
GEBRAUCHSANWEISUNG DE
NÁVOD K OBSLUZE CS
NÁVOD NA OBSLUHU SK
NOTICE D’UTILISATION FR
GEBRUIKSAANWIJZING NL
UPUTE ZA UPORABU HR
NAVODILO ZA UPORABO SL

- 2 -
GUIDELINES CONCERNING THE SAFETY OF USE 12
INSTALLATION AND OPERATING CONDITIONS OF THE APPLIANCE 15
INSTALLATION BEFORE USING THE APPLIANCE FOR THE FIRST TIME 15
MINIMUM DISTANCES FROM THE HEAT SOURCES 15
MAINS CONNECTION 16
DISCONNECTING THE MAINS 16
CLIMATE RANGE 16
UNPACKING 17
DISPOSAL OF OLD APPLIANCE 18
CONTROLS 19
APPLIANCE CONTROLS 19
ADJUST TEMPERATURE INSIDE THE APPLIANCE 19
ADDITIONAL INFORMATION ON THE TEMPERATURE 20
LIGHTING 20
REPLACE THE LIGHT BULB 20
OPERATION AND FUNCTIONS 21
STORAGE OF FOOD IN THE FRIDGE-FREEZER 21
FREEZING FOOD** 21
USING THE REFRIGERATOR EFFICIENTLY 23
PRACTICAL EVERYDAY TIPS 23
UNDERSTANDING THE STARS 23
PRACTICAL TIPS 24
FOOD THAT SHOULD NOT BE STORED IN A REFRIGERATOR 24
DEFROSTING, WASHING AND MAINTENANCE 25
DEFROSTING THE FRIDGE*** 25
DEFROSTING THE FREEZER** 25
DEFROST THE FREEZER CHAMBER FOLLOWING STEPS:** 26
AUTOMATIC FRIDGE DEFROSTING**** 26
AUTOMATIC FRIDGE DEFROSTING**** 26
WASHING THE FRIDGE AND FREEZER CHAMBERS MANUALLY**** 26
TAKING OUT AND PUTTING IN THE SHELVES***** 26
TAKING OUT AND PUTTING IN THE DOOR SHELF***** 26
TROUBLE-SHOOTING 27
WARRANTY AND AFTER SALES SERVICE 29
WARRANTY 29
EN- Table of contents

- 3 -
SICHERHEITSHINWEISE 31
INBETRIEBNAHME UND BETRIEBSBEDINGUNGEN DES GERÄTES 34
VORBEREITUNG FÜR DEN ERSTEN BERIEB 34
MINDESTABSTÄNDE ZU WÄRMEQUELLEN 34
ELEKTRISCHER ANSCHLUSS 35
GERÄT VOM STROMNETZ TRENNEN 35
KLIMAKLASSE 35
AUSPACKEN 36
ENTSORGUNG VON ALTGERÄTEN 37
STEUERUNG 38
STEUERUNG DES GERÄTES 38
EINSTELLUNG DER TEMPERATUR IM GERÄT 38
WEITERE INFORMATIONEN ZUR TEMPERATUR 39
BELEUCHTUNG 39
WECHSEL DER BELEUCHTUNG 39
BEDIENUNG UND FUNKTIONEN 40
AUFBEWAHREN DER LEBENSMITTEL IM KÜHL- UND GEFRIERRAUM 40
TIEFKÜHLUNG DER LEBENSMITTEL** 40
ENERGIESPARENDE NUTZUNG DES KÜHLSCHRANKS 42
PRAKTISCHE RATSCHLÄGE 42
WAS BEDEUTEN DIE STERNE? 42
ZONEN IM KÜHLSCHRANK 43
PRODUKTE, DIE NICHT IM KÜHLSCHRANK AUFBEWAHRT WERDEN SOLLTEN. 43
ABTAUEN, REINIGEN UND PFLEGEN 44
ABTAUEN DES KÜHLRAUMES*** 44
ABTAUEN DES GEFRIERRAUMES** 44
ABTAUENDES GEFRIERRAUMES:** 45
AUTOMATISCHE ABTAUUNG DES KÜHLRAUMES**** 45
AUTOMATISCHE ABTAUUNG DES GEFRIERRAUMES**** 45
REINIGEN DES KÜHL- UND GEFRIERRAUMES**** 45
EINBAU UND AUSBAU DER ABSTELLPLATTEN ***** 45
EINBAU UND AUSBAU DER TÜRFÄCHER ***** 45
LOKALISIERUNG VON STÖRUNGEN 46
GARANTIE, NACHVERKAUF-SERVICE 48
GARANTIE 48
DE- Inhaltsverzeichnis

- 4 -
POKYNY TÝKAJÍCÍ SE BEZPEČNOSTI POUŽÍVÁNÍ 50
INSTALACE A PROVOZNÍ PODMÍNKY SPOTŘEBIČE 53
INSTALACE PŘED PRVNÍM SPUŠTĚNÍM 53
MINIMÁLNÍ VZDÁLENOSTI OD TEPELNÝCH ZDROJŮ 53
PŘIPOJENÍ NAPÁJENÍ 54
ODPOJENÍ OD NAPÁJENÍ 54
KLIMATICKÁ TŘÍDA 54
VYBALENÍ 55
LIKVIDACE OPOTŘEBOVANÝCH ZAŘÍZENÍ 56
OVLÁDÁNÍ 57
OVLÁDÁNÍ ZAŘÍZENÍ 57
REGULACE TEPLOTY UVNITŘ ZAŘÍZENÍ 57
DALŠÍ INFORMACE O TEPLOTĚ 58
OSVĚTLENÍ 58
VÝMĚNA OSVĚTLENÍ 58
OBSLUHA A FUNKCE 59
UCHOVÁVÁNÍ POTRAVIN V CHLADNIČCE A MRAZNIČCE 59
ZMRAZOVÁNÍ VÝROBKŮ** 59
JAK EKONOMICKY POUŽÍVAT CHLADNIČKU 61
PRAKTICKÉ PORADY 61
CO ZNAMENAJÍ HVĚZDIČKY? 61
ZÓNY V CHLADNIČCE 62
PRODUKTY, KTERÉ BY NEMĚLY BÝT PŘECHOVÁVANÉ V CHLADNIČCE 62
ODMRAZOVÁNÍ, MYTÍ A ÚDRŽBA 63
ODMRAZOVÁNÍ CHLADNIČKY*** 63
ODMRAZOVÁNÍ MRAZNIČKY** 63
PRO ODMRAZENÍ MRAZICÍHO PROSTORU MRAZNIČKY JE TŘEBA** 64
AUTOMATICKÉ ODMRAZOVÁNÍ CHLADNIČKY**** 64
AUTOMATICKÉ ODMRAZOVÁNÍ MRAZNIČKY**** 64
RUČNÍ MYTÍ MRAZICÍHO PROSTORU CHLADNIČKY A MRAZNIČKY**** 64
VYTAHOVÁNÍ A VKLÁDÁNÍ POLIC ***** 64
VYTAHOVÁNÍ A VKLÁDÁNÍ DVEŘNÍHO REGÁLU ***** 64
URČOVÁNÍ ZÁVAD 65
ZÁRUKA, POPRODEJNÍ SERVIS 67
ZÁRUKA 67
CS- Obsah

- 5 -
DÔLEŽITÉ BEZPEČNOSTNÉ POKYNY 69
INŠTALÁCIA A PREVÁDZKOVÉ PODMIENKY SPOTREBIČA 72
INŠTALÁCIA PRED PRVÝM SPUSTENÍM 72
MINIMÁLNE VZDIALENOSTI OD TEPELNÝCH ZDROJOV 72
PRIPOJENIE NAPÁJANIA 73
ODPOJENIE OD NAPÁJANIA 73
KLIMATICKÁ TRIEDA 73
ROZBALENIE 74
LIKVIDÁCIA ZARIADENÍ 75
OVLÁDANIE 76
OVLÁDANIE ZARIADENIA 76
NASTAVENIE TEPLOTY VO VNÚTRI ZARIADENIA 76
DODATOČNÉ INFORMÁCIE O TEPLOTE 77
OSVETLENIE 77
VÝMENA OSVETLENIA 77
OBSLUHA A FUNKCIE 78
UCHOVÁVANIE POTRAVÍN V CHLADNIČKE A MRAZNIČKE 78
ZMRAZOVANIE VÝROBKOV** 78
AKO EKONOMICKY POUŽÍVAŤ CHLADNIČKU 80
PRAKTICKÉ RADY 80
ČO ZNAMENAJÚ HVIEZDIČKY? 80
ZÓNY V CHLADNIČKE 81
PRODUKTY, KTORÉ BY NEMALI BYŤ PRECHOVÁVANÉ V CHLADNIČKE 81
ODMRAZOVANIE, UMÝVANIE A ÚDRŽBA 82
ODMRAZOVANIE CHLADNIČKY*** 82
ODMRAZOVANIE MRAZNIČKY** 82
PRE ODMRAZENIE MRAZIACEHO PRIESTORU MRAZNIČKY JE POTREBA** 83
AUTOMATICKÉ ODMRAZOVANIE CHLADNIČKY**** 83
AUTOMATICKÉ ODMRAZOVANIE MRAZNIČKY**** 83
RUČNÉ UMÝVANIE KOMORY CHLADNIČKY A MRAZNIČKY**** 83
VYŤAHOVANIE A VKLADANIE POLÍC***** 83
VYŤAHOVANIE A VKLADANIE PRIEHRADKY***** 83
LOKALIZÁCIA ZÁVAD 84
ZÁRUKA, POPREDAJNÝ SERVIS 86
ZÁRUKA 86
SK- Obsah

- 6 -
CONSIGNES DE SECURITÉ D’UTILISATION 88
INSTALLATION ET CONDITIONS DE FONCTIONNEMENT DE L’APPAREIL 91
INSTALLATION AVANT LA PREMIÈRE MISE EN MARCHE 91
LES DISTANCES MINIMUMS DES SOURCES DE CHAUFFAGE 91
RACCORDEMENT AU RÉSEAU ÉLECTRIQUE 92
MISE HORS CIRCUIT 92
CLASSE CLIMATIQUE 92
DÉBALLAGE 93
ÉLIMINATION DES APPAREILS USAGÉS 94
COMMANDE 95
COMMANDE DE L’APPAREIL 95
RÉGLAGE DE LA TEMPÉRATURE À L’INTÉRIEUR DE L’APPAREIL 95
INFORMATIONS SUPPLÉMENTAIRES SUR LA TEMPÉRATURE 96
ÉCLAIRAGE 96
REMPLACEMENT DE L’ÉCLAIRAGE 96
UTILISATION ET FONCTIONS 97
CONSERVATION DES DENRÉES DANS LE RÉFRIGÉRATEUR 97
CONGÉLATION DES PRODUITS** 97
COMMENT EXPLOITER LE REFRIGERATEUR DE FAÇON ECONOMIQUE? 99
CONSEILS PRATIQUES 99
QUE VEULENT DIRE LES ÉTOILES? 99
ZONES DE STOCKAGE DANS LE RÉFRIGÉRATEUR 100
PRODUITS QUI NE DEVRAIENT PAS ÊTRE STOCKÉS DANS LE RÉFRIGÉRATEUR 100
DÉGIVRAGE, NETTOYAGE ET CONSERVATION 101
DÉGIVRAGE DU RÉFRIGÉRATEUR*** 101
DÉGIVRAGE DU CONGÉLATEUR** 101
MODE OPÉRATOIRE POUR LE DÉGIVRAGE DU COFFRE DU CONGÉLATEUR:** 102
DÉGIVRAGE AUTOMATIQUE DU RÉFRIGÉRATEUR**** 102
DÉGIVRAGE AUTOMATIQUE DU CONGÉLATEUR**** 102
LAVAGE À MAIN DU COMPARTIMENT RÉFRIG ÉRATEUR ET CONGÉLATEUR**** 102
ENLÈVEMENT ET MISE EN PLACE DES CLAYETTES ***** 102
ENLÈVEMENT ET MISE EN PLACE DU BALCONNET ***** 102
LOCALISATION DES PANNES 103
GARANTIE, SERVICE APRÈS-VENTE 105
GARANTIE 105
FR- Table des matières

- 7 -
AANWIJZINGEN BETREFFENDE VEILIGHEID VAN GEBRUIK 107
INSTALLATIE EN WERKOMSTANDIGHEDEN VAN HET APPARAAT 110
INSTALLATIE VOOR DE EERSTE INGEBRUIKNAME 110
MINIMALE AFSTANDEN VAN WARMTEBRONNEN 110
AANSLUITEN OP HET ELECTRICITEITSNET 111
UITSCHAKELEN 111
KLIMAATKLASSE 111
UITPAKKEN 112
VERWIJDERING VAN GEBRUIKTE APPARATUUR 113
BEDIENING 114
BEDIENING VAN HET APPARAAT 114
REGELEN VAN DE TEMPERATUUR IN HET APPARAAT 114
AANVULLENDE INFORMATIE BETREFFENDE DE TEMPERATUUR 115
VERLICHTING 115
VERVANGING VAN DE VERLICHTING 115
BEDIENING EN FUNCTIES 116
HET BEWAREN VAN PRODUCTEN IN DE KOELKAST 116
HET INVRIEZEN VAN PRODUCTEN** 116
HOE KAN DE KOELKAST ECONOMISCH GEBRUIKT WORDEN? 118
PRAKTISCHE TIPS 118
WAT BETEKENEN DE STERRETJES? 118
ZONES IN DE KOELKAST 119
LEVENSMIDDELEN DIE NIET IN DE KOELKAST BEWAARD MOGEN WORDEN 119
ONTDOOIEN, WASSEN EN ONDERHOUD 120
ONTDOOIEN VAN DE KOELKAST*** 120
ONTDOOIEN VAN DE DIEPVRIEZER** 120
OM DE VRIESRUIMTE TE ONTDOOIEN HANDELT U ALS VOLGT:** 121
AUTOMATISCH ONTDOOIEN VAN DE KOELKAST**** 121
AUTOMATISCH ONTDOOIEN VAN DE DIEPVRIEZER**** 121
HANDWASSEN VAN DE KOELKAST EN DIEPVRIEZER**** 121
UITHALEN EN INZETTEN VAN DE LEGPLATEAUS***** 121
PLAATSEN EN VERPLAATSEN VAN DE OPBERGVAK***** 121
STORINGEN VINDEN EN VERHELPEN 122
GARANTIE, SERVICE 124
GARANTIE 124
NL- Inhoudsopgave

- 8 -
VAŽNE SIGURNOSNE INFORMACIJE 126
INSTALACIJA I UVJETI RADA UREĐAJA 129
INSTALACIJA PRIJE PRVOG POKRETANJA 129
MINIMALNE UDALJENOSTI OD IZVORA TOPLINE 129
UKLJUČIVANJE U ELEKTRIČNU MREŽU 129
ISKLJUČIVANJE IZ ELEKTRIČNE MREŽE 130
KLIMATSKI RAZRED 130
UKLANJANJE PAKIRANJA 131
ZBRINJAVANJE POTROŠENIH UREĐAJA 132
UPRAVLJANJE 133
UPRAVLJANJE UREĐAJEM 133
REGULACIJA TEMPERATURE UNUTAR UREĐAJA 133
DODATNE INFORMACIJE O TEMPERATURI 134
RASVJETA 134
ZAMJENA ŽARULJE 134
UPORABA I FUNKCIJE 135
POHRANJIVANJE NAMIRNICA U HLADNJAKU I ZAMRZIVAČU 135
ZAMRZAVANJE NAMIRNICA** 135
EKONOMIČNA UPORABA HLADNJAKA 137
PRAKTIČNI SAVJETI 137
ŠTO ZNAČE ZVJEZDICE? 137
ZONE TEMPERATURA U HLADNJAKU 138
NAMIRNICE KOJE NE BI TREBALI ČUVATI U HLADNJAKU. 138
ODLEĐIVANJE, PRANJE I ODRŽAVANJE 139
ODLEĐIVANJE I PRANJE HLADNJAKA *** 139
ODLEĐIVANJE I PRANJE ZAMRZIVAČA** 139
U CILJU ODLEĐIVANJA KOMORE ZAMRZIVAČA:** 140
AUTOMATSKO ODLEĐIVANJE HLADNJAKA**** 140
AUTOMATSKO ODLEĐIVANJE ZAMRZIVAČA**** 140
RUČNO PRANJE HLADNJAKA I ZAMRZIVAČA.**** 140
VAĐENJE I UMETANJE POLICA***** 140
VAĐENJE I UMETANJE POLICE VRATA***** 140
RJEŠAVANJE PROBLEMA 141
JAMSTVO, POSLIJEPRODAJNE AKTIVNOSTI 143
JAMSTVO 143
HR- Kazalo

- 9 -
POMEMBNE VARNOSTNE NASTAVITVE 145
MONTAŽA IN POGOJI DELOVANJA NAPRAVE 148
INŠTALACIJA PRED PRVIM VKLOPOM 148
MINIMALNE ODDALJENOSTI OD TOPLOTNIH VIROV 148
POVEZAVA NAPAJANJA 149
ODKLOP OD NAPAJANJA 149
KLIMATSKI RAZRED 149
RAZPAKIRANJE 150
ODSTRANJEVANJE IZRABLJENIH NAPRAV 151
UPRAVLJANJE 152
UPRAVLJANJE NAPRAVE 152
REGULACIJA TEMPERATURE ZNOTRAJ NAPRAVE 152
DODATNE INFORMACIJE GLEDE TEMPERATURE 153
OSVETLITEV 153
MENJAVA OSVETLITVE 153
UPORABA IN FUNKCIJE 154
SHRANJEVANJE IZDELKOV V HLADILNIKU IN ZAMRZOVALNIKU 154
ZAMRZOVANJE IZDELKOV** 154
KAKO HLADILNIK UPORABLJAMO EKONOMIČNO 156
PRAKTIČNI NASVETI 156
KAJ POMENIJO ZVEZDICE? 156
TEMPERATURNE CONE V HLADILNIKU 157
IZDELKI, KI JIH NE SMETE SHRANJEVATI V HLADILNIKU 157
ODMRZOVANJE, ČIŠČENJE IN VZDRŽEVANJE 158
ODMRZOVANJE IN UMIVANJE HLADILNIKA *** 158
ODMRZOVANJE IN UMIVANJE ZAMRZOVALNIKA** 158
DA ODMRZNEMO KOMORO ZAMRZOVALNIKA, JE POTREBNO**: 159
AVTOMATIČNO ODMRZOVANJE HLADILNIKA**** 159
AVTOMATIČNO ODMRZOVANJE HLADILNIKA**** 159
ROČNO UMIVANJE NOTRANJOSTI HLADILNIKA IN ZAMRZOVALNIKA.**** 159
ODSTRANJEVANJE IN NAMEŠČANJE POLIC***** 159
ODSTRANJEVANJE IN NAMEŠČANJE BALKONOV***** 159
ZAZNAVA OKVARE 160
GARANCIJA, POPRODAJNE STORITVE 162
GARANCIJA 162
SL- Sadržaj

- 10 -
Dear customer,
From now on, your daily housework will be easier
than ever before. Your appliance is excepon-
ally easy to use and extremely ecient. Aer reading
these Operang Instrucons, operang the appliance
will be easy.
Before being packaged and leaving the manufacturer,
the appliance was thoroughly checked with regard to
safety and funconality.
Before using the appliance, please carefully read
these Operang Instrucons. By following these
instrucons carefully you will be able to avoid any
problems in using the appliance. It is important to
keep these Operang Instrucons and store them in a
safe place so that they can be consulted at any me.
Follow these instrucons carefully in order to avoid
possible accidents.
Sincerely,

- 11 -
GUIDELINES CONCERNING
THE SAFETY OF USE
• The appliance is intended for household use only.
• The manufacturer reserves the right to introduce
changes which do not aect the operation of the
appliance.
• Some provisions in this user manual are unied
for refrigerating products of dierent types (for a
refrigerator, refrigerator-freezer or freezer)
• The Manufacturer shall not be held liable for
damage arising from the failure to observe the
instructions contained in this manual.
• Keep this manual for future reference, or to pass
it over to the next user.
• This appliance is not intended for use by persons
(including children) with limited physical or men-
tal capabilities and persons who lack experience
or familiarity with the appliance.
• Do not allow children to use the appliance. Do
not allow them to play with the appliance. They
must not climb inside the drawers and swing on
the doors.
• The appliance operates properly at the ambient
temperature (see product che). Do not use it in
the cellar, unheated summer cottage during au-
tumn and winter.
• When placing, moving, lifting the appliance, do
not hold the door handles, do not pull the con-
denser at the rear part of the refrigerator and do
not touch the compressor unit.
• When transporting, moving or positioning the
fridge-freezer do not tilt it by more than 40°
from the vertical position. Should such a situa-
tion occur, the appliance should be switched on
after minimum 2 hours from its replacement in
the right position (g.2).

- 12 -
• Pull the plug out from the mains socket before
each maintenance activity. Do not pull on the
cord, but hold the body of the plug instead.
• The “cracking” sound, which the appliance may
emit is caused by the expansion and contraction
of parts as a result of temperature variations.
• For safety reasons do not repair the appliance
yourself. Repairs carried out by persons who do
not have the required qualications may result in
serious danger for the user of the appliance.
• Air the room in which the appliance is placed for
a few minutes (the size of the room for a product
containing isobuthane/R600a must be at least
4m3) to avoid damage to the cooling system.
• Do not refreeze partly thawed products.
• Do not store beverages in bottles and cans, espe-
cially carbonated beverages, in the freezer cham-
ber. The cans and the bottles may explode.
• Do not put frozen products, taken out directly
from the freezer (lollies, ice cubes, etc.) into your
mouth, their low temperature may cause severe
frostbite.
• Make sure you do not damage the cooling sys-
tem, by puncturing the refrigerant pipes in the
evaporator or breaking the pipes. The refrigerant
is ammable. If the refrigerant makes contact
with the eyes, rinse them with clean water and
call for medical assistance immediately.
• If the power wire gets broken, it should be re-
placed with a new one in a specialist repair shop.
• This appliance is intended for food storage, do
not use it for other purposes.
• When performing activities, such as cleaning,
maintenance or moving, the appliance must be
completely disconnected from power supply (by
pulling the plug out from the socket)
• This appliance can be used by children aged 8
years and older or by persons with physical, men-

- 13 -
tal or sensory handicaps, or by those who are
inexperienced or unfamiliar with the appliance,
provided they are supervised or have been in-
structed how to safely use the appliance and are
familiar with risks associated with the use of the
appliance. Ensure that children do not play with
the appliance. Cleaning and maintenance of the
appliance should not be performed by children
unless they are 8 years or older and are super-
vised by a competent person.
• In order to obtain more space in the freezer, you
can remove the drawers and place the food di-
rectly on the shelves. This has no eect on the
product mechanical properties and cooling per-
formance. Declared freezer capacity was calcu-
lated with the drawers removed.

- 14 -
INSTALLATION AND OPER-
ATING CONDITIONS OF THE
APPLIANCE
Installation before using the appliance for the rst time
• Take the product out of the package, remove the scotch tape protect-
ing the door and the equipment. Any remaining adhesive stains may
be removed with a mild washing agent.
• Do not throw away the polystyrene elements of the packaging. If it is
necessary to transport the fridge-freezer, pack it in the polystyrene
elements and lm as well as protect ing it with scotch tape
• Clean the interior surface of the fridge- freezer and the elements of
the equipment with a washing agent dissolved in lukewarm water,
then wipe it dry.
• Place the fridge-freezer on an even, at and stable surface, in dry,
aired and shaded room, far from the heat sources such as: oven,
hob, central heating radiators, central heating pipes, hot water in-
stallation, etc.
• On the exterior surface of the product may be a protective foil, this
foils should be removed.
• Make sure the appliance is placed in a horizontal position by screwing
in the 2 adjustable front legs (g. 3)
• To ensure that the door opens freely, the distance between the side
of the appliance (on door hinges side) and the wall is shown on gure
5.*
• Ensure adequate ventilation of the room and free air circulation from
all sides of the appliance (g. 6).*
Minimum distances from the heat sources
• from the electric gas and other ovens - 30 mm,
• from oil or coal red ovens - 300 mm,
• from built-in ovens - 50 mm
If there is no possibility of ensuring the above- mentioned distances,
provide an appropriate insulation board.
Warning:
• The rear wall of the refrigerator, in particular, the condenser and oth-
er elements of the cooling system must not contact other elements,
which may damage them, (e.g. central heating pipes and the water
supply pipes).
• It is forbidden to readjust or modify any parts of the unit. It is crucial
not to damage the capillary tube visible in the compressor recess.
The tube may not be bent, straightened or wound.
• If the capillary tube is damaged by the user the guarantee will be
void (g. 8).
• In some models the handle is put into the appliance, You should
screw it with Your own screwdriver,

- 15 -
Mains connection
• Prior to connection, it is recommended to set the temperature control
knob to an „OFF” or other position that disconnects the appliance
from the power supply (See page with the control description).
• This appliance should be connected to AC 220-240V 50Hz supply
socket. The socket must be tted properly, and must be supplied with
an earthing conduit and a 10A fuse.
• It is a legal requirement that the appliance is properly earthed. The
manufacturer will not be held liable for any damage or injury which
may result from the failure to full this requirement.
• Do not use adapters, multiple sockets and two-wire extension leads.
If it is necessary to use the extension lead, it must be equipped with
a protection ring and a single socket and must have a VDE/GS safety
certicate.
• If an extension lead is used (with a protection ring and safety certif-
icate), its socket must be located at a safe distance, away from the
sinks, and must not be in a place where it could be ooded by water
or waste water.
• See the type plate at the lower part of the internal wall of the appli-
ance for detailed specications**.
Disconnecting the mains
Make sure the appliance can be easily disconnected from the mains,
either by pulling the plug out of the mains socket, or by switching the
two-pole switch o (g. 9).
Climate range
The information about the climate range of the appliance is provided
on the rated plate. It indicates at which ambient temperature (that is,
room temperature, in which the appliance is working) the operation of
the appliance is optimal (proper).
Climate range Permissible ambient temperature
SN from +10°C to +32°C
N from +16°C to +32°C
ST from +16°C to +38°C
T from +16°C to +43°C
* Only free-standing appliances
** According to the model

- 16 -
UNPACKING
During transportation, protective
packaging was used to protect the
appliance against any damage. Af-
ter unpacking, please dispose of all
elements of packaging in a way that
will not cause damage to the environ-
ment.
All materials used for packaging the appliance are
environmentally friendly; they are 100% recyclable
and are marked with the appropriate symbol.
Important! Packaging materials (bags, polyethyl-
ene, polystyrene, etc.) should be kept away from
children during unpacking.

- 17 -
DISPOSAL OF OLD
APPLIANCE
In accordance with European Directive
2012/19/EU and Polish legislation re-
garding used electrical and electronic
goods, this appliance is marked with
the symbol of the crossed-out waste
container. This marking indicates that
the appliance must not be disposed
of together with other household waste after it has
been used.
The user is obliged to hand it over to waste collec-
tion centre collecting used electrical and electron-
ic goods. The collectors, including local collection
points, shops and local authority departments pro-
vide recycling schemes.
Proper handling of used electrical and electronic
goods helps avoid environmental and health haz-
ards resulting from the presence of dangerous com-
ponents and the inappropriate storage and process-
ing of such goods.

- 18 -
CONTROLS
Appliance controls
The control panel is shown in gure 10. For reference it is also shown
below:
2
1
1 — Light
2 — Temperature control dial
Adjust temperature inside the appliance
Turn the dial to adjust the temperature in the appliance:
OFF/0 position Appliance is o
Setting 1 The highest temperature inside the appliance
(warmer)
Settings 2-6 Medium temperature inside the appliance
Setting 7 The lowest temperature inside the appliance
(cooler)
Note:
• The temperature control dial in your appliance can be marked dif-
ferently than in this manual. The general principle of operation is
described above.
• If there is no position marked "OFF" or "0” on the dial, turn o your
appliance by unplugging the power cord from the wall outlet. Before
unplugging set the lowest setting on the temperature control dial.

- 19 -
Additional information on the temperature
• The temperature inside the appliance is inuenced by many factors.
How you set the temperature control dial depends on the ambient
temperature, sun exposure, how often you open the door and the
amount of food stored. The middle setting of the dial is most optimal
in most cases.
• Do not put food into the fridge freezer before it has reached its oper-
ating temperature, which takes minimum 4 hours.
• Do not change the temperature settings due to the change in the
season of the year. The ambient temperature increase will be detect-
ed by the sensor and the compressor will be switched on automati-
cally for a longer period of time in order to maintain the temperature
set inside the chambers.
• The slight changes in temperature are perfectly normal and may oc-
cur, for instance during the storage of great quantities of fresh prod-
ucts in the fridge, or when the door is open for a longer period of
time. This will not aect the condition of the stored foodstu, and the
temperature will quickly return to its set value.
LIGHTING
This section applies to units factory equipped with incandescent lightbulb
and selected appliances equipped with LED lighting with E14 thread.
Replace the light bulb
• Set the knob to "OFF", then unplug the appliance.
• Remove the bulb cover (Fig. 18).
• Replace the bulb with one having identical parameters as the factory
installed bulb (E14 thread, 220-240V, maximum dimensions: 26 mm
diameter, 55 mm length).
• Replace the bulb cover.
• Bulbs of a higher or lower power should not be used, only use bulbs
of the specication given above.
Note:
• The light bulb must not be used for room illumination.
• If Figure 18 is not shown in this manual, light source can only be
replaced by a qualied service technician.

- 20 -
OPERATION AND FUNCTIONS
Storage of food in the fridge-freezer
• The products should be placed on plates, in containers or packed in
food wrap. Distribute them evenly over the shelves.
• If the food contacts the rear wall, it may cause frosting or wetting of
the products.
• Do not put dishes with hot food into the fridge
• Products which absorb avours easily such as butter, milk, white
cheese and products with intense avour, such as sh, smoked meat,
hard cheese must be placed on shelves, packed in food wrap or in
tightly sealed containers.
• The storage of vegetables containing signicant quantities of water
will cause the deposition of condensation on the vegetable contain-
ers, it does not impact on the proper functioning of the fridge.
• Before putting the vegetables into the fridge, dry them well.
• Excessive moisture shortens the shelf life of vegetables, especially
the leafed vegetables.
• Do not wash the vegetables before storing in the refrigerator. Wash-
ing removes the natural protection, therefore it is better to wash the
vegetables directly before consumption.
• It is recommended to place the products in freezer drawers 1, 2, 3*
up to natural loading capacity (Fig. 11a / 11b).**
1. Packed products
2. Shelf
3. Natural loading capacity
4.
!
• Stacking of products on the freezer shelves is acceptable.*
• It is acceptable to place products beyond the natural loading capacity
by 20-30 mm.**
• In order to increase the loading capacity of the freezer chamber and
allow the stacking of products on the freezer evaporator wire shelves
up to maximum height it is possible to remove drawers 1 and 2.*
Freezing food**
• Practically all the food products, except for vegetables consumed
raw, such as lettuce can be frozen.
• Only food products of the highest quality, divided into small portions
for single use, should be frozen.
• Products should be packed in materials that are odourless, resistant
to air and moisture penetration, and not susceptible to fat. Plastic
bags, polyethylene and aluminium sheets are the best wrapping ma-
terials.
• The packaging should be tight and should stick to the frozen prod-
ucts. Do not use glass containers.
• Keep fresh and warm foodstu at ambient temperature away from
the products, which have already been frozen.
• We advise you not to place more of fresh food at a time to the freezer
per day (see table witch technical specication).
