Amica AWT714S User manual

WASHING MACHINES
AWT714S
IO-WMS-0476
(10.2017/1)
OPERATING
INSTRUCTIONS
EN
ONLY USE THE APPLIANCE WHEN YOU
HAVE READ AND UNDERSTAND THE
OPERATING
INSTRUCTIONS

2
ECOLOGY IN PRACTICE
BASIC INFORMATION
SAFETY AND GERMENT CARE LABELS
INSTALL THE APPLIANCE
PRODUCT DESCRIPTION
TROUBLESHOOTING
PRACTICAL TIPS ON WASHING
SPECIFICATIONS
PRODUCT FICHE
3
5
6
17
20
28
32
41
42
CONTENTS
In accordance with European Directive 2012/19/EU and Polish legislation regarding used
electrical and electronic goods, this appliance is marked with the symbol of the crossed-out
waste container.
This marking indicates that the appliance must not be disposed of together with other
household waste after it has been used. The user is obliged to hand it over to waste col-
lection centre collecting used electrical and electronic goods. The collectors, including local
collection points, shops and local authority departments provide recycling schemes. Proper
handling of used electrical and electronic goods helps avoid environmental and health haz-
ards resulting from the presence of dangerous components and the inappropriate storage
and processing of such goods.

3
For many years, Amica has consistently pursued pro-ecological policy.
Concern for the environment is as important for us as the use of modern technology. That's why
we focus on energy-ecient appliances of the highest energy eciency class — A+, A++ and
A+++.
The development of technology has enabled our factories to become more environmentally
friendly – we use less and less water, electricity and less waste water and solid waste is gener-
ated in the production.
A lot of attention is paid to materials used in production. We strive to use only those that do not
contain harmful substances and make recycling and safe disposal possible after use.
ECOLOGY IN PRACTICE

4
Dear customer!
Thank you for choosing an Amica product. For years we have deliv-
ered high-quality appliances, so that household chores become
a real pleasure. Before being packaged and leaving the manufac-
turer, the appliance was thoroughly checked with regard to safety
and functionality. We also endeavour to make sure that modern
technology in Amica products always goes hand in hand with a
unique design.
Before using the appliance, please carefully read these Operating
Instructions Follow these instruction to avoid improper use and
ensure long and reliable operation of the appliance. Learn the
principles of the safe use to avoid accidents.
Store these operating instructions in a safe place to use them for
reference whenever needed. These Operating Instructions contain
all the necessary information that will make the use of your Amica
appliance simple and fun. We also encourage you to nd out more
about other Amica appliances.
We hope using your new appliance is a pleasure.
MANUFACTURER’S DECLARATION

BASIC INFORMATION
Before plugging the washing machine into the mains, remove the safety packaging and
ensure the machine is level. The manufacturer reserves the right to introduce changes,
which do not aect operation of the appliance.
Temperatures below 0°C can damage the washing machine! In the event
of the machine being stored or transported in sub-zero temperatures, it
should be left to acclimatise in a temperature above 0°C for 8 hours before
being used.
This washing machine is intended for domestic use only to wash tex-
tiles and clothes designed to be machine washed in a detergent bath.
The manufacturer hereby declares that this product
meets the requirements of the following European
directives:
Low Voltage Directive, 2014/35/EU,
Electromagnetic Compatibility (EMC) Directive
2014/30/EE,
Eco-design Directive2009/125/EU,
RoHS Directive2011/65/EU,
and has been marked with the symbol and issued
with a declaration of compliance made available to
Carefully read the instructions below before using the appliance.
Never use the appliance outdoors or anywhere the temperature may fall below
freezing.
The machine should not be operated by children or anyone who has not read the
instructions.
USAGE
MANUFACTURER’S DECLARATION

SAFETY AND GERMENT CARE LABELS
The risk of death! This appliance should not be
used by children under 8 years
of age, persons with reduced
physical or mental capabilities,
and persons who do not have
sufficient skills to use this type
of appliance. Such persons
should be offered proper super-
vision or instructions on safe
handling of appliance and relat-
ed risks. Children must not play
with the appliance or perform
any maintenance-related activi-
ties. Children under 3 years of
age must be kept away from the
appliance unless continuously
supervised.
Children could get caught inside
the appliance and get into a life-
threatening situation.
Risk of suffocation! If you allow children to play with
the packaging/film or parts of
the package, they can get en-
tangled or put packaging over
their head and risk suffocation.
Keep packaging/plastic film or
parts of packaging out of reach
of children.
6

Risk of burns! If laundry is washed at high tem-
perature, door glass becomes
hot.
Prevent children from touching
the hot door.
Eye/skin irritation! Contact with detergents and
softeners may cause eye or skin
irritation. In case of eye/skin
contact, thoroughly rinse eyes/
skin to remove fabric detergent/
softener. Washing detergents
and fabric softeners should be
stored out of the reach of chil-
dren.
SAFETY AND GERMENT CARE LABELS
7

SAFETY AND GERMENT CARE LABELS
Risk of electric shock.
Risk of fire/damage to
property/appliance!
The power cord and the ground-
ed wall socket fit together and
the grounding system has been
properly installed.
Power cord cross section is suf-
ficient.
Power plug is always accessible.
If a miniature circuit-breaker is
used, always use a circuit-break-
er with the following designa-
tion:
This symbol is the only way to
make sure that all the necessary
requirements have been met.
8

Risk of fire/damage to
property/appliance! The use of extension cords or
splitters may result in fire due
to overheating or short circuit.
Connect the appliance directly
to a properly grounded wall
socket. Do not use extension
cords, splitters or power strips.
Health risk / risk of damage
to property/appliance! The appliance may vibrate or
displace while in use, poten-
tially causing injury or property
damage. Set the appliance on a
clean, level and hard surface us-
ing a level spirit.
If any protruding items are
caught by the appliance (e.g.
doors) when trying to lift or
move it, the item may come off
and cause injury.
Do not grasp any protruding
parts of the appliance to move
it.
SAFETY AND GERMENT CARE LABELS
9

SAFETY AND GERMENT CARE LABELS
Risk of injury! This appliance has sharp edges
that can cause a hand injury. Do
not hold the appliance by sharp
edges. Only lift the appliance
after you put on the gloves.
If the hoses or electrical cables
are not routed properly, you can
trip and sustain an injury. Rout
hoses and cables so that they do
not constitute a tripping hazard.
10

Important!
Damage to property/appli-
ance
Use only hoses supplied with
the appliance, or the original
hoses up designed for the appli-
ance.
The appliance is secured for
transport with transit bolts. If
you don’t remove transit bolts
before using the appliance, the
appliance may be damaged.
Remove all transit bolts before
using the appliance for the first
time.
Make sure you keep transit bolts
in a safe place for future use. If
the appliance will be transport-
ed, to avoid any damage, you
must reinstall the transit bolts.
SAFETY AND GERMENT CARE LABELS
11

SAFETY AND GERMENT CARE LABELS
Risk of poisoning! Cleaning agents containing
solvents may give off poisonous
vapours.
Do not use cleaning agents con-
taining solvents.
Risk of injury! Do not lean against/sit on open
appliance door as this can lead
to the appliance tipping over.
Do not lean against the open
door of the appliance.
Climbing on the appliance may
cause the worktop to break or
collapse and lead to an injury
Do not climb on the appliance.
Reaching into the drum while
is still rotates could injure your
hand.
Wait until the drum has come to
a standstill.
12

Eye/skin irritation! Fabric detergents and soften-
ers may splash, if the detergent
drawer remains open during
operation.
In case of eye/skin contact,
thoroughly rinse eyes/skin to
remove fabric detergent/sof-
tener.
In the event of accidental in-
gestion, consult your doctor.
SAFETY AND GERMENT CARE LABELS
13

SAFETY AND GERMENT CARE LABELSSAFETY AND GERMENT CARE LABELS
14

SAFETY AND GERMENT CARE LABELS
Risk of poisoning! Cleaning agents containing
solvents may give off poisonous
vapours.
Do not use cleaning agents con-
taining solvents.
Risk of electric shock / dam-
age to property / appliance! If water penetrates into the
appliance, it may cause a short
circuit.
Never use pressure washer or
steam cleaner to clean the ap-
pliance.
Health risk / risk of damage
to property/appliance! The use of third-party spare
parts and accessories is danger-
ous and may cause injury, dam-
age to property or appliance.
For safety reasons, use original
spare parts only.
SAFETY AND GERMENT CARE LABELS
15

SAFETY AND GERMENT CARE LABELS
Important!
Damage to property/appli-
ance
Make sure there is no contact
with the appliance surface.
Clean the appliance with a damp
cloth only.
UNDERSTANDING THE SYMBOLS ON CLOTHES LABELS
Washing
boil at 90°C normal wash at 60°C normal wash at 40°C Do NOT wash!
delicate handwash
Chemical cleaning
all solvents all except TRI petrol only NO
Dry clean!
Tumble dryer
normal low high Do NOT dry!
Ironing
110°C 150°C 200°C Do NOT Iron
16 Always pay attention to the symbols on garment labels
when choosing a washing programme.

UNDERSTANDING THE SYMBOLS ON CLOTHES LABELS
17
INSTALL THE APPLIANCE
unscrew the 4 transit bolts
remove the rubber and plastic transport
brackets from the sockets along with the
stop up the holes with the stoppers enclosed
in the accessories bag.
place the washing machine on a solid, level surface,
Level the appliance by adjusting the legs (1)
lock with washers (2)
loosen the plastic washer (2)
1
2
Remove the transit bolts
(keep the bolts for future use, e.g. when moving house).
Caution: the transit bolts MUST be removed before the wash-
ing machine is used!
After positioning and levelling the appliance, check that it is stable by pressing
down each corner and ensuring it does not move!
Position and level the washing machine

4
Use only the new hoses supplied with the machine. Do not re-use hoses.
A supply hose with seals is inside the drum of the machine.
Water pressure min 0.05 MPa (0.5 bar), max 1 MPa (10 bar).
The drain hose is at the back of the machine. Fix the drain hose so that it does
not move while the washing machine is in operation. If necessary, use the elbow
(1).
3
Connect the water supply
Water drain
1). after connecting, make sure the hose is not twisted
2) after connecting the hose and the valve, check they are sealed tight
3). regularly check the condition of the hose.
Supply the machine with cold water only.
18
Connection on the Connection on the
(1)

5
Electrical wall outlet where the appliance is connects must be
in a visible and accessible place,
Only plug the appliance into a properly installed socket with an
earthing pin,
Do not use an extension cord to connect
in the event of the power cord being damaged,
it must be replaced by an authorised service
technician,
the electrical system to which the appliance is to be connected must
be protected with a 10 A fuse.
Connect to power supply
19
Small items such as coins, paper clips, needles, etc., may damage the
laundry and the washing machine, you should therefore follow a few
important recommendations:
1). Empty pockets
2). Remove all metal items
3.) Delicate items such as bras or stockings should be washed in protective
mesh laundry bag
4). Close zippers and fasten buttons
Prepare to wash:

20
FEATURES AND COMPO-
NENTS
1. Detergent drawer
2. Drum
3. Control Panel
4. Door handle
5. Pump filter cover
DESCRIPTION OF THE APPLIANCE
Accessories:
Transport
hole plug
Hole plug
(optional) Inlet pipe
C
Inlet pipe H
(optional)
Outlet hose
support
(optional)
Other manuals for AWT714S
1
Table of contents
Other Amica Washer manuals

Amica
Amica AWI612L User manual

Amica
Amica WME612/1 User manual

Amica
Amica AWI714S User manual

Amica
Amica WA 461 030 User manual

Amica
Amica AWSN 10DA User manual

Amica
Amica AWT714S User manual

Amica
Amica WA 14 Ex User manual

Amica
Amica IO-WMS-0825 User manual

Amica
Amica WMA612 User manual

Amica
Amica WME712/1 User manual

Amica
Amica AWI814D User manual

Amica
Amica AWSM12D User manual

Amica
Amica AWN912DJB User manual

Amica
Amica WMS714 User manual

Amica
Amica AWP510L User manual

Amica
Amica WA 474 021 User manual

Amica
Amica AWB610L User manual

Amica
Amica AWN712D User manual

Amica
Amica WA 462 030 User manual

Amica
Amica AWB510LP User manual
