Amica WMS814 User manual

WASHING MACHINES
WMS814
IOWMS0814
10.2017/1
OPERATING INSTRUCTIONS
EN
ONLY USE THE APPLIANCE WHEN YOU HAVE READ
AND UNDERSTAND THE OPERATING
INSTRUCTIONS

2
ECOLOGY IN PRACTICE
BASIC INFORMATION
SAFETY AND GERMENT CARE LABELS
INSTALL THE APPLIANCE
PRODUCT DESCRIPTION
TROUBLESHOOTING
PRACTICAL TIPS ON WASHING
SPECIFICATIONS
PRODUCT FICHE
3
5
6
17
20
30
35
40
41
CONTENTS
In accordance with European Directive 2012/19/EU and Polish legislation regarding used elec-
trical and electronic goods, this appliance is marked with the symbol of the crossed-out waste
container.
This marking indicates that the appliance must not be disposed of together with other household
waste after it has been used. The user is obliged to hand it over to waste collection centre collect-
ing used electrical and electronic goods. The collectors, including local collection points, shops
and local authority departments provide recycling schemes. Proper handling of used electrical
and electronic goods helps avoid environmental and health hazards resulting from the presence
of dangerous components and the inappropriate storage and processing of such goods.

3
For many years, Amica has consistently pursued pro-ecological policy.
Concern for the environment is as important for us as the use of modern technology. That's why we
focus on energy-ecient appliances of the highest energy eciency class — A+, A++ and A+++.
The development of technology has enabled our factories to become more environmentally friendly
– we use less and less water, electricity and less waste water and solid waste is generated in the pro-
duction.
A lot of attention is paid to materials used in production. We strive to use only those that do not con-
tain harmful substances and make recycling and safe disposal possible after use.
ECOLOGY IN PRACTICE

4
Dear customer!
Thank you for choosing an Amica product. For years we have delivered
high-quality appliances, so that household chores become a real pleas-
ure. Before being packaged and leaving the manufacturer, the appli-
ance was thoroughly checked with regard to safety and functionality.
We also endeavour to make sure that modern technology in Amica
products always goes hand in hand with a unique design.
Before using the appliance, please carefully read these Operating
Instructions Follow these instruction to avoid improper use and ensure
long and reliable operation of the appliance. Learn the principles of the
safe use to avoid accidents.
Store these operating instructions in a safe place to use them for refer-
ence whenever needed. These Operating Instructions contain all the
necessary information that will make the use of your Amica appliance
simple and fun. We also encourage you to nd out more about other
Amica appliances.
We hope using your new appliance is a pleasure.
MANUFACTURER’S DECLARATION

BASIC INFORMATION
Before plugging the washing machine into the mains, remove the safety packaging and en-
sure the machine is level. The manufacturer reserves the right to introduce changes, which do
not aect operation of the appliance.
Temperatures below 0°C can damage the washing machine! In the event of the
machine being stored or transported in sub-zero temperatures, it should be left
to acclimatise in a temperature above 0°C for 8 hours before being used.
This washing machine is intended for domestic use only to wash textiles
and clothes designed to be machine washed in a detergent bath.
The manufacturer hereby declares that this product meets
the requirements of the following European directives:
Low Voltage Directive, 2014/35/EU,
Electromagnetic Compatibility (EMC) Directive 2014/30/
EE,
Eco-design Directive2009/125/EU,
RoHS Directive2011/65/EU,
and has been marked with the symbol and issued with
a declaration of compliance made available to market
regulators.
Carefully read the instructions below before using the appliance.
Never use the appliance outdoors or anywhere the temperature may fall below freezing.
The machine should not be operated by children or anyone who has not read the instruc-
tions.
USAGE
MANUFACTURER’S DECLARATION

SAFETY AND GERMENT CARE LABELS
The risk of death! This appliance should not be used
by children under 8 years of age,
persons with reduced physical or
mental capabilities, and persons
who do not have sufficient skills
to use this type of appliance. Such
persons should be offered proper
supervision or instructions on safe
handling of appliance and re-
lated risks. Children must not play
with the appliance or perform
any maintenance-related activi-
ties. Children under 3 years of age
must be kept away from the appli-
ance unless continuously super-
vised.
Children could get caught inside
the appliance and get into a life-
threatening situation.
Risk of suffocation! If you allow children to play with
the packaging/film or parts of the
package, they can get entangled
or put packaging over their head
and risk suffocation. Keep packag-
ing/plastic film or parts of packag-
ing out of reach of children.
Risk of poisoning! Washing detergents and fabric
softeners can cause poisoning if
ingested. In the event of acciden-
tal ingestion, consult your doctor.
Washing detergents and fabric
softeners should be stored out of
the reach of children.
6

Risk of burns! If laundry is washed at high tem-
perature, door glass becomes hot.
Prevent children from touching
the hot door.
Eye/skin irritation! Contact with detergents and
softeners may cause eye or skin
irritation. In case of eye/skin con-
tact, thoroughly rinse eyes/skin to
remove fabric detergent/softener.
Washing detergents and fabric
softeners should be stored out of
the reach of children.
Risk of electric shock.
Risk of fire/damage to prop-
erty/appliance!
If the appliance is not correctly in-
stalled, it may be dangerous. Make
sure that:
Mains voltage corresponds to the
voltage indicated on the appli-
ance nameplate
(identification plate)
The current load and required fuse
protection are specified on the
nameplate.
The appliance is connected to AC
source only through a properly in-
stalled and grounded wall socket
in accordance with national stand-
ards.
SAFETY AND GERMENT CARE LABELS
7

SAFETY AND GERMENT CARE LABELS
Risk of electric shock.
Risk of fire/damage to prop-
erty/appliance!
The power cord and the grounded
wall socket fit together and the
grounding system has been prop-
erly installed.
Power cord cross section is suffi-
cient.
Power plug is always accessible.
If a miniature circuit-breaker is
used, always use a circuit-breaker
with the following designation:
This symbol is the only way to
make sure that all the necessary
requirements have been met.
Risk of electric shock.
Risk of fire/damage to prop-
erty/appliance!
If the power cord is modified or
damaged, it may result in electric
shock, short circuit or fire due to
overheating.
The power cord must not be
kinked, crushed or modified or
come in contact with any heat
source.
8

Risk of fire/damage to prop-
erty/appliance!
The use of extension cords or
splitters may result in fire due to
overheating or short circuit. Con-
nect the appliance directly to a
properly grounded wall socket. Do
not use extension cords, splitters
or power strips.
Health risk / risk of damage
to property/appliance!
The appliance may vibrate or
displace while in use, potentially
causing injury or property dam-
age. Set the appliance on a clean,
level and hard surface using a
level spirit.
If any protruding items are caught
by the appliance (e.g. doors) when
trying to lift or move it, the item
may come off and cause injury.
Do not grasp any protruding parts
of the appliance to move it.
Risk of injury! The appliance is very heavy. Lift-
ing may cause injury. Do not lift
this appliance by yourself.
SAFETY AND GERMENT CARE LABELS
9

SAFETY AND GERMENT CARE LABELS
Risk of injury! This appliance has sharp edges
that can cause a hand injury. Do
not hold the appliance by sharp
edges. Only lift the appliance after
you put on the gloves.
If the hoses or electrical cables are
not routed properly, you can trip
and sustain an injury. Rout hoses
and cables so that they do not
constitute a tripping hazard.
Important!
Damage to property/appli-
ance
If the water level is too high or too
low, the appliance may not work
properly, which can cause damage
to property/appliance.
Make sure that water is supplied
under pressure of minimum 100
kPa (1 bar) and not exceeding
1000 kPa (10 bar).
If the water supplying hoses have
been modified or damaged, this
can cause damage to property/
appliance. The water supply hoses
must not be kinked, crushed,
modified or cut.
The use of third-party hoses to
connect the appliance to water
supply can cause damage to prop-
erty or the appliance.
10

Important!
Damage to property/appli-
ance
Use only hoses supplied with the
appliance, or the original hoses up
designed for the appliance.
The appliance is secured for trans-
port with transit bolts. If you don’t
remove transit bolts before using
the appliance, the appliance may
be damaged. Remove all transit
bolts before using the appliance
for the first time.
Make sure you keep transit bolts
in a safe place for future use. If the
appliance will be transported, to
avoid any damage, you must rein-
stall the transit bolts.
Risk of explosion/fire hazard! Laundry washed with detergents
that contain solvents and thin-
ners pose a risk of explosion in the
drum.
Thoroughly rinse laundry with
water before washing in the wash-
ing machine.
SAFETY AND GERMENT CARE LABELS
11

SAFETY AND GERMENT CARE LABELS
Risk of poisoning! Cleaning agents containing sol-
vents may give off poisonous
vapours.
Do not use cleaning agents con-
taining solvents.
Risk of injury! Do not lean against/sit on open
appliance door as this can lead to
the appliance tipping over.
Do not lean against the open door
of the appliance.
Climbing on the appliance may
cause the worktop to break or col-
lapse and lead to an injury
Do not climb on the appliance.
Reaching into the drum while is
still rotates could injure your hand.
Wait until the drum has come to a
standstill.
Risk of scalding! When washing at high tempera-
ture, there is a risk of scalding as
a result of contact with hot water
and detergent (e.g. when you
drain the water into the sink).
Do not put your hands in hot wa-
ter with detergent solution.
12

Eye/skin irritation! Fabric detergents and softeners
may splash, if the detergent draw-
er remains open during operation.
In case of eye/skin contact, thor-
oughly rinse eyes/skin to remove
fabric detergent/softener.
In the event of accidental inges-
tion, consult your doctor.
Important!
Damage to property/appli-
ance
If the amount of laundry in the
washing machine exceeds the
maximum load, it may not oper-
ate properly or cause damage to
property or the appliance.
Do not exceed the maximum load
capacity of dry laundry.
Do not exceed the maximum load
capacity for individual wash pro-
grammes.
Adding too much detergent or
fabric softener may cause damage
to property or the appliance.
Use fabric detergent/softener
according to the manufacturer's
instructions.
SAFETY AND GERMENT CARE LABELS
13

SAFETY AND GERMENT CARE LABELSSAFETY AND GERMENT CARE LABELS
The risk of death!! The appliance is powered by
electricity. Touching live elements
poses a risk of electric shock.
Therefore, remember:
Turn off the appliance:
Unplug the appliance from the
wall outlet.
We never grab the plug with wet
hands.
When pulling the plug, always
hold the plug, not the power cord,
because this can damage the
power cord.
Do not make any technical modi-
fications to the appliance or its
components.
Any repairs or other work on
the appliance must only be per-
formed by our service facility or by
an electrician. The same applies to
replacing the power cord (if nec-
essary).
You can order a spare power cord
in our service centres.
14

SAFETY AND GERMENT CARE LABELS
Risk of poisoning! Cleaning agents containing sol-
vents may give off poisonous
vapours.
Do not use cleaning agents con-
taining solvents.
Risk of electric shock / dam-
age to property / appliance!
If water penetrates into the appli-
ance, it may cause a short circuit.
Never use pressure washer or
steam cleaner to clean the appli-
ance.
Health risk / risk of damage
to property/appliance!
The use of third-party spare parts
and accessories is dangerous
and may cause injury, damage to
property or appliance.
For safety reasons, use original
spare parts only.
Important!
Damage to property/appli-
ance
Fabric cleaners, impregnating
agents, stain removers, pre-wash
agents, etc. may damage the ap-
pliance outer surface.
Therefore, remember:
SAFETY AND GERMENT CARE LABELS
15

SAFETY AND GERMENT CARE LABELS
Important!
Damage to property/appli-
ance
Make sure there is no contact with
the appliance surface.
Clean the appliance with a damp
cloth only.
UNDERSTANDING THE SYMBOLS ON CLOTHES LABELS
Washing
boil at 90°C normal wash at 60°C normal wash at 40°C Do NOT wash!
delicate handwash
Chemical cleaning
all solvents all except TRI petrol only NO
Dry clean!
Tumble dryer
normal low high Do NOT dry!
Ironing
110°C 150°C 200°C Do NOT Iron
16 Always pay attention to the symbols on garment labels when
choosing a washing programme.
“The wool wash programme used
in this washing machine has been
approved by Woolmark for wash-
ing garments made of wool. They
can be washed in this washing
machine, provided that the prod-
ucts are washed according to the
instructions on the garment label
and the washing machine operat-
ing instructions. M14111”.

UNDERSTANDING THE SYMBOLS ON CLOTHES LABELS
17
INSTALL THE APPLIANCE
unscrew the 4 transit bolts with
a spanner,
remove the rubber and plastic transport brackets
from the sockets along with the washers and bolts.
stop up the holes with the stoppers enclosed in
the accessories bag.
place the washing machine on a solid, level surface,
Level the appliance by adjusting the legs (1)
lock with washers (2)
loosen the plastic washer (2)
1
2
Remove the transit bolts
(keep the bolts for future use, e.g. when moving house).
Caution: the transit bolts MUST be removed before the washing
machine is used!
After positioning and levelling the appliance, check that it is stable by pressing down
each corner and ensuring it does not move!
Position and level the washing machine

4
Use only the new hoses supplied with the machine. Do not re-use hoses.
A supply hose with seals is inside the drum of the machine.
Water pressure min 0.05 MPa (0.5 bar), max 1 MPa (10 bar).
The drain hose is at the back of the machine. Fix the drain hose so that it does not
move while the washing machine is in operation. If necessary, use the elbow (1).
3
Connect the water supply
Water drain
1). after connecting, make sure the hose is not twisted
2) after connecting the hose and the valve, check they are sealed tight
3). regularly check the condition of the hose.
Supply the machine with cold water only.
18
Connection on the left Connection on the right
(1)

5
Electrical wall outlet where the appliance is connects must be in a
visible and accessible place,
Only plug the appliance into a properly installed socket with an
earthing pin,
Do not use an extension cord to connect
the appliance,
in the event of the power cord being damaged, it must
be replaced by an authorised service technician,
the electrical system to which the appliance is to be connected must be
protected with a 10 A fuse.
Connect to power supply
19
Small items such as coins, paper clips, needles, etc., may damage the laundry
and the washing machine, you should therefore follow a few important
recommendations:
1). Empty pockets
2). Remove all metal items
3.) Delicate items such as bras or stockings should be washed in protective
mesh laundry bag
4). Close zippers and fasten buttons
Prepare to wash:

20
FEATURES AND COMPONENTS
1. Detergent drawer
2. Drum
3. Control Panel
4. Door handle
5. Pump filter cover
DESCRIPTION OF THE APPLIANCE
Compartment A
use with liquid detergent.
Compartment II
detergent for the main wash, water softener,
bleach, stain remover.
Compartment
Fabric softener, liquid starch — do not exceed
the max level
Compartment I
Pre-wash detergent
4
5
3
1
2
A
