Amish Tables BROOKLYN 3 BD-8013 User manual

ITEM NO.: BD-8013
REVISED DEC 07, 2016
Printed in Vietnam
- 1 -
WARNING!
Serious or fatal injuries can occur from furniture tip over. Use tip over restraint (steel
band included) to secure this product to the wall.
ASSEMBLY INSTRUCTIONS
Description
Item No.
: BROOKLYN 3 DRAWER NIGHTSTAND
: BD-8013

ITEM NO.: BD-8013
REVISED DEC 07, 2016
Printed in Vietnam
- 2 -
Thank you for purchasing this quality product. This product has been designed for easy assembly and
constructed for durability. All parts were checked prior to packaging to insure quality. Prior to
beginning assembly, however, make sure all parts and hardware are included and free of obvious
defect. If a part is missing or defective, please contact the store where purchased. If hardware is
missing, or you need help with assembly, please call toll free 888-944-8396.
IMPORTANT NOTE:
-Place all wooden parts on a clean and smooth surface such as a rug or carpet to avoid the
parts from being scratched.
-Remove all wrapping material, including staples & packing straps before you start to assemble.
-DO NOT tighten all screws and bolts until completely assembled.
-Keep all hardware parts out of reach of children.
WARNING:
Long exposure to rubber or soft plastic may cause a chemical reaction and damage the finish
of your product. Protect the surface of the product with cloth if you are using any product
with rubber feet or base.
BEFORE ASSEMBLY
ASSEMBLY TOOLS REQUIRED
NOT INCLUDED

ITEM NO.: BD-8013
REVISED DEC 07, 2016
Printed in Vietnam
- 3 -
PART LIST
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have the following parts:
NO
Description
Qty
Sketch
NO
Description
Qty
Sketch
A
Top
1
B
Side panel
(L-R)
2
C
Bottom panel
1
D
Back panel
1
E
Upper
Drawer front
1
F
Upper
Drawer side
(L-R)
2
G
Upper
Drawer back
1
H
Lower
Drawer front
2
I
Lower
Drawer side
(L-R)
4
J
Lower
Drawer back
2
K
Drawer bottom
3

ITEM NO.: BD-8013
REVISED DEC 07, 2016
Printed in Vietnam
- 4 -
HARDWARE LIST
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have all of the following hardware:
NO
Description
Qty
Sketch
NO
Description
Qty
Sketch
1
Bolt
(M6 x 30mm)
8
2
Spring washer
(6.5 x11mm)
8
3
Flat washer
(6.5 x13mm)
8
4
Long screw
(M4 x 35mm)
26
5
Wooden knob
(30 x 30mm)
3
6
Pan head screw
(M4 x 30mm)
3
7
Allen key
(M4 x 30mm x 110mm)
1
8
Steel band
2
9
Short screw
(M3.5 x 15mm)
4
NOTE: WARNING LABEL (INCLUDED)

ITEM NO.: BD-8013
REVISED DEC 07, 2016
Printed in Vietnam
- 5 -
STEP 1
Attach top (A) and bottom panel (C) to side panel (B) with bolts (1), and washers (2) and (3) as shown
below. Tighten with Allen key (7).
Slide back panel (D) into the grooves as shown below.
STEP 2
Attach bottom panel (C) and top (A) to the other side panel (B) with bolts (1), and washers (2) and (3)
as shown below. Tighten with Allen key (7).

ITEM NO.: BD-8013
REVISED DEC 07, 2016
Printed in Vietnam
- 6 -
STEP 3
Attach drawer sides (F) to drawer front (E) with screws (4) as shown below. Tighten with a screwdriver.
Insert drawer bottom (K) into the grooves at bottom of drawer sides (F) and drawer front (E) as shown
below.
Attach drawer back (G) to drawer sides (F) with screws (4) as shown below. Tighten with a screwdriver.
STEP 5
Attach knob (5) to front of drawer with pan head screw (6) as shown below. Tighten with a screwdriver.
Carefully put the drawer into the unit.
STEP 4

ITEM NO.: BD-8013
REVISED DEC 07, 2016
Printed in Vietnam
- 7 -
STEP 6
Attach drawer sides (I) to drawer front (H) with screws (4) as shown below. Tighten with a screwdriver.
Insert drawer bottom (K) into the grooves at bottom of drawer sides (I) and drawer front (H) as shown
below.
Attach drawer back (J) to drawer sides (I) with screws (4) as shown below. Tighten with a screwdriver.
Attach knobs (5) to front of drawers with pan head screws (6) as shown below. Tighten with a
screwdriver.
Carefully put the drawers into the unit.
STEP 7
STEP 8

ITEM NO.: BD-8013
REVISED DEC 07, 2016
Printed in Vietnam
- 8 -
Attach steel bands (8) to the unit with screws (9) as shown below.
(to secure the product to the wall and reduce the risk of tipping over).
Important!
Properly attach steel bands (8) to the wall in an area of drywall or plaster with a wood stud:
Mark the attachment point(s) with a pencil at the appropriate height positioned over the wood stud(s)
in the wall.
Drill 1/8-inch (3mm) diameter hole(s) into the wood stud(s) located in the wall, where you marked
with the pencil.
Properly attach steel bands to the wall with screws (4) and tighten screw(s) firmly into the wall.
STEP 9
