Amped Wireless APR175P ProSeries AC1750 User manual

APR175P
ProSeries
High Power AC1750 Wi-Fi Access Point / Router
User’s Guide

APR175P
USER’S GUIDE
1
CONTENTS
INTRODUCTION ...........................................................4
GETTING STARTED.......................................................5
Package Contents ...........................................................5
LED Indicators .................................................................6
Side Panel Description ....................................................7
Mounting Instructions ....................................................8
GETTING STARTED.......................................................9
OPERATIONAL MODES (BASIC SETUP)........................ 10
ROUTER MODE .............................................................11
ACCESS POINT MODE....................................................22
WDS - ACCESS POINT MODE ........................................29
MANAGED ACCESS POINT MODE .................................36
ACCESS POINT CONTROLLER MODE .............................37
MORE SETTINGS ........................................................ 48
DASHBOARD ............................................................. 49
System Status................................................................49
Operational Mode ........................................................50
Basic Setup....................................................................51
Connected Devices .......................................................52
WDS Settings ................................................................53
WI-FI SETTINGS ..........................................................54
2.4GHz Status................................................................54
2.4GHz Basic Settings....................................................55
2.4GHz Security.............................................................57
2.4GHz Output Power ...................................................59
2.4GHz Site Survey ........................................................60
2.4GHz WDS..................................................................61
2.4GHz Access Schedule................................................63
2.4GHz Advanced Settings ............................................64
5.0GHz Status................................................................66
5.0GHz Basic Settings....................................................67
5.0GHz Security.............................................................69
5.0GHz Output Power ...................................................71
5.0GHz Site Survey ........................................................72
5.0GHz WDS..................................................................73
5.0GHz Access Schedule................................................75
5.0GHz Advanced Settings ............................................76
WPS Settings .................................................................78
MAC Address Filtering...................................................79

APR175P
USER’S GUIDE
2
RADIUS Server...............................................................80
Internal RADIUS Server .................................................82
Radius Accounts............................................................84
WMM / QoS..................................................................85
NETWORK SETTINGS.................................................. 86
Local Network (IPv4).....................................................86
LAN Port Settings ..........................................................87
VLAN .............................................................................89
Domain Redirect ...........................................................90
Internet Network (WAN) IPv4.......................................91
Advanced Settings ........................................................93
ADVANCED SETTINGS ................................................ 95
Port Forwarding............................................................95
Port Filtering .................................................................96
DMZ (Demilitarized Zone).............................................97
Denial of Service ...........................................................98
IDS (Intrusion Detection System)..................................99
ADMINISTRATION ................................................... 100
System Status..............................................................100
Network Statistics.......................................................101
System Clock...............................................................102
Advanced Settings ......................................................103
System Logs ................................................................105
Alarm and LED Settings...............................................106
Upgrade Firmware ......................................................107
Save / Reload Settings.................................................109
Password Settings .......................................................110
ACCESS POINT CONTROLLER SETTINGS.....................111
DASHBOARD...............................................................115
System Status..............................................................115
Operational Mode.......................................................116
Basic Setup..................................................................117
Managed AP Overview................................................118
Managed AP Map........................................................121
MANAGED AP STATUS................................................122
Access Points: Managed APs.......................................122
Access Points: Managed AP Groups............................126
Wi-Fi Status: Active Wi-Fi Networks ...........................129
Wi-Fi Status: Active Groups ........................................131
Connected Devices: Active Devices.............................132
AP Statistics.................................................................133
Managed AP Logs........................................................134
Network Tools.............................................................135

APR175P
USER’S GUIDE
3
MANAGED AP SETTINGS ............................................ 136
Access Points ..............................................................136
Wi-Fi Settings..............................................................141
RADIUS Server Settings...............................................146
Access Control ............................................................148
Managed AP Map Edit ................................................150
Firmware Upgrade...................................................... 151
LOCAL ACCESS POINT SETTINGS............................... 152
TECHNICAL SPECIFICATIONS.....................................153
DEFAULT SETTINGS ..................................................154
TROUBLESHOOTING & SUPPORT..............................155
WARRANTY & REGULATORY INFORMATION ............169
LEGAL NOTICES AND DISCLAIMERS………………….……..177

APR175P
USER’S GUIDE
4
INTRODUCTION
Thank you for purchasing this Amped Wireless product. At Amped Wireless we strive to provide you with the
highest quality products through innovation and advanced technology. We pride ourselves on delivering
products that outperform the competition and go beyond your expectations. If you have any questions please
feel free to contact us. We’d love to hear from you and thank you for your support!
Email: [e-mail]
Call: 888-573-8830
Web: www.ampedwireless.com

APR175P
USER’S GUIDE
5
GETTING STARTED
Package Contents
Check to make sure you have all the contents within your package:
ProSeries High Power AC1750 Wi-Fi Access Point / Router
3 x Detachable High Gain 3dBi Antennas
Magnetic Mounting Kit & Mounting Template
Setup Guide
CD: User’s Guide
Ethernet Cable
Power Adapter

APR175P
USER’S GUIDE
6
LED Indicators
From left to right:
PoE: Indicates when there is an active PoE connection on the LAN1 wired port. LED will remain on.
USB: Indicates when there is a USB device is attached to the USB port.
5.0GHz Wi-Fi:Blinks rapidly when Wi-Fi data traffic is transmitted or received over the wireless network.
2.4GHz Wi-Fi:Blinks rapidly when Wi-Fi data traffic is transmitted or received over the wireless network.
Wired Port 2: Indicates when a networking device is connected to wired port (LAN2) on the Access Point /
Router. The LED will blink rapidly when wired data traffic is transmitted or received.
Wired Port 1: Indicates when a networking device or modem is connected to wired port (LAN1 / WAN) on the
Access Point / Router. The LED will blink rapidly when wired data traffic is transmitted or received.
Status: Blinks when the Access Point / Router is booting up or resetting.
Power (PWR): Indicates when the Access Point / Router is powered on. The LED will remain on.

APR175P
USER’S GUIDE
7
Side Panel Description
PWR: Power adapter port. 12V 4A.
LAN1 / WAN (PoE): Gigabit RJ-45 port with Power over Ethernet input. Connect wired devices or to a PoE
switch to use the Access Point without the power adapter. Functions as the port connected to your network
in Access Point modes and WAN port in Router mode.
LAN2: Gigabit RJ-45 local network port for expanding your network.
USB:Attach USB devices to save or load settings, upgrade firmware, save system logs or load boot files.
Eject: To safely eject an attached USB device.
Console: Connect to a management console for diagnostics. (i.e. HyperTerminal)
WPS: Enables Wi-Fi Protected Setup’s push button configuration.
On/Off: Device power on/off switch.

APR175P
USER’S GUIDE
8
MOUNTING INSTRUCTIONS
Magnetic Mounting
The mounting kit included with the Access Point provides a convenient
method to mount the Access Point on a wall or ceiling. Once you have
chosen the location for where you want to install the Access Point, locate
the Mounting Template. Use it to mark the screw hole locations onto
your wall.
Once the screw holes have been marked, locate the Magnetic Mounting
Kit and use the included screws to fasten the two magnetic plates to the
wall.
Once the plates are fastened, attach the Access Point to the wall plates
and check that the magnets are firmly holding the Access Point to the
wall.
Wall Mounting
In addition to the Magnetic Mounting Kit, the Access Point can also be
mounted using the standard wall mounting clips on the bottom of the
device.

APR175P
USER’S GUIDE
9
GETTING STARTED
a) Attach the included antennas to the antenna ports on the Access Point / Router.
b) Power on the Access Point / Router by attaching either the power adapter to the Access Point /
Router and plugging in the other end into a power outlet or attaching a PoE Ethernet cable to LAN1 /
WAN on the side panel and the other end to an active PoE switch.
c) Connect to the Access Point / Router with your computer by attaching an Ethernet cable to the LAN2
ports on the side panel or connect to the Access Point / Router’s Wi-Fi network: Amped_APR_2.4 or
Amped_APR_5.0. Password: wireless

APR175P
USER’S GUIDE
10
OPERATIONAL MODES (BASIC SETUP)
The Access Point features five different operational modes that can be configured via the web menu:
-Router
-Access Point
-WDS Access Point
-Managed Access Point
-Access Point Controller

APR175P
USER’S GUIDE
11
ROUTER MODE OVERVIEW
Share a single Internet connection via a connection to a broadband modem or other Internet source and
provide a secure firewall for your network. Router mode features 2.4GHz and 5.0GHz Wi-Fi connections as well
as one wired port for local wired devices and switches.

APR175P
USER’S GUIDE
12
ROUTER MODE BASIC SETUP
Setup Preparations
Disconnect and power off your existing router (if you have one).
Disconnect your existing router from your computer, your broadband
modem and its power outlet. If you do not have an existing router please
continue to the next step.
Power off your Modem
Power off the modem by disconnecting the modem’s power adapter
from the power outlet. If your modem has a backup battery, remove the
backup battery from your modem. Do NOT power on the modem until
prompted at a later step.

APR175P
USER’S GUIDE
13
Connect the Router to your Modem
a) Use the included Ethernet cable and connect one end of the cable to your modem.
b) Connect the other end of the cable to the blue “Modem” port on the Router.

APR175P
USER’S GUIDE
14
Power on your Modem
Plug in your modem’s power adapter and backup battery (if available):

APR175P
USER’S GUIDE
15
Attach Antennas, Power On & Connect to your Computer
a) Attach the included antennas to the antenna ports on the Access Point / Router.
b) Power on the Access Point / Router by attaching either the power adapter to the Access Point /
Router and plugging in the other end into a power outlet or attaching a PoE Ethernet cable to LAN1 /
WAN on the side panel and the other end to an active PoE switch.
c) Connect to the Access Point / Router with your computer by attaching an Ethernet cable to the LAN2
ports on the side panel or connect to the Access Point / Router’s Wi-Fi network: Amped_APR_2.4 or
Amped_APR_5.0. Password: wireless

APR175P
USER’S GUIDE
16
Open your Web Browser
a) Open your web browser.
b) Type http://setup.ampedwireless.com
into the web address bar.
c) If the web menu fails to open, type in the following IP
address into your web address bar: http://192.168.80.1
If you have problems accessing the Web Menu… Disable third-party
firewalls such as Norton, Zone Alarm or Windows Defender. Check to
see that your computer is not connected to other wireless networks.
d) When prompted, enter the login and password:

APR175P
USER’S GUIDE
17
Select the Operational Mode
a) After the web menu appears, select Dashboard from
the navigation menu on the top of the page.
b) Select Operational Mode from the left hand
navigation.
c) Using the dropdown menu, select Router Mode for
the Operational Mode and click Apply.
d) When the web menu has reloaded, select Basic Setup.

APR175P
USER’S GUIDE
18
Basic Setup Wizard
Confirm that your hardware is correctly connected and Click Next to
begin.
Internet Connection Detection
The Wizard will try to detect your Internet settings and configure the
router. Please be patient.

APR175P
USER’S GUIDE
19
If there was a problem with the Automatic Configuration, the wizard will
notify you of the issue. If you continue to have problems, contact our
support department at 888-573-8820.
If the Internet connection detection was successful, you will see a green
check. Click Next to continue.
