Amped Wireless TAP-EX2 User manual

User’s Guide
TAP-EX2
HIGHPOWERTM TOUCH SCREEN
AC750 WI-FI®RANGE EXTENDER

TAP-EX2
USER’S GUIDE
1
CONTENTS
INTRODUCTION.....................................................................3
GETTING STARTED.................................................................4
Package Contents...................................................................... 4
Product Description................................................................... 5
SETUP GUIDE (TOUCH SCREEN)..............................................6
Find a Setup Location ................................................................ 6
Navigating the Touch Screen Menu .......................................... 8
Welcome to the Dashboard ...................................................... 9
Select a 2.4GHz Home Network to Extend .............................. 10
Connecting to a Secure Network (2.4GHz) .............................. 11
Select a 5GHz Home Network to Extend ................................ 12
Connecting to a Secure Network (5GHz) ................................. 13
Extended Network Settings..................................................... 14
Applying Settings..................................................................... 16
Setup Summary....................................................................... 17
MORE SETTINGS (TOUCH SCREEN) .......................................19
2.4GHz WI-FI SETTINGS (TOUCH SCREEN)............................. 20
Home Network Settings .......................................................... 20
Extended Network Settings..................................................... 21
Connected Devices.................................................................. 23
Wi-Fi Coverage Controls.......................................................... 24
Access Schedule ...................................................................... 25
Wi-Fi Protected Setup (WPS) ...................................................26
User Access..............................................................................27
5GHz WI-FI SETTINGS (TOUCH SCREEN) ................................28
Home Network Settings...........................................................28
Extended Network Settings .....................................................29
Connected Devices...................................................................31
Wi-Fi Coverage Controls ..........................................................32
Access Schedule.......................................................................33
Wi-Fi Protected Setup (WPS) ...................................................34
User Access..............................................................................35
BOOSTBAND TECHNOLOGY (TOUCH)....................................36
NETWORK SETTINGS (TOUCH)..............................................37
IP Settings ................................................................................37
Wired Port Routing ..................................................................38
MANAGEMENT SETTINGS (TOUCH) ......................................39
Screen Settings ........................................................................39
Clock / Date .............................................................................40
System Details..........................................................................41
Statistics...................................................................................43
USB Storage .............................................................................44
System Logs .............................................................................48
Upgrade Firmware...................................................................49

TAP-EX2
USER’S GUIDE
2
Reset Settings.......................................................................... 50
ACCESSING THE WEB MENU ................................................ 51
SETUP GUIDE (WEB MENU)..................................................52
Find a Setup Location .............................................................. 52
Open your Web Browser to Access the Setup Wizard............. 54
Welcome to the Dashboard .................................................... 55
Scan for a Home Network to Extend ....................................... 56
Connecting to a Secure Network............................................. 57
Extended Network Settings (SSID and Security) ...................... 58
Setup Summary....................................................................... 61
5GHz WI-FI SETTINGS (WEB MENU) ..................................... 64
Home Network Settings ......................................................... 64
Extended Network Settings .................................................... 65
Security ................................................................................... 67
Wi-Fi Protected Setup –WPS ................................................. 68
User Access ............................................................................ 69
Wireless Coverage Controls .................................................... 70
Access Schedule ..................................................................... 71
Advanced Settings .................................................................. 72
2.4GHz WI-FI SETTINGS (WEB MENU)...................................74
Home Network Settings ......................................................... 74
Extended Network Settings .................................................... 75
Security ................................................................................... 77
Wi-Fi Protected Setup –WPS ................................................. 78
User Access ............................................................................ 79
Wireless Coverage Controls ....................................................80
Access Schedule ......................................................................80
Advanced Settings ...................................................................82
BOOSTBAND™ TECHNOLOGY (WEB MENU)..........................84
NETWORK SETTINGS (WEB MENU).......................................85
IP Settings ................................................................................85
Wired Port Routing ..................................................................87
MANAGEMENT FEATURES (WEB MENU) ..............................88
Device Status ...........................................................................89
Network Statistics....................................................................91
System Clock............................................................................92
System Logs .............................................................................93
Upgrade Firmware...................................................................94
Save/Reload Settings ...............................................................96
Password Settings....................................................................97
TECHNICAL SPECIFICATIONS.................................................97
DEFAULT SETTINGS..............................................................99
TROUBLESHOOTING & SUPPORT INFORMATION ................100
WARRANTY AND REGULATORY INFORMATION ..................117
LEGAL NOTICES AND DISCLAIMERS ……………………………….…125

TAP-EX2
USER’S GUIDE
3
INTRODUCTION
Thank you for purchasing this Amped Wireless product. At Amped Wireless we strive to provide you with the
highest quality products through innovation and advanced technology. We pride ourselves on delivering
products that outperform the competition and go beyond your expectations. If you have any questions please
feel free to contact us. We’d love to hear from you and thank you for your support!
Email: [e-mail]
Call: 888-573-8830
Web: www.ampedwireless.com

TAP-EX2
USER’S GUIDE
4
GETTING STARTED
Package Contents
Check to make sure you have all the contents within your package:
High Power Touch Screen AC750 Wi-Fi Range Extender
Stylus
Detachable High Gain Antenna
Power Adapter
Setup Guide
CD: User’s Guide & Installation Video
Product Stand

TAP-EX2
USER’S GUIDE
5
Product Description
1. LCD Screen: 3.5” LCD touch screen. Displays the user interface for
configuring the Range Extender as well as the status.
2. Stylus: Input tool that assists in navigating the LCD touch screen Menu.
3. Antenna Connectors (ANT): RJ-SMA antenna connector. Compatible
with all antennas that have RP-SMA connectors.
4. Reset: Button used to reset device. Push down once to reboot, hold
down for 5-10 seconds to reset to factory default settings.
5. USB Port: USB 2.0 Port used to attach USB storage devices, such as a
USB flash drive or external hard drive, for file sharing.
6. Wired Ports: RJ-45 ports for connecting wired computers or network
devices.
7. Power (PWR): Power adapter port. DC 12V 1A.

TAP-EX2
USER’S GUIDE
6
6
SETUP GUIDE (TOUCH SCREEN)
Find a Setup Location
The location of where you install the Range Extender is important to how it will function. The optimal setup
location should be somewhere no more than halfway between your Wi-Fi router and your Wi-Fi dead zone.

TAP-EX2
USER’S GUIDE
7
7
Power On the Range Extender
a. Attach the included antenna.
b. Attach the Power Adapter to the Range Extender’s PWR Port and plug it into an available power outlet.
c. The Amped Wireless logo will appear as the unit boots up, then the Dashboard screen will appear.

TAP-EX2
USER’S GUIDE
8
8
Navigating the Touch Screen Menu
Before we begin, here are a few tips on how to navigate the Touch Screen Menu:
Language Selection: Tap the Globe icon, found on the bottom of the Settings screen, to
change the language of the menu.
Back Arrow: Tap the Left Arrow, found on the upper left corner of many screens, to
navigate back to the previous page.
Home Button: Tap the Home icon, found on the bottom of many screens, to return to the
Dashboard at any time.
Navigation Button: Tap the Left or Right Arrow to navigate between multiple pages for
one screen. The dots in this example indicate there are 3 pages to see.
Keyboards/Keypads: Tap on a Blank Field to access a keyboard or keypad for entering in
information such as your Network ID and Security Key.

TAP-EX2
USER’S GUIDE
9
9
Welcome to the Dashboard
The Dashboard will provide you with the current status of the
Range Extender.
Tap SCAN to find an available network to extend.
During the setup process, the wizard will refer to the Home
Network and the Extended Network:
The Home Network is the network you are trying to extend.
The Extended Network is the network that is rebroadcasted and extended by the Range Extender.

TAP-EX2
USER’S GUIDE
10
10
Select a 2.4GHz Home Network to Extend
The Range Extender can extend a single 2.4GHz network, a
single 5GHz network or both (2.4GHz and 5GHz)
simultaneously. The wizard will walk you through the setup of
the 2.4GHz network first, and then the 5GHz network.
Select the Wi-Fi network that you wish to extend. Check that
your Wi-Fi Network has a signal strength of 70% or greater.
If you wish to only extend a 5GHz network and not a 2.4GHz
network, tap Skip to move on to the 5GHz network selection.
Otherwise, tap Next to continue.
If you fail to find any Wi-Fi networks, or your signal strength is below 70%, the Range Extender may be placed
too far from the Wi-Fi network that you are trying to extend. Move your Range Extender closer to the Wi-Fi
network that you are trying to extend and tap Rescan to scan again.
The Scan results page will display information regarding the name of the network (SSID), the channel which the
Wi-Fi network is operating on and the security type of the network. The results page will also display what the
signal strength is of every network detected.

TAP-EX2
USER’S GUIDE
11
11
Connecting to a Secure Network (2.4GHz)
If the 2.4GHz Wi-Fi network you are trying to extend has Wi-Fi
security enabled, you will be prompted to enter a Security Key.
If you did not select a secure network, you will not see this
page.
Enter the security key in the space provided. You do not need
to select what type of security it is, just simply type in the key
and tap Next.
The Wizard will automatically detect your home network’s security settings. If you do not know the key to the
network you are trying to extend, then tap the Back arrow to select another network.

TAP-EX2
USER’S GUIDE
12
12
Select a 5GHz Home Network to Extend (5GHz)
Select the 5GHz Wi-Fi network that you wish to extend. Check
that your Wi-Fi Network has a signal strength of 70% or
greater.
If you have already selected a 2.4GHz network and do not wish
to select a 5GHz network, tap Skip to continue. Otherwise, tap
Next to continue.
If you fail to find any Wi-Fi networks, or your signal strength is
below 70%, the Range Extender may be placed too far from the Wi-Fi network that you are trying to extend.
Move your Range Extender closer to the Wi-Fi network that you are trying to extend and tap Rescan to scan
again.
The Scan results page will display information regarding the name of the network (SSID), the channel which the
Wi-Fi network is operating on and the security type of the network. The results page will also display what the
signal strength is of every network detected.

TAP-EX2
USER’S GUIDE
13
13
Connecting to a Secure Network (5GHz)
If the 5GHz Wi-Fi network you are trying to extend has Wi-Fi
security enabled, you will be prompted to enter a Security Key.
If you did not select a secure network, you will not see this
page.
Enter the security key in the space provided. You do not need
to select what type of security it is, just simply type in the key
and tap Next.
The Wizard will automatically detect your home network’s security settings. If you do not know the key to the
network you are trying to extend, then tap the Back arrow to select another network.

TAP-EX2
USER’S GUIDE
14
14
Extended Network Settings
The Range Extender features both a 2.4GHz and 5GHz Extended
Network. The wizard will walk you through the setup of your
2.4GHz extended network first, and then the 5GHz extended
network.
The default SSID of the Range Extender’s Extended Network is
“Amped TAPEX_2.4”.
If you choose to Clone the settings from your Home
Network, the wizard will copy the SSID and Security Key of your Home Network.
The SSID of the Extended Network will have a "_RE" at the end of its name. For example: Home_Network_RE.
You can also manually enter a new network ID and security key. The new security key must be at least 8
characters long.
Tap Next to apply the settings and repeat these steps for your 5GHz extended network.

TAP-EX2
USER’S GUIDE
15
15
The default SSID of the Range Extender’s Extended Network is
“Amped_TAPEX2_5.0”.
If you choose to Clone the settings from your Home Network,
the wizard will copy the SSID and Security Key of your Home
Network.
The SSID of the Extended Network will have a "_RE" at the end
of its name. For example: Home_Network_RE.
You can also manually enter a new network ID and security key. The new security key must be at least 8
characters long.
Tap Next to apply the settings.

TAP-EX2
USER’S GUIDE
16
16
Applying Settings
DO NOT LEAVE THIS SCREEN.
Allow the progress bar to complete and the Wizard will
automatically redirect you to the next step.

TAP-EX2
USER’S GUIDE
17
17
Setup Summary
Congratulations, the Range Extender is now successfully
configured! Your settings are now saved.
At this point you can connect your Wi-Fi devices to you
Extended Network using the Wi-Fi network name and
password on the screen.
If you haven’t already positioned your Range Extender in an
optimal location, you may do so now. All Range Extender
settings are saved and the unit can be safely powered off for relocation.
You may also attach any wired network devices to the wired ports on the side of the Range Extender at this
time.
If you experience any problems during this process, please contact our Amped Wireless Elite Support at
888-573-8820 or 909-217-3168.

TAP-EX2
USER’S GUIDE
18
18
If the Extended Network connection fails try the following…
The failed connection page will provide you with information on why the connection failed. Read the
instructions carefully and retry your connection. The tips below will help to solve common issues:
a. Check to make sure your Home Network security settings are correct.
b. On the SCAN page, check that your Home Network is showing a signal of 70% or greater. If not, move
the Range Extender closer to your Home Network router and try again. If you are connecting to a dual
band router, ensure that both the 2.4GHz and 5GHz networks show a signal strength of 70% or
greater.
c. Check that your Home Network router’s DHCP server is enabled.
d. Try changing the channel of the Home Network router to a higher channel number and run the Setup
Wizard again.
e. Check the internet connection on your Home Network wireless router. Connect directly to your router
and attempt to access the web. If this fails, the problem is with your internet connection. Contact
your broadband provider to fix this issue first before configuring the Range Extender.
f. Try to reboot (unplug the power from the Range Extender and plug it back in) the Range Extender and
check to see if the connection is established (some networks may be very slow and take longer than
the allotted time for the Range Extender to successfully connect).

TAP-EX2
USER’S GUIDE
19
19
MORE SETTINGS (TOUCH SCREEN)
The Range Extender’s Touch Screen Menu provides a host of features that you can easily configure
with the touch of your finger. To access the main Settings Menu tap Settings from the Dashboard.
From there you can access additional Wi-Fi Settings or Management Settings.
Note: For more advanced features and detailed options, please access the web menu
through web browser: http://setup.ampedwireless.com
