Amplifyze TCL Pulse User manual

User Guide
TCL Pulse Ver 2.0

Main Unit
Location of Control
1. Snooze button /
LED indicator
2. Pair
3. Reset
4. Alarm
5. Battery
Compartment
6. Battery door
6
5
4 3 2
1
FCC ID:
2AC3BA480110813
AmplicomU SA LLC
Model No: TCL Pulse
DC 4.5V 3 X 1.5V - - -
MADE IN CHINA
Warranty
AMPLIFYZE equipment is produced and tested according to the latest
production methods. The implementation of carefully chosen materials
and highly developed technologies ensure trouble free functioning and
a long service life. The terms of the warranty do not apply where the
cause of the equipment malfunction is the fault of the telephone
network operator or any interposed private branch extension system.
The terms of the warranty do not apply to the rechargeable battery
pack or power packs used in the products. The period of warranty is 12
months from the date of purchase. All deficiencies resulting from
material of production faults which occur during the period of warranty
will be eliminated free of charge. Rights to claims under the terms of
warranty are annulled following intervention by the purchaser or third
parties. Damage caused as a result of improper handling or operation,
incorrect positioning or storing, improper connection or installation,
Acts of God or other external influence are not covered by the terms of
warranty. In the case of complaints, we reserve the right to repair or
replace defect parts or provide a replacement device. Replacement
parts or devices become our property. Rights to compensation in the
case of damage are excluded where there is no evidence of intent or
gross negligence by the manufacturer. If your equipment shows signs
of defect during the period of warranty, please return to the sales outlet
in which you purchased the AMPLIFYZE equipment together with the
purchase receipt. All rights to claims under the terms of warranty in
accordance with this agreement must be asserted exclusively with
regard to your sales outlet. ONE year after the purchase of our
products, claims under the terms of warranty can no longer be
asserted.

Features
Thank you for purchasing the Vibration Alarm. This product
is designed as a Vibration Alarm by working with your
mobile devices.
- Support Bluetooth version 4.0.
- Set wake up buzzer alarm or vibration alarm with snooze
function, up to 10 alarms.
- Take full control of the Vibration Alarm with device app
via Bluetooth Low Energy.
- Selectable alarm tone pattern and volume to different
alarms.
- Set count down timer.
- Monitor the battery status of the Vibration Alarm and have
low battery warning if it is at low level.
Before you start using it
• Please make sure to read the instruction manual
carefully.
• Following and respecting the instuctions in your
manual will prevent damage to your instrument and
loss of your statutory rights arising from defects due
to incorrect use.
• We shall not be liable for any damage occuring as a
result of non-following of these instructions. Likewise,
we take no responsibility for any incorrect readings
and for any consequences which may result from
them.
• Please take particular note of the safety advice!
• Please keep this instruction manual for future
reference.
018-140077
BAC

Getting Started
1. Install battery:
1.1 Open the battery compartment.
1.2 Insert 3 x AAA batteries in polarity (+) and (-) as indicated.
1.3 Close the battery compartment.
.
2. Install on your device.
2.1 Access App Store or Google play search for TCL Alarm
2.2 Select and install TCL Alarm App on your device.
FCC ID:
2AC3BA480110813
Amplicom USA LLC
Model No: TCL Pulse
DC 4.5V 3 X 1.5V - - -
MADE IN CHINA
•
•
•
•
•
Disposal of Your Old Product
Your product is designed and manufactured with high quality
materials and components, which can be recycled and reused. When
this crossed-out wheeled bin symbol is attached to a product it
means the product is covered by the European Directive
2002/96/EC.
Please inform yourself about the local separate collection
system for electrical and electronic products.
Please act according to your local rules and do not dispose of your
old products with your normal household waste. The correct disposal
of your old product will help prevent potential negative consequences
for the environment and human health.
Disposal of Flat Batteries / Accumulators
You, as the end user, are legally obliged (Battery Ordinance)
to return all flat batteries and rechargeable batteries.
Disposal in the household waste is prohibited.
“European Directive 2006/66/EC” Batteries, including
rechargeable batteries, which contain hazardous substances
are marked by symbols which indicate the prohibition of
disposal in the household waste.
The designations for the heavy metals concerned
are as follows:
Cd = cadmium, Hg = mercury, Pd = lead. You can return flat
batteries / rechargeable batteries free of charge to the
collection points in your community or anywhere where
batteries / rechargeable batteries are sold.
You thus fulfil your statutory obligations and help protect the
environment.
Caution
Replace only with the same or equivalent type of battery, please refer
to the engraved battery marks inside the battery compartment for the
correct battery polarity (+) and (-). Danger of explosion is possible if
battery is incorrectly replaced.
This product complies with the requirement of the 1999/5/EC directive.
Use this unit and mobile phone only in environments with ambient
temperatures between 0°C and 40°C(32~104°F).
The maximum operating temperature of the unit is 40°C

Pairing the Vibration Alarm
appears. You need to pair the Vibration Alarm device before you
enter the main app screen.
iOS Version
Android Version
3. Pair the Vibration Alarm with TCL Alarm app.
3.1 Before running the TCL Alarm app, make sure the Bluetooth is
turned ON at your device.
AL
BL
AR
E
M
3.2 After you tap the app icon , the ‘Nearby Devices’ screen
Vibration Alarm
9:41 am 9:41 am
Vibration Alarm
Care of Your Vibration Alarm
The unit shall not be exposed to dripping or splashing.
Do not expose the unit and batteries to humid, rain, sand or
execessive heat caused by heating equipment.
No objects filled with liquids, such as vases, shall be placed on the
unit.
No naked flame sources, such as lightend candles, should be placed
on the unit.
To clean the set, use a soft dry cloth. Do not use any cleaning agents
containing alcohol, ammonia, benzene or abrasives as these may
harm the housing.
Manufacturer reserves the right to update the contents
of this manual and App.

Pairing the Vibration Alarm
3.3 Tap “ Pair New Device” to search for nearby devices.
3.4 Press and hold the [PAIR] button on the Vibration Alarm device for
5 seconds. You can find the flashing LED will turn from red to blue.
3.5 The New Vibration Alarm will be displayed on App and is ready for
pairing. Tap the "New Vibration Alarm" will start the pairingand
connection process. Once the Vibration Alarm is paired, it will start
time and data synchronization.
New Vibration Alarm
Vibration Alarm
9:41 am
New Vibration Alarm
iOS Version Android Version
Reset the Vibration Alarm
12. Reset the Alarm
If the Vibration Alarm is not working properly, press RESET button to
reset the unit. During reset, the LED flashes twice in (purple)color and
the Vibration Alarmvibrates twice. Then the LED will flash once per 6
seconds in red color.
Reset the unit will break the connection and clear the data in your unit.
Repeat step 3.3 - 3.5 to reconnect the unit. If the unit has connected
your mobile device before, you can select “Restore” to resume all
setting and data or select “Erase” to start all from scratch.
9:41 am
iOS Version Android Version

Pairing the Vibration Alarm
iOS Version
Android Version
3.6 Once connected, the following information will be synchronized:
i) Current time and date
ii) Alarms & timer setting
iii) Unit battery level
3.7 One Vibration Alarm unit can pair one device each time.
3.8 One device can pair up to 5 Vibration Alarm units.
9:41 am
Vibration Alarm
Alarm Sync ...
Battery Sync ...
Preference
11.2 Alarm Sound Duration: The alarm duration. User can set from 1 to 15
minutes.
11.3 Auto DST update: It will adjust Daylight Saving Time (DST)
automatically based on your idevice time zone setting. The alarm clock
will be automatically one hour ahead of Standard Time in summer time
and will be back to the normal Standard Time when back to winter
time, according to your idevice’s time zone.
11.4 Tap [Done] to save the setting or Tap [Cancel] to restore the setting.

Rename the Vibration Alarm
4. Rename the device.
Tap the device name (default is “Vibration Alarm”) at the top of the
screen to edit the Vibration Alarm device name.
iOS Version
Android Version
9:41 am
Vibration Alarm
9:41 am
Vibration Alarm
Preference
11. Preference setting
Tap the / to enter the Preference screen. You can edit and
adjust the following items on this screen.
11.1 Snooze Enabled: Tap to enable/disable Snooze function. If
“Snooze Enabled” is ON, you can set:
Maximum Snoozes: The number of times to repeat the snooze
function. User can set Unlimited or values from 1 to 9.
Snooze Duration: The time interval between snoozes. User can
set from 1 to 15 minutes.
9:41 am
iOS Version Android Version

Battery Status Indicator
5. Battery status indicator
It indicates the battery level of your Vibration Alarm device.While
the battery level drops below 20%, the battery icon is in red status
and a low battery warning will pop up to remind battery replacement.
Vibration Alarm
Warning
Vibration Alarm: Battery level very low!
Please replace device batteries.
Above 60%
iOS Version
Android Version
Between
20% ~ 60%
Below 20%
Above 60%
Between
20% ~ 60%
Below 20%
Vibration Alarm
Warning
Vibration Alarm: Battery level very low!
Please replace device batteries.
Delete Paired Vibration Alarm Unit
10. Delete the Vibration Alarm unit.
iOS Version
Tap at Nearby Devices screen to enter the Known Devices page. By
tapping “Edit” and then the , you can select “Delete” to erase any
paired Vibration Alarm unit.
Android Version
Mary’s Alarm
9:41 am
Mary’s Alarm
9:41 am
9:41 am
Mary’s Alarm

Setting the Alarm Time
6. Setting the alarm time
6.1 Tap [New Alarm] to create a new alarm or tap the existing alarm to
modify.
6.2 On alarm setting screen, you can edit and adjust the item below:
i) Alarm Name: Tap to edit you preferred name to this alarm.
ii) Time: Scroll up and down to adjust the alarm time.
iii) Day of Week: Tap to select which day of week to enable the alarm.
- If none is selected, it alarms once only.
- If all days are selected, it alarms daily.
iv) Sound pattern: Tap to select which tone pattern (5 options plus one
random pattern available) is applied to this alarm.
iOS Version Android Version
9:41 am
Setting the Timer
9.2 Using the Timer
In the Home screen, tap “Start” under Timer to start counting.
Tap “Stop” to stop counting and “Start” to start counting again.
Tap [Reset] to reset the time duration value.
Mary’s Alarm
9:41 am
9:41 am
Mary’s Alarm

Setting the Alarm Time
v) Alarm volume level: Tap to select the alarm sound volume level
(three options: Low, Med and High).
vi) Vibration strength: Tap to select the vibration strength
(four options: Off, Low, Med and High).
6.3 Complete the alarm setting.
i) Tap [Done] to save the alarm setting and go back to main screen.
ii) Tap [Cancel] to restore to the original alarm setting and go back to
main screen.
iii) Tap [Delete Alarm] to delete the current alarm and go back to main
screen.
iOS Version
Android Version
9:41 am
Mary’s Alarm
On
Off
BLE Wall Clock
9:41 am
6:00 am
Mary’s Alarm
Setting the Timer
9. To set the timer
Tap timer on main screen to go into setting screen.
iOS Version
Android Version
9.1 You can edit and adjust items below on this screen.
i) Timer period:
Scroll up and down to adjust the timer duration.
ii) Sound pattern:
Tap to select the tone pattern (5 options plus one random pattern
available).
iii) Sound volume level:
Tap to select the sound volume level (Four options: Off, Low, Med
and High).
iv) Vibration:
Tap to select the vibration strength (Four options: Off, Low, Med
and High).
9:41 am
9:41 am
Mary’s Alarm

Snooze Operation
7. Using the SNOOZE function
7.1 When the alarm sounds, press [Snooze] and alarm will repeat
every 5 minutes up to three times.
7.2 Above default value can be adjusted by setting the “Maximum
Snoozes” and “Snooze Duration” in the preference screen.
9:41 am
iOS Version Android Version
To Turn Off the Alarm
8. To disable the alarm
8.1 When alarm sounds, press [Snooze] once to stop the alarm and
activate the snooze funtion, or press [Alarm] to disable the alarm
completely.
8.2 If no button is pressed, the alarm will sound for 1 minute and stop
automatically. If Snooze Enabled setting is ON, the alarm will repeat
every 5 minutes. You can press the [Snooze] button to stop the
alarm, or can press [Alarm] button to turn off the alarm and stop the
snooze function completely.
8.3 User can tap the alarm time to disable the alarm completely ( Please
make sure your app is paired with the device)
9:41 am
Mary’s Alarm
iOS Version Android Version
