Krown Visual VibeAlert User manual

K-VVIB Visual VibeAlert™
Visual VibeAlert™ Alarm Clock with Bed Shaker
User Manual
(K-VVIB)
Voice/TDD: 817-738-2485 | VP: 817-200-1324| Fax: [phone] | www.krownmfg.com Voice/TDD: 817-738-2485 | VP: 817-200-1324| Fax: [phone] | www.krownmfg.com
MANUFACTURING
Innovation & Design for Accessibility, Diversity & Inclusion for All
PRODUCT FEATURES
•Large LED digital alarm display
•Wake options: Sound, light, bed shaker or a combination
•Snooze Duration: Select anywhere between 5 and 60 minutes
•Volume: 90dB with three adjustable settings
•Frequency: high, medium and low frequency settings…great for
people with varying degrees of hearing loss
•Dimmer: user selectable choice of high, medium or low
•USB Charging Port (cable not included)
•Battery Backup (2 AAA batteries not included)
•1-year Manufacturer’s Warranty
The Visual VibeAlert™ offers three wake options
which include powerful sound, flashing lights and
a strong and soothing bed shaker. Wake up to
sound, light, vibration or a combination.
This alarm will wake up even the deepest sleeper.
PARTS & FUNCTION
INSTALLATION
Plug the AC/DC adaptor into an AC outlet, and then plug the DC jack
into the back of the unit.
TO SET TIME, 12/24 HR AND THE SNOOZE DURATION
1. Press SET once, the hour digits “12” flash. Press / DEMO or to set
the time in hours (hold / DEMO or to advance rapidly).
2. Press SET again, the minute digits “00” flash. Press / DEMO or to
set the time in minutes. (hold / DEMO or to advance rapidly).
3. Press SET again, the display shows “12Hr” and flashes. Press /
DEMO or to select “12Hr” or “24Hr” time format.
If “12Hr” is selected, the PM will appear on the left side to indicate
the afternoon time; there is no AM indicator.
4. Press SET again, the display shows “05” and flashes. Press / DEMO
or to select your snooze time from 5 to 60 minutes.
5. Press SET again or if no key pressed for approx. 10 seconds to exit
the setting mode.
TO SET THE ALARM (default at 6:00 AM)
1. Press and hold AL SET / SELECT, the AL appearsand the alarm’s
hour digit flash. Press / DEMO or to set the alarm in hours.
(hold / DEMO or to advance rapidly).
2. Press AL SET / SELECT once again, the alarm’s minute digit flash.
Press / DEMO or to set the alarm in minutes. (hold / DEMO
or to advance rapidly).
3. Press AL SET / SELECT once again, LCD displays “HI” (vibration at HI
level) and flash, press / DEMO or to select:
HI (strong vibration level)
LO (soft vibration level)
4. Press AL SET / SELECT once again, LCD displays “F1” and flash,
press / DEMO or to select the alarm tone (frequency):
F1 (low tone, 800 Hz)
F2 (mid tone, 1 KHz)
F3 (high tone, 1.5 KHz)
5. Press AL SET / SELECT once again, LCD displays “L1” (low) and
flash, press / DEMO or to select the alarm sound level:
L1 (low)
L2 (medium)
L3 (high)
6. Press AL SET / SELECT once again, the display shows “A60” and
flashes. Press / DEMO or to select your alarm duration from 5
to 60 minutes.
7. Press AL SET / SELECT once again or no button around 10 seconds
to exit the alarm setting mode.

K-VVIB Visual VibeAlert™
Warning: To prevent fire or shock hazard. Do not expose this unit to rain or moisture.
The lighting flash with an
arrowhead within a triangle
alerts you to uninsulated
dangerous voltage within the
product's enclosure that could
cause an electric shock
CAUTION
The exclamation point within a
triangle alerts you to presence
of important operating,
maintenance and servicing
instructions in this user's
manual.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
TO REDUCE THE RISK OF ELECTRIC
SHOCK DO NOT REMOVE COVER
(OR BACK) NO USER SERVICEABLE
PARTS INSIDE. REFER SERVICING
TO QUALIFIED PERSONNEL.
Voice/TDD: 817-738-2485 | VP: 817-200-1324| Fax: [phone] | www.krownmfg.com Voice/TDD: 817-738-2485 | VP: 817-200-1324| Fax: [phone] | www.krownmfg.com
MANUFACTURING
TO SELECT THE ALARM MODE
At normal time display mode, press AL SET / SELECT one at a time to
activate the alarm(s), the corresponding alarm indicator(s) LED on the
right side of the time display will be on:
: only shaker alarm is activated
: both sound and shaker alarm are activated
: both strobe light and shaker alarm are activated
: strobe light, sound and shaker alarm are activated
Press AL SET / SELECT once more to turn off all the alarms, all
and alarm indicators disappear.
TO STOP AND RESET THE ALARM TO COME ON THE
NEXT DAY
When the alarm is sounding, the corresponding alarm indicator
flashes. Press AL SET / SELECT once to stop the alarm and reset it to
come on the following day. After that, the corresponding alarm
indicator stays on the display.
TO USE THE SNOOZE
When the alarm is sounding, press once, the alarm will stop
temporarily, and the corresponding alarm indicator keeps flashing.
Alarm will resume after the set snooze duration is over.
TO USE THE HI-MED-LO DIMMER
There is a 3-level brightness control for the LCD display. Press to
adjust the brightness (HI / MED / LO) of the LCD display. This can only
be done when the unit is not sounding.
TO USE DEMO
Press and hold / DEMO button for 2 second (and please button), test
mode runs by itself to demo the buzzer alarm sound (F1/F2/F3 +
L1/L2/L3), strobe light flashing and vibration (Hi-Lo) runs for one cycle
(around 27 seconds). In the middle of running the test mode, press /
DEMO once to stop.
TO CHARGE A SMARTPHONE WITH THE USB PORT
Connect the charging cable of your mobile phone to the A-type USB
port at the back of the unit, then connect the other end to your
mobile phone. The clock radio will charge the mobile phone
automatically.
TROUBLESHOOTING
If your clock displays the incorrect time or does not function properly
then unplug the DC jack to disconnect the AC power (and remove
the backup batteries). Leave it unplugged for a few minutes and then
plug in the adaptor to repower your clock. The clock is now restored
to the factory settings and is ready to be set again.
BACKUP BATTERY INSTALLATION
Your clock requires 2 x AAA batteries (not included) to provide backup
power for the clock in the event of a power interruption.
1. Place your unit face down on a flat surface.
2. Slide open and remove the battery cover at the bottom of your unit.
3Insert 2 x AAA batteries into the battery compartment by observing
the correct “+” and “-“polarity.
4Replace the battery cover.
Inspect the batteries annually (at a minimum), replacing as necessary.
A leaking battery can damage your clock.
IMPORTANT SAFETY INSTRUCTIONS
1. Read/keep these instructions.
2. Read all warnings.
3. Follow all instructions.
4. Risk of explosion if batteries are replaced by with an incorrect type.
5. Dispose of used batteries according to battery instructions.
6. Do not use this device near water.
7. Clean only with a dry cloth.
8. Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
9. Do not install near any heat sources such as radiators, heat registers,
stoves, or other.
10. Do not tamper with the polarized & grounding plug. Each blade of the
plug has a special purpose for seamless communication & safety. A
grounding type plug has two blades and a third grounding prong.
11. Only use attachments/accessories specified by the manufacturer.
12. Unplug this product during lightning storms or when unused for long
periods of time.
13. This product shall not be exposed to dripping or splashing water and
that no object filled with liquid such as vases shall be placed on the
product. Liquid damage is not covered by warranty.
14. Mains plug is used as disconnect device and it should remain readily
operable during intended use. In order to disconnect the apparatus
from the mains completely, the mains plug should be disconnected
from the mains socket outlet completely.
15. Caution marking is located at the bottom of device.
Innovation & Design for Accessibility, Diversity & Inclusion for All
CARE OF YOUR PRODUCT
1. Place your clock on a stable surface, away from sources of direct
sunlight or excessive heat or moisture.
2. Protect your furniture when placing your unit on a natural wood and
lacquered finish by using a cloth or protective material between the
clock and the furniture.
3. Clean your unit with a soft cloth moistened only with mild soap and
water. Stronger agents such as Benzene, thinner or similar chemicals
can damage the surface of the unit. Make sure the unit is
unplugged before cleaning.
4. If the unit is not to be used for a prolonged period, such as a month
or longer, remove the batteries to prevent possible corrosion. Should
the battery compartment become corroded or dirty, clean the
compartment thoroughly and replace the batteries.
SPECIFICATIONS DEFAULT SETTINGS:
Time format 12 hour
Time 12:00
Alarm 6:00 (AM)
Alarm & shaker level HI
Alarm sound frequency F-1
Alarm sound level L1 (low)
Alarm duration 1 hour (A60)
Snooze duration 5 minutes
