Ampronix Lumimaxx g11s User manual

User Manual

19’’ LCD MONITOR

G11S

LUMIMAXX

INTRODUCTION

About the Product

About the User Manual

Packing list (Standard vs Non-Standard)

SAFETY INFORMATION

PARTS, CONTROLS, and CONNECTORS

Front View

Back View

Connector Pin Assignments

CONNECTION & QUICK START

Connection

Quick Start

OPERATION

Power Indicator

Keys Function

OSD Menu

TECHNICAL SPECIFICATIONS

CLEANING AND DISINFECTION

TROUBLESHOOTING

APPENDIX

Markings and Symbols

Conformity Declaration

RoHS Information

Thank you for purchasing this product. For optimum

performance and safety, please read these instructions

carefully before connecting, operating or adjusting this

product. Please keep this manual for future reference.

Integrated with multiple display modes, the LUMIMAXX

G11S 19’’ LCD MONITOR allows medical

professionals to review multiple images at a time. The

displays excellent performance allows for clear clinical

imagery for hospitals and staff to make crucial decisions,

as well as improve the overall efﬁciency of the institution

and patient satisfaction.

Calibration of each monitor is compliant with DICOM

standards to ensure accuracy of the medical images

displayed and the built-in backlight stabilization system

provides assurance of consistent long-term performance.

LUMIMAXX

G11S 19’’ LCD MONITOR Table of Contents

The information in this manual has been carefully checked and is believed to be

accurate. We assume no responsibility for any infringements of patents or other

rights of third parties which may result from its use. We assume no responsibility

for any inaccuracies that may be contained in this document. We make no

commitment to update or to keep current the information contained in this

document. We reserve the right to make improvements to this document and/or

product at any time and without notice.

All products or service names mentioned in this document may be trademarks of

the companies with which they are associated.

No part of this document may be reproduced, transmitted, transcribed, stored

in a retrieval system, or any of its part translated into any language or computer

ﬁle, in any form or by any means — electronic, mechanical, magnetic, optical,

chemical, manual, or otherwise — without the express written permission and

consent of AMPRONIX.

Disclaimers

About the Product

The LUMIMAXX G11S 19’’ LCD MONITOR is a 19” grayscale medical display with

high resolution imaging. It is intended to be used in displaying and viewing the patient ’s

records (and other medical imagery) for diagnostic, interventional radiology, and other

medical applications. The display supports VGA, DVI-D, BNC IN and BNC OUT. Each

monitor has been precisely calibrated to comply with DICOM Part 3.14. With the accurate

image and stabilization of built-in backlight, the monitor can rapidly maintain brightness and

stability throughout its life.

About the User Manual

This document describes the functionality and the reasonable usage of the LUMIMAXX

G11S 19’’ LCD MONITOR. This user manual contains important information that we

have concluded will ensure your personal safety and prevent damages to your property,

but please keep in mind Ampronix assumes no responsibility for any inaccuracies that may

be contained in this document. We make no commitment to update or to keep current the

information contained in this document. Please read these safety information and product

information so that you can operate the machine safely and effectively.

This user manual is only suitable for the LUMIMAXX G11S 19’’ LCD MONITOR.

Please save this manual for future use.

This user manual may be updated or changed without any notice.

Introduction

Introduction - Packing List

Please check for the following articles in your packaging with your purchased display.

Please note that the photography is only for reference sake: your product (and the

contents included) may appear different from the reference photos.

Please note: We recommend saving the original container and packing material to transport or ship your monitor.

Standard

LCD Monitor

Power Cord

Warranty Card

Certiﬁcation

Non-Standard

VGA Signal Cable

DP Signal Cable

BNC Signal Cable

DVI Signal Cable

USB to Serial Port Cable

Serial Port to RJ11 Cable

Audio Cable

USB Cable

Adapter

Remote Control

User Manual

Optional Non-Optional

VGA Cable

Adapter

USB to Serial

Cable

LCD Monitor Warranty

Card

Serial to RJ11

Cable

Power Cord Certiﬁcation

BNC Cable

Audio Cable

DP Cable

Remote

Control

DVI Cable

User

Manual

USB Cable

Safety Information

To ensure personal safety and proper maintenances, please read this section and the caution statements on the unit.

If the unit begins to emit smoke, smells like something is burning, or

makes strange noises, disconnect all power connections immediately

and contact your dealer for advice.

Attempting to use a malfunctioning unit may result in ﬁre, electric shock, or equipment damage.

Do not open the cabinet or modify the unit.

Opening the cabinet or modifying the unit may result in ﬁre, electric shock, or burn.

Refer all servicing to qualiﬁed service personnel.

Do NOT attempt to service this product yourself as opening or removing covers may result in ﬁre, electric

shock, or equipment damage.

Keep small objects or liquids away from the unit.

Small objects accidentally falling through the ventilation slots into the cabinet or spillage into the cabinet

may result in ﬁre, electric shock, or equipment damage. If an object or liquid falls / spills into the cabinet,

unplug the unit immediately. Have the unit checked by a qualiﬁed service engineer before using it again.

It is recommended that the monitor is shut off when not in use.

The monitor is capable of running unused for an extended period of time, but the lifespan of the monitor

will decrease over time.

Place the device on a solid and stable surface.

Placing the device on an inadequate surface may cause a fall and result in personal injury or equipment

damage. If the unit falls, disconnect the power immediately and consult the dealer for help. Please do not

continue to use damaged equipment, as it may result in ﬁre or electric shock.

Set the unit in an appropriate location.

Do not place the unit outdoors, in transportation systems (ship, aircraft, automobiles, etc), in an

inﬂammable gas environment, in a dusty or humid environment, in a location where the steam would

obscure the screen, or in an area near heat generating devices or a humidiﬁer.

Avoid the danger of suffocation: keep plastic packaging bags away

from babies and children.

WARNING

Safety Information (cont.)

Use the enclosed power cord and connect to the standard power outlet

of your country.

Be sure to remain within the rated voltage of the power cord, as not doing so may result in a ﬁre or

electric shock.

If the power cord needs to be disconnected, please hold it tightly and

unplug it from the base.

Do not tug the cord, as this can damage it and result in a ﬁre or electric shock.

The equipment must be connected to a grounded main outlet.

Not doing so may result in a ﬁre or electric shock.

Use the correct voltage.

• This equipment only applies to the power adapter provided in particular. If the device is connected

to other power adapter that is not mentioned in this manual, that my result in a ﬁre, electric shock,

or equipment damage.

• Do not overload the power circuit, as this may result in a ﬁre or electrical shock.

Handle the power cord with care.

Do not pull the power cord under the unit or under another heavy object.

Do not pull up or twist the power cord.

If the power cord is broken, stop use immediately. Using a broken power cord may result in a ﬁre or

electric shock.

Never touch the plug or power cord if it begins to light up or emit a

thundering sound.

Never touch a damaged LCD panel directly with your bare hands.

The liquid crystal that may leak from the panel is poisonous if it enters the eyes or mouth. If any part

of the skin or body comes in direct contact with the panel, please wash thoroughly. If some physical

symptoms result, seek immediate medical attention.

Please follow the local laws and regulations of your country in the

disposal of scrap resulting from this product.

Safety Information (cont.)

CAUTION

Handle with care when carrying or transporting the unit.

Disconnect the power cord and signal cables, and remove the optional unit. Moving the unit with the

cord or the optional unit attached is dangerous, and may result in injury or damage to the unit.

When handling the unit, grip the bottom of the unit ﬁrmly with both

hands ensuring the panel faces outward before lifting.

Dropping the unit may result in injury or equipment damage.

Do not block the ventilation slots on the cabinet.

Do not place any objects on the ventilation slots.

Do not install the unit in a closed space.

Do not use the unit laid down or upside down.

Blocking the ventilation slots prevents proper airﬂow and may result in ﬁre, electric shock, or equipment

damage.

Do NOT touch the plug with wet hands.

Doing so may result in a ﬁre or electrical shock.

Periodically clean the area around the plug.

Dust, water, oil, or other residue on the plug may result in a ﬁre.

Unplug the unit before cleaning it.

Cleaning the unit while it is plugged into a power outlet may result in an electric shock.

If you plan to leave the unit unused for an extended period, disconnect

the power cord from the wall socket after turning off the power switch

for the safety of your work environment and to preserve power.

LCD Panel Information

When the monitor is cold and brought into a room or the room temperature goes up quickly, dew

condensation may occur inside and outside the monitor. If you observe or believe that this is the case, do

not turn the monitor on until dew condensation disappears. Use otherwise may result in damages.

In order to suppress the luminosity change by long-term use and to maintain the stable luminosity,

please use the monitor with lower brightness settings.

The screen may have defective pixels. Thesepixels may appear as a slightly lighter or darker area on the

screen. This is due to the characteristics of the panel itself, and not the product.

The backlight of the LED panel has a ﬁxed life span. When the screen becomes dark or begins to ﬂicker,

please contact your dealer.

Do not press on the panel or edge of the frame strongly. Do not scratch or press on the panel with any

sharp objects. Do not attempt to brush the panel with tissues. Any of these may damage or scratch the

LED panel. Avoid displaying images for long periods of time with the use of a screensaver or timer.

Parts, Controls, and Connectors

Front View

Back View

Parts, Controls, and Connectors (Cont.)

DVI Connector

VGA Connector

Parts, controls andconnectors

3.3Connector pinassignments

3.3.1DVI connector

3.3.2VGA connector

Thehorizontal15-pinD-sub connectorofthe signal cable:

PinNo. Assignment PinNo. Assignment

1Red VideoInput 2Green VideoInput/SOG

3BlueVideo Input4Sense(GND)

5Cable Detect (GND)6RedVideo Ground

7Green VideoGround8Blue VideoGround

dnuorGcigoL01V5+CDD9

)ADS(eniLataDlaireS21dnuorG11

cnyS.V41cnyS.H31

15 Data ClockLine(SCL)

PinNo. Signal Assignment PinNo. Signal Assignment

1T.M.D.S.Data2-13Noconnect

2T.M.D.S.Data2+14+5V Power

3T.M.D.S.Data2/4 Shield 15 Ground (for +5V)

tceteDgulPtoH61tcennocoN4

-0ataD.S.D.M.T71tcennocoN5

+0ataD.S.D.M.T81kcolCCDD6

dleihS5/0ataD.S.D.M.T91ataDCDD7

tcennocoN02tcennocoN8

9T.M.D.S.Data1-21Noconnect

10 T.M.D.S. Data1+ 22 T.M.D.S. ClockShield

11 T.M.D.SData1/3 Shield 23 T.M.D.S. Clock+

-kcolC.S.D.M.T42tcennocoN21

Parts, controls andconnectors

3.3Connector pinassignments

3.3.1DVI connector

3.3.2VGA connector

Thehorizontal15-pinD-sub connectorofthe signal cable:

PinNo. Assignment PinNo. Assignment

1Red VideoInput 2Green VideoInput/SOG

3BlueVideo Input4Sense(GND)

5Cable Detect (GND)6RedVideo Ground

7Green VideoGround8Blue VideoGround

dnuorGcigoL01V5+CDD9

)ADS(eniLataDlaireS21dnuorG11

cnyS.V41cnyS.H31

15 Data ClockLine(SCL)

PinNo. Signal Assignment PinNo. Signal Assignment

1T.M.D.S.Data2-13Noconnect

2T.M.D.S.Data2+14+5V Power

3T.M.D.S.Data2/4 Shield 15 Ground (for +5V)

tceteDgulPtoH61tcennocoN4

-0ataD.S.D.M.T71tcennocoN5

+0ataD.S.D.M.T81kcolCCDD6

dleihS5/0ataD.S.D.M.T91ataDCDD7

tcennocoN02tcennocoN8

9T.M.D.S.Data1-21Noconnect

10 T.M.D.S. Data1+ 22 T.M.D.S. ClockShield

11 T.M.D.SData1/3 Shield 23 T.M.D.S. Clock+

-kcolC.S.D.M.T42tcennocoN21

Connection and Quick Start

Note: Be sure that the power switches of both the computer and the monitor are OFF.

Connect all the cables to the corresponding connectors as shown in the following ﬁgure:

Turn on the monitor. The power indicator should become orange. Start the computer to set the display mode as:

Resolution: 1280 x 1024 Refreshing Frequency: 60 Hz

If the image is not displaying, please refer to “Troubleshooting”.

Connection

Quick Start

Use the enclosed power cord and connect to the standard power outlet of your country.

Be sure to remain within the rated voltage of the power cord, as not doing so may result in a ﬁre or electric shock.

The equipment must be connected to a grounded main outlet.

Not doing so may result in a ﬁre or electric shock.

Adjust the height, position, and angle of the monitor.

When you’re adjusting the monitor, please grasp the middle of both sides of the monitor screen with your hands and move it slowly.

WARNING

Operation

Power Indicator

Keys Function

Operation

5.3OSD Menu

Alladjustments andsettingsfor OSDmenuare listed in thefollowing table.

Main Menu Function Adjustment Description

InputMaininput VGA, DVI,BNC Select theinput source.


Main/Pip

Select .tcudorpsihtrofelbaliavAtoN>>>

.ssenthgirbehttsujdA001-0ssenthgirB

.tsartnocehttsujdA001-0tsartnoC

.tcudorpsihtrofelbaliavAtoN05noitarutaS

.ssenprahsehttsujdA42-0ssenprahS

Aspect RatioFull/Native/ Fu ll

Aspect/4:3/5:4/UserSelect thezoommode.

.noitcelesedomgnippalrevO>>>tceleSedoM

Setup

.tcudorpsihtrofelbaliavAtoN>>>pmeTroloC

GammaDSA/ DSI/CT

MRI/2.6/2.4/2.2/ DICOM Select thepresetgamma curve

RGB/ YPbPr

SELRGB/ YPbPrNot Availablefor this product.

OSDPositionCenter/To pLeft/To pRight

Bottom Left/BottomRighSelect themenuposition.

OSD

Language

English, español

portuguêsSelect themenulanguage.

Auto Scan

InputedomnacsehttceleSffO,nO

gnittestluafeD>>>teseRyrotcaF

VGA

.yllacitamotuaneercsehtteS>>>tsujdAotuA

H-position 0-100Adjust thescreenhorizontal

position.

V-position 0-100Adustthe vertical position for

screen.

.kcolcehttsujdA>>>kcolC

.esahpehttsujdA36-0esahP

.tcudorpsihtrofelbaliavAtoN>>>>>>oiduA

Status

FW VersionV3.58 Aboutthe software version

information.

Main InputSuchasDVI Aboutthe signal source

information.

Main Format Such as 1280 x102460HzAboutthe resolution

information.

OSD Menu

All adjustments and settings for OSD Menu are listed in the following table.

Technical Speciﬁcation

Technical Speciﬁcation (Cont.)

Cleaning and Disinfection

Periodic cleaning is recommended to keep the monitor clean and to

prolong its operation lifetime.

• Be sure to unplug the power cable from the machine when cleaning your LCD

Monitor.

• Take care not to use any hard or abrasive material to scratch the screen.

• Use a soft damp microﬁber cloth with a small amount of recommended cleaning

agent to remove the dust, ﬁngerprint and grease etc. from screen or housing parts.

• Make sure that liquids do not permeate the machine. If this occurs, it may result in

an electric shock or fault in the device.

• The screen is extremely sensitive to mechanical inﬂuences, so scratching or shocks

should be avoided.

• Only use tested disinfectants.

• If a Cleaning Agent is sprayed directly onto the screen surface, use a microﬁber

cloth to remove drops which run down before they reach the edge of the panel.

• Wipe off liquid drops immediately. Discoloration or calcium deposits can occur due

to contact with liquids over a long period of time.

snoituloSelbissoPhtiWkcehCotstnioPsmelborP

1. No picture

Indicatorstatus: Off

Checkthatthe powercordiscorrectly connected. If the

problempersists, turn offthe monitorpower forafew

minutes, then turn it back on andtry again.

Indicatorstatus: GreenCheck the<Backlight> shortcut keysetting.

Indicatorstatus: Orange Try pressing thekeysonthe computer keyboard or

clicking themouse

2. Displaypositionis

incorrect.

Adjust theimage position by usingthe <H-Position> and

<V-Position> .Ifthe problempersists, usethe graphics

board'sutility software to change thedisplay position if

available. (onlyfor VGAsignal)

3. Vertical bars of

distortion appear.

Decrease thehorizontalbarsbyusing the<Clock> .(only

forVGA signal)

4. Horizontalbarsof

distortion appear.

Decrease thehorizontalbarsbyusing the<Ph ase> .

(onlyfor VGAsignal)

5. Thescreenistoo bright

or toodark.

Adjust <Backlight>shortcutkey (The backlightofthe LCD

monitorhas afixed life span.Whenthe screenbecomes

dark or begins to flicker, please contactyourdealer.)

6. Afterimage

phenomenaappear

Make sure that whetheryou have used thescreensaver

or timerwhendisplayingthe same imagefor extended

periodsoftimeornot.

Afterimagesare particular to LCDmonitors. Avoid

displaying thesameimage forextendedperiods of time.

7. Thescreenhas

defectivepixels.

Thisisdue to thecharacteristics of thepanel itself,and not

theLCD product.

8. Theautomatic

adjustment keycan not

be operated.

The automaticadjustmentkey is invalidwhenthe digital

signal is input. (onlyfor VGAsignal)

Troubleshooting

If a problem persists even after applying the suggested remedies, contact a dealer.

Appendix

Conformity Delaration

1 . This equipment is in conformity with the provisions of the CCC standard.

2 . This equipment sat isﬁes the following two conditions: (1) The device will not bring dangerous interference; (2) The device will not be inﬂuenced by outer interference and cause

unpredictable results.

1. To avoid interference with radio or TV receiving, please use the power adapter and cable matched; Use other cable and power adapter may interfere the other electronic equip-

ment;

2. This equipment has passed the standards of CCC; the device will have a wireless electromagnetic wave, incorrect installation and using will cause interference with wireless

communication systems.

3. We don’t guarantee that the equipment will never produce inter ference when it is installed. You can judge whether the equipment can disturb radio or the television reception by

switching this equipment’s power source. Please do the following steps if there is interference to the other devices when running this equipment:

• Adjust the angle and posit ion of the radio or the television recept ion antenna;

• Increase the distance between this equipment and the radio or the television reception antenna;

• This equipment doesn’t share the same the power input circuit with the radio or the television reception antenna;

• Please consult the professional person if any problem;

Other ancillary equipment is connected to our monitor must also be passed CCC standards. When conﬁgures a medical system , any device is connected to the input or output of
