Amrel Rocky DB7 User manual

USER’S GUIDE
RUGGED HANDHELD COMPUTER

Notice
Copyright© 2015, American Reliance Inc., dba AMREL ®. All rights reserved.
No part of this publication may be reproduced and modified without the written permission
of AMREL
AMREL reserves the right to make changes in the products or the product specifications
without any prior notice. Customers are advised to contact AMREL for updated product
information.
AMREL makes no representations or warranties, either expressed or implied, with respect
to the contents hereof and specifically disclaims any warranties for the correctness of this
book, nor any license grant of AMREL's patents or intellectual properties. AMREL assumes
no liability for customer's loss or damage caused by using this document.
Trademarks
All other brands and product names are trademarks or registered trademarks of their
respective holders.

Revision History:
Revision Date Changes Author
1.0.0 2015/8/24 Initial Release Pablo Tseng

Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance
20cm between the radiator & your body.
Regulatory Information/ Disclaimers
Installation and use of this computer must be in strict accordance with the instructions
included in the user documentation provided with the product. Any changes or
modifications (including the antennas) made to this device that are not expressly approved
by the manufacturer may void the user’s authority to operate the equipment.
The manufacturer is not responsible for any radio or television interference caused by
unauthorized modification of this device, or the substitution of the connecting cables and
equipment other than manufacturer specified. It is the responsibility of the user to correct
any interference caused by such unauthorized modification, substitution or attachment.
Manufacturer and its authorized resellers or distributors will assume no liability for any
damage or violation of government regulations arising from failing to comply with these
guidelines.

FCC (Federal Communications Commission) Statement
This equipment has been tested and found to comply with the limits for a Class-B digital
device pursuant part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates, uses, and radiates radio frequency energy. If not being installed
and used in accordance with the instructions, it may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
Re-orient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
This device may not cause harmful interference.
This device must accept any interference received, including interference that may
cause undesired operation.
FCC Caution
To assure continued compliance, any changes or modifications not expressly approved by
the party responsible for compliance could void the user's authority to operate this
equipment. (Example: use only shielded interface cables when connecting to computer or
peripheral devices).

CE
Products with the CE Marking comply with both the EMC Directive (2004/108/EC) and the
Low Voltage Directive (2006/95/EC) issued by the Commission of the European
Community.
Compliance with these directives implies conformity to the following European Norms:
EN55022 CISPR 22 Radio Frequency Interference
EN55024 EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6,
EN61000-4-8, EN61000-4-11, EN61000-3-2, EN61000-3-3, Generic Immunity
Standard
LVD EN 60950-1: 2006+ A11: 2009+ A1: 2010+ A12: 2011+ A2: 2013
R&TTE (CE) Manual Regulatory Requirement
WLAN - IEEE 802.11 a/b/g/n
802.11 a/b/g/n Restrictions:
European standards dictate maximum radiated transmit power of 100 mW EIRP and
frequency range 2.400-2.4835 GHz.

CE Declaration of Conformity
It is confirmed to comply with the requirements set out in the Council Directive on the
approximation of the laws of the member states relating to Electromagnetic Compatibility
Directive (2004/108/EC), Low-voltage Directive (2006/95/EC) and the procedures given in
R&TTE Directive (99/5/EC).
The equipment was passed, and the equipment test was performed according to the
following European standards:
EN 300 328 V1.8.1 (2012)
EN 301 893 V1.7.1 (2012)
EN 301 489-1 V1.9.2 (2011)
EN 301 489-3 V1.6.1 (2013)
EN 301 489-17 V2.2.1 (2012)
EN300440-1 V1.6.1 2010
EN300440-2 V1.4.1 2010
EN50566 2013
EN62311 2008
EN62209-2 2010
UL, TÜV
AC Adapter (TÜV includes LVD EN60950)

Power Conservation
This handheld computer consumes less power compared to conventional consumer
computers. The power consumption may be further reduced by properly configuring the
Power Management Setup.
It is recommended that the power saving features be enabled even when not running on
battery power. Power Management features can conserve power without degrading system
performance.
Power Safety
There are specific power requirements for your handheld computer:
Only use an approved AC adapter designed for this handheld computer.
There is a 3-prong grounded plug for the AC adapter. The 3rd prong is an important
mechanism for ensuring product safety. Please do not neglect the importance of this
mechanism. If you are unable to access a compatible outlet, please hire a qualified
electrician to install a compatible outlet for you.
When unplugging the AC power cord, please make sure to disconnect the cord by
pulling from the plug head instead of pulling from the wire to prevent wire damage.
Make sure the power outlet and any other extension cord(s) you use can support the
total current load of all the connected devices.
Before cleaning the handheld computer, please make sure it is disconnected from any
external power source.
Warning
Before any upgrade procedures, make sure the power is turned off, and all the
cables are disconnected. Also, it is advisable to remove your battery to prevent
your handheld computer from accidentally turning on.

Battery Precautions
Only use batteries designed for this handheld computer. Using incompatible battery
types may cause explosion, leakage or damage to the computer.
Do not remove the battery from the computer while the computer is powered on.
Do not continuously use a battery that has been dropped, or that appears damaged
(e.g. bent or twisted) in any way. Even if the computer is able to continuously work with
a damaged battery, the circuit damage may occur and possibly cause fire.
Always use the charger designed for this computer to recharge the battery. Incorrect
recharging may cause the battery to explode.
Do not try to service a battery by yourself. For battery service or replacement, please
contact your service representatives.
Please dispose of damaged battery promptly and carefully. Explosion or leakage may
occur, if the battery is exposed to fire, improperly handled or discarded.
Battery Disposal & Caution
The product that you have purchased contains a rechargeable
battery. The battery is recyclable. At the end of its service life,
under various state and local laws, it may be illegal to dispose of
this battery into the municipal waste stream. Check with your local
solid waste officials for details in your area for recycling options or
proper disposal. Danger of explosion may possibly occur, if the
battery is incorrectly replaced. Replace only with the same or the
equivalent battery recommended by the manufacturer. Discard
the used battery according to the manufacturer’s instructions.

Environmental Information, Material Safety & Recycling
All materials used in the manufacturing of this equipment are recyclable or environmentally
friendly. Please recycle the packing materials in accordance with local regulations at the
end of the product's service life.
Notice:
The equipment may contain insignificant amount of hazardous substances for health
and environment below control level.
To avoid spreading such substances into the eco system and to minimize the pressure
on the natural environment, you are encouraged to reuse or recycle most of the
materials in a safe way after the product’s service life.
For more information on collection, reuse and recycle of materials, please consult local
or regional waste administrations for more information. You can also contact your
dealer for more information on the environmental details of the equipment.
The symbol of the crossed out wheeled bin indicates that the product
(electrical and electronic equipment) should not be placed in municipal
waste. Please check local regulations for disposal of electronic products.

TABLE OF CONTENTS
CHAPTER ONE -GETTING STARTED................................................................... 1
UNPACKING.............................................................................................1
APPEARANCE OVERVIEW..........................................................................2
..............................................................................................................6
READY FOR USE......................................................................................7
CHAPTER TWO -OPERATING INFORMATION......................................................... 9
START USING YOUR HANDHELD COMPUTER...............................................9
STOP USING YOUR HANDHELD COMPUTER................................................9
INSTALLING OPERATION SYSTEM.............................................................10
USING INDICATORS AND KEYPAD .............................................................11
USING APPLICATION MENU .....................................................................13
USING TOUCH SCREEN ..........................................................................13
USING MICROPHONE..............................................................................16
OPERATING WIRELESS DEVICES .............................................................17
USING CRADLE (OPTIONAL)....................................................................21
CHAPTER THREE -MANAGING POWER............................................................. 22
CHARGING BATTERY ..............................................................................22
CHECKING THE BATTERY LEVEL ..............................................................22
POWER CONSERVATION .........................................................................23
REPLACING BATTERY .............................................................................23
POWER SAVING TIPS..............................................................................23
SUPPORTING ACPI................................................................................24
ACADAPTER AND AC POWER CORD SAFETY...........................................25
BATTERY PRECAUTIONS .........................................................................26
CHAPTER FOUR -BIOS SETUP ....................................................................... 27
MAIN MENU...........................................................................................27
ADVANCED MENU ..................................................................................28
CHIPSET MENU......................................................................................29
SECURITY MENU....................................................................................30
BOOT MENU..........................................................................................31
SAVE &EXIT MENU................................................................................32
CHAPTER FIVE -DRIVERS AND APPLICATIONS................................................... 33
CHIPSET ...............................................................................................33

VGA.....................................................................................................33
TOUCH SCREEN.....................................................................................34
STICKPOINTER.......................................................................................34
AUDIO...................................................................................................34
DEVICE POWER MANAGER .....................................................................34
WIRELESS DEVICES (OPTIONAL).............................................................35
GLAN (OPTIONAL) ................................................................................36
TPM (OPTIONAL)...................................................................................36
CRADLE (OPTIONAL)..............................................................................36
CHAPTER SIX -SPECIFICATIONS ...................................................................... 37
PLATFORM ............................................................................................37
CPU.....................................................................................................37
MEMORY...............................................................................................37
GRAPHIC CONTROLLER..........................................................................37
STORAGE..............................................................................................37
AUDIO...................................................................................................37
TOUCH SCREEN.....................................................................................38
I/O PORTS ............................................................................................38
POWER.................................................................................................39
DIMENSIONS &WEIGHT..........................................................................39
CASE MATERIAL &COLORS ....................................................................39
ENVIRONMENTAL SPECIFICATIONS...........................................................40
CERTIFICATION ......................................................................................40
CHAPTER SEVEN –OPTIONAL DEVICES............................................................ 41
COMMUNICATION ...................................................................................41
DOUBLE CAPACITY BATTERY PACK (BD62B)............................................41
TRUST PLATFORM MODULE (TPM)..........................................................41
CRADLE CRDB7...................................................................................42
MULTI CHARGER (MCDB)......................................................................43
MINI KEYBOARD KBD ............................................................................44
CHAPTER EIGHT -MAINTENANCE AND SERVICE ................................................ 45
CLEANING .............................................................................................45
TROUBLESHOOTING ...............................................................................45
RMASERVICE.......................................................................................46

Chapter One - 1
Getting Started
Chapter One - Getting Started
Unpacking
After unpacking, the followings are the standard items along with your computer. If there is
any missing or damaged, please notify the dealer immediately.
Handheld Computer Unit
AC Adapter
AC Power Cord
Utility DVD
Stylus Pen
Quick Guide

Chapter One - 2
Getting Started
1
2
3
4
Appearance Overview
Before starting to use your handheld computer, we suggest you to have a quick glance at it
to know the external components well.
Front
1. Embedded Antennas
2. LCD Display
3. LED Indicators
4. Keypad

Chapter One - 3
Getting Started
1
Rear
1. Speaker
2. Battery Lock
3. Stylus Pen
4. Battery
4
1
2
3

Chapter One - 4
Getting Started
L1
L2
Top
L1 & L2:
(Select 1 out of 7)
- Optional Sealed GLAN
- Optional Sealed USB Port
- Optional Sealed Audio
- Optional Sealed RS232 (Trade-off: L5 RS232)
- Optional SMAANT for WLAN, BT, GPS

Chapter One - 5
Getting Started
L5
1
Bottom
1. DC Power Jack
L5 Optional Expansion POGO Connector
Note:
DC-In:
- Default: Fischer 3-pin Connector
Expansion POGO Connector signals include:
- COM1(RS232) x1(Trade off with L1/L2 RS232)
- USB 2.0 (Host) x1
- GLAN x1
- VGA x1 (Trade off with cradle VGA)
- DC-in

Chapter One - 6
Getting Started
L4
2
3
1
Left
L4 Cradle POGO Connector
Right
1. SIM Card
2. USB 2.0 (Host) x1
3. SD (SDHC) Card
Note:
Cradle POGO Connector signals include:
- USB 2.0 (Host) x1
- VGA x1
- DC-in
- V5S

Chapter One - 7
Getting Started
Ready for Use
After taking a quick look at your handheld computer, the following illustrations will get you
ready for using it.
Mounting the Battery
1. Mount the battery into the
battery bay.
2. Use a suitable-size coin to
lock.
Connecting with AC Adapter
1. Insert the DC Jack to the end.
2. Plug the AC cord to the AC
adapter.
3. Plug the AC cord to a right electrical outlet.

Chapter One - 8
Getting Started
Turning ON the Power
1. Make sure the battery is mounted or connect all power cords well for the stable power
supply.
2. Now, you are able to turn ON the power of your handheld computer by pressing “Power
Button”.
Turning OFF the Power
Directly click “Shut down” from your OS to turn OFF the power of your handheld computer.
Note:
The above-mentioned description is a standard way to turn
OFF the power. Directly turn OFF the power by pressing
“Power Button”will cause data lose and is not suggested.
There are still other ways to stop your handheld computer
from operating, see more information in “Operating
Information”.
Note:
The power is able to be ON without any battery mounted once all
the power cords are connected well.
Please see more information in “Operating Information”.
Press on the keypad to
turn on the power of your
handheld computer.
