AMX IS-SPX-1000 - SCHEMA User manual

Installation Guide
IS-SPX-1000 InspiredSignage XPress Player
Overview
The IS-SPX-1000 InspiredSignage XPress Player (FG1231-01) offers a simple
way to deliver digital signage solutions. The rich set of functionalities offered by
the SPX-1000 simplifies the implementation, management and maintenance of
a range of audio/visual communication solutions. The SPX-1000 is designed to
satisfy the reliability needs of nonstop 24/7 service and minimize maintenance
costs. The SPX-1000 contains no moving parts and is engineered to be used
wherever digital signage displays are utilized. Whether integrated behind
displays, beneath a technical floor, or in a custom enclosure, the IS-SPX-1000 is
ready to deliver with a small form factor and a low power draw. The USB
interface can be used to extend the internal storage through memory sticks or
externally powered hard drives. The same interface can support external
devices such as touch screen controllers or keyboards.
Specifications
Remote Monitoring
The IS-SPX-1000 implements an intuitive on-board web interface. By
connecting to the IP address of a unit with any web browser, the user can
monitor the status of the unit and even configure specific parameters. To support
the management of a large distributed network of IS-SPX-1000 devices, native
support for the SNMP protocol is provided. Through this standard protocol, the
devices can publish all their vital parameters, including storage level and CPU
status. Via this protocol, the IS-SPX-1000 can interface with any SNMP network
management. These tools can provide graphical frameworks for remote
monitoring the status of an individual IS-SPX-1000 unit or a complex network of
units.
Storage
The IS-SPX-1000 comes with 2 gigabytes of internal memory, but this may be
expanded by connecting to external hard drives, thumb drives, or other storage
options via the USB port on the front of the device. The USB port also allows
connection to external control devices such as touch panels.
Configuration
The IS-SPX-1000 is configured via an intuitive web interface that can be
accessed by using AMX ZeroConfiguration technology or by entering the
device’s IP Address into a ZeroConfiguration-enabled browser. This interface
allows the configuration of display modes, network settings, time zone settings,
firmware updates and other operational parameters. For more details, please
refer to the IS-SPX-1000 Operation/Reference Guide, available at
www.amx.com.
Connectivity
The IS-SPX-1000 connects to displays through onboard HDMI and VGA
connectors. Through the HDMI output, it is possible to support DVI displays via
an adapter cable, but in this case the digital audio is lost. Both connectors are
simultaneously active so that two displays can be supported without the need of
additional splitters or distribution amplifiers. Where analog audio is needed, an
analog audio connector is provided.
The IS-SPX-1000 is a high-definition ready device: it can render content on
digital displays with resolution up to 1280x720 at 60Hz (720p resolution). The
maximum resolution supported by the IS-SPX-1000 is:
• 1280x720 (16:9)
• 1024x640 (16:10)
• 1024x768 (4:3)
The IS-SPX-1000 connects to the network through a standard RJ-45 connector.
Each device has a unique MAC address that allows the network to identify the
unit and thus the associated display.
FIG. 1 IS-SPX-1000 InspiredSignage XPress Player
IS-SPX-1000 Specifications
Dimensions (HWD) 1.0” x 6.27” x 3.24” (25.4mm x 159.26mm x 82.30mm).
Weight 0.60 lbs (272.16 g).
Enclosure: Metal with black matte finish.
Power Supply: • 5V DC, typ. 0.4A
• 2 watts
Power Supply Input: • 100-240V 50-60 Hz, max input current 0.6A.
Real time clock: • Min. accuracy 1 minute/month free running, battery backed.
Storage: • Internal storage: 2GB solid state.
• External storage: Flash drives and hard disks via USB 2.0
port.
Front Panel Components:
• Ethernet RJ45 Ethernet 10/100 Mbit/s (RJ-45), IEEE 802.3u, 802.3x.
• USB 2.0
Connector
Used with Flash drives and hard disks for additional external
storage; interactivity events via touch screen, keyboard and
mouse.
• Status LED LED displays status of device:
• Green LED flashing once per second (regular operation)
• Green LED flashing 4 times per second (recovery mode)
• Green LED on and flashing occasionally (booting up)
• Orange LED blinks steadily (Zeroconf link-local IP address
is assigned to device)
• LED alternates between red and orange (failure)
• Reset Reset button for rebooting device.
Rear Panel Components:
• DC Power Input 5V DC, typ. 0.4A (2W).
• HDMI HDMI (incl. digital audio), DVI via adapter.
• Analog Audio Out Supported audio codecs: MPEG audio layer 1/2/3 (MP3), ITU
G.711, G.722, G.729,PCM, Microsoft WMA, Real Audio.
front
rear
5V-DC Input
RS232 Interface
Ethernet
RJ45
USB 2.0
Connector Reset
Analog Video
Out (VGA)
Analog
Audio
Out
Digital Video Out (HDMI)
Status LED
IS-SPX-1000 Specifications (Cont.)
Rear Panel Components (Cont.):
• Analog Video Out VGA (DB15 HD connector).
• RS232 Interface RS232, up to 115200 bauds, mini-jack 3.5mm.
Digital Display Compatibility
• Aspect ratio • 16:9, 16:10, 4:3 (horizontal & vertical)
• Maximum
resolution
• 1280x720 (16:9), 1024x640 (16:10), 1024x768 (4:3)
• Video output • 720p (HD-Ready), 576p, 480p, VGA; 50 or 60 fps
• Video connectors • HDMI (incl. digital audio), DVI via adapter. VGA (DB15 HD
connector). Simultaneous use of HDMI and VGA possible.
Certifications: • FCC
•CE
•RoHS
Operating
Temperature:
HDMI: 32ºF to 104ºF (0ºC to 40ºC); 10% to 90% RH
VGA: 50ºF to 104ºF (10ºC to 40ºC); 10% to 90% RH
Storage
Temperature:
-13ºF to 113ºF (-25ºC to 45ºC); 10% to 90% RH
Included
Accessories
• Power Source (3A-161WP05)
• IS-SPX-1000 Installation Guide (93-1231-01)
Other AMX
Equipment
• NXA-AVB Breakout Box Mounting Kit (KA-2250-40)
• IS-SPX-MNT Mount adapter (FG1231-71)

For full warranty information, refer to the AMX Instruction Manual(s) associated with your Product(s).
3/10
©2010 AMX. All rights reserved. AMX and the AMX logo are registered trademarks of AMX.
AMX reserves the right to alter specifications without notice at any time.
3000 RESEARCH DRIVE, RICHARDSON, TX 75082 • 800.222.0193 • fax [phone] • technical support 800.932.6993 • www.amx.com
93-1231-01 REV: C
The IS-SPX-1000 supports 10/100BASE-T Ethernet via a standard RJ-45
connector. Each unit has a unique MAC address and supports all the required
protocols to connect to network file systems and retrieve media elements. These
include:
• Ethernet 10/100 Mbit/s,
• IPv4, DHCP or fixed address
• HTTP configuration server, password protected
• HTTP client for web content retrieval
• WebDAV server, password protected
• SNMPv1/v2c,
•NTP
The IS-SPX-1000 supports USB2.0 Hi-Speed with a bandwidth up to 10 Mbyte/
second.
Installation of the IS-SPX-1000
The installation of an IS-SPX-1000 starts by plugging in two cables, the power
cable and the video cable (HDMI and/or VGA), to the display. As soon as it is
connected to the power cable, the device will boot in a few seconds and
automatically select the resolution supported by the associated digital display.
Content rendering will begin in approximately 1½ minutes. When connected to a
local network through the RJ45 connector, the IS-SPX-1000 supports both
DHCP for automatic configuration of the network and manual configuration by
specifying a static IP address and network properties. The unit can be easily
located near the display, as it does not put off significant heat nor does it contain
any moving mechanical parts.
NOTE: When installing the unit, be careful to avoid any water or high humidity
exposure.
Once installed, getting started with the IS-SPX-1000 is a matter of a few simple
steps. The following sections show how to connect one or more units to a
network and how to publish content from the AMX InspiredSignage XPress
software to specific displays.
Powering up the IS-SPX-1000
To power up the IS-SPX-1000:
1. Check your digital display. The IS-SPX-1000 can drive a digital display
through HDMI or VGA connections. Make sure that your display supports
at least one of the two.
2. Connect the IS-SPX-1000 to the display. Simply plug the HDMI or the VGA
cable between the corresponding video connector on the IS-SPX-1000
and the corresponding video input connector of your display.
3. Power up the display. Make sure to select the right video input.
4. Power up the IS-SPX-1000. Use the cables and the power converter
provided in the IS-SPX-1000 package. Simply plug the power converter on
one side to a 110-220V outlet and on the other to the back panel DC jack.
Shortly after power up, the screen displays the AMX splash screen.
The first time the IS-SPX-1000 boots, the automatic configuration procedure
takes about 1½ minutes. The process will be reduced to less than 50 seconds
when the IS-SPX-1000 is rebooted. During this booting process, the front panel
LED shows green and red activity. At the end of the boot process, the screen will
start displaying the animated AMX logo. This is the default content. At this time,
the green LED blinks regularly on and off every second to indicate that the IS-
SPX-1000 in operating normally.
If your system does not behave as described above, make sure that the digital
displays are functional and powered and that the correct input has been
selected. (Some displays have multiple inputs and you may need to manually
select the right one.) Also make sure that the Reset push button is not being
pressed by some other system component. If the set-up appears correct, try
power-cycling the IS-SPX-1000 by unplugging and replugging the power to the
device.
Accessing the Configuration Pages
The IS-SPX-1000 automatically uses DHCP to assign an IP address to the
device when first configured, but this may be changed to a preassigned IP
address. To access the IP address for the IS-SPX-1000:
1. In a Zero-Configuration-enabled application, such as NetLinx Studio or in a
ZeroConfiguration-enabled browser, look for the entry for the IS-SPX-1000
and its assigned serial number. (This serial number may be found on the
underside of the device.)
2. Click on the entry to open the device’s Web-Based Configuration Pages.
(For more information, please refer to the IS-SPX-1000
Operation/Reference Guide, available from www.amx.com.)
3. In the Status page of the Information section, the IP address is displayed
below the serial number and firmware version.
Resetting the IS-SPX-1000 to Factory Default Settings
WARNING: The following procedure will delete all the content and
configurations on the IS-SPX-1000 unit.
To reinitialize the IS-SPX-1000 unit to its factory default settings:
1. Unplug the unit from the power.
2. Push the reset button and keep it pressed.
3. Power up the IS-SPX-1000 unit.
4. Wait with the reset button pressed for at least 8 seconds.
5. Release the reset button.
6. The IS-SPX-1000 unit will now boot in the factory default mode and will
have the factory default IP address.
Updating Firmware
To check if a new version of the firmware is available for your unit:
1. With a Zero-Configuration-enabled browser, connect to the HTTP server
for the IS-SPX-1000 to access the device’s Web-Based Configuration
Pages. For more information, refer to the Accessing the Configuration
Pages section.
2. Click on Firmware Update under the Administration menu on your left.
3. Check that the field Server URI is equal to: "http://webservices.amx.com/
InspiredSignage/IS-SPX-1000/updates/". (If this is not the case, click the
Reset to Default button)
4. In the Manual Update section, select the update source "From server" and
click the Check for Update button.
A new page will open. At the end of the check, the page reports the current
update status of your IS-SPX-1000 unit. Three cases are possible:
• No updates are available.
• Updates are ready to install. See the section 'Updating IS-SPX-1000
firmware' section to learn how to process with the update.
• The update failed.
The most probable source of this error is that your IS-SPX-1000 could not
contact the update server. It is recommended to check your internet connection
and your network configuration. Make sure that a Gateway and a DNS server
are configured. If the IS-SPX-1000 is not connected to the internet, you need to
contact AMX Technical Support to check which update procedure is best suited
to your configuration. Please specify in your message if your IS-SPX-1000
device(s) are in a location where you can easily plug an USB key or if they have
local network connectivity.
Fatal Error: If the update process reports a fatal error, please contact AMX
Technical Support to find how to restore the firmware of your IS-SPX-1000.
If the check for updates procedure reported that updates are available for your
IS-SPX-1000, click the Update Now button to start the update process.
Important: Do not power down the IS-SPX-1000 at any time during the update
process.
The IS-SPX-1000 will restart automatically once the update process is over. It is
possible that the web page displays a time-out error during the update.
However, this has no influence on the update process itself. At the end of this
process, refresh your web browser to display the new firmware version under
the Current Versions section. If you click the Check for Update button again,
the page will report that no updates are available.
Automatic update
If your IS-SPX-1000 is configured to use automatic update and has direct
access to the Internet, it will update its firmware automatically as soon as a
firmware update is available. The update will take place at 3:00 AM and will not
modify the content played by the IS-SPX-1000. This update also will not affect
its display and networks settings.
To enable the automatic update feature:
1. Check the Enable automatic updates check box
2. Select the update time.
3. Press Apply to validate your changes.
4. The IS-SPX-1000 will reboot at the end of the next update.
NOTE: During large updates, the IS-SPX-1000 stops its normal function during
the update process.
WARNING: Enabling automatic updates requires either a stable power grid or
the use of an UPS power source. The IS-SPX-1000 could become corrupt if a
power loss occurs during the update. If the device becomes corrupted, a
complete firmware re-installation and device reconfiguration is necessary.
