MICODUS MP90G User manual

MP90G User Manual V1.0
Learn how to set up your new MiCODUS Tracker
Copyright ©2022 MiCODUS | All Rights Reserved
R

1. Main Features
2.Specifications
4G LTE
+ 2G GSM
Historical Route
Playback
Real-time
Tracking SOS Waterproof IP65
Voice
Monitor
Overspeed
Alarm
Vibration
AlarmGeo-fence 3000mAh
Model
Weight
Dimensions
Charging Time
Battery Working Time
MP90G
120g
76mm(L) * 40mm(W) * 27mm(H)
Around 6 hours
Tracking Mode, 1 minutes’ reporting: 5 days
Device Information
Working Voltage
Working Current
Sleep Current
Battery Capacity
Working Temperature
Working Humidity
Working Frequency
SIM Card
Cellular Antenna
Positioning Type
GPS Antenna
Cold Start
Hot Start
Tracking sensitivity
GPS Channels
GPS+BEIDOU+LBS
Built-in
6HFRQGV
6HFRQG
-162 dBm
64
4G LTE FDD: B1/B2/B3/B4/B5/B7/B8/B28/B66
2G GSM/GPRS/EDGE: 850/900/1800/1900MHz
Micro SIM Card
Built-in
DC 3.4V - 4.5V
4V/Average 45mA
4V/less than 5mA
3.7V 3000mAh Lion Polymer battery
-20℃- 75℃
10%-85%RH non-condensing
Working Parameters
Cellular Specifications
GNSS Specifications
SOS

Microphone, SOS,Type-C Recharging External Interface
3. Activate Device
LED Event State
Charging
Charger inserted and battery has been fully charged
Charger has not been inserted
Searching for network
POWER LED (RED)
CELL LED
(YELLOW) Network has been registered
Solid
Dark
Dark
Flash every 1 second
Solid
GPS has fixed
GPS is in fixing Flash every 1 second
Device is working but stopped more than 5min
Device has not been turn on
Device ran out of battery
GPS LED (BLUE)
ALL LED
Solid
ALL LED TURN OFF
Install the SIM card via the correct direction as below:
APN,ApnName,User,
Password# SET APN OK APN,orange, orange,orange#
APN,internet#SET APN OKAPN,ApnName#
SMS Command
Format Reply Example Note
If the SIM card has APN user and APN
password, then use this command.
If the SIM card operator doesn't have APN
user and APN password, then please use this
command.
Position Accuracy 5-10m
Normal SIM
Please get the exact correct APN name from local SIM card provider.Take the tracker
to a good signal place for operation and configure the APN for it as below:
Note: The APN information is very important, it must 100% correct to match with the sim card
RIWKHWUDFNHULI\RXFRQ¿JXUHGZURQJ$31WKHWUDFNHUDOVRZLOOUHSO\6(7$31RNEXWLWZLOO
can't get online!

4. Package Content
Main Unit MP90G
Charging Cable
Screws
Screwdriver
Rubber Pad
SIM Card Slot Cover
User Guide
Genunie Packing Box
x 1
x 1
x 4
x 1
x 1
x 1
x 1
x 1
5. Functions Explanation
a. Voice Monitor:
* Set center number by this sms command:
CENTER,A,center number#
For example:
* Switch the tracker to voice monitor mode
by this sms command:MONITOR#
b. Vibration Alert:
This vibration alert function just work under stationary
status. How to use this function:
* Enable the device to enter into arm mode by this
sms command: ARM#
* Conifgure the alarm ways by this sms command:
SENALM,[A][,M]#
A=ON/OFF, default: OFF;
M=0/1/2, way of alarming,
0 :GPRS only, 1: SMS+GPRS, 2: GPRS+SMS+phone call, default:1
* Configure SOS numbers for the tracker by this sms
command:SOS,A,1st number,2nd number,3rd number#
3 SOS numbers supports at the most
* Keep the device under stationary status more than 5min to let it enter into sleep arm mode;
* Vibrate the device then the tracker will send the vibration alarm messages
* Dial the sim number of the tracker from the center
number, then the tracker will pick up the call automatically
and you will can remote monitor the voice around it.
CENTER,A,12345678910#
MONITOR#
SET CENTER NUMBER OK
SET MONITOR MODE OK
MP90G
For example:
SOS,A,12345678910#
SET SOS NUMBER OK
ARM#
SET ARM MODE OK
SENALM,ON,1#
SET VIBRATE ALARM OK
MP90G
Please follow with the quick user guide carefully!

6. Applications
* Set sos alarm numbers via this sms command:
SOS,A,1st number,2nd number,3rd number#
* Press the SOS panic button 3 times continuously, then the
SOS emergency message and call will be sent out to the
SOS numbers.
d. Enable SOS Emergency Call For example:
SOS,A,12345678910#
SET SOS NUMBER OK
MP90G
Personal Valuables
Suitcase Vehicles

Unable to connect to
tracking platform
Check the APN and settings.
Check whrther the data service of SIM card is enabled.
Check the balance of SIM card.
Tracker shows offline
Check whether external power is still connected.
Check if the vehicle entered netword blind area.
Check the balance of SIM card.
7. Troubleshooting
Type Use
8. Full SMS Commands List
Location drift
In area with poor GNSS signal (tall building around or
basement), drifting may happen.
Check whether vibration happens around to trigger the
accelerator.
Unable to locate
Make sure the top side facing upward without metallic things
shielded.
Make sure it’s not in area with no satellite coverage.
No command reply
Make sure command format is correct.
Vehicle may be in network blind area.
Make sure SIM card is well inserted and has SMS servi.
APN Setting
Server Setting
If set with IP: SERVER,0,IP,Port#
APN,Network name[,name,password]#
If set with Domain Name: SERVER,1,
Domain,Port# SERVER,1,d.micodus.net,7700#
SERVER,0,47.254.77.28,7700#
APN,CMNET# (if no name & Password)
APN,internet,internet,internet# (if with name
& Password)
Restart device RESTART#
Internet Traffic Switch
Version Inquiry
INTERNET,OFF#
INTERNET,ON#
VERSION#
Restore factory settings FACTORY#
Functions Command Format Explanation

Functions Command Format Explanation
Parameter Inquiry PARAM#
Status Inquiry STATUS#
BATTERY: XX% (Built-in Battery Power Percent)
INTERNET: CLOSED (No Network)
FAILED (Connecting Network or Failure) SUCCESS
(Connected to Network）
NET: NONE (No GSM Signal) , HIGH / MED /
LOW (Signal Strength) 18
GPS: CLOSED (GPS Module Closed) FIXED,N
(Positioned and satellite number)
UNFIX,0 (Not Positioned yet)
SPEED:30KM/H
SENSOR: ON/OFF (Sensor on or off), LEVEL: 3
(Sensitivity level 1-9)
STATE: ARM (Arm or Disarm)
Alarms Parameters
Latitude & Longitude
Inquiry
Map URL Inquiry
WHERE#
URL#
ALARM#
ID: 19172012644 (ID number of device)
STATE: ARM(DISARM)(Defense status of device)
SPEED: ON/OFF(alarm status); 30km/h(alarm value);
0/1/2(alarm way)
SHIFT: ON/OFF(alarm status); 300m(alarm value);
0/1/2(alarm way)
VIBRATE: ON/OFF(alarm status);3(sensitivity level);
0/1/2(alarm way)
LOW BATTERY: ON/OFF(alarm status);1/2/3
(alarm way)
NOTE: Alarm Ways: 0/1/2 ( 0 :GPRS only, 1: SMS+
GPRS, 2 : GPRS+SMS+phone call )
Working Mode Setting MODE,A,T1,T2#
GMT,E,8# (if no half time zone)
GMT,W,9,30# (if has half time zone)
NOTE: Parameter : E / W；0 ~ 12; 0/15/30/45
A=1/2/3, 1:Tracking mode 2:Power saving mode
3: Hibernation mode; Default mode: 1
A=1
T1：upload interval of GPS data in moving status,
unit: second,10-3600s; default: 10s
T2：upload interval of GPS data in static status,
unit: second, 180-65535s; default: 3600s
A=2
T1: interval start time,format: HH:MM
T2: time interval,range: 1-72
unit: hour,default interval: 24hours
A=3
T1: interval start time,format: HH:MM
T2: time interval,range: 1-72
unit: hour,default interval: 24hours
Time Zone Setting GMT,Time zone orientation,
Whole Time Zone[,Half Time Zone]#
Note: The difference between mode 2 and mode 3 is
that in mode 2, sms commands and phone calls can
wake up the device, but vibration cannot. In mode 3,
only manual restart operation can wake up the
device, after that, device will work for 5 minutes and
then go to sleep.

Set the angle upload
ANGLEREP,[X][,A][,B]#
ANGLEREP,OFF#
Functions Command Format Explanation
Add SOS Administrator
Number
Delete SOS Administrator
Number
Add Center Number
SOS,D,1st number,
2nd number,3rd number#
or SOS,D,1,2,3#
CENTER,A,center number#
SOS,A,1st number,
2nd number,3rd number#
Directly delete the number:
SOS,D,13800138000#
Delete 1st number:
SOS,D,1#
Delete 2nd number:
SOS,D,2#
Delete the 2nd and 3rd number:
SOS,D,2,3#
CENTER,A,13800138000#
NOTE: Center number is only used for cutting off power & oil,
it can only be set by SOS Administrator when using this
command by SMS.
Set 3 numbers at a time:
SOS,A,13800138000,1380013800 1,13800138002#
Set the first numberseparately:
SOS,A,13800138000#
Set the second number separately:
SOS,A,,13800138001#
Means to set 3rd number separately:
SOS,A,,,13800138002#
Delete Center Number
Sleep Mode Setting
CENTER,D#
SLEEP#
Voice Monitor Mode MONITOR#
NOTE: After set this sleep mode, the device will enter into
sleep mode automatically when the device keep stationary
status more than 5min.
NOTE: Before monitoring the voice around the device, the
user must change the device to this monitor mode firstly.
Mileage Statistics
MILEAGE,[A],[B]#
MIELEAGE#
Track Mode TRACK# NOTE: After used the voice monitor mode, user can switch
the device back to track mode by this command.
SLEEP,OFF#
X=ON/OFF, default：ON; A=5～180 degrees, diversion
angle degree, default：30 degrees；B=2～5 seconds,
detecting time, default：3 seconds,
A=ON/OFF, On/Off mileage calculation, default: Off
B=0～999999，Mileage initial value , unit：km ; default: 0,
mileage return to zero
Query current mileage

Heartbeat Packet
Upload
Sensor Sensitivity
Vibration Alarm
Setting
Overspeed Alarm
Setting
HBT,time#
SENLEVEL,sensitivity#
SENLEVEL,2#
NOTE: Sensitivity Level：1-9 (1-9 is from week to
strong vibration)
A=ON/OFF; default:ON
M=0/1/2, way of alarming, 0 :GPRS only, 1: SMS+GPRS,
2: GPRS+SMS+phone call, default:1
A=ON/OFF, open or close over speed alarm, default：OFF
B=1～255(km/h), speed limit, default：100(km/h);
C=0/1/2, way of alarm, 0 : GPRS only, 1: SMS+GPRS,
2: GPRS+SMS+CALL; default: 1
SENALM,[A][,M]#
SENALM,OFF#
SPEED,[A][,B][,C]#
SPEED,OFF#
HBT,3#
NOTE: Range :1-60min, default 3min.
Functions Command Format Explanation
SHIFT,[A][,B][,M]#
SHIFT,OFF#
Example: SHIFT,ON,100,1# ( Means Setting 100 meters
shift alarm range, when the ignition turned off, vehicle’s 100
meters’ shift will trigger the alarm. )
A=ON/OFF; default:ON
B=Shift Distance (Range: 100-9999m)
M=0/1/2; way of alarm, 0 : GPRS only, 1: SMS+GPRS,
2: GPRS+SMS+CALL, default:1
Shift Alarm Setting
BATALM, [A][, M]#
BATALM,OFF#
A=ON/OFF, default：ON;
M=0/1/2, way of alarming, 0: GPRS only, 1: SMS+GPRS,
2: SMS+GPRS+Call,default:1；
NOTE: Once the battery level is below 20% device will alarm.
Low Battery Alarm
Setting
SOSALM, [A][, M]#
SOSALM,OFF#
A=ON/OFF, default：ON;
M=0/1/2, way of alarming, 0: GPRS only, 1: SMS+GPRS,
2: SMS+GPRS+Call,default:2；
NOTE: Press the SOS button 3 times continuously to trigger
the SOS alarm. And please configure SOS numbers firstly.
SOS Alarm Setting
Cancel vibration alarm
Cancel
speed alarm
Cancel
shift alarm
Cancel
low battery alarm
Cancel
SOS alarm

E-mail: [email protected]
Skype: MiCODUS
9. Any Questions?
10. Download the APP
Download on the
APP Store
Download for
Android
Search "MiCODUS" in iOS APP store or Google Play
Store, or just scan the QR code as below to download
MiCODUS APP:
