Introduction
1
AXU-SPL4 Mini-LCD Panel
Introduction
The AXU-SPL4 Mini-LCD Panel is a versatile product primarily designed for civic and
commercial voting systems. However, the it can also accommodate a broad range of other
commercial applications. The backlit LCD has a two line by 16-character menu that provides time,
date, user name, menu titles, and control function information. Menus are modified using Axcess
programming software. The bottom menu line can be used to define the functions of the four LED
pushbuttons. For example, a voting menu could provide choices for YES, NO, ABSTAIN or
CANCEL. A meeting menu can have a member's name, time, and date on the top line, and REQ,
CANCEL, and MUTE on the bottom line to control the request-to-speak microphone operation.
Specifications
AXU-SPL4 Specifications
Power required 12 VDC@ 100 mA (180 mA with backlight on)
Sensitivity • 0 - 1.5 VDC min.
• 3.5 - 12 VDC max.
I/O Ports Two solid-state Input/Output ports detects a low 0 - 1.5 VDC signal as a PUSH
and a high 3.5 - 12.0 VDC signal as a RELEASE.
Relays Two audio-quality relays for microphone mute or similar applications.
Jumpers A two-position jumper next to each relay selects Normally Open (NO) (default
setting) and Normally Closed (NC) operation. Remove the jumper and insert
over the NC pin for NC operation.
LED Indicators Green LED (on rear panel) lights to indicate AXlink status:
• One blink per second power is active and AXlink communication is
functioning.
• Two blinks per second devices specified in the master program do not match
the specified devices found.
• Three blinks per second indicate an AXlink communication error.
• Full-on indicates power is active and AXlink data communication is not
functional.
4 pushbutton red LEDs on the front
Bus Link 4-wire AXlink - used to interconnect the panels to the Axcess control
system.
Connectors 4-pin captive screw connector
Pushbuttons 4 multi-function with LCD status indicators
Can be defined interactively using the LCD.
Contrast Potentiometer Allows adjustment of LCD Contrast
Control Screen Backlit LCD, 2 lines, 16 characters
Buzzer Internal - for audible notification or alarm
Cover Plate Magnetic - removes easily for panel setup and service
Dimensions (HWD) 4.50" x 6.78" x 2.50" (114.3 mm x 172.2 mm x 63.5 mm)
Weight 1.10 lb (498.95 g)
Enclosures UniMount can be mounted on any flat surface or installed in a standard three-
gang wall box.
Optional Accessories BB-SPL4 - AMX Back Box and expansion screws

Introduction
2AXU-SPL4 Mini-LCD Panel

Installation and Wiring
3
AXU-SPL4 Mini-LCD Panel
Installation and Wiring
AXU-SPL4 Internal Rear View
AXlink Device Number
The following table shows the AXU-SPL4 device number DIP switch. Set the AXU-SPL4 device
number before connecting AXlink wiring.
The AXU-SPL4 can be assigned as one of 255 devices in the Axcess system. Set the device number
by referencing the table above. The device number is set by the total of all ON (up) switches. For
example, the DIP switch shown above is set as device number 18 (2 + 16 = 18).
Adjusting the Contrast Potentiometer
An adjustable contrast potentiometer is located under the cover plate and left of the four LED
pushbuttons. Use a Phillips-head screwdriver to turn the potentiometer to the left or right to adjust
LCD contrast. The contrast potentiometer can be accessed via a hole in the back plate located to the
top left of the DIP switch, as shown in FIG. 1.
FIG. 1 AXU-SPL4 internal rear view
DEVICE DIP Switch Settings
Position 12345678
Value 1 2 4 8 16 32 64 128
I/O Ports (P3)
Relays (P2)
DIP Switch
Contrast
Potentiometer
Jumpers
AXlink Status
LED
AXLink
Connector
12345678
ON

Installation and Wiring
4AXU-SPL4 Mini-LCD Panel
Wiring
AXlink wiring
After the device number is set, install the AXlink data/power bus wiring as shown in FIG. 2.
Remove and reconnect the AXlink terminal after changing the device number to set the new device
number in the AXU-SPL4 memory.
Setting Jumpers
A two-position jumper (FIG. 3) next to each relay selects Normally Open (NO) (default setting)
and Normally Closed (NC) operation. Remove the jumper and insert over the NC pin for NC
operation.
Relay connections
Connect up to two independent external relay devices to the 4-pin Relay connector shown in
FIG. 4. Use Afor common and Bfor output. Each relay is isolated and normally open.
FIG. 2 AXlink wiring
FIG. 3 Jumpers
FIG. 4 (P2) Relay connection
PWR
AXP
AXM
GND
PWR
AXP
AXM
GND
AXlink
AXU-SPL4
AXlink Power
Controller
NO
E2
NC
E3
K1 K2
P2
B
A
B
A
K2
K1

Installation and Wiring
5
AXU-SPL4 Mini-LCD Panel
Input/Output connections
Connect up to two input/output (I/O) devices to the INPUT/OUTPUT four-pin connector as shown
in FIG. 5. A contact closure between GND and an I/O port is detected as a PUSH. When used for a
voltage input, the I/O port detects a low (0-1.5 VDC) as a PUSH, and a high signal (3.5-22.0 VDC)
as a RELEASE. When used for an output, each I/O port acts as a switch to GND and is rated at 200
mA @ 12 VDC.
! PWR 12 VDC power output for I/O-type equipment
! I/O 1-2 Two I/O ports
! GND Common ground shared with I/O ports 1-2
Preparing/Connecting Captive Wires
1. Strip 0.25 inch of wire insulation off all wires.
2. Insert each wire into the appropriate opening on the connector according to the wiring
diagrams and connector types described in this section. Do not tighten the screws excessively;
doing so may strip the threads and damage the connector.
FIG. 5 (P3) INPUT/OUTPUT 4-pin connector
P3
PWR
I/O 2
I/O 1
GND

Installation and Wiring
6AXU-SPL4 Mini-LCD Panel
Mounting Options
The AXU-SPL4 can be mounted onto any flat surface, a standard three-gang wall box, or into a
BB-SPL4 back box, as described in the following subsections.
BB-SPL4 Back Box (Optional)
FIG. 6 represents a drawing and dimensions of the BB-SPL4 back box. The BB-SPL4 is available
as an optional accessory.
To install the AXU-SPL4 into the optional BB-SPL4 back box:
1. Cutout the finished surface according to the dimensions in FIG. 6.
2. Insert the BB-SPL4 wall enclosure onto cutout so the back box flanges are exposed.
3. Mount the BB-SPL4 to the wall using wood screws, metal screws, or the supplied expansion
screws.
4. Remove the standard back box from the AXU-SPL4.
FIG. 6 Drawing and dimensions of the BB-SPL4 back box
BB-SPL4 Back Box Dimensions
Item Inch mm Item Inch mm
A 6.78 172.21 E 5.67 144.02
B 4.50 114.30 F 3.05 77.47
C 0.31 7.87 G 1.10 27.94
D 2.50 63.50 H 0.35 8.89
J Optional tab cutout for BB-SPL4 installation.
K Four 6-32 (4.8 mm) screw positions for direct attachment to flat
surface or wall box.
BF
JJ
KCUTOUT LINE
.062 MAX RADIUS
IN CORNERS
G
G
E
D
A
Allow 2-1/2 inch depth for installation
C
H
Expansion screws are provided to install the BB-SPL4 to a finished surface that does
not have rear access. The panel can also be installed with studs using the stud-
mounting holes.

Installation and Wiring
7
AXU-SPL4 Mini-LCD Panel
5. Attach the panel to the BB-SPL4, using a screwdriver, and tighten.
6. Insert the cover plate into the magnetic bezel.
Three-gang wall box
To install the AXU-SPL4 into a three-gang box:
1. Mount the three-gang wall box. Minimum dimensions (HWD) are 5.38" x 2.88" x 2.00"
(13.67 cm x 7.32 cm x 5.08 cm).
2. Attach the panel to the three-gang wall box using machine screws.
3. Insert the cover plate into the magnetic bezel.
Finished surface
To mount the AXU-SPL4 to a finished surface:
1. Cut out the finished surface according to the cutout dimensions in FIG. 6.
2. Place the panel over the cutout and mark the screw positions.
3. Attach the panel to the finished surface using wood or machine screws according to surface, as
shown in FIG. 7, FIG. 8, and FIG. 9, on the following pages.
4. Insert the cover plate into the magnetic bezel.

Installation and Wiring
8AXU-SPL4 Mini-LCD Panel
FIG. 7 demonstrates how to install the AXU-SPL4 into sheetrock using "OLD-WORK" expansion
clips. The expansion clips provide permanent installation allowing for easy removal for servicing.
FIG. 7 Installing the AXU-SPL4 into sheetrock using "OLD-WORK" expansion clips

Installation and Wiring
9
AXU-SPL4 Mini-LCD Panel
FIG. 8 demonstrates how to permanently install the back box with the face frame into a solid
surface, such as a podium or desk.
FIG. 8 Installing the AXU-SPL4 face frame and back box permanently into a hard surface

Installation and Wiring
10 AXU-SPL4 Mini-LCD Panel
FIG. 9 demonstrates how to install the AXU-SPL4 face frame and back box into a hard surface
(podium, desk) as a single assembly.
FIG. 9 Installing the AXU-SPL4 face frame and back box into a hard surface as a single assembly

Installation and Wiring
11
AXU-SPL4 Mini-LCD Panel
Connecting to the Control System
Once the AXU-SPL4 unit is programmed and the mount is prepared, it is ready for final
installation.
Perform the following after pre-installation and wiring is complete:
1. Verify control wiring of I/O and relay ports are installed correctly.
2. Connect the AXU-SPL4 to an AXlink data/power bus. The AXlink LED should blink once per
second.
3. The LCD will display AMX AXU-SPL4. The display will change if any text functions are
preprogrammed in the Axcess system.
Testing
Connect a computer equipped with Axcess software to an Axcess CardFrame or Control System
master port and perform the following:
1. Press an LED pushbutton on the panel. The LCD should display text as programmed.
2. Verify proper LED pushbutton feedback.
3. Look at the lower left Axcess software screen to verify correct device and channel number for
the pushbutton.
4. Test the remaining pushbuttons for proper operation.

Installation and Wiring
12 AXU-SPL4 Mini-LCD Panel

Programming
13
AXU-SPL4 Mini-LCD Panel
Programming
Channels
The following table show the pushbuttons, control channels and their functions.
Send_String
Use Send_String commands to send characters to the LCD using two 16-character screen lines.
Each character moves the unseen cursor to the right where the following characters will appear. The
following table lists the characters with their descriptions and results.
SEND_STRING SPL4, "12, 'VOTE'"
Clears the screen and starts screen on line 1.
SEND_STRING SPL4, "17, 2, 1, 'YES NO ABS CNCL'"
Starts at line 2, column 1.
AXU-SPL4 Pushbuttons, Control Channels and Functions
Pushbuttons (left to right) Control Channels Function
1 = Pushbutton 1 253 = Input/Output Port 1 While channel is ON, relay 1 (energized), everything
else is OFF.
2 = Pushbutton 2 254 = Input/Output Port 2 While channel is ON, relay 2 (energized), everything
else is OFF.
3 = Pushbutton 3 251 = Relay 1 While channel is on, I/O 1 is on (switch to GND),
everything else OFF.
4 = Pushbutton 4 252 = Relay 2 While channel is on, I/O 2 is on (switch to GND),
everything else OFF.
Orientation of the pushbuttons are from left to right.
AXU-SPL4 Send_String Characters Functions
Char (decimal) Desc Result
2 STX Moves the cursor to home (line 1, column 1).
3 ETX Moves the cursor to the end (line 2, column 16).
8 BS Moves the cursor one position left.
9 HT Moves the cursor one position right.
10 LF Moves the cursor one line down.
12 FF Clears the display and moves the cursor to home (line 1, column 1).
13 CR Moves the cursor to column 1 of the current line.
17 DC1 Moves the cursor to the line and column stated in next two characters
(17, <line>, <column>).

Programming
14 AXU-SPL4 Mini-LCD Panel
Send_Commands
The following Send_Commands are listed to program the AXU-SPL4:
AXU-SPL4 Send_Commands
BEEP
Generates a beep of the
specified time duration. By
sending another beep com-
mand before the previous one
times out, the duration can be
extended.
Syntax:
'BEEP<time>'
Variable:
time = 0 - 9
Examples:
SEND_COMMAND SPL4, 'BEEP5'
Sets the beep at 0.5 seconds. Time is measured in tenth of seconds.
SEND_COMMAND SPL4, 'BEEP'
Turns beep OFF immediately.
LIGHT
Sets backlight level.
Syntax:
'LIGHT<Backlight brightness>'
Variable:
brightness = 0 - 9; default is zero.
Example:
SEND_COMMAND SPL4, 'LIGHT9'
This command sets the backlight to full brightness.
SEND_COMMAND SPL4, 'LIGHT'
This command turns the backlight OFF.
OFFSET
Sets the offset for the four
pushbutton switches. Default
is 1.
Syntax:
'OFFSET<Switch offset>'
Example:
SEND_COMMAND SPL4, 'OFFSET97'
This command sets the first switch (left most) to use channel 97. Switch 1 will
be channel 97 for its PUSH, RELEASE, and feedback channel. Similarly,
switch 2 through 4 (right most) will use 98 through 100 respectively.
TIME
Sets the amount of time with-
out a switch press before the
backlight times out and shuts
OFF.
Syntax:
'TIME<Timeout>'
Variable:
timeout = 1 - 99, measured in minutes. Default si 15 minutes.
Example:
SEND_COMMAND SPL4, 'TIME10'
This command sets the timer to turn backlight OFF after 10 minutes of
inactivity.
SEND_COMMAND SPL4, 'TIME'
This command resets the backlight timer.

Programming
17
AXU-SPL4 Mini-LCD Panel

AMX reserves the right to alter specifications without notice at any time.
brussels • dallas • los angeles • mexico city • philadelphia • shanghai • singapore • tampa • toronto • york
3000 research drive, richardson, TX 75082 USA • 469.624.8000 • 800.222.0193 • fax [phone] • technical support 800.932.6993
037-004-1053 11/01 ©2001 AMX Corporation. All rights reserved. AMX, the AMX logo, the building icon, the home icon, and the light bulb icon are all trademarks of AMX Corporation.
AMX reserves the right to alter specifications without notice at any time. *In Canada doing business as Panja Inc.
