Planar PT191MU User manual

PT191MU
Touchscreen Monitor
USER’S GUIDE
www.planar.com

2PT191MU User’s Guide (020-0418-00 B)
The information contained in this document is subject to change without notice.This document
contains proprietary information that is protected by copyright. All rights are reserved. No part of
this document may be reproduced, translated to another language or stored in a retrieval system,
or transmitted by any means, electronic, mechanical, photocopying, recording, or otherwise, with-
out prior written permission.
Windows® is a registered trademark of Microsoft, Inc.
Other brands or product names are trademarks of their respective holders.
Important Recycle Instruction:
LCD Lamp(s) inside this product contain mercury. This product may contain other
electronic waste that can be hazardous if not disposed of properly. Recycle or dispose
in accordance with local, state, or federal Laws. For more information, contact the
Electronic Industries Alliance at HYPERLINK“http://WWW.EIAE.ORG”WWW.EIAE.OR
For lamp specific disposal information check WWW.LAMPRECYCLE.ORG.

PT191MU User’s Guide (020-0418-00 B) 3
Table of Contents
Usage Notice
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Introduction
About the Product . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Touchscreen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Package Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Installation
Product Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Start Your Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
User Controls
Front Panel Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
How to Use the OSD Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
On-Screen Display Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Appendix
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Warning Signal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Product Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Compatibility Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Touchscreen Driver Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

4PT191MU User’s Guide (020-0418-00 B)
Usage Notice
Precautions
Follow all warnings, precautions and maintenance as recommended in this user’s
manual to maximize the life of your unit.
Do:
qTurn o the product before cleaning.
qUse only a dry soft cloth or clean room wiper when cleaning
the LCD panel surface.
qUse a soft cloth moistened with mild detergent to clean the
display housing.
qUse only high quality and safety approved AC/DC power adapter.
qDisconnect the power plug from AC outlet if the product is not
used for a long period of time.
Don’t:
qDo not touch the LCD panel surface with sharp or hard objects.
qDo not use abrasive cleaners, waxes or solvents for cleaning.
qDo not operate the product under the following conditions:
- Extremely hot, cold or humid environment.
- Areas susceptible to excessive dust and dirt.
- Near any appliance generating a strong magnetic eld.
- Place in direct sunlight.
WARNING – To prevent the risk of re or shock hazards, do not expose
this product to rain or moisture.
WARNING – Please do not open or disassemble the product as this may
cause electric shock.
!
!

PT191MU User’s Guide (020-0418-00 B) 5
Introduction
About Planar’s PT191MU
The PT191MU is a 19” at panel screen with an active matrix, thin-lm transis-
tor (TFT), liquid crystal display (LCD).
Features include:
qAnalog and Digital dual signal input
q19” diagonal screen size
q1280 x 1024 high resolution
q16.7 million displayable colors
q31.5~80kHz horizontal scan
q56~75 Hz high refresh rate
q0.294 mm x 0.294 mm pixel pitch
q300 cd/m2(typ.) brightness
q4 CCFT backlight lamps w/ 50,000 hrs life
q1000:1(typ.) contrast ratio
qL/R=89°/89°, U/D =89°/89° viewing angle, CR=10:1
qTr + Tf: 8 ms (typ.) response time
qAuto-adjustment function
qIntegrated multimedia audio function
qMultilingual OSD user controls
qVESA DPMS power saving
qUSB hub with 1 upstream and 2 downstream ports on the stand base
qStand with tilt and swivel functions
q3M® ClearTek™ II Capacitive touchscreen

6PT191MU User’s Guide (020-0418-00 B)
Touchscreen for PT191MU
qSurface: Anti-glare treatment
qInterface: USB
qDurability:
Capacitive: 225 million activations
qHardness of surface =
Capacitive: 6.5 Mohs
qTransmittance: Up to 91.5% typical
qS/W Driver Compatibility: Windows® 95/98/Me/NT/2000/XP, Linux

PT191MU User’s Guide (020-0418-00 B) 7
Package Overview
LCD Display
VGA Signal Cable
USB Upstream Cable
Power Adapter
DVI-D Cable
Power Cord
Audio-In Cable
User’s Guide Landing Strip
Touchscreen Driver
Installation CD-ROM

8PT191MU User’s Guide (020-0418-00 B)
Installation
Product Overview
• Front View
• Rear View
LCD Display
Front Panel Con-
trols
Stand

PT191MU User’s Guide (020-0418-00 B) 9
• USB Hub Ports
1. USB Downstream Ports
These two USB ports are available for connecting USB type peripheral
devices such as keyboard, mouse, printer and so on.
2. USB Upstream Port
This Port is for connecting the USB Upstream cable to computer’s or other
hub’s USB port.

10 PT191MU User’s Guide (020-0418-00 B)
• VESA Mount your monitor• VESA Mount your monitor
• VESA Mount your monitor• VESA Mount your monitor
• VESA Mount your monitor
This monitor conforms to the VESA Flat Panel Mounting Physical Mounting
Interface Standard which denes a physical mounting interface for at panel
monitors, and corresponding standards for at panel monitor mounting devices,
such as wall and table arms.The VESA mounting interface is located on the back
of your monitor.To mount the monitor on a swing arm or other mounting
xture, follow the instruction included with the mounting xture to be used.
Note!Note!
Note!Note!
Note!
Please select the proper screws!
The distance between the back cover surface and the bottom of the screw
hole is 8mm. Please use a M4 screw.
!
