Ancona AN-2401 Manual

Elite Induction Cooktop
30” and 36”
User Manual
&
Installation Instructions
IMPORTANT SAFETY INSTRUCTIONS
Carefully read the important information
regarding installation, safety and maintenance.
Keep these instructions for future reference.
MAAN2401-EN-2.1
2021-09-09

Table of Contents
IMPORTANT SAFETY INFORMATION......................................................................... 3
INTRODUCTION TO INDUCTION COOKING ............................................................. 9
CARE AND CLEANING ............................................................................................... 12
IMPORTANT INSTALLATION INSTRUCTIONS .......................................................... 13
CONTROL PANEL OVERVIEW.....................................................................................16
18
HOW TO USE ..............................................................................................................19
OTHER FUNCTIONS................................................................................................... 21
SPECIFICATIONS .......................................................................................................
COUNTER INSTALLATION INSTRUCTIONS ............................................................. 15
TROUBLESHOOTING ERROR CODES ...................................................................... 22
Please read the entire instruction manual prior to using your unit.
— 2 —
You can download an owner's & installation manual at www.anconahome.com

Cooktop ventilation
It is very important to provide
adequate ventilation for optimal
operation. Installing over vented
cabinets is highly recommended.
Recommended space between cooktop base if installing above oven
Cooktop ventilation areas - DO NOT OBSTRUCT!
36 inch
Model: AN-2411
30 inch
Model: AN-2401
Keep ventilation areas clear, to allow proper airow.
CAUTION: During cooking, built-in fan inside the cooktop will operate
constantly to keep the internal components cool. The air intake is on the bottom
of the cooktop box, and the warm air exhaust is located on the back and side of
rim, as shown on the schematic. If the air intake or the exhaust is obstructed,
the cooktop safeties will either diminish the power output or shut down the unit.
WARNING Allow enough space between cooktop and cabinet for proper airow.
If airow is blocked, burners can overheat and stop working temporarily.
Top view Top view
Rear view Rear view

(Only 36 in.
model AN-2411)
WARNING DO NOT apply any sealant along the perimeter. The cooktop must
breath freely.


All electric cooktops run off a three phase, two live wire cable, 240 Volt, 60 Hertz, AC-only
electrical supply with ground.
Maximum distance between cooktop and overhead cabinetry is 30 inches (76.2 cm)
24” Min. (61 cm)
30” Max. (76.2 cm)
4” ×8” (10.2 cm ×20.3 cm)
opening to route armored
cable if panel is pressent.

— 15 —

— 16 —
Master power button

— 17 —
Master power button

— 18 —

— 19 —
With the cooktop being ON as mentioned above, press the desired cooking
zone “+” key. The display will blink and show a “1”.
Then press either the “+” key, “-” key or “Boost” to select a cooking level.
The cooking zone will automatically turn on readiness mode if a key is not
pressed within 30 seconds.

— 20 —
a. Press the desired cooking zone key, the corresponding display shuts
off. The unit is now in readiness mode.
