Andersson Android Smart-TV stick User manual

User manual
English | Svenska | Norsk
ADS 2.0 | Android Smart-TV stick

Copyright
This manual is the copyright of CI no 556520-4137. No part of this manual may be
revised, copied or transmitted in any way without written permission from CI no
556520-4137.
Statement
This manual does not provide any warranty or related declarations. All information
in this manual including the product specification, pictures and literatures is just for
reference, CI no 556520-4137 reserves the rights to update contents of this manual
without further notice.
Upphovsrätt
Org.nr 556520-4137 äger upphovsrätten till den här handboken. Inga delar av hand-
boken får ändras, kopieras eller överföras utan skriftligt tillstånd från org. nr 556520-
4137.
Meddelande
Den här handboken innehåller inga garantier eller andra typer av utfästelser. All in-
formation i handboken, inklusive tekniska data, bilder och texter, är endast exempel
och används i referenssyfte. Org.nr 556520-4137 förbehåller sig rätten att upp-datera
innehållet i handboken utan föregående meddelande.
Opphavsrett
Org.nr 556520-4137 har opphavsretten til denne håndboken. Ingen deler av denne
håndboken skal revideres, kopieres eller overføres på noen måte uten skriftlig samtykke
fra org.nr 556520-4137.
Erklæring
Denne håndboken gir ingen garanti eller tilhørende forsikringer. All informasjon i denne
håndboken, inklusiv produktspesifikasjon, bilder og tekst, er bare ment som referanse.
Org.nr 556520-4137 forbeholder seg retten til å oppdatere innholdet i denne håndboken
uten forvarsel.

Table of Content / Innehållsförteckning / Register
About the Product 4
Important Notice 4
Overview and Functions of Android Stick 5
Initial Operation 6
Functions of Air Mouse Remote 7
Instructions for Remote 8-9
Android User Interface 10-14
Specifications 15
Om produkten 16
Viktig information 16
Översikt och funktioner för Android Stick 17
Kom igång 18
Air Mouse-fjärrkontrollens funktioner 19
Instruktioner för fjärrkontroll 20-21
Android användargränssnitt 22-26
Specifikationer 27
Om produktet 28
Viktig informasjon 28
Android Stick: Oversikt og funksjoner 29
Komme i gang 30
Air Mouse-fjernkontroll - Funksjoner 31
Instruksjoner for fjernkontroll 32-33
Android brukergrensesnitt 34-38
Spesifikasjoner 39

English Svenska Norsk
4
About the Product
The Android Smart-TV stick works with a great variety of
platforms such as: Computers, Projectors, Smart TV, HTPC,
Android tablets, Android media players, smart devices, etc.
It is easily connected via Plug-and-Play, and compatible with
USB1.1 and USB2.0 interface. It supports Windows, LUNIX,
Mac and Android OS.
The included remote control features an air mouse function
which lets you navigate the screen with a mouse cursor
as you would with a traditional mouse. With gyroscope
technology, you can easily move the mouse cursor simply by
moving your wrist slightly.
Important Notice
Æ Avoid exposing this product to moist or under water
conditions, high temperature or direct sunshine.
ÆAvoid dropping the product.
Æ Do not try to repair the product on your own. Always
contact the retailer or an authorized technician.
Æ Do not shut down or disconnect the device when it is
formatting or upgrading. Interrupting will cause system
error.

English Svenska Norsk
5
Overview and Functions of Android Stick
ÆHDMI: Audio/Video out.
ÆMicroSD memory card slot.
ÆMicro USB OTG: Connect to power supply.
Æ USB port: Connect to mouse, keyboard or external HDD.
HDMIUSB port
Power Memory card slot

English Svenska Norsk
6
Initial Operation
Connecting the Android Stick
Connect the Android Stick to the TV set or LCD monitor
via HDMI. Set the TV or monitor input source to HDMI
port. (Refer to TV user manual). Connect power supply and
devices. Booting information will appear on the screen within
1 minute.
To control the Android user interface, you can connect
the included air mouse remote, or any USB mouse and
keyboard. If no physical keyboard is connected, the Android
user interface will provide a virtual onscreen “soft keyboard”.
When a physical keyboard is connected, it will be hidden
automatically.
Press left button of the mouse to confirm (“OK”) or open.
Press the right button to return or go back. Hold left button to
pull icon or copy & paste file.
Further instructions on how to connect and use the included
Air Mouse remote follows on the next page.
Since there is only one USB port, if you want to connect more
devices, such as a keyboard, you can plug a USB hub into
the USB port to acquire more ports.

English Svenska Norsk
7
Functions of Air Mouse Remote
ADS 2.0 | Android Smart-TV stick
Power indicator light.
The light is red when
power charging, and
turns blue during use.
Left button Right button
Locking button
Reset button
Lithium battery charge port
Direction buttons
and enter button

English Svenska Norsk
8
Instructions for Remote
Charging
The built-in lithium battery can be charged by using the USB
cable to power from PC usb port or other USB power adapter.
Connecting the remote control
Take out the USB receiver from the bottom of the remote.
Plug the USB receiver into the USB port of the Android stick
(or optionally, any other smart device you wish to control).

English Svenska Norsk
9
ÆInstructions for Remote
Operation
Press the -icon on the remote control to activate it. The
LED indicator on the remote control will be lit to indicate that
the remote control is active.
If you move your wrist, the cursor should follow your movement
on the screen of the Android stick or the connected device.
The remote will enter power-saving standby mode after 2
minutes of inactivity. To activate it again, simply press the
-button.
Pairing
If the cursor disappears from the screen, the remote might
have lost contact with the USB receiver. Unplug the USB re-
ceiver from the Android Smart-TV stick, press and hold left
and up direction button simultaneously. When the LED light
starts to flash, release the buttons and plug the USB receiver
back into the stick. When the LED light stops flashing, the
pairing was successful.
Resetting the remote
If the remote does not work, there might be something wrong
with the software. You can reset the remote by using a small
pin and inserting it into the hole on the back of the remote.

English Svenska Norsk
10
Android User Interface
When the Android Stick is connected to a monitor via HDMI,
and to a power supply as well as a USB device for control,
you are ready to use the Android Stick.
Status bar
Return button
Home button - return back to the main menu
See applications that are currently running
Decrease or increase volume
Turn OFF the Android stick
Hide the status bar

English Svenska Norsk
11
ÆAndroid User Interface
Delete an icon from the home page
Put the cursor over the icon, press and hold left button and
hold a couple of seconds. An X will appear on top of the
screen. Pull the icon onto the X, and it will be deleted from
the home page
Add application icons on the home page
Open the application page, move the cursor to the icon you
want, press and hold left button, and pull the icon to the
home page.
Move icons
Put the cursor over the icon, press and hold left button, pull
the icon to the desired position and release the left button to
place it.
Slide pages
You can slide pages by pressing and holding the left button,
and then pulling the page to the left or right side.
Application page
If you press the top-right icon, you will go to a page contain-
ing all the applications that are installed.

English Svenska Norsk
12
ÆAndroid User Interface
Application page:
Settings
Wi-fi Settings: ON/OFF.
Click on ON/OFF to switch ON or
OFF. When switched on, available
networks will be listed. Press a de-
sired network to connect, and type
the password if required.
USB to RJ45 LAN adapter:
If there is no wireless network avail-
able you can connect to the internet
via cable. A USB2.0 LAN adapter is required (not included). Plug
it in the USB Host or OTG port. Connect RJ45 LAN cable, click
“Settings” -> “more” -> “Ethernet” -> tick “Use Ethernet”.
Language & input
In this menu you can select language and usual input
method. The device includes 54 different languages. Click
“Settings” -> “Language & input”.

English Svenska Norsk
13
Keyboard and Mouse
If the device is only connected with the mouse, an onscreen
keyboard will appear within the user interface. If a keyboard
is connected, the onscreen keyboard will be hidden automat-
ically once the hardware is detected. Options for keyboard
and mouse can be configured under “Settings” -> “Person-
al” -> “Language and Input”.
Download apps from Google Play
You can download apps from Google Play Store. Click on the
Google Play Store icon to open. You will need to register or
log in with an existing account.
Android Application management
Click on the -icon to manage applications.
Install program:
Click install to find the downloaded soft-
ware installation package. Click to install.
If it cannot be installed successfully, note
that before installing, you might need to tick
the option in “Settings” -> “Security” ->
“Unknown sources” to allow installation of
apps from unknown sources.
Delete Application
To delete an application, click “manage”, then choose a pro-
gram and delete it.
ÆAndroid User Interface

English Svenska Norsk
14
ÆAndroid User Interface
File Explorer
With the File Explorer you can browse any multimedia files,
such as music, video and photos, which are stored on a USB
memory stick or memory card which is connected to the unit.
E-home Media Center
Ensure that that all the computers or media devices use the
same router as the Android Smart-TV-stick. Open windows
media player (the screenshot is from Windows 7, for refer-
ence).
Click “share your music, picture and video files.” You should
be able to find the PC on the Android Smart-TV-stick. Click
media player. If your PC is sharing, then you can find and play
the files through E-home Media Center.

English Svenska Norsk
15
Specifications
RF radio frequency: 2.4G RF
Power (stick): USB 5V/2A
Power (remote): 3.7V Lithium battery
Button life-span: 1500,000 keystrokes
USB receiver working current: 21.5mA
Remote control working current: 20mA
Signal transmission mode: 2.4G RF
Time before power-saving mode: 2 minutes
Supported Operating System: Windows, Mac OS 10.0/
LUNIX 9.0 and over,
Android.
Included in package:
Android Smart-TV-Stick
Air mouse remote
USB power cable for air mouse remote
USB power cable for stick
HDMI extension cable
AC-USB adapter
User manual

English Svenska Norsk
16
Om produkten
Android Smart-TV-stickan fungerar med ett brett urval av
plattformer såsom datorer, projektorer, Smart-TV, HTPC,
surfplattor, Android-mediaspelare, Smart-enheter med mera.
Den ansluts lätt med Plug-and-Play och är kompatibel med
USB 1.1, och USB 2.0-gränssnitt. Den stöder Windows, LU-
NIX, Mac och Android OS.
Den medföljande fjärrkontrollen har en så kallad air
mouse-funktion som låter dig styra enheten och navigera på
skärmen med en mus-markör såsom du skulle ha gjort med
en vanlig datormus. Med gyroskopisk teknologi kan du lätt
flytta musmarkören genom att vrida lätt på handleden.
Viktig information
Æ Undvik att utsätta produkten för fukt eller vatten, höga
temperaturer eller direkt solljus.
ÆUndvik att tappa eller stöta till produkten.
ÆFörsök inte att reparera produkten på egen hand. Kon-
takta återförsäljaren eller en auktoriserad tekniker ifall det
uppstår problem.
ÆStäng inte av eller koppla ur enheten när den formaterar
eller uppgraderar. Avbrott kan orsaka systemfel.

English Svenska Norsk
17
Översikt och funktioner för Android Stick
ÆHDMI: Audio/Video out.
ÆMicroSD minneskortläsare.
ÆMicro USB OTG: Anslut till strömförsörjning.
ÆUSB-port: Anslut till mus, tangentbord eller extern hård-
disk.
HDMIUSB-port
Ström Minneskortläsare

English Svenska Norsk
18
Kom igång
Anslut Android Smart-TV stick
Anslut Android Smart-TV stick till TV:n eller monitorn via
HDMI. Ställ in TV:ns eller monitorns ingångskälla till HDMI-
porten (Se TV-manualen). Anslut strömförsörjningen och
enheter till stickan. Uppstart av systemet visas på skärmen
inom någon minut.
För att styra Android-användargränssnittet kan du ansluta
den medföljande fjärrkontrollen, eller valfri USB-mus och
tangentbord. Om inget fysiskt tangentbord är anslutet,
kommer Android-användargränssnittet att förse dig
med ett virtuellt tangentbord på skärmen - så kallat “soft
keyboard”. När ett fysiskt tangentbord är anslutet döljs
skärmtangentbordet automatiskt.
Tryck på vänster musknapp för att bekräfta (“OK”) eller
öppna. Tryck på den högra knappen för att gå tillbaka. Håll
ned vänster musknapp för att dra en ikon eller kopiera och
klistra in en fil.
Närmare instruktioner om hur du ansluter och använder den
medföljande Air Mouse-fjärrkontrollen följer på nästa sida.
Stickan har bara en tillgänglig USB-port. Om du vill ansluta
fler enheter, såsom tangentbord, kan du ansluta en USB-hub
till USB-porten för att få fler portar.

English Svenska Norsk
19
Air Mouse-fjärrkontrollens funktioner
ADS 2.0 | Android Smart-TV stick
Ström-indikatorlampa:
Lyser rött när enheten
laddas och blått under
användning.
Vänsterknapp Högerknapp
Låsknapp
Återställnings-
knapp
Litiumbatteriets laddningsport
Pilknappar och
enter-knapp

English Svenska Norsk
20
Instruktioner för fjärrkontroll
Laddning
Det inbyggda litium-batteriet kan laddas med en USB-kabel
som kopplas till ström från en dators USB-port eller en annan
USB-nätadapter.
Anslut fjärrkontrollen
Ta ut USB-mottagaren från botten av fjärrkontrollen. Anslut
USB-mottagaren till USB-porten på Android Smart-TV stick
(eller eventuellt någon annan smart media-enhet du vill styra).
