ANHEUSER-BUSCH BUD LIGHT FR109BULT User manual

2022 ANHEUSER-BUSCH, LLC. BUD LIGHT IS A REGISTERED
TRADEMARK OF ANHEUSER-BUSCH, USED UNDER LICENSE.
REFRIGERATOR
FR109BULT

MODELNO.
CAPACITY OF FRIDGE IN CU FT AND INTERIOR SIZE (IN.) (WxHxD)
SHELF MATERIAL
TEMPERATURECONTROL TYPE
TEMPERATURE RANGE FRIDGE IN FAHRENHEIT AND CELSIUS
DEPTH (LESS DOOR) (IN.)
DEPTH WITH DOOR OPEN 90 DEGREES (IN.)
HEIGHT TO TOP OF REFRIGERATOR (IN.)
PRODUCT WIDTH (IN.)
PRODUCT DEPTH (IN.)
PRODUCT HEIGTH (IN.)
POWER CORD LENGTH (IN.)
BPA FREE (YES/NO)
REFRIGERANT TYPE
MAXIMUM POWER CONSUMPTION IN AMPS
OPERATION NOISE dBA
FR109BULT
1.6/14.6X14.6X16.1
STEEL WIRE
MECHANICAL THERMOSTAT
32℉~50℉(0℃~10℃)
16.1
34.3
18.50
17.5
18.6
19.6
70.8
YES
R600a
0.8A/60W
43
This refrigerator is freestanding design. You must leave sufficient room on all four sides in order
for the refrigerator to exhaust properly. If heat is not allowed to exhaust properly, the refrigerator
will not operate efficiently. Moreover, due to the design of thermoelectric units, they should not
be placed in a warm room. Typically it will cool anywhere between units, they should not be
placed in a warm room. Typically it will cool anywhere between 20-28 °F below the ambient
temperature but this depends on many environmental factors.
SAVE THESE INSTRUCTIONS HOUSEHOLD USE ONLY
FEATURES
SAFETY PRECAUTIONS
When using this appliance, always exercise basic safety precautions, including the following:
Use this appliance only for its intended purpose as described in this use and care guide.
This refrigerator must be properly installed in accordance with the installation instructions
before it is used. See grounding instructions in the installation section.
Never unplug your refrigerator by pulling on the power cord. Always grasp the plug firmly
and pull straight out from the outlet.
Repair or replace immediately, all electric service cords that have become frayed or
otherwise damaged. Do not use a cord that shows cracks or abrasion damage along its
length, the plug or the connector end.
Unplug your refrigerator before cleaning or before making any repairs. Note: If for any
reason this product requires service, we strongly recommend that a certified technician
performs the service.
Do not use any electrical device or any sharp instrument in defrosting your refrigerator.
If your old refrigerator is not being used, we recommend that you remove the doors and
leave the shelves in place. This will reduce the possibility of danger to children.
After your refrigerator is in operation, do not touch the cold surfaces in the refrigerator
compartment, particularly when hands are damp or wet. Skin may adhere to these extremely
cold surfaces.
This refrigerator should not be recessed or built-in an enclosed cabinet. It is designed for
freestanding installation only.
Do not operate your refrigerator in the presence of explosive fumes.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.

Parts And Features
1. Freezer Compartment
2. Drip Tray
3. Full Width Shelf
4. Temperature Control (not shown rear mounted)
5. 1 Full and 1 Half Door Storage Width Shelf
2022 ANHEUSER-BUSCH, LLC. BUD LIGHT IS A REGISTERED
TRADEMARK OF ANHEUSER-BUSCH, USED UNDER LICENSE.

Correct positioning
Well Ventilating
There is need of good ventilation around the refrigerator for easy dissipation of heat, high
efficiency of refrigeration and low power consumption. For this purpose, sufficient clear space
should be needed around the refrigerator, its back is at least 100mm away from the wall, its
sides at least have a space of 100mm separately and the height from over its top is not less
than 200mm. A clear space should be left to open its doors to 160°
Power Supply
The refrigerator is only applied with power supply of single phase alternating current of
115V/60Hz.If fluctuation of voltage in the district user is of so large that the voltage exceeds
the above scope, for safety sake, be sure to apply A.C. automatic voltage regulator to the
refrigerator. The refrigerator must employ a special power socket instead of common one with
other electric appliances. Its plug must match the socket with ground wire.
Power Line Cord
The cord should be neither lengthened nor folded into coil during operation. Moreover, it is
forbidden that cord is kept close onto the compressor at the back of the refrigerator, the surface
temperature of which is quite high when operating. Touching with it would deactivate the
insulation or cause leakage for electricity.
Do not use with Extension cord.
Correct positioning
Protection from Moisture
Avoiding placing the refrigerator in a place where heavy moisture is present so as to minimize
possibility of rusty for its metal parts. Still more, the refrigerator is forbidden to be directly
sprayed by water, otherwise, poor insulation and current leakage would occur.
Protection from Heat
The refrigerator should be far away from any heat source or direct sunshine.
Fixing Stable
Floor on which refrigerator will be placed must be flat and solid. It should not be laid on any
soft material such as foam plastic, etc. If the refrigerator is not on the same level, adjust the
screws suitably. The refrigerator should not be placed near anything which may echo.
Keep Away from Danger
It is inadvisable that the refrigerator is placed near any volatillizable or combustibles such as
gas, petrot, alcohol, lacquer and banana oil, etc. The above-mentioned objects can not be
stored in the refrigerator.
Moving
When fixed or moved, the refrigerator can not be set horizontally or declined to more than 45°
or upside-down.

Cautions
Water contained in food or getting into air inside the refrigerator by opening doors may form
a layer of frost inside, It will weaken the refrigerator when the frost is thick, while it is more
than 2mm thick, you should defrost.
Defrosting in freezer chamber is operated manually. Before defrosting, take the food, the ice
tray and the shelf out into the cold storing chamber temporarily then set the knob of the
temperature regulator to position"0"(where the compressor will stop working )and leave the
door open until ice and frost dissolve thoroughly deposited at the bottom of the freezer
chamber, wipe off the water with soft cloth. In the case of speeding up the defrosting, you
may put a bowl of warm water (about 50℃)into the freezer chamber, and be sure to set the
knob of the temperature regulator to original position after defrosting.
It's inadvisable to heat the freezer chamber directly with hot water or hair dryer while
defrosting to prevent deformation of the inner case.
It's also inadvisable to scrape of ice and frost or separate food from the containers which
have been congealed together with the food with sharp tool or wooden bars, so as not to
damage the inner casing or the surface of the evaporator.
If the supply cord of this appliance is damaged, it must only be replaced by a repair shop
appointed by the manufacturer, because special purpose tools are required.
To Prevent A Child From Being Entrapped, Keep Out of Reach Of Children And
Not In The Vicinity Of Freezer (Or Refrigerator).
•
•
•
•
•
•
Maintenance
The refrigerator should be cleaned and maintained once a month.
When performing maintenance, make absolutely sure that the power plug is first
disconnected from the power outlet.
Wipe the inner and outer surface of the refrigerator and its accessories with wet cloth. If
they are too dirty, scrub them with neutral detergent, and then clean them with water and
dry them with clean cloth. After this, a small quantify of glass wax is recommended to
polish the refrigerator surface with a flannelette.
For cleaning, don't use hot water、diluent、petrol、alcohol. kerosene 、washing powder、
cleanser、aikailinous detergent、acid、Chemical cloth、etc. So as not to damage the
lacquer coat and plastics. It is forbidden than the refrigerators directly sprayed with water.
Otherwise, it would cause rusty or weaken the insulation.
Be careful to upkeep the sealing rubber bars of the doors, They should always be cleaned.
If the plastic parts in refrigerator remain contaminated for a long time by oil (animal or
vegetable), they will be easy aged and possibly cracked. The drain pan gets dirty very
easily if it is not cleaned regularly, bad odours will be produced, get into the habit of
cleaning this pan regularly.
•
•
•
•
•
•

Troubleshooting
When the refrigerator does not work:
Check if there is a power failure.
Check if the power plug is plugged into the power outlet.
Check that the fuse has not blown.
When the refrigerator is cooling excessively:
The temperature control dial may be set too high.
If you place foodstuffs containing a lot of moisture directly under the cool air outlets，they will
freeze easily. This does not indicate a malfunction.
When the refrigerator is not cooling sufficiently:
The food may be packed too tightly together which will block the flow of cool air.
You may have put something hot or a lot of foodstuffs into the refrigerator.
The door may not have been closed properly.
The door gaskets may be damaged.
The refrigerator may not be ventilated.
There may be insufficient clearance between the refrigerator and the surfaces immediately
both sides and above.
The temperature control dial may not be set properly.
1.
2.
3.
4.
5.
6.
7.
8.
When the defrosting water overflows inside the refrigerator and onto the floor:
Check that the drain pipe and the drain hose are not clogged.
Check that the drain pan is housed properly。
When the refrigerator's cabinet front heats up:
In order to safeguard against condensation，there is an anti condensation, pipe which
heats up the cabinet front when running actuated: A warm cabinet front does not indicate a
malfunction.
When condensation form on the outside of the refrigerator:
Condensation may form on the outside when the humidity is high such as during a wet
season. This is the same result as the condensation formed when chilled water is poured
into a glass. It does not, therefore，indicate a failure，wipe dry with a dry cloth.
When you hear a sound like water flowing:
A sound like water flowing is the refrigerant flowing. It does not Indicate a malfunction。
When the cabinet's side panel heats up:
The side panel of the cabinet will heat up when the door is opened or closed frequently.
when starting the unit and when the unit operates in summer with high ambient outside
temperature. In such case, do not touch the panel，it results from the dissipation of the
heat from inside the cabinet，and it does not mean that something is wrong with the
refrigerator.

Door reversal instructions
Your refrigerator is built with a reversible door. You have the choice of either opening
it from the left or the right side. In order to reverse the opening direction of your door,
please follow these simple instructions.

V1

V1

Instructions pour inversion de la porte
Votre réfrigérateur est construit avec une porte réversible.
Vous avez le choix d'ouvrir la porte a droite ou a gauche.
Si vous voulez reverser I'ouverture de la porte, suivre les instructions simples.
