Anker Eufy T8420 User manual

Anker Innovations Limited. All rights reserved. eufy Security and eufy Security
Logo are trademarks of Anker Innovations Limited, registered in the United
States and other countries. All other trademarks are the property of their
respective owners.
Model: T8420 51005001853 V01
Quick Start Guide
eufy Security Floodlight Camera

Table of Contents
Safety Instructions 01
What's in the Box 01
Getting Started 02
Installing the Junction Box 04
Mounting Floodlight Camera 07
Adjusting Floodlight Camera 09
Restoring Power 10
Using the Floodlight Camera on the Eufy Security App 10
NOTICE 11
Customer Service 13

01 02
Getting Started
1. Shut power off at the breaker in your house. Switch on/off the lights to
make sure the electricity in your house is properly shut off.
2. Access the area you want to be lit and the area you need camera coverage,
and install your Floodlight Camera on the front wall or on the side wall. The
latter way is highly recommended to get an optimal coverage for the floodlight
and camera. *
* The motion sensor is more sensitive to the movements across the camera field of view than
movements towards or away from the sensor. We highly recommend you install the floodlight
camera on the side wall.
Safety Instructions
1. Shut off power at the fuse or circuit breaker before installing.
2. Do not install the device near flammable surfaces.
3. Must have a licensed electrician install the Floodlight Camera.
4. Do not use the device in the environment at too high or too low temperature,
never expose the device under strong sunshine or too wet environment.
5. The suitable temperature for the product and accessories is -20°C to 50°C.
What's in the Box
Floodlight Camera
(T8420)
Junction Box
Central Screw Cap Plate Screws
Installation Hook
Central Screw

03 04
On the side wall:
Move towards or leave vertically
Move horizontally
Increased
detection range
for vertical
movement
up to 26ft (8m)
Increased detection
range for horizontal
movement
up to 33ft (10m)
On the front wall:
Move towards or leave vertically
Move horizontally
Detection range
for vertical
movement
up to 20ft (6m)
Detection range
for horizontal
movement
up to 26ft (8m)
Installing the Junction Box
1. Remove the rubber plugs indicated in the illustration below.
2. Run the power cable wire through the grommet and access hole.

05 06
4. Unscrew the bolt with a flat-head screwdriver. Connect the Neutral (blue) /
Ground (green / green and yellow) / Live (brown) wire to the Neutral /
Ground / Live wire connector in the junction box respectively. Secure the
wires tightly to prevent wires from falling.
N
L
Neutral
Ground
Live
1 2
3. Install the junction box:
• Orientate the two mounting holes vertically to ensure stable mounting.
• On wooden walls, DO NOT pre-drill holes. Use the screws provided to fix
the junction box onto the wall.
• On walls that are made out of hard materials, such as stucco, brick, or
concrete, drill holes with a 15/64 inch (6 mm) drill bit, and then insert
the anchors provided into the holes. Use the screws provided to fix the
junction box on the wall.
1 2

07 08
Connect Wires
1. Connect Ground wire from the Floodlight Camera to the Ground wire from the
wire connector in the junction box.
2. Connect the Live / Neutral wire from the Floodlight Camera to the Live /
Neutral wire from the wire connector in the junction box respectively.
3. Secure the wires with a flat-head screwdriver.
Green / green and yellow, brown and blue wires must connect to
the matching colors. Never cross connect.
Mounting Floodlight Camera
Hang Floodlight Camera
Hang Floodlight Camera on the junction box with the hook provided.

09 10
Restoring Power
Switch on the main circuit breaker in the house. To confirm that the Floodlight
Camera is operating, check that the red LED indicator is flashing ready for
connection.
If Floodlight Camera is not powered on, switch off the circuit
breaker before checking the wiring of Floodlight Camera.
Using the Floodlight Camera on the Eufy Security App
1. Download the eufy Security app from the App Store (iOS devices) or Google
Play (Android devices).
2. Sign up for a eufy Security account. Follow the onscreen instructions to
connect Floodlight Camera to your Wi-Fi network. Now you can check live
stream in the eufy Security App.
The Floodlight Camera can be used only after your phone and the
Floodlight Camera are connected to the same wireless network.
For troubleshooting, check the Help section in the Eufy Security app.
Refer to the app for information on the various LED status indications.
Mount Floodlight Camera On the Junction Box
1. Align the hole on the junction box with the opening in the Floodlight Camera.
2. Screw the central screw through the center of Floodlight Camera to mount it
in position.
3. Cover the central screw with the central screw cap to prevent it from rusting.
Adjusting Floodlight Camera
1. After installation is complete, loosen the adjustment screws on the camera
and floodlight to adjust the camera and light position to the desired angles.
2. Tighten the screws firmly to complete the installation.

1211
NOTICE
FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Warning: Changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures: (1) Reorient or relocate the receiving antenna. (2) Increase the separation between
the equipment and receiver. (3) Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected. (4) Consult the dealer or an experienced radio/ TV technician for help.
FCC Radio Frequency Exposure Statement
The device has been evaluated to meet general RF exposure requirements. The device can be used in
fixed/mobile exposure condition. The min separation distance is 20cm.
Notice: Shielded cables
All connections to other computing devices must be made using shielded cables to maintain compliance
with FCC regulations.
The following importer is the responsible party
Company Name: Fantasia Trading LLC
Address: 9155 Archibald Avenue, Suite 202, Rancho Cucamonga, CA 91730, USA
Telephone:[phone]
This product complies with the radio interference requirements of the European Community.
Declaration of Conformity
Hereby, Anker Innovations Limited declares that this device is in compliance with the essential
requirements and other relevant provisions of Directive 2014/53/EU.For the declaration of conformity,
visit www.eufylife.com
Do not use the Device in the environment at too high or too low temperature, never expose the Device
under strong sunshine or too wet environment.
The suitable temperature for the product and accessories is -20°C-50°C.
RF exposure information: The Maximum Permissible Exposure (MPE) level has been calculated based on a
distance of d=20 cm between the device and the human body. To maintain compliance with RF exposure
requirement, use product that maintain a 20cm distance between the device and the human body.
CAUTION RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED
BATTERIES ACCORDING TO THE INSTRUCTIONS
Wi-Fi Operating Frequency Range:2412~2472MHz for EU;
This product is designed and manufactured with high quality materials and components, which
can be recycled and reused.
This symbol means the product must not be discarded as household waste, and should be
delivered to an appropriate collection facility for recycling. Proper disposal and recycling helps
protect natural resources, human health and the environment. For more information on disposal
and recycling of this product, contact your local municipality, disposal service, or the shop where
you bought this product.
IC Statement
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired
operation of the device."
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitation est autorisée aux deux conditions suivantes:
(1) l'appareil nedoit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage
est susceptible d'en compromettre le fonctionnement."
IC RF Statement
When using the product, maintain a distance of 20cm from the body to ensure compliance with RF
exposure requirements.
Lors de l'utilisation du produit, maintenez une distance de 20 cm du corps afin de vous conformer aux
exigences en matière d'exposition RF.
FCC ID:2AOKB-T8420 IC:23451-T8420
Anker Innovations Limited
Room 1318-19, Hollywood Plaza, 610 Nathan Road, Mongkok, Kowloon, Hong Kong

13
Customer Service
• Warranty
12-month limited warranty
• Call Us
United States [phone] Mon-Fri 9AM-5PM (PT)
United Kingdom [phone] Mon-Fri 6AM-11AM (GMT)
Germany [phone] Mo-Fr 6:00-11:00
• Email Us
Customer Support: [email protected]
