Anova BIO150S Instruction Manual

BIO150S
Milesur, SL.
Rúa Eduardo Pondal, nº 23 - Pol. Ind. Sigüeiro
15688 - Oroso - A Coruña - 981 696 465 www.millasur.com
EN
INSTRUCTIONS AND USER MANUAL

ANOVA wishes to congratulate you for choosing one of our
products and guarantees the assistance and cooperation that has
always distinguished our brand over time.
This machine is designed to last for many years and to be of great use
if used in accordance with the instructions contained in the user
manual. We therefore recommend that you read this instruction
manual carefully and follow all our recommendations.
For more information or doubts, you can contact us through our web
supports such as www.anova.es.
INFORMATION ABOUT THIS MANUAL
Pay attention to the information provided in this manual and on the
machine for your safety and that of others.
•This manual contains instructions for use and maintenance.
•Take this manual with you when you go to work with the machine.
•The contents are correct at the time of printing.
•The rights to make changes at any time are reserved without
affecting our legal responsibilities.
•This manual is considered an integral part of the product and
must remain with it in case of loan or resale.
•Ask your dealer for a new manual in case of loss or damage.
READ THIS MANUAL CAREFULLY BEFORE USING THE MACHINE
To ensure that your machine provides the best results, please read the
usage and safety regulations carefully before using it.
OTHER WARNINGS:
Incorrect use could cause damage to the machine or other objects.
The adaptation of the machine to new technical requirements could
cause differences between the content of this manual and the
purchased product.
Read and follow all instructions in this manual. Failure to follow these
instructions could result in serious personal injury.

Content
1. Safety instructions
Protection
Safety for children and pets
Safety with gasoline engines
2. Technical data
3. Commissioning
Procedure
4. Maintenance
Maintenance procedure
engine service
Lubrication
blades
entrance knife
Jam
5. Troubleshooting
6. Assembly guide
7. Environment
8. Exploded view
9. CE declaration of conformity

1. Safety instructions
Caveat
The machine must not be used in any other way than described in the manual.
Only use original spare parts. If you use unapproved replacement parts, there is an increased
risk and therefore it is not allowed.
All liability is disclaimed in the event of an accident or other damage caused by the use of
unapproved parts.
Before using the machine for the first time, please read this manual.
Check the emergency stop switch before each operation.
Make sure all bolts and nuts are tight before start-up.
Choose a flat workplace. The machine can only be used outdoors, away from flammable
materials.
The user must wear close-fitting work clothes, work gloves, eye protection, ear plugs, a dust-
proof mask and work boots.
Before and after using the machine, proper maintenance is necessary.
Failure to follow these safety instructions could result in personal injury and/or product damage.
Protection
Caveat
This is a high powered machine, with moving parts that operate with a large amount of energy.
You must use the machine safely. Unsafe operation can create a number of hazards for you and
anyone else in the vicinity.
Always take the following precautions when using this machine:
•Please note that the operator is responsible for accidents or hazards to other people, their
property and themselves.
•Always wear safety glasses with side shields while using the mower to protect your eyes
from debris.
•Avoid wearing loose clothing or jewelry, which can be caught in moving parts.
•We recommend wearing gloves. Make sure your gloves fit well and do not have loose
cuffs or drawstrings
•Wear steel-toed boots with slip-resistant treads. Do not use the machine without proper
footwear.
•Wear long pants.
•Keep other people at least 15 meters away from your work area at all times. Stop the
engine when another person or pet approaches.
Safety for children and pets
Caveat
Tragic accidents can occur if the operator is not alert to the presence of children and pets.
Children are often attracted to the machine and how it works. Never assume that children will
remain where you last saw them. Always follow these precautions:

•Keep children and pets at least 15 meters away from the work area and make sure they
are under the care of a responsible adult.
•Be alert and turn off the machine if children or pets come near the work area.
•Never let children use the machine.
Safety with gasoline engines
Caveat
Gasoline is a highly flammable liquid. It also gives off flammable vapors that can easily ignite
and cause a fire or explosion. Never ignore the dangers of gasoline. Always follow these
precautions:
•Never run the engine in an enclosed area or without adequate ventilation, as engine
exhaust contains carbon monoxide, which is an odorless, tasteless, and deadly
poisonous gas.
•Store all fuel and oil in containers specifically designed and approved for this purpose
and keep them away from heat and open flame, and out of the reach of children.
•Fill the gas tank outdoors with the engine off and allow the engine to cool completely. Do
not handle gasoline if you or someone nearby is smoking, or if you start something that
could cause it to ignite or explode. Reinstall the fuel tank cap and fuel container cap
securely.
•If you spill gasoline, do not try to start the engine. Move machine away from spill area
and avoid creating any sources of ignition until gas vapors have dissipated. Clean up
spilled fuel to avoid a fire hazard and dispose of waste properly.
•Let the motor cool down completely before storing it in any enclosure. Never store a
machine that has gasoline in the tank or fuel container near an open flame or spark, such
as a water heater, space heater, clothes dryer, or oven.
•Never make adjustments or repairs with the engine running. Stop engine, disconnect
spark plug wire, keeping it away from spark plug to prevent accidental starting, wait 5
minutes before making adjustments or repairs.
•Never alter the engine governor setting. Over-revving the engine is dangerous and will
damage the engine and other moving parts of the machine. The engine governor setting
has been preset at the factory.
•Keep combustible substances away from the engine when it is hot.
•Never cover the machine while the muffler is still hot.
•Do not run the engine with the air filter or carburetor air inlet cover removed. Removal of
such parts could create a fire hazard. Do not use flammable solutions to clean the air
filter.
•The muffler and engine become very hot and can cause severe burns. Do not touch.
Note
No list of warnings and precautions can be exhaustive. If situations occur that are not covered
by this manual, the operator must apply common sense and operate the shredder safely.
The product does NOT come with oil. There may be residue from the factory tests, but it is not
enough to run the engine.
We recommend 10W-30 motor oil and the motor holds 1.2 quarts.
Both yellow oil fill holes go to the same reservoir. Use the one that is easiest to reach.

Make sure all bolts are tight before running.
2. Technical data
Model
BIO150S
Motor
DUCAR
Displacement
420cc
Type of waste
granulated minced
Function
Shredded leaves, branches, fodder, agricultural feed
Cutting speed
2530rpm
Fuel type
Unleaded petrol
Weight
175kg
3. Commissioning
All branches must not exceed 4 inches in diameter. Freshly cut branches and straw are
recommended for best performance. Due to the different hardness and moisture content, the
motor may have problems, but it will continue to chip. Proper branch insertion is from large
diameter to smaller diameter. It is best to put branches with leaves all together.
It is recommended to place small logs with branches together for safety reasons.
Procedure
1. Make sure the machine is on a flat, dry surface.
2. Adjust the outlet chute to the location for the processed material.
3. See the engine manual for how to start the engine.
4. Set throttle to full RPM.
5. Do not stand directly behind the intake chute. Stand to the side of the entrance ramp as
material can back up.
6. Load material from the large diameter side.
7. When the machine starts to feed automatically, release the branch.
8. Let the material fully process before adding more.
9. If the machine does not feed automatically, you may need to load the branches slowly or
use other branches to guide it in.

4. Maintenance
Regular maintenance is the way to ensure the best performance and long life of your machine.
Consult this manual for proper maintenance procedures.
Caveat
Before performing any maintenance or inspection procedures, stop the engine, unplug the
power cord and wait 5 minutes to allow all parts to cool. Disconnect the spark plug wire to
prevent accidental starting.
Maintenance procedure
Procedure
Before each
use
every 5
hours
every 25
hours
every 100
hours
Check engine oil level
Δ
Check the general equipment
Δ
grease bearings
Δ
check belts
Δ
engine cleaning
Δ
Change engine oil
After first use/
Every 5 hours
of use
Δ
Replace air filter
Δ
replace spark plug
Δ
engine service
Refer to the engine manufacturer's user manual for information on engine maintenance.
Lubrication
We recommend 1 pump of lithium grease in each bearing before each use.
blades
Check blades for cracks, dents, or chips. If there are cracks, do not use it until it has been
replaced. If the blade shows wear or is chipped, these blades can be reversed and used on
the other side.
The blades can be removed using the included T-bar wrench or a 17mm socket with extension
and ratcheting screwdriver. Be sure to use soft material on the drum to prevent it from moving.
If the drum moves, you can remove the screws. Also, use rags or paper towels at the entrance
to prevent bolts or blades from falling into the drum.
entrance knife
The blade is located at the bottom of the drum housing towards the inlet chute. Create a gap
for the shredding blades and create a scissor action.

If you have poor shredding performance, we recommend adjusting by loosening the bolts
below, adjusting the inlet blade approx 2-5mm to the shredding blades, make sure it is parallel
to the shredding blades, and retighten.
media jam
Stop the machine, remove both the inlet duct and the outlet duct. Remove the bearing cap and
turn the shaft with the included wrench.
You can also use a larger adjustable wrench if you need more force. Try twisting in both
directions to loosen jammed material.
5. Troubleshooting
SYMPTOM
POSSIBLE CAUSE
The motor does not start.
•Is the ignition switch in the "ON" position?
•Is the fuel shutoff valve open?
•Are you using clean, fresh gas? If the gas is old, change
it.
•Use a fuel stabilizer if holding fuel for more than 30 days.
•Is the spark plug clean? If the spark plug is dirty or
cracked, replace it. If it's oily, leave it out, put a rag over
the plug hole and pull the recoil cable a few times to blow
the oil into the cylinder, then wipe the plug clean and
reinsert it.
Engine lacks power
or is not running gently.
•Check that the throttle lever is in the "Run" position.
•Is the air filter clean? If it is dirty, replace it following the
procedure in the engine manufacturer's owner's manual.
•Is the spark plug clean? If it is dirty or cracked, replace it.
If it's oily, leave it out, put a rag over the plug hole and pull
the recoil cable several times to blow the oil out of the
cylinder, then wipe the plug clean and reinsert it.
•Are you using clean, fresh, unleaded gas? If it's old,
replace it. Use a fuel stabilizer if you keep the fuel for
more than 30 days.
•Does your engine have the proper amount of clean oil? If
it is dirty, replace it following the procedure in the engine
manufacturer's owner's manual.
•Check the oil level and adjust it as necessary.
The engine smokes
•Check the oil level and adjust it as necessary.
•Check the air filter and clean or replace it if necessary.
•You may be using the wrong oil, too light for the
temperature. See the Engine Owner's Manual for detailed
information.
•Clean the cooling fins if they are dirty.
Motor stalls while chipping
•Check if the motor is stopped due to overload.
•
Check if there is something blocked in the ducts.

•Check the emergency stop button and protection switch.
The drum is stuck
•Stop the machine, remove the inlet chute, the outlet chute,
the cap over the bearing, and rotate the shaft to expel the
material. You can use the included wrench or use a larger
adjustable wrench for more strength.
poor shredding performance
•Check the gap between the entry blade and the shredding
blades. We recommend 1-5mm clearance for best
performance
6. Assembly guide
Installation procedure:
1. Place the drum shell (1) on a small platform. Make sure there is space on the sides for
the installation of the wheels (2) and the support leg (4).
2. Attach the wheels (2) to the axle bracket (3) and use the appropriate nuts to secure.
3. Attach the wheels (2) with the axle bracket (3) to the drum housing (1) using the
appropriate bolts and nuts.
4. Install the drawbar joint (5) to the drum housing (1) using the appropriate bolts and nuts.
5. Attach the support leg (4) to the tow bar joint (5) using a bolt, nut and shear pin (8).
6. The tow bar (6) connects to the tow bar joint (5) and use the locking knob (7) to secure
it.
7. Remove from platform.

10.Attach the input ramp hinge (9) to the drum housing hinge (1). Use swivel nuts or hex
nuts to secure.
11.Attach the outlet chute hinge (10) to the drum housing hinge (1). Use swivel nuts or hex
nuts to secure.
12.Attach the adjustable diverter (11) to the top of the outlet chute (10) and use the
adjustment knob (12) to secure.

13.Put the battery into the battery cover first, and then slide it onto the battery pedestal
under the power chute.
7. Environment
Protect the environment. Recycle the oil used by this machine by taking it to a
recycling center. Do not pour used oil into drains, land, rivers, lakes or seas.
Please dispose of your machine in an ecological way. We must not dispose of
machines together with household waste. Its plastic and metal components can be
sorted according to their nature and recycled.
The materials used to pack this machine are recyclable. Please do not dispose of the
packaging in household waste. Please dispose of these packages at an official waste
collection point.

8. Exploded view
BIO150S

9. CE declaration of conformity
DISTRIBUTION COMPANY
MILLASUR, SL
RUA EDUARDO PONDAL, Nº 23 PISIGÜEIRO
15688 OROSO - A CORUÑA
SPAIN
EC DECLARATION OF CONFORMITY
In compliance with the different CE directives, it is hereby confirmed that, due to
its design and construction, and according to the CE mark printed by the manufacturer
on it, the machine identified in this document complies with the relevant and fundamental
health and safety requirements. of the aforementioned EC directives. This declaration
validates the product to display the CE symbol.
In the event that the machine is modified and this modification is not approved by
the manufacturer and communicated to the distributor, this declaration will lose its value
and validity.
Name of the machine: BIO-SHREDDER
Model: BIO150S
Recognized and approved standard to which it conforms:
directive2006/42/EC
2014/30/EU
Tested according to standards:
EN ISO 12100-2010, BS EN ISO 14120:2015,
EN 13683:2003+A2:2011+AC:2015,
ENISO13854:2019, ENISO13857:2019,
EN13525:2020, ENISO14982:2009
Company
seal
09/05/2020
