1-1 Introduction
This guide provides performance verification procedures for Anritsu
N Type Model 34 Series Precision Coaxial Adapters.
1-2 Description
The N Type Model 34 Series family consists of the following models:
1-3 Recommended Test Equipment
Table 1-1. Model 34 Series Precision Coaxial Adapters
Anritsu
Part Number Description
34NN50A N male to N male Precision Adapter, DC to 18 GHz
34NFNF50 N female to N female Precision Adapter, DC to 18 GHz
Table 1-2. Recommended Test Equipment
Equipment Critical Specification Recommended Manufacturer/Model
Vector Network
Analyzer Frequency: 40 MHz to 20 GHz Anritsu Model 37247D or 37347D
Calibration Kit Connector Type: N
Impedance: 50 Ohm Anritsu Model 3653
Adapter Connector: N(m) to K(f) Anritsu Model 34NKF50
Adapter Connector: N(f) to K(f) Anritsu Model 34NFKF50

1-2 PN: 10100-00057 Rev. B Model 34 Series CG

Model 34 Series CG PN: 10100-00057 Rev. B 2-1
Chapter 2 — Performance
Verification
2-1 Introduction
This chapter contains tests that can be used to verify the performance of
the N Type Model 34 Series Precision Coaxial Adapters.
2-2 Specifications
Refer to Table 2-1 for the N Type Model 34 series specifications.
Table 2-1. Model 34 Series Specifications
Anritsu Part Number
Specification 34NN50A 34NFNF50
Frequency Range DC to 18 GHz DC to 18 GHz
SWR 1.1 1.1

2-2 PN: 10100-00057 Rev. B Model 34 Series CG
2-3 Test Procedure Performance Verification
2-3 Test Procedure
1. Allow the VNA to warm up for a minimum of 1 hour.
2. Install an appropriate K to N adapter to the VNA Port 1 so the test
port has a connector than can mate with the Adapter Under Test.
For example, install a 34NFKF50 adapter for testing the
34NN50A adapter.
3. Press the Default Program key to reset the VNA.
4. Set the Start Frequency to 40 MHz and the Stop Frequency to
18 GHz.
5. Load the Cal Kit Coefficients disk into the VNA
(Utility Menu key).
6. Perform a Reflection-Only Port 1 Calibration using the following
steps:
a. Press “Begin Cal”
b. Ensure that the Cal Method is “SOLT” and the
Transmission Line type is “Coaxial”.
c. Make the following selections to set up the calibration:
i. Next Cal Step
ii. Reflection Only
iii. Port 1 Only
iv. Normal (1601 Data Points)
v. 401 Max Points
vi. Start frequency: 40 MHz
vii. Stop frequency: 18 GHz
viii. Next Cal Step
ix. Port 1 Connector type should be changed to
“Type N(f)” for 34NN50A
or
“Type N(m)” for 34NFNF50
x. Load type: BROADBAND FIXED LOAD
xi. Start Cal
7. Follow instructions on the VNA display.
8. After the calibration is complete, set the VNA to display Single
Channel, S11, SWR Graph type.

Model 34 Series CG PN: 10100-00057 Rev. B 2-3
Performance Verification 2-3 Test Procedure
9. Under the Set Scale Key:
a. Set the Resolution to 500 mU/div.
b. Set the Reference Value equal to 1.1
10. Install the Adapter Under Test to VNA Port 1.
11. Install the appropriate termination from the 3653 cal kit to the
open end of the Adapter Under Test.
12. Verify that the SWR of the Adapter Under Test is within
specification (refer to Table 2-1, “Model 34 Series Specifications).
Hint: Use a marker to find the maximum SWR value.
