ansio MINI STEAM IRON User manual
ANSIO 1502 (Feb’23v01) 1
MINI STEAM IRON
Instruction Manual
This product is for household use only. It should not be used for
commercial purposes.
THANK YOU
We thank you for purchasing our appliance and understand that this purchase
represents your trust in us. To demonstrate our gratitude, please feel assured that
we aspire to deliver the best value to you in return. We are proud of our creation
and take every precaution to avoid problems. If, in the rare occurrence, a damaged
or faulty appliance reaches you, do not hesitate to contact us. Our responsive
customer service team will happily assist you regarding any aspect or problems
with your purchase.
You can contact us by:
•Sending an email to support@ansio.co.uk
•Calling us on 0800 080 6781 (UK Toll Free) or +44 207 157 9795
ALL OUR Steam Irons UNDERGO TESTING PRIOR TO BEING SHIPPED TO
THE CUSTOMERS.
If you see some residual water/droplets within, please be assured that this is from
the testing at the factory. We will NEVER sell a used product.
Contact Customer Support at 0800 080 6781 (Toll Free); +44 207 157 9795
IMPORTANT SAFEGUARDS
•Product should only be used as according to the
manual’s specification. Usage out of these boundaries
may result in serious injury.
•DO read this user manual carefully before you use the
appliance and save it for future reference.
•DO make sure that the voltage indicated at the bottom
of the iron matches the mains voltage in your location
BEFORE you connect the device to the mains supply.
If it does not, switch to the correct voltage range.
•DO NOT leave the iron unattended when plugged in.
•Keep away from children.
•DO unplug the iron by pulling gently the plug and
never the cord.
•DO keep the heat-plate away from body parts and
heat sensitive objects
•DO unplug the iron before you fill or empty the
container with water.
•DO NOT continue to use if the iron malfunctions (such
as scorch, smoke etc.) You should immediately unplug
the device and contact us.
•DO NOT repair the iron by yourself. It should be
repaired sending to a qualified service repair person.
•DO NOT iron buttons or fasteners. This could damage
the iron.
Contact Customer Support at 0800 080 6781 (Toll Free); +44 207 157 9795
•DO NOT use when the light is on - the light turning
off indicates that the iron has reached the correct
temperature
•Do NOT connect the Steam Iron Plug before setting it
to the right voltage according to your location
•DO NOT iron directly onto synthetic fabric. Iron the
fabric inside out or with the synthetic fabric covered
by other material.
Note: Water will drip out if the temperature dial is not
set.
•Do NOT leave water in the water tank when not in use.
This can corrode and damage the ceramic soleplate.
•Do NOT fill in the water tank with any other liquid
except water.
•If the supply cord is damaged, it must be replaced by
a service agent to avoid electrical hazard.
•This iron is NOT intended for use by persons
(including children) with reduced physical, sensory
and mental capabilities, or lack of experience and
knowledge.
•This iron is for household use only.
WARNING:
1. The iron must be used and rested on a stable surface
2. When placing the iron on its stand, ensure that the surface on
which the stand is placed is stable.
Contact Customer Support at 0800 080 6781 (Toll Free); +44 207 157 9795
GUARANTEE
This product comes with a standard One-year warranty against all manufacturing
defects. In addition, register your purchase at www.ansio.co.uk within
15 days, and you can get an additional one year FREE Extended
Warranty. If you have any issues, please contact our customer service.
This guarantee is invalid if the product is found to have been abused or tampered
with in any way, or not used for the purpose for which it was intended.
Faulty goods should be returned to their place of purchase, no product can be
returned to us without prior permission. This guarantee does not affect your
statutory rights.
COMPONENTS
1. Steam button
7. Temperature control dial
2. Water tank windows
8. Hand grip
3. Water tank Cap
9. Water tank (Internal)
4. Power cord clip
10. Voltage selector
5. Heating indicator light
11. Stand
6. Ceramic soleplate
12. Main body
10
1
7
8
9
11
12
2
3
4
5
6
Contact Customer Support at 0800 080 6781 (Toll Free); +44 207 157 9795
HOW TO USE
•Place the iron
horizontally on a flat
surface
•Set the temperature dial
to "0" position
•Fill the iron with water
taking care not allow the
water to overflow
Note:
Use pure water or distilled
water especially if the tap
water in your area is hard.
•Plug the AC cord into
electrical outlet & connect to power supply
•Adjust the temperature regulator according to the cloth's ironing temperature
Note:
When using steam burst, please turn the temperature dial to max position (A)
•Preheat the iron until the indicator light goes out and it has reached the set
temperature
•Press the steam button to its raised position to release steam – the iron will
begin emitting steam from the steam vents and the steam lasts until the water
tank is empty
Note: The steam button has to be in the raised position (C) in order to release
steam. Steam will not be released when the button is pressed down to its lowered
position (D) The iron is designed to release steam only in horizontal position. Steam
flow will stop whenever the iron is in vertical upright position.
ARROW
A
Synthet ics , Sil ks
(LOW TEMP)
Woo l
(MEDIUM TEMP)
Cott on, Linen
(HIGH TEMP)
B
CD
Contact Customer Support at 0800 080 6781 (Toll Free); +44 207 157 9795
Note: Use Steam mainly for thicker fabrics or ones with stubborn wrinkles. To stop
steam flow, press steam button to its lowered position - this will also prevent water
from accidentally dripping during next use.
VOLTAGE SELECTOR SWITCH
The Voltage Selector is the recessed switch located at the back of the Steam iron,
which can be set to either 100-127V or 220-240V electrical voltage standards
based on the country where it is used. By default, the Voltage Selector is set to
220-240V.
SETTING VOLTAGE
The Steam Iron features dual-voltage functionality, which allows it to function
correctly in regions with either 100-127V or 220-240V electrical voltage standards.
Voltage is set using the Voltage Selector.
For use in the United Kingdom, Europe and most countries in Asia, the voltage
selector switch must be placed in the 220-240 Volt position. Countries in North
America, Japan, Taiwan, Venezuela, Colombia, Ecuador & Caribbean Islands, the
voltage selector must be placed in the 100-127 Volt position. For further
information, visit http://www.worldstandards.eu/electricity/plug-voltage-by-
country.
NOTE: Make sure to CONFIRM the voltage available at each location before using
the iron.
IMPORTANT:
1. By default, the Voltage Selector is set to the 220-240V setting. Make sure to
select the correct voltage for your location before plugging power cord into an
electrical outlet.
2. Always use appropriate high-quality plug convertor. Using a low quality or an
inappropriate plug can be dangerous.
Voltage Selector
Contact Customer Support at 0800 080 6781 (Toll Free); +44 207 157 9795
STEPS TO CHANGE THE VOLTAGE SETTING
NOTE: These steps assume that Voltage Selector is set to 220-240V default.
1. Locate the Voltage Selector, recessed inside slot at the back of the Steam iron.
Locate the white open notch in middle of
Voltage Selector (FIGURE 1-A)
2. Use a tool with a fine tip.
3. Carefully insert the tip of the tool into the
white notch. Slide Voltage Selector to
the left, towards 100-127V label
(FIGURE 1-B). The iron is now ready for
use in a 120V region.
4. To set unit back to 220V, slide the
Voltage Selector as far to the right
(towards 220-240V label) as possible.
IMPORTANT:
Be sure that Voltage Selector is moved as far to the right as possible for voltage
setting to take effect correctly. Voltage Selector should appear as shown (FIGURE
1-C)
FABRIC IRONING RECOMMENDATIONS
•For heat-sensitive fabric, cover it with a piece of cotton fabric on top to avoid
damage
•Iron clothes with lower heat resistance first.
•Use an ironing board to avoid any damage to clothing or the iron
•If the iron is too hot, it might leave yellow traces on your clothing. If it
happens, humidify the stains with oxidized water, rinse and dry.
•Black or dark clothing should be ironed from the inside out to avoid leaving
a trace.
MAINTENANCE
•Always unplug when not in use
•Ensure that all water is removed after use
•When the iron cools down completely, wipe the main body and the ceramic
sole plate with a soft cloth slightly moistened with water.
•Do NOT clean the ceramic sole plate with detergents or de-scalers, abrasive
or corrosive products.
•Do NOT submerge the iron or hold under running water.
•Wait for the iron to be completely cool before it is stored away.
•Install the water tank cap to product main body.
Contact Customer Support at 0800 080 6781 (Toll Free); +44 207 157 9795
SAFE DISPOSAL
You can help protect the environment! Please remember to respect
local recycling laws. Dispose of faulty or unwanted electrical
appliances in accordance with local policies and service centres.
•This item must not be disposed of with household waste.
•Please recycle where facilities exist. In the interests of health,
safety and the environment, please check with your Local
Authority for recycling advice.
•By ensuring that you dispose of your old electrical and electronic equipment
according to The European Directive 2012/19/EU on Waste Electrical and
Electronic Equipment (WEEE), you are helping to preserve our natural
resources.
For your nearest disposal facility, visit www.recycle-more.co.uk
Environmental Agency Registration Number for ANSIO: WEE/MM6674AA
Ansio Ltd., PO Box 106, Banstead, SM7 9BU, UK
www.ansio.co.uk
