Antares P.064 Series Quick guide

P.064
Circulation pump Alfa Max at high
energy eciency, class A
INSTALLATION AND INSTRUCTION MANUAL
ANTARES
®
for water & re S.r.l. - Via degli Alpini, 144 - 55100 Lucca - Italia
Tel: [phone] - Fax: [phone] - [e-mail] - www.antaresint.com
for water & fire
ANTARES®for water & re S.r.l.- Via degli Alpini, 144 - 55100 Lucca - ITALIA
Tel. + 39 0583 473701 Fax [phone] - [email protected] www.antaresint.com
REV. 06/2023
Energy-saving Pipeline Canned
Motor Pump
Installation and Operating
Instructions
EEI≤0,20

P.064P.064
EN
EN2
01. Read the manual carefully before installation.
02. In case of damage caused to things and/or
people due to lack of respect for installation
and use precautions, the manufacturer cannot
be held responsible.
03. For installation and use, comply with current
regulations safety standards.
04. The user must ensure that the installation
and maintenance is carried out by personnel
qualied and informed about the present
instructions.
05. The circulator must not be installed in humid
environments or wherever it may be subject to
water splashes.
06. To facilitate maintenance, it would be
appropriate to place a ball valve with union
connection at the inlet and outlet from the
circulator.
07. Electricity must be cut off during the
installation and maintenance of the circulator.
08. The P.064 series is not for circulating
domestic hot water.
09. Using the circulator with water rich in calcium
may cause blockage impeller.
10. Do not start the circulator when there is no
liquid in the system.
11. Before removing the circulator it is necessary
unload the relative section of the system in as
much as the presence of water inside is under
pressure and high temperature could cause
damage to people and/or things.
12. During the summer period or when the
room temperature is high, pay attention
to ventilation to avoid condensation and
consequent electrical failure.
13. During the winter when the temperature is
≤ 0°C, if the system is not operational, the
relative section of the plant should be emptied
thus avoiding that the frost cracks the body of
the pump.
14. If the pump is not used for a long time
period, close the shut-off valves delivery
and outlet pipes of the pump and remove
the electrical feed to the same.
15. If the cable is damaged, contact the
maintenance supplier to have it replaced
together with the connector.
16. If we are in the presence of the engine
abnormally overheated, cut off the
power immediately then close the shut-
off valves.
17. If the fault cannot be found and resolved
as instructed cut off the electrical supply,
close the valves of interception and
contact maintenance or service center.
18. Liquid under high pressure and high
temperature it will ow out if the set of
screws are removed: be careful that the
liquid does not cause injury or damage.
19. The product must be installed outside of
the reach of children.
20. The product must be installed in a
dry,cool and ventilated environment.
Precautions in the use of the product - Component not intended for public use
Component not intended for public use.

P.064P.064
EN
EN3
Warning
Before starting installation, the Installation and Operating
Instructions of device must be read carefully. Installation and
use of the device must comply with local regulations and
follow good operation specification.
Warning
Personnel with physical decline, dysesthesia or poor mental
ability and lacking of experience and relevant knowledge
(including children) should use the pump under the
supervision and guidance of people who can take charge of
their safety.
1. Symbol description
Warning:Failure to comply with this security declaration will
likely result in personal injury!
Failure to comply with this security declaration will likely
cause failure or damage to the equipment!
Notes or instructions facilitating the work and ensuring
operational safety.
Caution
Note
01
Warning
Before starting installation, the Installation and Operating
Instructions of device must be read carefully. Installation and
use of the device must comply with local regulations and
follow good operation specification.
Warning
Personnel with physical decline, dysesthesia or poor mental
ability and lacking of experience and relevant knowledge
(including children) should use the pump under the
supervision and guidance of people who can take charge of
their safety.
1. Symbol description
Warning:Failure to comply with this security declaration will
likely result in personal injury!
Failure to comply with this security declaration will likely
cause failure or damage to the equipment!
Notes or instructions facilitating the work and ensuring
operational safety.
Caution
Note
01
Warning
Warning
Before starting installation, the Installation and Operating
Instructions of device must be read carefully. Installation and
use of the device must comply with local regulations and
follow good operation specification.
Warning
Personnel with physical decline, dysesthesia or poor mental
ability and lacking of experience and relevant knowledge
(including children) should use the pump under the
supervision and guidance of people who can take charge of
their safety.
1. Symbol description
Warning:Failure to comply with this security declaration will
likely result in personal injury!
Failure to comply with this security declaration will likely
cause failure or damage to the equipment!
Notes or instructions facilitating the work and ensuring
operational safety.
Caution
Note
01
Warning
Before starting installation, the Installation and Operating
Instructions of device must be read carefully. Installation and
use of the device must comply with local regulations and
follow good operation specification.
Warning
Personnel with physical decline, dysesthesia or poor mental
ability and lacking of experience and relevant knowledge
(including children) should use the pump under the
supervision and guidance of people who can take charge of
their safety.
1. Symbol description
Warning:Failure to comply with this security declaration will
likely result in personal injury!
Failure to comply with this security declaration will likely
cause failure or damage to the equipment!
Notes or instructions facilitating the work and ensuring
operational safety.
Caution
Note
01
Warning
Warning
Before starting installation, the Installation and Operating
Instructions of device must be read carefully. Installation and
use of the device must comply with local regulations and
follow good operation specification.
Warning
Personnel with physical decline, dysesthesia or poor mental
ability and lacking of experience and relevant knowledge
(including children) should use the pump under the
supervision and guidance of people who can take charge of
their safety.
1. Symbol description
Warning:Failure to comply with this security declaration will
likely result in personal injury!
Failure to comply with this security declaration will likely
cause failure or damage to the equipment!
Notes or instructions facilitating the work and ensuring
operational safety.
Caution
Note
01
Warning
Before starting installation, the Installation and Operating
Instructions of device must be read carefully. Installation and
use of the device must comply with local regulations and
follow good operation specification.
Warning
Personnel with physical decline, dysesthesia or poor mental
ability and lacking of experience and relevant knowledge
(including children) should use the pump under the
supervision and guidance of people who can take charge of
their safety.
1. Symbol description
Warning:Failure to comply with this security declaration will
likely result in personal injury!
Failure to comply with this security declaration will likely
cause failure or damage to the equipment!
Notes or instructions facilitating the work and ensuring
operational safety.
Caution
Note
01
Warning
1. Description of symbols
Before installing, carefully read the
instructions. The installment must comply
with local safety regulations e follow the
relevant rules.
This product is not intended for the general
public, but for professionally specialized
companies
Keep out of the reach of children
2 . Overview
The P.064 series is suitable for:
• Heating systems with
adjustable flow.
• Heating system with variable
temperature.
• Heating systems with night
mode.
• Systems with air conditioning.
• Industrial Circulation systems.
• The series is equipped with self-
adaptation mode "AUTO" (factory
setting).
• The series is equipped with a
permanent magnets and controller
of differential pressure which
can fix performance of the pump
automatically and continuously to
cope to the needs of the system.
• The series is supplied with a
front panel control to facilitate
programming.
• Extremely silent.
• Energy saving Compared to pumps
conventional consumption energy
is very low. The minimum energy
consumption P.064 series can
reach only 5W.
2.1 P.064 pumps are especially
suitable for water recirculation
for heating.
2.2 The installation of the P.064 series
presents numerous advantages:
Warning
Before starting installation, the Installation and Operating
Instructions of device must be read carefully. Installation and
use of the device must comply with local regulations and
follow good operation specification.
Warning
Personnel with physical decline, dysesthesia or poor mental
ability and lacking of experience and relevant knowledge
(including children) should use the pump under the
supervision and guidance of people who can take charge of
their safety.
1. Symbol description
Warning:Failure to comply with this security declaration will
likely result in personal injury!
Failure to comply with this security declaration will likely
cause failure or damage to the equipment!
Notes or instructions facilitating the work and ensuring
operational safety.
Caution
Note
01
WARNING:
Failure to heed the warning accompanying the symbol may result in damage to people
and things.
CAUTION:
Failure to observe the warning accompanying the symbol may cause malfunction or damage
to the equipment.
NOTE:
Notes or instructions to facilitate safe installation and commissioning.
CAUTION
NOTE

P.064P.064
EN
EN4
3.1 Room temperature: The room temperature must be between 0°C and + 40°C
3.2 Degree of humidity: The degree of humidity must be < 95%
3.3 Average temperature of the circulating liquid: The temperature of the circulating liquid
must be between +2°C and +110°C.
3.4 System pressure: Maximum pressure 1.0 Mpa (10bar).
3.5 Protection level: IP42
3.6 Inlet pressure: To avoid damage to the pump due to cavitation, the following pressure
must be maintained at the inlet
3. Service conditions
Liquid temperature < 85°C 90°C 110°C
Inlet pressure 0.05 bar 0.28 bar 1 bar
Head of delivery
of 0.5m
Head of delivery
of 2.8m
Head of delivery
of 10m
3.7 Pumping liquid
Thin, clean, non-corrosive and non-explosive liquid does not contain any
solid particles, fibers or mineral oil; the pump should not be used for conveying
flammable liquid such as vegetable oil and gasoline absolutely. If the circulating
pump is used for the case of high viscosity, the pump performance will reduce,
therefore, when selecting a pump, the viscosity of liquid must be considered.
4.1 Installation
· Install P.064 series circulating pump, arrows on the pump housing indicate the
direction of liquid flowing through the pump body.
· When the pump is installed on the pipeline, its inlet and outlet must be installed
with two leather packings provided.
· During installation, the pump shaft must be in the horizontal position.
4. Installation
04
It must be fluid, clean, non-corrosive and non-explosive, without particles or fibers or mineral oils; the pump
must be used for the flow / transport of inflammable liquid such as vegetable oil or diesel. If the circulation
pump is used with a highly viscous liquid, the yield will be lower, therefore when choosing the pump, keep
in mind or into into account the viscosity of the liquid.
3.7 Liquid inside the pump

P.064P.064
EN
EN5
4.2 Position of junction box
4.3 Change to the position of junction box
The junction box can rotate in 90 ° . To change the position of junction box, follow the
operating steps below:
1.Switch the valves of inlet and outlet and conduct decompression;
2.Loosen and remove the four socket head cap screws that fix the pump body;
3.Rotate the motor to the desired position and match the four screw holes;
4.Put the four socket head cap screws back and tighten them in the cross direction
order;
5.Open the valve of inlet and outlet.
05
3.7 Pumping liquid
Thin, clean, non-corrosive and non-explosive liquid does not contain any
solid particles, fibers or mineral oil; the pump should not be used for conveying
flammable liquid such as vegetable oil and gasoline absolutely. If the circulating
pump is used for the case of high viscosity, the pump performance will reduce,
therefore, when selecting a pump, the viscosity of liquid must be considered.
4.1 Installation
· Install P.064 series circulating pump, arrows on the pump housing indicate the
direction of liquid flowing through the pump body.
· When the pump is installed on the pipeline, its inlet and outlet must be installed
with two leather packings provided.
· During installation, the pump shaft must be in the horizontal position.
4. Installation
04
The arrows on the pump body indicate the direction of flow of the liquid passing through the pump. When the
pump is installed, the inlet and outlet must be sealed with the two gaskets provided. During installation the pump
shaft must be in a horizontal position.
4.1 Installation
4. Installation
The junction box can rotate 90°. To change the position, follow the instructions below:
1 – Close the inlet and outlet valves.
2 – Unscrew and remove the four screws that connect the body to the pump
3 – Rotate the motor to the desired position and align the four screw holes
4 - Put the four screws in their place by tightening them with the "cross" method
5 – Gradually open the inlet and outlet valves
4.2 Location of the junction box
4.3 Change to the position of junction box

P.064P.064
EN
EN6
4.2 Position of junction box
4.3 Change to the position of junction box
The junction box can rotate in 90 ° . To change the position of junction box, follow the
operating steps below:
1.Switch the valves of inlet and outlet and conduct decompression;
2.Loosen and remove the four socket head cap screws that fix the pump body;
3.Rotate the motor to the desired position and match the four screw holes;
4.Put the four socket head cap screws back and tighten them in the cross direction
order;
5.Open the valve of inlet and outlet.
05
Warning
Before starting installation, the Installation and Operating
Instructions of device must be read carefully. Installation and
use of the device must comply with local regulations and
follow good operation specification.
Warning
Personnel with physical decline, dysesthesia or poor mental
ability and lacking of experience and relevant knowledge
(including children) should use the pump under the
supervision and guidance of people who can take charge of
their safety.
1. Symbol description
Warning:Failure to comply with this security declaration will
likely result in personal injury!
Failure to comply with this security declaration will likely
cause failure or damage to the equipment!
Notes or instructions facilitating the work and ensuring
operational safety.
Caution
Note
01
Warning：
Pumping liquid may be of high temperature and pressure, therefore,
liquid in the system should be drained off or valves on both sides of the
pump must be switched off before removing socket head cap screws.
Change the position of junction box, the pump should not be started
until the system has been filled with pumping liquid or valves on both
sides of the pump are open.
Catution
4.4 Thermal insulation of electric pump body
Restrict the thermal losses of electric pump body and pipeline.
Conduct thermal insulation for electric pump body and pipeline so as
to reduce the thermal losses of pump and pipeline.
Isolating or covering junction box and control panel is not allowed.
Caution
Note
06
Warning:
The liquid owing in the pump can have high pressure and temperature and therefore the
system must be emptied or the two valves on both sides must be closed before removing
the screws.
By changing the position of the junction box, the pump will not have to be started until the
system will not have been lled with liquid and until both valves have been opened
Caution
Limits heat loss from the pump and pipeline.
Do not insulate or cover the electrical part of the pump.
Caution
Note

P.064P.064
EN
EN7
5. Electrical connections
Electrical connection and protection should be carried out in accordance
with local regulations.
Warning
The electric pump must be connected to earth wire.
The pump must be connected with an external power switch; the
minimum gap betweenall the electrodes is 3 mm.
·
P.064 series circulating pump does not need external
motor protection.
· Check whether the voltage of power supply and
frequency match with the parameters marked by pump
nameplate.
· Use the pump associated plug to connect power supply.
· If the indicator lamp on the control panel lights, it
indicates that the power supply is switched on.
08

P.064P.064
EN
EN8
Warning
Before starting installation, the Installation and Operating
Instructions of device must be read carefully. Installation and
use of the device must comply with local regulations and
follow good operation specification.
Warning
Personnel with physical decline, dysesthesia or poor mental
ability and lacking of experience and relevant knowledge
(including children) should use the pump under the
supervision and guidance of people who can take charge of
their safety.
1. Symbol description
Warning:Failure to comply with this security declaration will
likely result in personal injury!
Failure to comply with this security declaration will likely
cause failure or damage to the equipment!
Notes or instructions facilitating the work and ensuring
operational safety.
Caution
Note
01
6. Control panel
6.1 Control panel components
Electrical connection and protection must be performed in accordance with local regulations.
Warning:
The pump must be earthed.
• The P.064 series circulator does not require external motor protection.
• Verify that the supply voltage and frequency correspond to the marked parameters from the pump
nameplate.
• Use the plug associated with the pump to connect the power supply.
• If the light on the control panel turns on, it means that the power is on.
Electrical connection and protection should be carried out in accordance
with local regulations.
Warning
The electric pump must be connected to earth wire.
The pump must be connected with an external power switch; the
minimum gap betweenall the electrodes is 3 mm.
·
P.064 series circulating pump does not need external
motor protection.
· Check whether the voltage of power supply and
frequency match with the parameters marked by pump
nameplate.
· Use the pump associated plug to connect power supply.
· If the indicator lamp on the control panel lights, it
indicates that the power supply is switched on.
08
6.Control panel
6.1 Components on the control panel
Fault code Fault
description
E0
E1
E2
E3
E2-E4
Over-voltage protection
Undervoltage protection
Locked
- rotor and
overcurrent protection
Underloading protection
Locked - rotor protection
6.2 Fault code display status
After the power is turned on,
position 6 light area displays the status.
During operation, the gear display light
is on constantly.
When the electric pump can not
operate properly, the gear display light
will flash continuously, the
corresponding faults are as shown
below:
1
2
3
4
5
6
7
No. Explanation
Electric pump automatic gearshift
display (AUTO)
Electric pump gear shifting button
Electric pump proportion gear display
(BLI/BL2)
Electric pump night mode button and
display
Electric pump constant voltage gear
display (HDI/HD2)
Electric pump power display
Electric pump constant speed display
(HS1/HS2/HS3)
If the fault is displayed, the power supply
must be disconnected to facilitate
troubleshooting,
After troubleshooting, switch on the power
supply again and re-start the electric pump.
09
After switching on, the status display ( position 6 ) will show
the status of the pump. During the correct operation, the
display will always be on and will show the power absorbed
by the pump. If the pump should not work properly, the light
of the display will ash continuously, showing the code
corresponding to one of the errors listed alongside
After viewing the failure, the power supply must be
disconnected to facilitate the resolution of the problem.
After troubleshooting, turn it on again the power supply and
restart the pump
6.2 Error code display
Number Description
1Automatic speed change display (AUTO)
2Speed change button
3
Proportional pressure display (BL1/BL2)
4Display and button for night mode
5Constant pressure display (HD1/HD29 )
6Status display
7
Constant speed display (HS1/HS2/HS3
Fault code Fault description
E0 Overvoltage protection
E1 Undervoltage protection
E2 Overload protection
E3 Underload protection
E4 Protection - phase and neutral – reversed
E5 Pump blockage
E6 Pump not starting
The P.064 series circulator has 9 types of settings that can be selected using a button:
6.3 Selection programm
Butto position Times pressed Fixed light Mode
2
0 AUTO Self adaptation
1.2 BL1/BL2
Proportional pressure
3.4 HD1/HD2 Constant pressure
5.6.7 HS1/HS2/HS3 Constant speed
4 Switch on/off Night mode Night mode

P.064P.064
EN
EN9
6.3 Light area displaying the settings of electric pump
P.064 series circulating pump has 9 kinds of settings, which can be
selected by buttons.
The setting of electric pump is indicated by the light lit of 9 locations:
7.Setting of electric pump
7.1 The electric pump should be set according to system
type
Key position Number of
times of key
0
1、2
3、4
5、6、7
Switch on/off
Fixed light area
AUTO
BL1/BL2
HD1/HD2
HS1/HS2/HS3
Night mode
Explanation
Auto adaptation
Proportional
pressure curve
Constant
pressure curve
Constant
speed curve
Night mode
curve
2
4
10
7.1 The pump should be programmed according to the system
7. Programming the pump
Factory setting = AUTO (self-adaptation mode)
Available and recommended pump programs
Position Type of system
Programming the pump
Optimal settings Or other optional settings
A Floor AUTO HD1/HD2
B Double heating pipeline AUTO BL1/BL2
CSingle heating pipeline BL1 BL1/BL2
The AUTO mode (self-adaptation) automatically adjusts the pump performance according to the actual demand
system heat. Since the performance is adjusted gradually, it is recommended to leave it in AUTO mode (auto-
adaptation) for at least a week before changing the pump settings.
• If we choose to return to AUTO mode (self-adaptation), the P.064 series pump remembers the set
points of the previous AUTO mode.
• For the relationship between the pump settings and the performance curve, see Section 11.1.
w

P.064P.064
EN
EN10
Warning
Before starting installation, the Installation and Operating
Instructions of device must be read carefully. Installation and
use of the device must comply with local regulations and
follow good operation specification.
Warning
Personnel with physical decline, dysesthesia or poor mental
ability and lacking of experience and relevant knowledge
(including children) should use the pump under the
supervision and guidance of people who can take charge of
their safety.
1. Symbol description
Warning:Failure to comply with this security declaration will
likely result in personal injury!
Failure to comply with this security declaration will likely
cause failure or damage to the equipment!
Notes or instructions facilitating the work and ensuring
operational safety.
Caution
Note
01
Warning:
Night mode should not be turned on in gas boiler heating systems with small capacity of water.
To ensure correct operation in night mode, the following condition must be met:
• The pump must be installed on the system water delivery pipe and near the outlet water from the boiler.
Press button to activate night mode.
Warning
Before starting installation, the Installation and Operating
Instructions of device must be read carefully. Installation and
use of the device must comply with local regulations and
follow good operation specification.
Warning
Personnel with physical decline, dysesthesia or poor mental
ability and lacking of experience and relevant knowledge
(including children) should use the pump under the
supervision and guidance of people who can take charge of
their safety.
1. Symbol description
Warning:Failure to comply with this security declaration will
likely result in personal injury!
Failure to comply with this security declaration will likely
cause failure or damage to the equipment!
Notes or instructions facilitating the work and ensuring
operational safety.
Caution
Note
01
. If HS1, HS2 or HS3 mode is selected, night mode will be disabled.
Warning
Before starting installation, the Installation and Operating
Instructions of device must be read carefully. Installation and
use of the device must comply with local regulations and
follow good operation specification.
Warning
Personnel with physical decline, dysesthesia or poor mental
ability and lacking of experience and relevant knowledge
(including children) should use the pump under the
supervision and guidance of people who can take charge of
their safety.
1. Symbol description
Warning:Failure to comply with this security declaration will
likely result in personal injury!
Failure to comply with this security declaration will likely
cause failure or damage to the equipment!
Notes or instructions facilitating the work and ensuring
operational safety.
Caution
Note
01
If the heat supply to the heating system is insufcient, disable night mode.
8.1 1 Basic principle
8. Night Mode

P.064P.064
EN
EN11
Diverter valve:
The function of the diverter valve is to ensure that when all heating valves are closed, the flow from
the boiler is diverted into the return, ensuring a minimum flow through the pump.
Components:
•Diverter valve
•Flow meter. L position
Minimum ow must be ensured even when all valves are closed.
The programming of the pump depends on the type of diverter valve inserted.
Ex diverter valves manually opened or thermostatic diverter valves.
9.1 Use of bypass valve
8.A bypass valve system is fitted between the
inlet pipeline and return pipeline
8.1 Use of bypass valve
Bypass valve
The role of bypass valve is: when all the valves in the floor heating circuit or
the temperature control valve of radiator are closed, it can be ensured that
the heat from the boiler will be assigned.
System components:
·Bypass valve
·Flowmeter, position L.
The minimum flow must be ensured when all valves are closed.
Water pump settings depend on the type of bypass valve it equipped with,
i.e. manually-operated bypass valve or temperature-controlled bypass
valve.
12
Chapter 7
Sezione VII
Once night mode is set, the P.064 series pump will automatically alternate between normal and night mode. Switching of
the P.064 series pump between normal mode and night mode depends on the temperature of the system delivery pipe.
When the temperature drop of the system inlet pipeline within two hours is more than 10 ~ 15°C, the pump of the P.064
series will automatically switch to night mode. The temperature drop must be at least 0.1°C/min. When the system pipe
temperature rises about 10°C, it will switch to normal mode.
8.2 Night mode function
9. System with diverter valve between
delivery pipe and return pipe

P.064P.064
EN
EN12
Follow these steps:
1/ When you adjust the diverter valve, the water pump should be in mod. HS1 (constant speed 1) The minimum system
flow (Q min) must always be ensured. See valve supplier manual diverter.
2/ When the diverter valve has been adjusted, program the water pump by referring to section 11.1 pump programming.
Follow these steps:
1/ When you adjust the diverter valve, the water pump should be in mod. HS1 (constant speed 1) The minimum system
ow (Q min) must always be ensured. See valve supplier manual diverter
2/ When the diverter valve has been adjusted, program the pump in constant pressure mode. For the relationship
between pump schedule and performance curve, see section 11.1
Before starting the pump make sure that the system is full of liquid, the air is out and the pressure is inlet reaches the
minimum pressure required (see chap.3)
The P.064 series pump has the function of automatic gas discharge (vent). It is not necessary to discharge the gas before
starting. The gas in the pump will cause noise. The noise will disappear after operating for a few minutes. Set the pump
in HS3 mode and in short time, depending on the size and structure of the system, the gas will be discharged. After the
gas purge, that is after the noise disappears, set the pump according to the recommended instructions. Please refer to
chapter 7.
9.2 Manual diverter valves
9.3 Automatic diverter valves (thermostatic)
10.1 Before startup
10.2 Gas/air leaking from the pump
10. Start up
9.3Gas-exhausting of heating system
14
9.3Gas-exhausting of heating system
14

P.064P.064
EN
EN13
10.Settings and performance of pump
10.1 Relationship between pump settings and its
performance
Settings
AUTO
（factory
settings）
BL1/BL2
HD1/HD2
HS1/HS2
/HS3
Water pump
characteristic curve Function
Highest to lowest
proportional
pressure curve
Proportional
pressure curve
Constant
pressure curve
Constant
speed curve
Night mode
Run at the lowest performance and power
“ Autoadaptation” function will automatically
control the water pump performance within the
specified range.
· Adjust the performance of water pump
according to the size of system;
· Adjust the performance of water pump
according to the load change of a period of time;
In the "Autoadaptation" mode, the water pump is
set to proportional pressure control mode.
Water pump working point will move up and down
on the proportional pressure curve according to
the flow needs of system, when the flow demand
reduces, the water pump pressure supply will
drop while when the flow demand increases, it
will rise.
Water pump working point will move back and
forth on the constant pressure curve according to
the flow needs of system. The pressure supply of
water pump remains constant, having nothing to
do with the flow demand.
Run on the constant curve at a constant speed. In
speed 󰾬󰾬
HS (1-3) mode, the water pump is set to run on
the maximum curve under all working conditions.
Set the water pump to HS3 mode in a short time,
then gas in the pump will be vented quickly.
15
11.1 Relationship between pump scheduling and performance
11. Pump programming and performance
Settings Water pump
characteristic curve Function
AUTO (factory
settings)
From highest to lowest
proportional pressure
The "Auto-adapt" function will automatically check the pump performance
within the specified range
• Adjust the performance of the water pump according to the system size
• Adjusts pump performance according to load change
BL1/BL2 Proportional pressure
The duty point of the pump will move up and down on the curve proportional
pressure according to system flow needs, when the flow demand decreases,
the pressure supplied by the pump decreases while increases when the flow
demand increases
HD1/HD2 Constant curve pressure
The duty point of the pump will move back and forth on the constant pressure
curve according to flow rate requirements of the plant. The pressure supplied
by the pump remains constant
HS1/HS2/HS3 Constant speed
Curve at constant speed. In HS mode (1-3), the pump is set to operate at
constant speed in all conditions of work. Set the pump in HS3 mode and in a
short time any gases in the pump will be vented
Night mode Operation at minimum performance and consumption.

P.064P.064
EN
EN14
12.1 -Working conditions described by the curves
12.2 Curve conditions
12. Characteristic curves of the P.064 series
• Test liquid: gas-free water
• Density: p = 983.2 kg/m ³
• Liquid temperature + 60°C.
• Kinematic viscosity u = 0.474 mm²/s (0.474.CcST)
P. 064 series 5 m.
P. 064 series 8 m.
P. 064 series 6 m.

P.064P.064
EN
EN15
13.01 – Description on the badge
13. Characteristics
1
9
2
10
3
11
6
4
12
7
58
13
AlfaMax RS 25/80
P.064.48
220V AC 50/60 Hz
Class H TF 110
IP 42 EEI≤0,20-Part2
Number Explanations
1Product name
2Product code
3Voltage
4Insulation class
5Degree of protection
6Frequency (Hz)
7Degrees temperature
8Energy efficiency label
9Power
Maximum power
Minimum power
10 Current
Maximum current
Minimum current
11 Maximum pressure
12 Product number
13 Manufacturer

P.064P.064
EN
EN16
14.1 Technical information
14. Technical information
Supply voltage 1 x 230V +6%/-10%, 50Hz, PE
Motor protection The pump does not need external protection
Protection Level IP42
Insulation class H
Ambient humidity Max. 95%
Maximum pressure 1.0mpa (MPa)
Minimum pressure incoming
Liquid temperature Minimum inlet pressure
≤ +85°C 0.005 MPa
≤ +90°C 0.028 MPa
≤ +110°C 0.100 MPa
EMC standards EN6 100-6-1 EN 61000-6-3
Sound pressure level Noise level of the pump less than 43dB (A)
Ambient temperature 0 ~+40°C
Temperature degrees TF 110
Surface temperature
°C Maximum surface temperature must not exceed +125°C
Liquid temperature 2 ~+110°C

P.064P.064
EN
EN17
14.2 Space encumbrance
To prevent the control box and stator from appearing condensate water, the temperature
of pump conveying liquid must be always higher than the ambient temperature
Liquid temperature
2
10
20
30
35
40
Minimum (℃)
Ambient
temperature (℃)
0
10
20
30
35
40
In domestic hot water, it is recommended to keep the temperature of water
below 65℃ so as to reduce scaling
110
110
110
110
90
70
Maximum (℃)
13.2 Installation dimension
20
Power
input (W)
Model
Voltage Material Dimension(mm)
220~240V/50Hz
Cast
Iron
Plastic Copper
Stainless
steel
L1 L2 B1 B2 H1 H2 G
32
P.064.59
● ● ● ● 65 130 52 99 133 153 1”
P.064.50
● ● ● ● 65 130 52 99 128 156 1 1/2”
P.064.58
● ● ● ● 90 180 52 99 128 156 1 1/2”
45
P.064.69
● ● ● ● 65 130 52 99 133 153 1”
P.064.60
● ● ● ● 65 130 52 99 128 156 1 1/2”
P.064.68
● ● ● ● 90 180 52 99 128 156 1 1/2”
P.064.62
● ● ● ● 90 180 52 99 128 156 2”
70
P.064.89
● ● ● ● 30 130 52 99 133 153 1"
P.064.84
● ● ● ● 65 130 52 99 128 156 1 1/2"
P.064.80
● ● ● ● 65 180 52 99 128 156 1 1/2"
P.064.82
● ● ● ● 65 180 52 99 128 156 2"

P.064P.064
EN
EN18
Eliminating method
Fuse in equipment burned out
Breaker of current cont rol or
voltage control disconnects
Electric pump failure
Too low voltage
Locked-rotor of electric pump
(stuck)
Gas in the system
Excess flow
Gas in the pump
Too low inlet pressure
Too low performance of pump
Pump fails to start
14. Fault checklist
Warning：
Before carrying out any maintenance and repair to the electric
pump, make sure the power is disconnected and will not be
accidentally switched on.
Fault Cause
Replace fuse
Connect the breaker
Replace the pump
Check whether the power
is within the specified range
Remove impurities
Conduct gas-exhausting
for the system
Reduce the pump inlet
pressure
Conduct gas-exhausting
for the system
Increase the inlet pressure
Increase the inlet pressure
of pump
System noise
Noise in the pump
Shortage of heat
22
15. Problem solving
Warning
Before carrying out any maintenance and repairs on the electric pump, make sure
that the power is disconnected and that no one accidentally reactivated it
Problem Cause Solution
Pump does not start Connector disconnected Connect connector
Pump fault Replace pump
Voltage too low Check that the voltage is in the
established limits
Rotor blocked Remove impurities
Noise in the system
Air in the system Venting
Excessive flow Reduce Pump Power
Noise in the pump
Air in the pump Venting
Inlet pressure too low Increase inlet pressure
No heat Pump performance too low Increase inlet pressure
