ANTIFERENCE HDMI0104SV2 User manual

HDMI0104SV2
1 to 4 4K HDMI Splitter with EDID Control & HDCP 2.2 support
User Guide

Important Safety Notice
Thank you for purchasing this Antiference HDMI distribution product.
Please read the following instructions carefully and retain for future
reference.
1. Please pay careful attention to the following safety considerations:
2. Do not place any items on the device
3. Ensure no liquids are on or near the device as splashes may damage the
unit
4. For cleaning, use a damp cloth only without solvents
5. Do not attempt to open the case as there is a danger of electric shock
6. Repairs should be carried out by a qualified technician
7. Place the unit in a well ventilated area to prevent overheating
8. Carry out the installation before connecting the device to a source of power
9. Use only the supplied power supply as 3rd party products may damage the
product
Introduction
This Antiference HDMI device splits a single 4K HDMI source to 4 points/
displays over HDMI cables. The product features an EDID management system
for complete flexibility.
The splitter supports full 4K resolutions with HDCP 2.2 support.
Compatible with SKY Q/HD, Blu Ray, Apple TV, CCTV DVR etc
Features
1. Distribute 1 HDMI source to 4 HDMI displays
2. Support Ultra HD resolution 4K×2K@60Hz
3. 3D Support
4. EDID function
5. Compatible with a wide range of devices and cables
6. Metal heat sink design
7. Plug and play system

Package contents
Installation Requirement
1. HDMI source device (SKY Q/HD, Blu Ray, PS3, Apple TV, CCTV etc)
2. HDMI display device(s) such as HDTV or projector with HDMI port.
3. High quality HDMI cable (supports 4Kx2K).
Interface Specification
HDMI Splitter×1 User Manual×1
DC5V/2A Power
Adapter×1
HDMI Output
Ports
Power Input
（DC5V/2A）
HDMI Input
Port
HDMI Output
Ports
EDID Dial Switch Output LED
Power indicator
Output LED

Installation
1. Connections
1. Connect the HDMI video source device output port to the splitter input port
via an HDMI cable
2. Connect the splitter output port to the HDMI display (TV) via HDMI cable
3. Power on the splitter (Power indicator led will light up)
HDMI Splitter
Display
1
2
3
4
DVD

2. Operation
1. Before the HDMI signal outputs, the splitter will read the EDID information of
the connected TVs and send it back to HDMI source.
2. This process determines the output mode/resolution.
3. Indicator led shows the working status
4. The splitter features 16 EDID options to select from. These can be selected
by the position of the EDID dip switches located on the front of the unit.
Details are in the table below:
Notes:
Copy - Reads the EDID of the display connected to output 1 only
MIX1 - Highest audio format, and lowest video format
MIX2 - Highest video format
MIX3 - Lowest video format
o
N1 2 3 4
o
N1 2 3 4 Switch up for“1”Switch down for “0”
Switch
Status
1 2 3 4 EDID information
0 0 0 0 4k@60Hz 2CH
1 0 0 0 4k@60Hz 7.1CH
0 1 0 0 4k@30Hz 2CH
1 1 0 0 4k@30Hz 7.1CH
0 0 1 0 1080p@60Hz 2CH
1 0 1 0 1080p@60Hz 7.1CH
0 1 1 0 1080i@60Hz 2CH
1 1 1 0 1080i@60Hz 7.1CH
0 0 0 1 720p@60Hz 2CH
1 0 0 1 720P@60Hz 7.1CH
0 1 0 1 480P@60Hz 2CH
1 1 0 1 480p@60Hz 7.1CH
0 0 1 1 Copy once
1 0 1 1 MIX1
0 1 1 1 MIX2
1 1 1 1 MIX3

FAQ
Q: No audio or video displayed
A:
1 ) Check the power supply to make sure the power light is on.
2 ) Ensure all the HDMI cables connected properly.
3 ) Check and make sure the correct HDMI input is selected on the TV.
4 ) If using a laptop, ensure the output setting is activated and display
setting is duplicated or extended desktop
Q: Display is unstable, splash screen, snowflakes or audio stuck.
A:
1 ) Check and make sure all connections are good and correct.
2 ) Try connecting HDMI source to display, if it is the same,
please change the source device.
3 ) Use high-quality high speed HDMI cable for transmitting 4K×2K UHD
signal.

Specification
Items Specification
Input Ports 1 x HDMI
Output Ports 4 x HDMI
Power Indicator LED 1 x LED
Signal Indicator LED 4 x LED
HDMI Version Compatible with DVI1.0, HDMI1.4, HDMI2.0
HDCP Version Compatible with HDCP1.4, HDCP2.2
HDMI Resolution 480i/480p/756i/756p/720p/1080i/1080p/4Kx2K@24/25/30/60Hz
Frequency Range 25MHz~594MHz
Video From Support 12 bit full HD video, 3D video and 4Kx2K@30/60Hz ultra HD
video
Input and Output TMDS
Signal
0.5 ~1.5Vp-p(TMDS)
Input and Output DDC
Signal
5Vp-p(TTL)
Audio Support standard audio and DSD (Direct Steam Digital) and HD(HBR)
audio
Working Temperature 0ºC - 60ºC
Power Supply DC5V/1A
Power Consumption <5W
Dimension 96mm(L)x59mm(W)x16.8mm(H)
Weight 100g
Colour Black
Declaration of Conformity
We, ANTIFERENCE LIMITED herewith declare that the HDMI splitter kit
complies with all essential requirements and any other applicable conditions set
forth on directive 1999/05/CE.
According to the WEEE (Waste Electrical and Electronic Equipment) EU
Directive, do not dispose of this product as household waste or commercial
waste. Waste Electrical and Electronic Equipment should be appropriately
collected and recycled as required by practices established for your country. For
information on recycling of this product, please contact your local authorities,
your household waste disposal service or the shop where you purchased the
product.
www.antiference.co.uk
