Antonio Carraro 15 Series User guide

Series 15
Tigre 4000
Series 17
Tigre 4400 F
Use and maintenance
Ed. June - 2016
Code
47302483/02
LITERARY
AND ARTISTIC PROPERTY
OF
ANTONIO CARRARO SPA
Reproduction of text and illustrations, even in part,
is prohibited
Translation of the "ORIGINAL INSTRUCTIONS"

Congratulations! You have made an excellent choice. Your tractor has been designed and
built with technologically advanced processes.
"Antonio Carraro" tractors are extremely versatile and can be used for various uses in many
sectors: agricultural, industrial and for public authorities, etc.
In the National and International sectors "Antonio Carraro" represents a high technological
value and corresponds with development programs with the objective of confirming the
strong and strongly innovative leadership of this mark.
Antonio Carraro S.p.A.
Via Caltana, 24
35011 CAMPODARSEGO (Padova) Italia
Tel. [phone] - Fax [phone] - http://www.antoniocarraro.com
Use and maintenance manual supplied with the tractor
identified by the elements listed.
Tractor model........................... Serial number........................... Year of manufacture.................

Dichiarazione2.fm
CERTIFICATE OF CONFORMITY
Antonio Carraro S.p.A.
Via Caltana, 24 - 35011 Campodarsego Padova Italy
Phone [phone] - [e-mail] - www.antoniocarraro.com
Partita IVA IT 00186830287 - Cap. Soc. 2.107.320 i.v. - M/PD010221
R.E.A. PD 126503 - Registro imprese PD060-9846
CE DECLARATION OF CONFORMITY CE FOR MACHINES
(Machinery Directive 2006/42/CE, Attached II A)
Manufacturer: ANTONIO CARRARO S.p.A.
Address: Via Caltana, 24 - 35011 Campodarsego - PD - ITALY
Name and address of the person authorised to constitute the technical file:
Name: (ANTONIO CARRARO S.p.A. – GENERAL MANAGEMENT)
Address: Via Caltana, 24 - 35011 Campodarsego - PD - ITALY
We herewith declare that the machine
Farming tractor
series/model: 17 / Tigre 4400 F
Identification n. see the identification plate
is compliant with the pertaining dispositions of Machinery Directive (2006/42/EC) and suc-
cessive modifications,
is compliant with the 2003/37/CE Directive, and successive modifications, relating to appro-
val of farming tractors
Campodarsego, Signature:
__/__/____ ANTONIO CARRARO S.p.A.
MARCELLO CARRARO
Director General

Dichiarazione.fm
CERTIFICATE OF CONFORMITY
Antonio Carraro S.p.A.
Via Caltana, 24 - 35011 Campodarsego Padova Italy
Phone [phone] - [e-mail] - www.antoniocarraro.com
Partita IVA IT 00186830287 - Cap. Soc. 2.107.320 i.v. - M/PD010221
R.E.A. PD 126503 - Registro imprese PD060-9846
CE DECLARATION OF CONFORMITY CE FOR MACHINES
(Machinery Directive 2006/42/CE, Attached II A)
Manufacturer: ANTONIO CARRARO S.p.A.
Address: Via Caltana, 24 - 35011 Campodarsego - PD - ITALY
Name and address of the person authorised to constitute the technical file:
Name: (ANTONIO CARRARO S.p.A. – GENERAL MANAGEMENT)
Address: Via Caltana, 24 - 35011 Campodarsego - PD - ITALY
We herewith declare that the machine
Farming tractor
series/model: 15 / Tigre 4000
Identification n. see the identification plate
is compliant with the pertaining dispositions of Machinery Directive (2006/42/EC) and suc-
cessive modifications,
is compliant with the 2003/37/CE Directive, and successive modifications, relating to appro-
val of farming tractors
Campodarsego, Signature:
__/__/____ ANTONIO CARRARO S.p.A.
MARCELLO CARRARO
Director General

438-045-2TOC.fm
- 1 -
English
SUMMARY
1 GENERAL INFORMATION
Purpose of this manual ......................................... 3
Requesting technical assistance........................... 4
Accompanying documentation .............................. 5
Terms and definitions............................................ 5
2 SAFETY INFORMATION
Introduction to safety warnings ............................. 9
General safety warnings ..................................... 10
Safety warnings for the employer........................ 12
Safety warnings for handling and transport......... 13
Safety warnings for the driver ............................. 15
Safety warning regarding circulation on roads .... 18
Safety warnings before use................................. 20
Safety warnings for connection and disconnection
of implements (carried or towed)......................... 23
Safety warnings during use................................. 26
Safety warnings during use on sloping or uneven
terrains ................................................................ 29
Safety warnings regarding use with tools (carried or
towed) ................................................................. 31
Warnings for use with spraying tools .................. 33
Safety warnings regarding use in forestry........... 34
Safety warnings regarding use with ballasts
installed ............................................................... 35
Safety warnings at end of use............................. 36
Safety warnings for regulations and maintenance ..
37
Safety warnings regarding environmental impact 40
Warnings on residual risks .................................. 41
description of safety signs................................... 42
3 TECHNICAL INFORMATION
Identification of the machine and its
manufacturer ....................................................... 44
General description of the machine .................... 46
Description of the main parts .............................. 48
Description of hydraulic circuits........................... 51
Description of lift unit........................................... 52
Description of the equipment on request
(Tigre 4000)......................................................... 53
Description of the equipment on request
(Tigre 4400 F) ..................................................... 55
Description of devices for driving on public roads60
description of safety devices ............................... 61
Position safety signals and information............... 63
Dangerous areas and zones ............................... 64
4 HANDLING AND TRANSPORT
INSTRUCTIONS
recommendations for handling, loading and
unloading............................................................. 65
method of transport ............................................. 65
loading and unloading method ............................ 66
Machine emergency towing method.................... 68
5 INFORMATION ON ADJUSTMENTS
Recommendations regarding regulations............ 69
Adjusting the driving position............................... 70
Adjustment of headlights..................................... 71
Regulation of the rear lifting unit.......................... 73
Adjustment of clutch pedal travel ........................ 74
Brake (Tigre 4000) pedal adjustment.................. 75
Brake (Tigre 4400 F) pedal adjustment............... 76
Track change-over .............................................. 77
6 OPERATING INSTRUCTIONS
Recommendations for use and functioning......... 78
Description of controls......................................... 78
Description of instruments and LEDs .................. 79
Description of dashboard controls....................... 81
Description of advance and stop controls ........... 83
Description of work controls (Tigre 4000)............ 85
Description of work controls (Tigre 4400 F) ........ 87
Description of power lifting unit controls
(standard) ............................................................ 89
(Tigre 4400 F) "Controlled effort" power lift unit
use....................................................................... 91
Description of hydraulic sockets controls ............ 92
Description of control plates ................................ 93
Use safety arch (ROPS)...................................... 94
Access to driver's seat ........................................ 95
Engine start/stop ................................................. 96
Moving and stopping the machine....................... 98
Starting the engine with flat battery..................... 99
Set-up for driving on public roads...................... 100
Hitching and disconnecting tool - rear power lift
unit..................................................................... 102
Hitching and disconnecting tool - towing hook .. 104
connection and disconnection of cardan drive
shaft................................................................... 106
Hydraulic coupling connection........................... 108
Electric couplings hitching ................................. 109
Wheel ballast installation................................... 110
Formula for calculating ballasts with carried carried
tool ......................................................................... 110
No part of this document may be reproduced without the written authorization of the manufacturer, who is committed to the continuous improvement of its products
and reserves the right to modify this publication without prior notice provided that this does not constitute a safety risk.
© 2009 - IDM experts in technical communication - Forlì - Author of the texts, illustrations and page layout. The texts can be reproduced entirely or partially, as long
as the author is stated.

438-045-2TOC.fm
- 2 -
English
Ballasts for improved drive ................................... 111
Operating reminders ......................................... 113
Refuelling .......................................................... 115
Prolonged machine inactivity ............................ 116
Putting the machine back into service............... 117
7 INFORMATION ON MAINTENANCE
Maintenance recommendations ........................ 118
Maintenance during the running-in period......... 119
Maintenance interval table ................................ 120
Cleaning the machine ....................................... 122
Cleaning the radiator......................................... 122
cleaning the engine air cleaner ......................... 123
Checking the pressure of the tyres ................... 124
Check battery charge level................................ 126
Location of lubrication points............................. 127
Lubricant table................................................... 128
Coolant composition table................................. 128
Checking the engine oil level ............................ 129
Checking the engine coolant level .................... 130
Front transmission oil level check ..................... 131
Rare transmission oil level check...................... 132
Changing the front transmission oil................... 133
Changing the rear transmission oil.................... 134
Changing the hydraulic oil filter ......................... 135
Major servicing .................................................. 136
8 FAULT FINDING INSTRUCTIONS
Troubleshooting ................................................ 137
9 INFORMATION ON PARTS
REPLACEMENT
Part replacement instructions............................ 142
gas spring replacement..................................... 143
Replacing the air filter ....................................... 144
Changing the battery......................................... 145
Changing tyres .................................................. 146
Replacing front lighting bulbs ............................ 147
Replacing (Tigre 4000) indicator light bulbs
(rear) ................................................................. 148
Replacing (Tigre 4400 F) indicator light bulbs
(rear) ................................................................. 150
Replacement of the work light lamp .................. 151
replacing fuses .................................................. 152
Disposal and scrapping of the machine ............ 153
10 TECHNICAL DATA TABLES
Technical data tables introduction..................... 154
Kerb weight ....................................................... 154
Machine maximum weight accepted ................. 155
Rear power lift dimensions................................ 156
Model Tigre 4000 .................................................. 156
Model Tigre 4400 F............................................... 157
Ballasts:............................................................. 158
Dimensions........................................................ 159
Engine, transmission and plants features ......... 160
Cardan shaft...................................................... 164
PTO features ..................................................... 165
Noise levels ....................................................... 166
Vibrations transmitted to the driver.................... 166
Gradients (machine in static position) ............... 167
Machine tracks .................................................. 168
Vehicle speed.................................................... 170
Rear towing hook .............................................. 172
Italian type-approval .............................................. 172
CE type-approval................................................... 173
Maximum vertical load provided for on the coupling
hook................................................................... 174
Italian type-approval .............................................. 174
CE type-approval................................................... 175
Maximum drawbar pull provided for at the coupling
hook, in Newtons............................................... 176
Italian type-approval .............................................. 176
CE type-approval................................................... 176
11 ENCLOSURES
Front cabling wiring diagram ............................. 178
Dashboard wiring diagram ................................ 180

C143803602.fm
- 3 - General informationEnglish
1
GENERAL INFORMATION
–The purpose of this manual is to transfer the "User instructions" to the ad-
dressees (driver and operators), to prevent and minimise risks in man-machine
interaction.
The information is professionally written by the manufacturer in the
original language (ITALIAN), in compliance with ISO 3600:1996 and the
current Standards.
To facilitate reading and understanding the information, principles of
communication most suitable to the addressees characteristics have
been adopted.
To know the exact definition of certain specific terms used in the man-
ual, go to paragraph "Terms and definitions".
The information may be translated into other languages to satisfy com-
mercial and/or legal requirements.
The manuals must be translated directly, without changes, from the
ORIGINAL INSTRUCTIONS.
Every translation (including that realised by the sender or whoever in-
troduces the machine in the linguistic area in question) must have the
wording "TRANSLATION OF THE ORIGINAL INSTRUCTIONS".
–The manual addressees must know the machine features, respect the safety
warnings and comply with the laws in force in the work place.
–Keep this manual safe for the working life of the machine, in a known and easily
accessible place so that it is always readily available for consultation.
–Consult the analytic index to easily trace the specific subjects of interest.
–Some information may not fully correspond to the effective configuration of the
delivered machine.
The eventually inserted additional information does not influence legibility and
does not jeopardise the level of safety.
PURPOSE OF THIS MANUAL

C143803602.fm
- 4 - General informationEnglish
–The illustrations may represent the machine without safety protections and de-
vices, to make the information clearer and immediate.
The illustrations without the safety protections and devices MUST NOT be taken
as reference during the normal operation of the machine.
–The manufacturer reserves the right to change the information without prior no-
tice of any kind, as long as these modifications do not alter the safety level.
–The symbols represented and described below are used to highlight particularly
important text or specifications.
Danger
Warning
The symbol identifies situations of imminent danger which, if ignored,
lead to serious risks to personal health and safety.
Caution
Precaution
The symbol identifies situations in which it is essential to behave in a
certain way to avoid risks to personal health and safety and risks of
damage to equipment.
Important
The symbol identifies specially important technical and operational in-
formation that must not be ignored.
–Contact the manufacturer’s Technical Assistance Service for technical assist-
ance requirements.
When making a request for technical assistance relating to the machine, indicate
the details shown on the i/d data plate, the approximate number of hours oper-
ation, and the nature of the defect.
REQUESTING TECHNICAL ASSISTANCE

C143803602.fm
- 5 - General informationEnglish
Customers receive the following documentation along with this manual.
–Operation and service manual for the motor
–Certificate of warranty
–CE Declaration of Conformity
The CE Declaration of Conformity is issued for machines introduced into the Eu-
ropean Community States.
The list shows some terms and definitions, with a brief explanation of the meaning
to facilitate understanding when reading.
Terms
–CATEGORY 1 (cab): the code identifies that the cab DOES NOT have a specific
protection for the driver during the spraying of plant protection products.
–IPD (Individual Protection Devices): must be worn by the operators, de-
pending on the type of risk, to protect their safety during work.
–EGR (Engine Gas Recirculation): the code identifies the motor exhaust gas re-
circulation plant valve.
–FOPS (Falling Objects Protective Structure): the code identifies the structure
that protects the driver in the event of falling objects.
–OPS (Operator Protective Structure): the code identifies the structure that
protects the driver in the event of side penetration of objects.
–ROPS (Roll Over Protective Structure): the code identifies that the safety arch
and cab/frame structures are approved and reduce risks of injury for the driver
in case of overturning.
ACCOMPANYING DOCUMENTATION
TERMS AND DEFINITIONS

C143803602.fm
- 6 - General informationEnglish
Definitions
Some definitions are written in simplified form (e.g. "machine stopped in safe con-
dition") without repeating the full explanation to avoid excessive redundancies.
Machine stopped in safe conditions
This state foresees the listed conditions to be carried out in the indicated order.
- Position the machine on to a stable and flat surface.
- Engage the reverser lever in the "forward gear" or "reverse gear" position. (if
present)
- Position the gearbox lever in "first gear".
- Engage the parking brake of the machine.
- Deactivate the PTO of the machine.
a) With equipment carried: lower the power lift unit until it rests on the ground.
b) With equipment towed: engage the parking brake of the equipment.
- Switch off the engine and remove the ignition key.
- Place the safety wedges below the wheels to improve stopping conditions.
Machine parked and on in safe conditions
This state foresees the listed conditions to be carried out in the indicated order.
- Position the machine on to a stable and flat surface.
- Bring the reverser lever to the "neutral gear" position. (if present)
- Bring the gearbox lever to the "neutral gear" position.
- Engage the parking brake of the machine.
- Deactivate the PTO of the machine.
a) With equipment carried: lower the power lift unit until it rests on the ground.
b) With equipment towed: engage the parking brake of the equipment.
Place the safety wedges below the wheels if operating conditions so require.
Machine operation
The definition indicates "all intended uses where man-machine interaction
happens".
The man-machine interaction includes, for example, transport, driving, use,
routine maintenance, etc.
"Cab" version machine
The definition indicates "driver's seat equipped with closed cab". May also be with
air conditioning system.

C143803602.fm
- 7 - General informationEnglish
"Frame" version machine
The definition indicates "driver's seat equipped with cab without doors and lateral
windows".
Ordinary maintenance
The definition indicates "the set of service operations that must be performed in
order to keep the machine functional and fully effective".
The routine maintenance is normally scheduled by the manufacturer, who states
the intervals and the necessary instructions.
Service Engineer
The definition indicates "a person who has received the necessary qualifications
and instructions to perform interventions without risks and is authorised to do so".
Major servicing
The definition indicates "the set of service operations that must be performed in
order to keep the machine functional and fully effective".
The extraordinary maintenance is not described in the "use and maintenance"
manual and must be executed by the service engineer.
Authorised service centre
The definition indicates "structure selected and authorised by the machine
manufacturer to perform routine and extraordinary maintenance".
Residue risk
The definition indicates "all residue risks despite all safety solutions have been
used and integrated during designing".
Operator
The definition indicates "staff with recognised capacities able to interact during
the different working phases of the machine".
Carrier
The definition indicates "staff with recognised capacities in charge of loading and
unloading the machine onto transport means".
Incorrect use
The definition indicates "different use of machine to that indicated in the user
manual, that may derive from the easily predictable human behaviour".

C143803602.fm
- 8 - General informationEnglish
The illustration carries the directional preferences used in the manual.
Dangerous area
The definition indicates "any area around and/or near the machine, in which an
individual constitutes a personal risk to health and safety".
Driver
The definition indicates "staff with recognised capacities able to drive the machine
during the different working phases".
IDM-43803600100.tif
RIGHT SIDE
LEFT SIDE
FRONT
REAR

C243803602.fm
- 9 - Safety informationEnglish
2
SAFETY INFORMATION
–The "Safety information" section contains the warnings to make the addressees
(driver and operator) interacting with the machine pay particular attention".
–The information recalls attention on the behaviours to have, in order to minimise
risks during man-machine interaction.
–The list shows the safety warnings divided according to operational activity.
–General safety warnings
–Safety warnings for the employer
–Safety warnings for handling and transport
–Safety warnings for the driver
–Safety warning regarding circulation on roads
–Safety warnings before use
–Safety warnings for connection and disconnection of implements (carried or
towed)
–Safety warnings during use
–Safety warnings during use on sloping or uneven terrains
–Safety warnings regarding use with tools (carried or towed)
–Warnings for use with spraying tools
–Safety warnings regarding use in forestry
–Safety warnings regarding use with ballasts installed
–Safety warnings at end of use
–Safety warnings for regulations and maintenance
–Safety warnings regarding environmental impact
–Warnings on residual risks
Also reported in the safety warnings are the INCORRECT USES associated with
the relative operational activity.
Important
The safety warnings are also repeated in view of operational phases, to
emphasise the necessary caution and behaviours the operators must
have.
INTRODUCTION TO SAFETY WARNINGS

C243803602.fm
- 10 - Safety informationEnglish
–As well as complying with the laws in
force, during designing the manufac-
turer has adopted all correct manufac-
turing techniques.
The Evaluation of Risks has been car-
ried out to identify the limits of use, the
dangers and estimate risk to protect
personal safety.
–It has arisen from the Evaluation of
Risks that the machine has been
equipped with all devices that make
safety intrinsic.
–The incorrect or "negligent" use of the
machine by the driver can cause acci-
dents (even fatal) despite the adopted
safety solutions.
–Use the machine ONLY with original
safety devices installed by the manu-
facturer.
The tampering and avoidance of the safety devices can cause risks (even fatal)
for the operators.
GENERAL SAFETY WARNINGS
The general safety warnings indicate some principles that must be
respected during man-machine interaction, to prevent and minimise the
risks throughout the life-span.
Accidents (often serious) involving the use of farming implements and
machines depend on many factors.
One factor that may affect safety is often the environmental condition when
working, where it is not always possible to foresee all risks.
Other factors that may determine risks during man-machine interaction, are
the poor attention, the behaviours and incompetence of the operators.
IDM-43800104100.tif
IDM-43801805500.tif

C243803602.fm
- 11 - Safety informationEnglish
–Caution is always necessary. Safety is also in the hands of the operators
working the machine throughout its life span.
It is always too late to remember that which should have been done when it has
already occurred.
–Carefully read the "User instructions"
in this manual and those directly ap-
plied on the machine.
It is important to read the "User instruc-
tions" to minimise risks and avoid dan-
gerous accidents.
The driver must ensure having under-
stood the "User instructions" before in-
teracting with the machine.
–Carefully read the SAFETY WARN-
INGS in the "User instructions" and those directly applied on the machine.
–Ensure the information signals are legible and respect the reported indications.
The information signals can be of different shapes and colours, to signal dan-
gers, obligations, prohibitions and indications.
IDM-43801805400.tif

C243803602.fm
- 12 - Safety informationEnglish
–Entrust driving of the machine ONLY to competent and experienced operators
in using farming machines or similar sectors.
–Foresee a training plan for operators that may not have the necessary compe-
tences for using the machine.
–Inform the operators on the reasonably predictable INCORRECT USES and on
the RESIDUAL RISKS.
–The operator must be able to read and understand the user manual and recog-
nise the safety signals.
–The operator must prove to have the adequate competences and be in adequate
conditions to safely carry out the activities.
–The employer should document the training attended by the operators, so that it
can be produced in the event of a dispute.
–To avoid inadequate safety conditions DO NOT entrust unsuitable operators
with driving the machine.
SAFETY WARNINGS FOR THE EMPLOYER

C243803602.fm
- 13 - Safety informationEnglish
–The machine can be transported directly with the driver in the driver's seat, or
with the machine loaded onto a transport mean.
–Carry out load, unload and transfer following the information reported directly on
the machine and in the "User instructions".
–Staff in charge of loading and un-
loading onto a transport mean to
transfer the machine, must be compe-
tent and skilful and work cautiously.
–ONLY use suitable ramps or other sys-
tems able to ensure safe conditions
during loading and unloading from the
mean of transport.
–ONLY use relevant bar (correctly
hooked to the hitching points of the
machine) when the towed machine must be loaded/unloaded.
–An assistant may be used (situated at
a safe distance) to signal the manoeu-
vres during loading and unloading of
the machine onto the transport mean.
–ALWAYS deactivate the PTO of the
machine before loading it onto the
transport mean.
–Disconnect the interchangeable equip-
ment from the machine in the event of
health risks during loading and un-
loading onto the transport mean.
SAFETY WARNINGS FOR HANDLING AND TRANSPORT
The safety warnings indicate some principles that staff (driver and
operator) must respect during machine handling and transporting.
IDM-43801805800.tif
IDM-43801805900.tif

C243803602.fm
- 14 - Safety informationEnglish
–Ensure the machine and its components are safely anchored to the transport
mean.
–Verify and arrange the opportune signals, if the shape of the machine exceeds
the admitted clearance for road circulation.
–Perform transport using suitable means and of adequate capacity.
–On reception, check the integrity of the machine and components. In the event
of damage or lack of parts, contact the manufacturer or local authorised dealer
to agree on the procedure to be followed.
The listed prohibitions represent the most common incorrect uses. The
non compliance can entail risks for the personal health and safety.
–DO NOT lift the machine using lifting devices with hook (crane) or forks (lifting
truck).
Incorrect uses
