Baroness SP05A Operation manual

Bunker Rake
Owner's Operating Manual
Serial No. SP05A:20991-
"Required reading"
Read this manual before using the machine.
Original Instructions Ver.1.6

Thank you for purchasing the Baroness product.
This manual describes the proper handling,
adjustment, and inspection of your product.
We hope you will use the product safely, and take
advantage of its best performance.
Keeping The Owner's Operating
Manual
Keep this Owner's Operating Manual in the box
on the right side of the seat.
1
bhf6qq-004
Keeping The Owner's Operating Manual_001
1Box
SP05A
Greeting

Read this manual carefully to ensure that you thoroughly understand how to properly operate and maintain the
product, and to avoid causing injury to yourself or others.
The operator is responsible for operating the product properly and safely.
Maintenance should only be performed by a certified specialist.
If you have any questions concerning maintenance or genuine parts, please contact a Baroness dealer or
Kyoeisha.
When making inquiries about the product, please specify the product's model designation and serial number.
When loaning or transferring the product, please also provide this manual together with the product.
Kyoeisha Co., Ltd.
Warning Symbols
This manual uses the following warning symbols for handling precautions that are important for your
safety.
696cq5-001
Warning symbol
This symbol indicates the articles regarding “Danger,” “Warning,” or “Caution.”
Those articles describe important safety precautions and so read them carefully to understand completely before
operating the machine.
Failure to adequately follow these safety precautions may cause an accident.
Danger
Danger
This symbol indicates that serious injury or death will occur if the warning is ignored.
Warning
This symbol indicates that serious injury or death may occur if the warning is ignored.
Caution
This symbol indicates that injury or damage to property may occur if the warning is ignored.
Important
This symbol indicates precautions on the mechanism of the machine.
SP05A
Introduction

Precautionary Statement
Caution
The information described in this manual is
subject to change for improvement without
prior notice.
When replacing parts, be sure to use genuine
Baroness parts or parts designated by
Kyoeisha.
Note that the Baroness product warranty may
not apply to defects caused by the use of
parts from other companies.
Prior to use, carefully read the following
manuals to thoroughly understand the contents
for safe and correct operation.
Baroness Owner's Operating Manual
The Engine's Owner's Manual
The Battery's Owner's Manual
Purpose
This product is intended for leveling bunkers at
golf courses.
Do not use this product in any other way than its
intended purpose, and do not modify the
product.
Operating this product for other purposes and
modifying it may be very dangerous and may
cause damage to the machine.
In addition, this product is not authorized for
operation as a special motor vehicle. Do not
operate it on public roads.
・
・
・
SP05A
Introduction

Safety .............................................................. Page 1-1
Safe Operating Practices ...............................Page 1-2
Disposal .......................................................... Page 2-1
Recycle and Waste Disposal ......................... Page 2-2
Product Overview .......................................... Page 3-1
Specifications .................................................Page 3-2
Names of Each Section ................................. Page 3-4
Regulation Decals ..........................................Page 3-4
Safety Signs and Instruction Signs ................ Page 3-6
Handling Instructions .................................... Page 4-1
Inspections .....................................................Page 4-2
Tightening Torques ......................................Page 4-11
Adjustment before Work .............................. Page 4-14
Procedure to Start/Stop Engine ................... Page 4-17
Operation Method ........................................ Page 4-18
Instruments .................................................. Page 4-25
Travel of Machine ........................................ Page 4-26
Operations ................................................... Page 4-27
Transporting .................................................Page 4-31
Storage ........................................................ Page 4-31
Maintenance ................................................... Page 5-1
Maintenance Precautions .............................. Page 5-2
Maintenance Schedule .................................. Page 5-2
Jacking Up The Machine ............................... Page 5-4
Greasing ........................................................ Page 5-5
Lubrication ..................................................... Page 5-8
Maintenance Work .........................................Page 5-8
SP05A
Contents

SP05A
Contents

Safe Operating Practices ...................... Page 1-2
Training ..................................................Page 1-2
Preparation ............................................ Page 1-2
Operation ...............................................Page 1-3
Maintenance and Storage ..................... Page 1-4
Safety
SP05A
Safety
Page 1-1

Failure to adequately follow these safety
precautions may cause an accident resulting in
injury or death.
Danger
Danger
This product is designed to ensure safe
operation and has been tested and inspected
thoroughly before shipment from the factory.
The product is equipped with safety devices to
prevent accidents.
However, whether the product demonstrates
its original performance level depends on the
manner in which it is operated and handled,
as well as the manner in which it is managed
on a daily basis.
Inappropriate use or management of the
product may result in injury or death.
Observe the following safety instructions to
ensure safe operation.
Safe Operating Practices
Training
Read this manual and other training material
carefully. Be familiar with the controls, safety
signs, and the proper use of the equipment.
If the operator or mechanic can not read
English it is the owner's responsibility to
explain this manual to them.
All operators and mechanics should seek
and obtain professional and practical
instruction.
The owner is responsible for training the
users.
Such instruction should emphasize.
The need for care and concentration when
working with ride-on machines.
Control of a ride-on machine sliding on a
slope will not be regained by the
application of the brake.
The main reasons for loss of control are
Insufficient wheel grip
Being driven too fast
Inadequate braking
The type of machine is unsuitable for its
task
Lack of awareness of the effect of
ground conditions, especially slopes
Incorrect hitching and load distribution
1.
2.
3.
[1]
[2]
-
-
-
-
-
-
Never allow children or people unfamiliar
with these instructions to use or service the
machine.
Local regulations may restrict the age of the
operator.
The owner/user can prevent and is
responsible for accidents or injuries
occurring to themselves, other people, or
property.
Keep in mind that the owner, operator, and
mechanic are responsible for accidents or
hazards occurring to other people or their
property.
You can find additional safety information
where needed throughout this manual.
Determine the left and right sides of the
machine from the normal operating position.
Preparation
Evaluate the terrain to determine what
accessories and attachments are needed to
properly and safety perform the job.
Only use accessories and attachments
approved by the manufacturer.
While operating, always wear substantial
footwear, long trousers, hard hat, safety
glasses, and ear protection.
Long hair, loose clothing, or jewelry may get
tangled in moving parts.
Do not operate the equipment when barefoot
or wearing open sandals.
Inspect the area where the equipment is to
be used and remove all objects such as
rocks, toys and wire which can be thrown by
the machine.
Keep children out of the operating area and
under the watchful care of a responsible
adult other than the operator.
Exercise care in the handling of fuel.
Warning
Warning-Fuel is highly flammable.
Take the following precautions.
Store fuel in containers specifically
designed for this purpose.
Add fuel before starting the engine.
Never remove the cap of the fuel tank or
add fuel while the engine is running or
when the engine is hot.
Refuel outdoors only and do not smoke
while refueling.
4.
5.
6.
7.
8.
1.
2.
3.
4.
5.
[1]
[2]
[3]
SP05A
Safety
Page 1-2 Safe Operating Practices

If fuel is spilled, do not attempt to start the
engine but move the machine away from
the area of spillage and avoid creating any
source of ignition until petrol vapours have
dissipated.
Replace all fuel tanks and container caps
securely.
Check that operator's presence controls,
safety switches and shields are attached and
functioning properly.
Do not operate unless they are functioning
properly.
If the brake operation is faulty, be sure to
adjust or repair them before operating the
machine.
Replace faulty mufflers.
Operation
Do not operate the engine in a confined
space where dangerous carbon monoxide
fumes can collect.
Only operate in good light, keeping away
from holes and hidden hazards.
Before attempting to start the engine,
disengage all attachments, shift into neutral,
and engage the parking brake.
Only start engine from the operator's
position.
Use seat belts if provided.
Remember there is no such thing as a safe
slope.
Travel on grass slopes requires particular
care.
To guard against overturning:
Do not stop or start suddenly when going
up or downhill.
Engage clutch slowly, always keep
machine in gear, especially when traveling
downhill.
Machine speeds should be kept low on
slopes and during tight turns.
Stay alert for humps and hollows and
other hidden hazards.
Never operate across the face of the
slope, unless the machine is designed for
this purpose.
Never drive the machine on a slope with
an angle of gradient that is greater than
that specified or in a place where there is
a danger of the machine slipping.
[4]
[5]
6.
7.
8.
1.
2.
3.
4.
[1]
[2]
[3]
[4]
[5]
[6]
Use extra care while operating machine with
a grass catcher or other attachments.
They can affect the stability of the machine.
Never operate the machine with damaged
guards, shields, or without safety protective
devices in place.
Be sure all interlocks are attached, adjusted
and functioning properly.
Do not change the engine governor settings
or overspeed the engine.
Operating the engine at excessive speed
may increase the hazard of personal injury.
Do the following before leaving the
operator’s position.
Stop on level ground.
Change into neutral and set the parking
brake.
Stop the engine and remove the key.
Stop the engine, and remove the ignition key
in the following conditions.
Before refueling.
Before making height adjustment unless
adjustment can be made from the
operator's position.
Before checking, cleaning or working the
machine.
After striking a foreign object or if an
abnormal vibration occurs.
Inspect the machine for damage and
make repairs before restarting and
operating the equipment.
Do not mow in reverse unless absolutely
necessary. Always look down and behind
before and while backing.
Do not carry passengers.
Never operate while people, especially
children, or pets are nearby.
Slow down and use caution when making
turns and crossing roads and sidewalks.
Do not operate the machine under the
influence of alcohol or drugs.
Take care when loading or unloading the
machine into a trailer or a truck.
Load or unload the machine in a flat and
safe place.
Before loading or unloading, set the parking
brake on the truck or trailer, stop the engine,
and chock the wheels.
5.
6.
7.
8.
[1]
[2]
[3]
9.
[1]
[2]
[3]
[4]
10.
11.
12.
13.
14.
15.
Safety
SP05A
Safety
Page 1-3
Safe Operating Practices

When transporting the machine on a truck or
a trailer, set the parking brake, stop the
engine, and fasten the machine to the truck
with a rope or other suitable restraining
device that has sufficient strength.
When using a loading ramp, select one with
sufficient strength, length, and width and that
will not cause the machine to slip.
Close the fuel valve before transporting the
machine.
Use care when approaching blind corners,
shrubs, trees, or other objects that may
obscure vision.
Do not take your eyes off the road ahead.
Do not operate the machine with no hands.
Reduce the throttle setting during engine
run-out and, if the engine is provided with a
shut-off valve, turn the fuel off at the
conclusion of operation.
Do not operate the machine when there is
the risk of lightning.
Maintenance and Storage
Disengage drives on level ground, set
parking brake, stop engine and remove key
from ignition.
Wait for all movement to stop before
adjusting, cleaning or repairing.
To reduce the fire hazard, keep the engine,
silencer/muffler, battery compartment fuel
storage area, attachments and drives free of
grass, leaves, or excessive grease.
Clean up oil or fuel spillage.
Allow the engine to cool before storing in any
enclosure.
Only cover the machine with a sheet after
hot parts have sufficiently cooled down.
Never store the equipment with fuel in the
tank inside a building where fumes may
reach an open flame or spark.
If the engine is provided with a shut-off
valve, shut off valve while storing or
transporting.
Do not store fuel near flames.
Never allow untrained personnel to service
machine.
Allow the engine/muffler to cool before
checking/maintenance.
Appropriately manage and correctly use the
tools necessary for servicing or adjusting the
machine.
16.
17.
18.
19.
20.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
Use jack stands to support components
when required.
Carefully release pressure from components
with stored energy.
Be sure to depressurize the hydraulic system
before performing maintenance operations
on it such as removing hydraulic equipment.
Check whether line connectors in the
hydraulic system are properly tightened.
Before applying hydraulic pressure, check
the connections of the hydraulic pressure
lines and the condition of the hoses.
When checking the hydraulic circuit for
pinhole leaks or oil leakage from nozzles, do
not use your hands.
Use items such as paper or corrugated
cardboard to find leakage points.
Be extremely careful with high-pressure oil
as it may pierce your skin, result.
If fluid is injected into the skin it must be
surgically removed within a few hours by a
doctor familiar with this form of injury or
gangrene may result.
Disconnect battery before making any
repairs.
Disconnect the negative terminal first and
the positive last.
Reconnect positive first and negative last.
Make sure that parts such as wires are not
touching each other and that their covers
have not come off.
Keep hands and feet away from moving
parts.
If possible, do not make adjustments with the
engine running.
Charge batteries in an open well ventilated
area, away from spark and flames.
Unplug charger before connecting or
disconnecting from battery.
Wear protective clothing and use insulated
tools.
Keep all parts in good working condition and
all hardware tightened.
Replace all worn or damaged decals.
Keep all nuts, bolts and screws tight to be
sure the equipment is in safe working
condition.
If the fuel tank has to be drained, do this
outdoors.
11.
12.
13.
14.
15.
16.
17.
18.
19.
20.
21.
22.
SP05A
Safety
Page 1-4 Safe Operating Practices

Recycle and Waste Disposal
About Recycle
Recycling battery etc. is recommended for
environmental conservation and economical
use of resources.
It may be required by local laws.
About Waste Disposal
Make sure that waste generated when
servicing or repairing the machine is disposed
of in accordance with local regulations.
(e.g. waste oil, antifreeze, rubber products, and
wires etc.)
SP05A
Disposal
Page 2-2 Recycle and Waste Disposal

Specifications ........................................ Page 3-2
Specifications .........................................Page 3-2
Sound Pressure Level ........................... Page 3-3
Sound Power Level ............................... Page 3-3
Vibration Level .......................................Page 3-3
Carbon Dioxide (CO2) Emissions
Measurement .........................................Page 3-3
Names of Each Section ......................... Page 3-4
Regulation Decals ..................................Page 3-4
Positions of Regulation Decals ..............Page 3-4
Description of Regulation Decals .......... Page 3-5
Safety Signs and Instruction Signs ..... Page 3-6
About Safety Signs and Instruction
Signs ......................................................Page 3-6
Positions of Safety Decals and
Instruction Decals .................................. Page 3-6
Description of Safety Decals and
Instruction Decals .................................. Page 3-6
Product Overview
SP05A
Product Overview
Page 3-1

Specifications
Specifications
Model SP05A (2WD) SP05A (3WD)
Dimensions
Total length
with Rake
and Blade 84.65 in 215 cm ←
with Blade 90.55 in 230 cm ←
Total width 74.80 in 190 cm ←
Total height 47.24 in 120 cm ←
Weight
Machine (empty
fuel tank) with Rake 987.65 lb 448 kg 1047.18 lb 475 kg
Blade 55.11 lb 25 kg ←
Cultivator 41.89 lb 19 kg ←
Finishing brush 23.37 lb 10.6 kg ←
Minimum turning radius 133.46 in 339 cm ←
Engine
Model Vanguard 356447 ←
Type Air-cooled 4-cycle gasoline engine ←
Total displacement 34.78 cu.in. 570 cm3 (0.57 L) ←
Maximum output 13.2 kW (18.0 PS)/3,600 rpm ←
Fuel tank capacity Gasoline 3.96
U.S.gal.
Gasoline 15.0
dm3 (15.0 L) ←
Fuel consumption 228 g/PS・h
(rated output)
310 g/kW・h
(rated output) ←
Engine oil capacity 0.42 U.S.gal. 1.6 dm3 (1.6 L) ←
Coolant volume - ←
Hydraulic tank capacity 3.96 U.S.gal. 15.0 dm3 (15.0 L) ←
Operating
width
Rake 74.80 in 190 cm ←
Blade 31.50 in 80 cm ←
Cultivator 45.67 in 116 cm ←
Finishing brush 76.77 in 195 cm ←
Drive Traveling HST
2WD[3WD(2WD/3WD selectable)] ←
Operating - ←
Speed (HST) Forward 0 - 9.94 mph 0 - 16.0 km/h 0 - 7.96 mph 0 - 12.8 km/h
Reverse 0 - 3.73 mph 0 - 6.0 km/h 0 - 2.98 mph 0 - 4.8 km/h
Speed (Mechanical) - ←
Efficiency - ←
Maximum inclination for operation 15 degrees ←
Tire size Front wheel PD21 x 11.00 - 10 ←
Rear wheel 25 x 13.00 - 9 ←
Tire pneumatic
pressure
Front wheel 10.15 psi 70 kPa
(0.7 kgf/cm2)←
Rear wheel 5.80 psi 40 kPa
(0.4 kgf/cm2)←
Battery 46B19R ←
SP05A
Product Overview
Page 3-2 Specifications

Engine plug PLUG, CHAMPION XC92YC ←
The factory default maximum engine rpm is 3,000 rpm.
Sound Pressure Level
Sound Pressure Level
This machine was confirmed to have a
continuous A-weighted sound pressure level
of 84 dB by measuring identical machines in
accordance with the procedure specified in
ISO5395-1:2013.
Sound Power Level
Sound Power Level
This machine was confirmed to have a sound
power level of 98 dB by measuring identical
machines in accordance with the procedure
specified in ISO5395-1:2013.
Vibration Level
Hand-Arm Vibration
This machine was confirmed not to exceed a
vibration level of 2.5 m/s2 to hands and arms
by measuring identical machines in
accordance with the procedure specified in
ISO 5395-1:2013.
Whole Body Vibration
This machine was confirmed not to exceed a
vibration level of 0.5 m/s2 to the whole body
by measuring identical machines in
accordance with the procedure specified in
ISO 5395-1:2013.
Carbon Dioxide (CO2) Emissions
Measurement
For CO2 emissions measurement on the
engine of this machine, refer to the engine's
owner's manual.
Product Overview
SP05A
Product Overview
Page 3-3
Specifications

Names of Each Section
1
10
2
8
6
7
3
5
4
14
15
17
16
12
11
9
13
18
19
quwxcl-172
Names of Each Section_001
1Steering wheel
2 Front cover
3 Blade (option)
4 Front tire
5 Traveling pedal
6 Oil gauge
7 Cultivator (option)
8 Rear tire
9 Air cleaner
10 2WD/3WD selector lever (3WD
specifications)
11 Brake pedal
12 Tilt lever
13 Throttle lever
14 Up/down lever
15 Fuel filler
16 Broom holder
17 Rear cover
18 Fuel cock
19 Finishing brush (option)
Regulation Decals
Positions of Regulation Decals
D,E
A
B
C
quwxcl-249
Positions of Regulation Decals_001
ASerial number plate
B Specification decal
C Year of manufacture decal
D Battery capacity decal
E Recycle decal
SP05A
Product Overview
Page 3-4 Names of Each Section

Description of Regulation Decals
Serial Number Plate
The serial number plate indicates the model
and serial number of the machine.
4ogipb-001
Serial Number Plate_001
Specification Decal
(For Europe)
The Specification decal indicates the CE
marking, model , and weight, etc.
kj8jic-001
Specification Decal_001
Year of Manufacture Decal
(For Europe)
The year of manufacture decal indicates the
year when this machine was manufactured.
YEAR OF
MANUFACTURE
wvzv36-001
Year of Manufacture Decal_001
Battery Capacity Decal
(For Europe)
The battery capacity decal indicates the
capacity by 20HR and CCA.
2z2dxu-001
Battery Capacity Decal_001
Recycle Decal
Recycle Decal illustrates Recycle Mark in
accordance with local regulation.
(For Europe)
Pb y7wov5-001
Recycle Decal_001
(For USA)
LEAD
RETURN
RECYCLE
y7wov5-002
Recycle Decal_002
Product Overview
SP05A
Product Overview
Page 3-5
Regulation Decals

Safety Signs and Instruction Signs
About Safety Signs and Instruction Signs
Important
Safety decals and instruction decals are
attached to this product.
Make sure that they are preserved in their
entirety. If they are damaged, become dirty, or
peel off, replace them with new ones.
Part numbers for decals that need to be
replaced are listed in the parts catalog.
Order them from a Baroness dealer or
Kyoeisha.
Positions of Safety Decals and Instruction
Decals
7
6
2
1
5
8
4
3
6
6iul4h-173
Positions of Safety Decals and Instruction Decals_001
1Operation decal
2 Caution to getting pinched decal
3 Caution exhaust gas decal
4 Lead-free gasoline decal
5 Fire prohibited decal
6 Caution to getting entangled decal
7 Caution for high temperatures decal
8 Caution to noise decal
Description of Safety Decals and
Instruction Decals
Operation Decal
SP05---0560C0
Sticker, operation
Warning
Read the Owner's Operating Manual.
Warning
Apply the parking brake, stop the engine,
remove the ignition key, and then leave the
machine.
Warning
Rollover - Do not work on slopes of 15
degrees or more.
When you descend a slope, drive at low
speed.
Caution
Flying objects - Be sure that people around
the machine keep a safe distance away.
2
1
1
4
2
3
jh9nw4-002
Operation Decal_001
1.
2.
3.
4.
SP05A
Product Overview
Page 3-6 Safety Signs and Instruction Signs

Caution to Getting Pinched Decal
K4205001930
Decal, caution to getting pinched
Caution
May pinch - There is a risk of being pinched.
tgp289-002
Caution to Getting Pinched Decal_001
Caution Exhaust Gas Decal
K4205001950
Decal, caution exhaust gas
Warning
Caution for exhaust gas
kvwx52-001
Caution Exhaust Gas Decal_001
Lead-Free Gasoline Decal
K4209001310
Decal, lead-free gasoline
Use lead-free gasoline.
xmitt2-002
Lead-Free Gasoline Decal_001
Fire Prohibited Decal
K4205001940
Decal, fire prohibited
Warning
Keep away from fire.
r653fo-001
Fire Prohibited Decal_001
Product Overview
SP05A
Product Overview
Page 3-7
Safety Signs and Instruction Signs

Caution to Getting Entangled Decal
K4205001910
Decal, caution to getting entangled
Warning
Watch for rotating parts - Keep your hands
away from the belts while the engine is
running.
hj8m6e-001
Caution to Getting Entangled Decal_001
Caution for High Temperatures Decal
K4205001920
Decal, caution for high temperatures
Caution
High temperature - Do not touch. Otherwise,
you will get burned.
xekv4l-001
Caution for High Temperatures Decal_001
Caution to Noise Decal
K4205002090
Decal, caution to noise
bwu9po-001
Caution to Noise Decal_001
SP05A
Product Overview
Page 3-8 Safety Signs and Instruction Signs
Other manuals for SP05A
2
Table of contents
