VHF/UHF Masthead Amplifier Model: AP700
Thanks for purchasing this AP700 Masthead Amplifier.
Before installation,
Please read this manual carefully and keep this manual
for further information.
APPLICATIONS
• For effective amplification of the TV signal received by TV antenna(s) (approximately 30dB)
• Use in weak TV signal areas or for multiple TVs
• Use with individual VHF and/or UHF antennas or a single combination VHF/UHF antenna
INSTALLATION INSTRUCTIONS
Head Unit
VHF/UHF
Antenna
UHF
Antenna
Second TV
(if required)
To TV
(via “IN”connection
on power supply)
1. Attach Head Unit to the mast
using cable tie supplied. (Fig 1)
2. Make connection to Head Unit
as shown (Fig 2).
Close cover after ensuring
cables are attached securely and
positioned correctly.
3. Attach the power supply to wall
or skirting board.
A ventilation gap of at least 25mm
should be left around the front and
sides of the unit.
4. Connect the downlead from
the head unit to the “IN” socket.
Connect the output lead from the
socket marked “TV” to the recieving
installation (satellite reciever, VCR,
TV etc). When all connections have
been made, plug power supply into
mains outlet and switch on - Yellow
light will illuminate.
Note: If light shows red colour
there is a short circuit on the “IN”
connection.
TIP: If installing amplifier to old
antenna, ensure antenna is in good
condition and cable terminations
are secure.
Power supply
Wallplate
Fig 1 Fig 2
CPIN002337
AP700-BUN_CPIN002337.indd 1 29/03/12 10:17 AM
ANTSIG is proudly produced by Antsig Australia Pty. Ltd.
Visit us at: www.ANTSIG.com
Arlec Australia Pty. Ltd. ACN 009 322 105 (“Arlec”) gives the Warranty.
Arlec’s telephone number, address and email address are:
Customer Service: (03) 9982 5111
Building 3, 31 – 41 Joseph Street, Blackburn North, Victoria, 3130
Blackburn North LPO, P.O. Box 1065, Blackburn North, 3130
Email: [email protected]
CPIN002337
CONTENTS:
Package includes:
• F-Connector 0.9 metre fly lead.
• 2 x F-Connector male to PAL female adaptor.
• 2 x twist on F-Connector male for RG6 cable.
• Cable tie.
• Masthead amplifier unit.
• Power supply unit.
SAFETY INFORMATION
The Power Supply is designed for indoor use only.
The supply plug must remain readily accessilbe.
Unit is not disconnected from mains unless supply plug is removed.
Antsig guarantees this product in accordance with the Australian Consumer Law.
Antsig also warrants to the original first purchaser of this product (“you”) from a retailer that this product will be
free of defects in materials and workmanship for a period of 12 months from the date of purchase; provided the
product is not used other than for the purpose, or in a manner not within the scope of the recommendations and
limitations, specified by Antsig, is new and not damaged at the time of purchase, has not been subjected to abuse,
misuse, neglect or damage, has not been modified or repaired without the approval of Antsig and has not been
used for commercial purposes (“Warranty”).
If you wish to claim on the Warranty, you must, at your own expense, return the product, and provide proof of
original purchase and your name, address and telephone number, to Antsig at the address below or the retailer
from whom you originally purchased the product within 12 months from the date of purchase.
Antsig will (or authorise the retailer to) assess any claim you may make on the Warranty in the above manner and
if, in Antsig’s reasonable opinion, the Warranty applies, Antsig will at its own option and expense (or authorise the
retailer to) replace the product with the same or similar product or repair the product and return it to you or refund
the price you paid for the product. Antsig will bear its own expenses of doing those things, and you must bear any
other expenses of claiming on the Warranty.
The Warranty is in addition to other rights and remedies you may have under a law in relation to the product to
which the Warranty relates.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law.
You are entitled to a replacement or refund for a major failure and for compensation for any other reasonably
foreseeable loss or damage.
You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure.
© This instruction leaflet is
subject to copyright and
must not be reproduced,
copied or otherwise used in
any way or for any purpose
without the consent in
writing of the owner
WARRANTY
AP700-BUN_CPIN002337.indd 2 29/03/12 10:17 AM
