Anybus Wireless Bridge II User manual

Anybus
®Wireless Bridge II™
INSTALLATION GUIDE
SCM-1202-013/SP2167 1.1 ENGLISH

Important User Information
Liability
Every care has been taken in the preparation of this document. Please inform HMS Industrial Net-
works AB of any inaccuracies or omissions. The data and illustrations found in this document are
not binding. We, HMS Industrial Networks AB, reserve the right to modify our products in line with
our policy of continuous product development. The information in this document is subject to
change without notice and should not be considered as a commitment by HMS Industrial Networks
AB. HMS Industrial Networks AB assumes no responsibility for any errors that may appear in this
document.
There are many applications of this product. Those responsible for the use of this device must en-
sure that all the necessary steps have been taken to verify that the applications meet all perform-
ance and safety requirements including any applicable laws, regulations, codes, and standards.
HMS Industrial Networks AB will under no circumstances assume liability or responsibility for any
problems that may arise as a result from the use of undocumented features, timing, or functional
side effects found outside the documented scope of this product. The effects caused by any direct
or indirect use of such aspects of the product are undefined, and may include e.g. compatibility is-
sues and stability issues.
The examples and illustrations in this document are included solely for illustrative purposes. Be-
cause of the many variables and requirements associated with any particular implementation,
HMS Industrial Networks AB cannot assume responsibility for actual use based on these exam-
ples and illustrations.
Intellectual Property Rights
HMS Industrial Networks AB has intellectual property rights relating to technology embodied in the
product described in this document. These intellectual property rights may include patents and
pending patent applications in the USA and other countries.
Anybus®Wireless Bridge II™Installation Guide SCM-1202-013/SP2167 1.1

About This Document 3 (16)
1 About This Document
This document describes how to install Anybus Wireless Bridge II and set up a
basic configuration. For additional documentation and technical support, please
visit the Anybus support website www.anybus.com/support.
Trademark Information
Anybus®is a registered trademark and Wireless Bridge II™is a trademark of
HMS Industrial Networks AB. All other trademarks mentioned in this document
are the property of their respective holders.
Anybus®Wireless Bridge II™Installation Guide SCM-1202-013/SP2167 1.1

Product Description 4 (16)
2 Product Description
Anybus Wireless Bridge II provides wireless communication over WLAN and/or
Bluetooth®to wired networks.
Typical applications for Anybus Wireless Bridge II include:
• Adding wireless cloud connectivity to industrial devices
• Accessing devices from a laptop, smartphone or tablet
• Ethernet cable replacement between devices
Limitations:
Bluetooth PAN (Personal Area Network) may not work with some devices due to
different implementations of Bluetooth by different manufacturers.
WLAN 5 GHz cannot be used at the same time as WLAN 2.4 GHz or Bluetooth.
WLAN or Bluetooth?
Choose WLAN when data throughput and seamless roaming are most important
and there are few other radio emitting devices in the environment.
Choose Bluetooth if connection robustness and low latency are most important,
and in environments with many other radio emitters.
Anybus®Wireless Bridge II™Installation Guide SCM-1202-013/SP2167 1.1

Installation 5 (16)
3 Installation
Caution
This equipment emits RF energy in the ISM (Industrial, Scientific,
Medical) band. Make sure that all medical devices used in proximity to
this device meet appropriate susceptibility specifications for this type of
RF energy.
This product is recommended for use in both industrial and domestic
environments. For industrial environments it is mandatory to use the
functional earth connection to comply with immunity requirements. For
domestic environments the functional earth must be omitted if a shielded
Ethernet cable is used, in order to meet emission requirements.
This product contains parts that can be damaged by electrostatic
discharge (ESD). Use ESD protective measures to avoid equipment
damage.
Anybus Wireless Bridge II can be screw-mounted directly onto a flat surface or
mounted on a standard DIN rail using the optional DIN mounting kit.
Make sure that you have all the necessary information about the capabilities and
restrictions of your local network environment before installation.
For optimal reception, wireless devices require a zone between them clear of ob-
jects that could otherwise obstruct or reflect the signal. A minimum distance of
50 cm between the devices should also be observed to avoid interference.
The characteristics of the internal antenna should be considered when choosing
the placement and orientation of the unit (unless an external antenna is used).
See the Anybus Wireless Bridge II User Manual for more information.
Anybus®Wireless Bridge II™Installation Guide SCM-1202-013/SP2167 1.1

Installation 6 (16)
3.1 Dimensions
15.4
33.2
26.4
92.7
82
112.5
67.8
58
R2
12.2
4.9
3022
19.8
All measurements are in mm.
Anybus®Wireless Bridge II™Installation Guide SCM-1202-013/SP2167 1.1

Installation 7 (16)
3.2 Connectors
Power Connector (A-coded male M12)
Pin Function
1 Power + (9–30 V)
2 Digital Input Ground
3 Power Ground
4 Digital Input + (9–30 V)
5 Functional Earth
Signal wiring for the digital input must be carried in the same cable as
power and functional earth if wiring length exceeds 3 meters.
LAN Connector (D-coded female M12)
Pin Function Color coding (T568B)
1 Transmit + Orange/White
2 Receive + Green/White
3 Transmit - Orange
4 Receive - Green
Anybus®Wireless Bridge II™Installation Guide SCM-1202-013/SP2167 1.1

Installation 8 (16)
3.3 LED Indicators
PWR Off No power
Green Normal operation
WLAN
Off WLAN disabled or no power
Blue Access Point mode: Connected to at least one client
Client mode: Connected to access point
Blue, flickering WLAN data activity (when connected)
Purple, blinking Client mode: Scanning for access points
Purple Client mode: Connecting to a detected access point
Red Unrecoverable error
LAN
Off No Ethernet connection
Yellow Ethernet link present
Yellow, flickering Ethernet data activity (when connected)
BT
Off Bluetooth disabled or no power
Blue NAP mode: Connected to at least one PANU client
PANU mode: Connected to NAP
Blue, flickering Bluetooth data activity (when connected)
Purple PANU mode: Trying to connect to NAP
Red Unrecoverable error
A-B-C-D Green RSSI (received signal strength) or Link Quality
See also Easy Config, p. 10.
RSSI (WLAN Client) / Link Quality (Bluetooth PANU) A B C D
No connection
RSSI/Link Quality < 25 %
RSSI/Link Quality 25–50 %
RSSI/Link Quality 50–75 %
RSSI/Link Quality > 75 %
Additional LED indications are used when the unit is in Recovery Mode.
See Recovery Mode LED Indications, p. 12.
Anybus®Wireless Bridge II™Installation Guide SCM-1202-013/SP2167 1.1

Configuration 9 (16)
4 Configuration
Anybus Wireless Bridge II can be configured via the web interface or using one
of the pre-configured Easy Config modes.
Advanced configuration can be carried out by issuing AT (modem) commands
through the web interface or over a Telnet or RAW TCP connection to port 8080.
A list the of supported AT commands is included in the web interface.
4.1 The Web Interface
The web interface is accessed by pointing your web browser to the IP address of
the Wireless Bridge. The default address is 192.168.0.99.
Most configuration settings are self-explanatory. See also the built-in help and
the Anybus Wireless Bridge II User Manual.
The web interface is designed for the current stable versions of Internet
Explorer, Chrome, Firefox and Safari. Other browser versions may not
support all functions of the interface.
Anybus®Wireless Bridge II™Installation Guide SCM-1202-013/SP2167 1.1

Configuration 10 (16)
4.2 Easy Config
1. Power on the unit and wait for the Link Quality LEDs to light up and go out
again, then press and release the MODE button.
Step 1 must be carried out within 5 seconds of startup.
2. Press MODE repeatedly to cycle through the Easy Config modes until the
desired mode is indicated by the A-B-C-D LEDs.
Mode 2 is the first mode, which means that the number of required button
presses are always one less than the mode number.
3. Press and hold MODE for 2 seconds, then release the button. This will con-
firm the selected mode and restart the unit.
Step 3 must be carried out within 20 seconds of step 2, otherwise the unit
will exit Easy Config setup and return to the previous settings.
4.2.1 Easy Config Modes
Mode Role Description A B C D
2 — Reset configuration to factory defaults
3 — Reset IP settings to factory defaults
4 Client Wait for discovery and configuration
5 WLAN AP Discover units in Mode 4 and configure
them as clients
6 Bluetooth NAP
Modes 4, 5 and 6 are used in combination to automatically set up a WLAN or
Bluetooth network with units of this type.
Modes 5 and 6 will scan for units in Mode 4. Each detected unit in Mode 4 will be
reconfigured as a client, and the scanning unit will be configured as an access
point. The clients will then restart and connect to the access point.
Mode Timeout
• Mode 5 and 6 will scan for 120 seconds. The mode can be activated repeat-
edly to scan for additional units.
• Mode 4 will listen for 120 seconds, or until it has received a valid configura-
tion from a unit scanning in Mode 5 or 6.
The IP address of a client may be changed by the configuration from the
access point. Active browser sessions could therefore be lost.
Anybus®Wireless Bridge II™Installation Guide SCM-1202-013/SP2167 1.1

Configuration 11 (16)
4.3 Factory Restore
The unit can be restored to the factory default settings using any of the following
methods:
► Press and hold the MODE button for >10 seconds and then release it
► Execute Easy Config Mode 2
► Click on Factory Restore on the System Settings page
► Issue the AT command AT&F and reboot
Default Network Settings
IP Assignment Static
IP Address 192.168.0.99
Subnet Mask 255.255.255.0
Default Gateway 192.168.0.99
Default WLAN Settings
Operating Mode Client
Channel Bands 2.4 GHz & 5 GHz
Authentication Mode Open
Channel Auto
Bridge Mode Layer 2 tunnel
Default Bluetooth Settings
Operating Mode PANU (Client)
Local Name [generated from MAC address]
Security Mode Disabled
Default System Settings
Password [empty]
Setting a secure password for the unit is strongly recommended.
Anybus®Wireless Bridge II™Installation Guide SCM-1202-013/SP2167 1.1

Configuration 12 (16)
4.4 MODE Button
The MODE button can be used to restart or reset the unit as well as for selecting
Easy Config modes. See Easy Config, p. 10.
► When the unit is powered on, press and hold MODE for >10 seconds and
then release it to reset to the factory default settings.
► Press and hold MODE while applying power to boot into Recovery Mode.
Recovery Mode can be used to reinstall firmware using an external applica-
tion if the web interface cannot be accessed. Please refer to the support
website for more information.
Firmware updates should normally be carried out through the web
interface. Recovery Mode should only be used if the unit is unresponsive
and the web interface cannot be accessed.
Recovery Mode LED Indications
In Recovery Mode the LEDs will indicate firmware update status.
PWR Green Firmware update in progress
Green, blinking Waiting for valid firmware
WLAN + BT Alternating red/blue Firmware update in progress
Anybus®Wireless Bridge II™Installation Guide SCM-1202-013/SP2167 1.1

Configuration 13 (16)
4.5 Configuration Examples
Settings not mentioned here should be left at their default values.
Ethernet Bridge over WLAN – Easy Config setup
This example describes how to connect two Ethernet networks over WLAN using
two Wireless Bridges. Both units are configured using only the MODE button.
1. Power on the first Wireless Bridge, wait for the LEDs to light
up and go out, then press MODE and release it immediately.
2. Press MODE repeatedly until only LED Cis lit, indicating
Easy Config Mode 4, then confirm by pressing and holding
MODE for 2 seconds.
This unit will now be discoverable and open for automatic
configuration.
3. Power on the second Wireless Bridge, wait for the LEDs to
light up and go out, then press and release MODE.
4. Press MODE repeatedly on the second unit until A+Care lit,
indicating Easy Config Mode 5, then confirm by pressing and
holding MODE for 2 seconds.
This unit should now automatically discover and configure
the other unit as a WLAN client.
PROFINET communication
WLAN communication with PROFINET devices requires that Bridge Mode is set
to Layer 2 tunnel on the WLAN Settings page of the web interface.
Anybus®Wireless Bridge II™Installation Guide SCM-1202-013/SP2167 1.1

Technical Data 14 (16)
5 Technical Data
5.1 Technical Specifications
General Specifications
Order code AWB3000 AWB3010
Antenna Internal External
Maximum range 400 m (WLAN and Bluetooth)
Using an external antenna does not extend the range but allows sep-
arate placement of antenna and unit (e.g. if unit is placed in an
enclosure).
Wired Interface type Ethernet
Dimensions (LxWxH) 93 x 68 x 33.2 mm
Weight 120 g
Operating temperature -30 to +65 °C
Storage temperature -40 to +85 °C
Vibration Sinusoidal vibration test according to IEC 60068-2-6:2007 and with
extra severities. Shock test according to IEC 60068-2-27:2008 and
with extra severities.
See Anybus Wireless Bridge II Compliance Sheet for details.
Humidity EN 600068-2-78: Damp heat, +40 °C, 93 % humidity for 4 days
Housing Plastic (Bayblend FR3010)
Protection class IP65
Mounting Screw mount or DIN rail using optional clip
Power connector M12 male A-coded
Ethernet connector M12 female D-coded
Power supply 9–30 VDC (-5 % +20 %)
Cranking 12 V (ISO 7637-2:2011 pulse 4)
Reverse polarity protection
Power consumption 0.7 W (idle), 1.7 W (max)
Configuration Push-button, web interface, AT commands
Browser support Internet Explorer, Firefox, Chrome, Safari (current stable versions)
Certifications See Anybus Wireless Bridge II Compliance Sheet.
Host Communication
Ethernet interface 10/100BASE-T, auto MDI/MDIX cross-over detection
Supports all common Ethernet protocols based on TCP/IP including
the industrial protocols EtherNet/IP, Modbus TCP, BACnet/IP and
Profinet IO.
Digital input 9–30 VDC
Signal cable length must be <3 m if separate from power supply cable.
Anybus®Wireless Bridge II™Installation Guide SCM-1202-013/SP2167 1.1

Technical Data 15 (16)
WLAN Specifications
Wireless standards WLAN 802.11a/b/g/d/e/i/h
Operation modes Access Point or Client
2.4 GHz channels 1–11
5 GHz channels Access Point: 36–48 (U-NII-1)
Client: 36–140 (U-NII-1, U-NII-2A, U-NII-2C)
RF output power 16 dBm
Max number of clients 7 (for access point)
Power consumption 54 mA @ 24 VDC (WLAN interface only)
Data throughput Gross data throughput: 54 Mbit/s
Net data througput: up to 20 Mbit/s
Authentication WPA/WPA2-PSK, LEAP, PEAP
Encryption WEP64/128, TKIP, AES/CCMP
Bluetooth Specifications
Core specification 4.0
Wireless profiles PAN (PANU & NAP)
Operation modes Access Point or Client
RF output power 10 dBm
Max number of clients 7 (for access point)
Power consumption 36 mA @ 24 VDC (Bluetooth interface only)
Net data troughput Up to 1 Mbit/s
Security Authentication & Authorization, Encryption & Data Protection,
Privacy & Confidentiality, NIST Compliant, FIPS Approved
Anybus®Wireless Bridge II™Installation Guide SCM-1202-013/SP2167 1.1

last page
© 2017 HMS Industrial Networks AB
Box 4126
300 04 Halmstad, Sweden
[email protected] SCM-1202-013/SP2167 1.1.3825 / 2017-04-19 15:09
