AOC L42H961 User manual

L42H961
Description 42" Full HD LCD TV with Analog NTSC, Digital ATSC and Clear
QAM Tuners
Panel
Size VIS: 42", Diagonal
Resolution Widescreen 1920x1080, 16:9 Aspect Ratio
Brightness 500 cd/m2 (typ)
Contrast Ratio 25000:1(DCR), 1500:1 (typ)
Response Time 6.5ms Gray-Gray (typ)
Viewing Angle Horizontal: 176 Degrees
Vertical: 176 Degrees
Analog TV Tuner
TV Tuning NTSC
Color System NTSC
Sound System MTS + SAP
Closed Caption Yes
V-Chip Parental Control Yes
Digital Tuner
TV Tuning ATSC (8VSB)* with Clear-QAM
Video Inputs
Composite + L/R Audio 2
S Video + L/R Audio
2
S
-
Video
+
L/R
Audio
2
Component YCbCr/YPbPr + L/R Audio
2
HDMI (High Definition Multimedia
Interface)
4
Graphic (PC) Input
Signal Input Analog RGB (Dsub)
Maximum Resolution 1920x1200x60Hz
Audio
Built-in Speakers 20 Watts Total
Headphone Output Yes
Line Output
Stereo (RCA Jack)
Line
Output
Stereo
(RCA
Jack)
Digital Audio Output Stream S/PDIF
Power Source Universal 100~240VAC, 50/60Hz
(
Internal
)
Power Consumption 250W Max
User Control Volume Up/Down, Channel Up/Down, Menu, Input, Power
OSD Function
TV Mode
Tuning Band, DTV Signal, Auto CH Search, Add On CH Search,
Manual Channel Set, Channel Labels, Menu language, Aspect
Ratio, Favorite Channel Mode
TV & Video Mode
Auto Picture Mode (Vivid, Standard, PWR, Theater, Sport or
Custom), Contrast, Brightness, Sharpness, Color, Tint, Backlight,
Default Settin
g
PC Mode
Picture Mode, Color Temp, Backling, Aspect Ratio, H/V Position,
Clock, Phase, Auto Ad
j
ust
Audio
Auto Audio Mode(Standard, Movie, News or Custom), Bass,
Treble, Balance, Audio Source, Audio Language, Digital Audio
Output, TV Spearker ON/OFF, AVL
Sleep Timer
Off, 5/10/15/30/45/60/90/120/180/240 minutes
Features
V
ideo
3
D Y
/C
Co
m
b
Filt
e
r
,
MPE
G
N
o
i
se
R
educ
ti
o
n
,
M
o
ti
o
n A
dap
tiv
e
D
e
-
Features
3 /CCo b te, G ose educto , oto dapt e e
interlacer, Sharpness Control, Adaptive Contrast, Extended Color
Gamut Available
Audio
Mono/Stereo/Virtual Surround, MTS/SAP
Others
Wall Mountable(200mmx200mm)*, Multi-function Remote, Multi-
function Remote, Multiple Picture Mode (Normal, Zoom, Wide,
Cinema mode, Auto ), V-Chip Parental Control, Closed Caption,
Swivel Function, Hospitality Grade Setting(Volume & channel
settin
g
, USB clone
)
*
Regulations
FCC cULus ROHS EPA3 0
Regulations
FCC
,
cULus
,
ROHS
,
EPA3
.
0
Included Accessories Power Cord, Remote Control w/ batteries, Base, User's Manual
Monitor 40.0x26.7x10.8inch (1015.3x677.5x275.5mm)
Monitor w/o Base 40.0x25.5x3.8inch (1015.3x648.6x97.7mm)
Carton 46.1x33.8x11.8inch (1172x858x299mm)
Weight (lbs) 46.2lbs (21kg with base)
40.0lbs (18.2kg w/o base&stand)
Gross 57lbs(25.9kg)
Dimensions (WxHxD inches)
Net
Loading Qty w/pallet 40' Std = 138 pcs., 20' = 66 pcs.
UPC Code 685417024681
Note: Specifications are subject to change without notice. *Wall Mount Arm & Bracket not included. A0409
