AOC LE24H138 User manual

LE24H138
Descri
p
tion 24" widescreen Full HD LED-LCD TV with NTSC, PAL-M& N
Tuners
,
Slim Desi
g
n
Description
Tuners
,
Slim
Design
Panel Size VIS: 24", Diagonal
Resolution Widescreen 1920x1080, 16:9 Aspect Ratio
Brightness 300 cd/m2
Dynamic Contrast Ratio 2,000,000:1
Response Time 5ms
Viewing Angle(CR>5) Horizontal: 170 Degrees
Vertical: 170 Degrees
Analog TV Tuner
TV Tuning NTSC, PAL-M, PAL-N
Color System NTSC, PAL
Sound System MTS + SAP
Closed Caption Yes
V-Chip Parental Control Yes
Video Inputs
Composite + L/R Audio 1
Component YCbCr/YPbPr + L/R Audio
1
HDMI (High Definition Multimedia
Interface)
1
Ghi(PC)I t
Al RGB(Db)
Graphic (PC) Input Signal Input Analog RGB (Dsub)
Maximum Resolution 1920x1080x60Hz
AV Output
Video/Audio(L/R) 1
Audio
Buit-in Speakers 6 Watts Total
Headphone Output Yes
Digital Audio Output S/PDIF
Power Source 100-240 Vac 50/60Hz
Power Consumption TBC
User Control
Power Menu CH up/down Volume up/down Input
User
Control
Power
,
Menu
,
CH
up/down
,
Volume
up/down
,
Input
Features
TV & Video
TV Channel Set up, Preset Video Mode (Personal, Standard,
Vivid, Movie, ECO
)
, Noise Reduction, Multi
p
le Picture Mode
Audio
Preset Audio Mode( Personal, Standard, Music, Speech), SRS,
Stereo/SAP/Mono
PC Mode
Auto Ad
j
ust, H/V Position, Clock/Phase
Others
Wall Mountable(75mmx75mm)*, Multi-function Remote, Sleep
Timer, DCR, Parental Control, Closed Ca
p
tion
Regulations
FCC UL RoHS
Reg
u
lations
FCC
,
UL
,
RoHS
Included Accessories Remote Control w/ batteries, Power Cable, VGA Cable, Audio
Cable, User's Manual, QSG, Warranty Card & SA Service Center
List
TV Unit 23.0x 14.9x 4.9 in (584x 379x 125.7 mm)
TV Unit w/o Base 23.0x 14.6x 1.48 in (584x 371.6x 37.7 mm)
Carton 26.0x 17.5x 6.1 in (660x 445x 155 mm)
Weight (lbs) 12.1 lbs (5.5 kg)
9.2 lbs (4.2 kg, w/o base & stand)
Dimensions (WxHxD inches)
Net
(g )
Gross 16.28 lbs (7.4 kg)
Loading Qty w/pallet 40' STD = 1008, 20'STD = 480 pcs.
UPC Code 685417035489
Note: Specifications are subject to change without notice. *Wall Mount Arm & Bracket not included. A0211
