AOC GK500 Mechanical Gaming Keyboard
USER'S GUIDE
Ver.:1.00
CAUTION: To use this product properly, please read the user's guide before installing.
Contents
1. PACKAGE CONTENTS/SYSTEM REQUIREMENTS
1
2. SPECIFICATIONS
1
3. DEVICE LAYOUT AND FUNCTIONAL INTRODUCTION
2
4. AOC G-TOOLS INSTALLATION
3
5. AOC G-TOOLS INTRODUCTION
4
6. SAFETY GUIDE AND MAINTENANCE
13

1
PACKAGE CONTENTS/SYSTEM REQUIREMENTS
Package Contents
◼AOC GK500 Mechanical Gaming Keyboard
◼Quick Setup Guide
◼Wrist Rest
◼Gaming Keycap Kit
Product System Requirements
◼Windows® 7/8/8.1/10 Or mac OS
◼Available USB port
◼160MB free hard disk space
◼Internet connection
AOC G-Tools System Requirements
◼Windows® 7 or above
◼160MB free hard disk space
◼Internet connection
Technical Support
◼2 years limited warranty
◼Free online technical support at www.aoc.com
SPECIFICATIONS
Technical Specifications
◼50 Million keystroke lifespan with Outemu blue mechanical switches.
◼All key programmable
◼All key roll-over anti-ghosting
◼Up to 1000Hz/ms report rate
◼Customizable RGB lighting effect syncing with other AOC gaming devices
◼1.8M Braided cable
Approximate Size & Weight
◼Length: 433 mm/ 190.5 in
◼Width: 191.6 mm/ 75.4 in
◼Height: 36.94 mm/ 14.5 in
◼Weight: 875 g/1.9 lbs
◼Cable Length: 1.8 m/ 5.9 ft
Operating Environment
◼Operating Temperature: 0 ° C - 40 ° C
◼Operating Humidity: 10% - 85%

2
DEVICE LAYOUT AND FUNCTIONAL INTRODUCTION
Device Layout
Key Function (* compound key, press together with Fn key to operate)
Ctrl+G
Switching Key Mode
Switch to All Keys
Ctrl+N
Switching Key Mode
Switch to Standard
F6-
Mute
Turn off computer sound
F7-
Volume down(Voice-)
Decrease computer sound volume
F8-
Volume up(Voice+)
Increase computer sound volume
F9-
Previous
Switch to previous media track
F10-
Next
Switch to next media track
F11-
Play/Pause
Switch between playing and pausing media
F12-
Stop media
Stop playing the media
W
Switch WASD keys with arrow
keys.
Switch back by pressing again.
Switch Win Lock
Turn on/off the function of the Win Key
Increase backlight brightness/
lower backlight brightness
Up for brighter/ Down for darker
Go to previous lighting effect/
go to next lighting effect
Switch between the lighting effects of Light FX
cycle
Turn on/off backlight
Switch between turning on/off the backlight
Customized G Keys
Multimedia Keys
LED Indicator
Wrist Rest

3
AOC G-TOOLS INSTALLATION
Step 1: Plug the device into a USB port on your computer.
Step 2: The computer operating system will automatically detect the device.
Step 3: Download AOC G-Tools. Browse to http://www.aoc.com and search for "AOC G-Tools."
Step 4: Start the installation by clicking on the file “Setup.exe”.
Step 6: Windows® will prompt you if installation should continue; install the driver despite this.
Note:
The driver will automatically uninstall any previous version of the driver; for this reason, it may
take some time for the driver to install before you may begin programming the device.
Step 6: When the installation process is complete, please reboot your computer system.
Step 7: The AOC G-Tools icon is displayed in the Windows® taskbar while it is running. Access the
Configuration menu by right-clicking the AOC G-Tools icon.

4
AOC G-TOOLS INSTRUCTION
Game Profile Management
Under Game Profile Management, you may export a customized profile by clicking the Export button
or import a profile from your computer by clicking the Import button ..
The default profile names are Profile 1 to Profile 5. You may rename your profiles by typing in the text
field below Profile Name.
Each profile can be activated along with a linked program. To do so, enter the executable path of the
program you want to link to in the Path To Executable (*EXE) text field.
Reset To Factory Default Settings
By clicking the ‘GO’ button, the device will be reset to the factory default settings.
Buttons
◼Button Assignment
For each key other than Fn, Win, ESC, and Shift keys, you may assign an action from the menu,
which will be shown when you left-click on the key. Options available from the menu include
Macro Manager, Multimedia, Window Management, Text Editor, etc. Options listed are explained
in the following.

5
➔Macro Manager
When you choose this option from the menu, the Macro Manager window will pop-up. Please refer
to the Macro Manager section for more information
➔Multimedia
Open player: Start media player.
Pre Track: Toggle to the previous media track.
Next Track: Toggle to the next media track.
Play/Pause: Toggle between playing and pausing media.
Stop: Stop playing the media.
Mute: Mute (turns off) the computer sound.
Volume +: Increase the computer sound volume.
Volume -: Decrease the computer sound volume.
➔Window Management
Calculator: Start Microsoft Calculator.
Email: Start the default mail program.
WWW Favorites: Open the default web browser Favorites.
WWW Forward: Go to the next webpage.
WWW Back: Go to the previous webpage.
WWW Stop: Stop loading webpage.
My Computer: Open the My Computer window ( or This PC for Win10).
WWW Refresh: Refresh the current webpage.
WWW Home: Start the default web browser and load the homepage.
WWW Search: Go to default web browser search bar or Search Windows.
Show Desktop: Switch between desktop and the current view.

6
➔Text Editor
Nine text commands are available: Cut, Copy, Paste, Undo, Select All, Find, New, Safe, and Open.
➔Left Click
Perform a left-click.
➔Right Click
Perform a right-click and quick function menu.
➔Middle Click
Activate the universal scrolling function.
➔Browser Backward
Perform a "Backward" command for most internet browsers.
➔Browser Forward
Perform a "Forward" command for most internet browsers.
➔Double Click
Perform a double-click.
➔Fire Button
Perform a fire button until release.
➔Assign a Shortcut
Assign a shortcut combination.
➔Windows Key
Open the Windows Start menu.
➔Preset Button
Removes the assigned action and restores the original action.
◼Macro Manager
A macro is a prerecorded sequence of keystrokes and button presses executed with precise
timing. By assigning a macro to a button, you can execute complex combinations with ease.
The device allows you to create, delete, import, and export your customized macros. Click the
Macro Manager button, and a pop-up box will show for further operations.

7
1. Create a Macro
(1) Click the  button and name the macro you are about to record. Confirm the name by pressing
the Enter key on your keyboard.
(2) Set the delay time between events:
-Recording: The delay between events are registered as they are recorded.
-Fixed: Use a predefined time (shown in millisecond) for the delay.
-Ignore: Omit all the pauses between keystrokes and button presses.
(3) Click the Start button to record all your keystrokes and mouse button commands into the
macro. When done, click the Stop button to complete this recording.
(4) Click the Cancel button if you want to discard this recording, or the Ok button to confirm this
recording. Successfully recorded macros can be found on the Macro Select. drop-down list.
(5) For any recorded macro, you may delete or adjust its event sequences, or add new events by
initiating another recording session.
2. Delete a Macro
Select the macro to be deleted and click on the Trash Bin button.
A confirmation message pop up window will appear. Click the Ok
button to delete the macro.
3. Edit Delay
To adjust the delay time, double-click the field to be revised and enter the new value. Some
games may not be able to detect short delays.
4. Delete Recorded Actions
To delete a single or multiple actions or delay time of the macro, click the Trash Bin button.

8
5. Insert Macro Item
Click the  button to insert another macro into an existing macro. Choose to record this new
macro before or after the existing one; then click the Start button to start the recording. When
done, click the Stop button to complete the session and then click the Save button to keep the
recording. You can also insert delay time before/after the selected event. After entering the
desired time value, click the Save button.
◼Game Mode
➔Disable Alt + Tab
The Alt + Tab key combination switches between application-level
windows. Click on this option to turn off(dark) this keyboard
shortcut; click the option again to turn it on(bright).
➔Disable Alt + F4
The Alt + F4 key combination most often used to close the current
active window. If no programs are open or you are at the desktop,
Alt+F4 opens the Shutdown window. Click on this option to turn off (dark)this keyboard shortcut;
click the option again to turn it on(bright).
➔Disable Windows Key
The Windows key opens the Start menu. Click on this option to turn off (dark)this keyboard
shortcut; click the option again to turn it on(bright).
➔Switch WASD and Arrow Key
This option allows you to switch the function of the WASD keys and the arrow keys. Click on this
option to turn off (dark) this keyboard shortcut; click the option again to turn it on (bright).
➔Key Mode
1.Standard: Without anti-ghosting. If multiple (non-modifier) keys are pressed at the same time
only the first key is detected. Click on this option to turn off (dark) this keyboard shortcut; click
the option again to turn it on (bright).
2. All key: N-key rollover anti-ghosting. This allows all key presses to be detected. Click on this
option to turn off (dark) this keyboard shortcut; click the option again to turn it on (bright).
◼Mode-Key
Press the Mode key to switch between the five5 profiles that includeing G1-G5
key/Lighting/Polling Rate.
◼G1-G5 Key
Macro hot keys: Click one of the G keys and set up (See Create a Macro section) or select the
completed macros, then press the APPLY button. After pressing the APPLY button, the keyboard
will play the appointed macro directly. The G1/G2/G3/G4/G5 keys of the keyboard can play
existing macro functions.

9
Sensitivity
◼Polling Rate
Choose from four polling rate: 125Hz/8ms, 250Hz/4ms, 500Hz/2ms, 1000Hz/1ms(default).
◼Repeat Delay
Drag the slider bar knob left or right to set the Repeat Delay; four options are available from
Long to Short.
◼Repeat Rate
Drag the slider bar knob left or right to adjust the Repeat Rate, set the speed to any point
of the slider.
◼Repeat Rate Test
To test the speed of Repeat Rate & Repeat Delay settings, hold down a key or type in this text
field to see how the setting works.

10
Light FX
◼Light FX
Choose from the Light FX drop-down menu for your favorite light setting. Options
are: Static, Breathing, React, Flashing, Ripple, Radar, Fireworks, Blink, Wave, Custom
setup, Concentric Circle, W Wave. Related setting options like Direction and Stop
Time will be displayed when applicable to the selected Light FX. To restore the
default light settings, press the Go button beside “Reset To Factory Default
Settings”.
◼LED Settings
Decide your favorite color by picking a color from the RGB color panel or entering
the RGB values for your lighting effect, or take the Random color option for the
lighting effect to display RGB colors that continuously change.
◼Pulsation
Drag the Pulsation slider bar knob toward left or right to set up the speed of the
lighting effect, three options are available from Slow to Fast. This setting option is
available for most of the lighting effects except Static and Custom Setup.
◼Brightness
Drag the Brightness slider bar knob toward left or right to set up the brightness of
the lighting effect, four levels of lighting brightness are available from Off to Bright.
This setting option is available for all of the lighting effects.

11
◼Direction
Set the direction of the chosen lighting effect. This setting option is available for
the lighting effects of Flashing, Radar, Wave, and Concentric Circles.
◼Stop Time
Set up the length of time of the chosen lighting effect. This setting option is
available for the lighting effects of Static, Breathing, Flashing, Radar, Wave, Custom
Setup, Concentric Circles, and W Wave.
◼Number of Stops
Set up the number of times for the chosen lighting effects to be displayed. This
setting option is available for the lighting effect of Blink.
Light FX Sync
The lighting effect of the device can be synchronized with other AOC gaming devices that support the
AOC Light FX Sync. To sync the devices, select the icons of the devices of your choice and click the
Apply button. The synchronized devices are hightlighted in red.
◼Reset To Factory Default Settings
By clicking the GO button, the device will be reset to factory default settings.

12
Online Update
When there are new updates available, a notice balloon will show on the upper right corner along
with the tool icon.
Click on the notice balloon, the Online Update pop-up window will show the update options. Select
the updates to download and install. Click the Update button to complete the update process.

13
SAFETY AND MAINTENANCE
Important
For your safety, please carefully read the following guidelines for the device.
1. Do not operate the device under abnormal conditions.
2. Avoid looking directly at the device's tracking beam or pointing the beam at anyone's eyes. Please
note that the tracking beam is not visible to the naked eye and is set as always-on.
3. Do not disassemble the device (this will void the warranty) and do not attempt to operate under
abnormal current loads.
4. Keep the device away from liquid or moisture. Operate the device only within the indicated
temperature range: 0 ° C (32 ° F) to 40 ° C (104 ° F). If the temperature of the device is too high,
unplug the device to lower the temperature.
5. If the RGB lighting is not running properly, or the device is not functioning, or if there is an
abnormal thermal situation, troubleshoot the device by unplugging the device and plugging the
device back in .
6. If the troubleshooting process does not resolve the issue, unplug the device and visit
www.aoc.com for support. Do not attempt to repair the device yourself.
Safety
Federal Communication Commission Interference Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may cause
undesired operation.
Note: This device has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This device generates uses and can radiate
radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will
not occur in a particular installation. If this device does cause harmful interference to radio or
television reception, which can be determined by turning the device off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the device and receiver.
—Connect the device into an outlet on a circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
